Quick Installation and Configuration
Welcome to the Citrix NetScaler Application Delivery product line.
Please review the following information before proceeding with installation of the MPX
appliance.
Before you Begin
Verify that the following components and accessories are included:
wOne NetScaler MPX appliance
wOne accessory kit that contains:
• One RJ-45 to DB-9 adapter
• One 6 ft RJ-45/DB-9 cable
• One power cable for the MPX 5500 and MPX 7500/9500 appliances
• Two power cables for the MPX 15000, MPX 17000, MPX 9700/10500/12500/15500,
MPX 11500/13500/14500/16500/18500/20500, MPX 17500/19500/21500, and MPX
17550/19550/20550/21550 appliances
Note: Make sure that a power outlet is available for each cable.
wOne mounting rail kit
Note: SFP and SFP+ transceivers are sold separately. Contact your Citrix sales
representative to order transceivers for your appliance. Only transceivers supplied by
Citrix are supported on the appliance.
Citrix NetScaler Command Center MPX 7500
and MPX 9500
The Citrix NetScaler MPX 7500/9500 are 1U appliances, each with 1 quad-core
processor, and 8 gigabytes (GB) of memory. The MPX 7500/9500 appliances are
available in two port configurations: 8xCopper Ethernet (Cu) and 4xSFP+4xCu.
The Command Center hardware platform is the MPX™ 7500 appliance, which is a 1U
appliance with one quad-core processor and 8 gigabytes (GB) of memory. The MPX 7500
appliance is available in an 8x Copper Ethernet (Cu) port configuration.
The following figure shows the front panel of the MPX 7500/9500 (8xCu) appliances.
3

Figure 1-1. Citrix NetScalerCommand Center MPX 7500/9500 (8xCu), front panel
The following figure shows the front panel of the MPX 7500/9500 (4xSFP+4xCu)
appliances.
Figure 1-2. Citrix NetScaler MPX 7500/9500 (4xSFP+4xCu), front panel
The following figure shows the back panel of the MPX 7500/9500appliance.
Figure 1-3. Citrix NetScalerCommand Center MPX 7500/9500, back panel
Configuration Requirements
Determine the following information for performing the initial configuration.
wNetScaler IP address: The management IP address of the appliance.
wSubnet IP address or Mapped IP address: The IP address used by the appliance to
represent the client when communicating with a server.
wDefault gateway: The IP address of the router that forwards traffic out of the
appliance’s subnet.
Quick Installation and Configuration
4

wRoot password: The root user (nsroot) has full administrative privileges on the
appliance. The root password is used to authenticate the root user.
Installation
Installation involves rack-mounting the appliance, installing transceivers (if available),
and connecting the appliance to the network and a power source.
Note: The appliances illustrated in the installation instructions may not represent the
actual NetScaler appliance.
Rack Mounting a Citrix NetScaler Appliance
The appliance is shipped with rack-rail hardware. This hardware consists of two inner
rails that you attach to the appliance, one on each side, and a rack-rail assembly that
you attach to the rack. The following figure illustrates the steps involved in mounting
the Citrix NetScaler appliance to a rack.
Figure 1-4. Rack Mounting the Appliance
Appliance Precautions
wDetermine the placement of each component in the rack before you install the rail.
wInstall the heaviest appliance first at the bottom of the rack, and then work
upward. Distribute the load on the rack evenly. An unbalanced rack is hazardous.
wAllow the power supply units and hard drives to cool before touching them.
wInstall the equipment near a socket outlet for easy access.
Citrix® NetScaler® 10 Quick Start Guide: MPX 7500/9500 Platform
5

wMount equipment into a rack with sufficient airflow for safe operation.
wFor a closed or multi-unit rack assembly, the ambient operating temperature of the
rack environment may be greater than the ambient temperature of the room.
Therefore, consider the lowest and highest operating temperatures of the
equipment when making a decision about where to install the appliance in the rack.
Rack Precautions
wMake sure that the leveling jacks on the bottom of the rack are fully extended to
the floor, with the full weight of the rack resting on them.
wFor a single-rack installation, attach a stabilizer to the rack.
wFor a multiple-rack installation, couple (attach) the racks together.
wAlways make sure that the rack is stable before extending a component from the rack.
wExtend only one component at a time. Extending two or more simultaneously may
cause the rack to become unstable.
wThe handles on the left and right of the front panel of the appliance should only be
used for extending the appliance out of the rack. These handles should not be used
for mounting the appliance on the rack. Rack-rail hardware described later should
be used instead.
Installing Transceivers
The MPX appliances support both copper and fiber transceivers
Warning: Only those transceivers provided by Citrix Systems, Inc. are supported. You
must not attempt to install third-party transceivers. Doing so voids the warranty.
To install the transceiver
1. Carefully remove the transceiver from its box.
2. Align the transceiver to the front of the transceiver slot on the front panel of the
appliance.
3. Hold the transceiver between your thumb and index finger and insert it into the
transceiver slot, pressing it in until you hear the transceiver snap into place.
4. Lock the transceiver.
Note: To remove an SFP+ transceiver, you may first need to remove the SFP
transceiver below it.
Connecting a NetScaler Appliance to the Network
Connect the interfaces on the appliance to the network ports on the appropriate
switches by using Ethernet/fiber optic cables.
Quick Installation and Configuration
6

Figure 1-5. Connecting a Citrix NetScaler appliance to the network
Warning: Connecting multiple network ports to the same switch or VLAN can result in
a network loop.
Note: By default, the NetScaler MPX appliance is configured to use auto-negotiation.
When you install a NetScaler appliance for the first time, be sure to configure your
other equipment to use auto-negotiation for the ports that are connected to the
NetScaler appliance. After initial logon and configuration, you can choose to disable auto-
negotiation.
Connecting a NetScaler Appliance to a Power Source
Connect the power cable to one of the inlet receptacles on the back of the appliance
and connect the other end of the power cable to a power outlet. If your appliance has
a second power supply, repeat this process. All models function properly with a single
power supply. The extra power supply on some models serves as a backup. The Citrix
logo and LCD on the front of the NetScaler illuminate after the appliance starts, and
the LCD indicates the operational status of the appliance.
Figure 1-6. Connecting a Citrix NetScaler appliance to a power source
Note: If you want to upgrade to the latest release of the system software before
proceeding, see the Citrix NetScaler Migration Guide. For a link to the guide, see the
Documentation Library of this guide.
Electrical Safety Precautions
Basic electrical safety precautions should be followed to protect yourself from harm
and the appliance from damage.
Citrix® NetScaler® 10 Quick Start Guide: MPX 7500/9500 Platform
7

wBe aware of the location of the emergency power off (EPO) switch. If an electrical
accident occurs, you can quickly remove power to the appliance.
wUse a regulating uninterruptible power supply (UPS) to protect the appliance from
power surges and voltage spikes, and to keep the appliance operating in case of
power failure.
wDo not work alone when working with high voltage components.
wAlways disconnect the appliance from power before removing or installing any
component. When disconnecting power, you should first shut down the appliance
and then unplug the power cords of all the power supply units connected to the
appliance. As long as the power cord is plugged in, line voltages may be present in
the power supply, even when the power switch is OFF.
wDo not use mats designed to decrease static electrical discharge as protection from
electrical shock. Instead, use rubber mats that have been specifically designed as
electrical insulators.
wMake sure that the power supply cords include grounding plugs and are plugged into
grounded electrical outlets.
wMake sure that the power source can handle the appliance's maximum power
consumption rating with no danger of an overload.
wA reliable ground must be maintained at all times. Therefore, the rack should be
grounded. Pay particular attention to power supply connections other than the
direct connection to the branch circuit (for example, connections to power strips).
Setting Up Connectivity
Connect the appliance to a management workstation or the network by using the
NetScaler configuration utility, the command-line interface (CLI), or the LCD keypad.
Configuration Utility Setup
To set up the appliance by using the configuration utility, you need a management
workstation or laptop configured on the same network as the appliance. To run the
configuration utility, the Java RunTime Environment (JRE) version 1.4.2_04 or later
must be installed on the workstation or laptop.
Note: The Setup Wizard automatically opens upon log on when the appliance is
configured with the default IP address, when licenses are not installed on the
appliance, and when either the mapped IP address or subnet IP address is not
configured.
To configure the NetScaler by using the configuration utility
1. Connect the NetScaler to a management workstation or network.
2. Open a browser and type: http://192.168.100.1
Quick Installation and Configuration
8

Note: The NetScaler is preconfigured with the IP address 192.168.100.1.
3. In User Name, type nsroot.
4. In Password, type nsroot.
5. In the Setup Wizard, click Next and follow the instructions in the wizard.
6. To confirm that the NetScaler is configured correctly, you can either ping the new
NetScaler IP address (NSIP) or use the new NSIP to open the configuration utility in
a browser.
CLI Setup
To set up the appliance by using the command-line interface (CLI), connect the serial
cable to the console port. Access the command line with a terminal or terminal
emulator with the following settings:
wBaud rate: 9600
wData bits: 8
wParity: None
wStop bits: 1
wFlow control: None
Log on to the NetScaler with the following credentials:
User name: nsroot
Password: nsroot
To configure the NetScaler by using the NetScaler
command line
At the NetScaler command prompt, type:
wset ns config -ipaddress<IPAddress> -netmask<subnetMask>
wadd ns ip<IPAddress> <subnetMask> -type<type>
wadd route Network<subnetMask> <gateway>
wset system user<userName> <password>
wsave ns config
wreboot
Example
set ns config -ipaddress 10.102.29.60 -netmask
255.255.255.0 add ns ip 10.102.29.61 255.255.255.0 -
type snip add route 0.0.0.0 0.0.0.0 10.102.29.1 set
Citrix® NetScaler® 10 Quick Start Guide: MPX 7500/9500 Platform
9

system user nsroot administrator save ns config
reboot
Note: For information about deploying a high availability (HA) pair, see the Citrix
NetScaler Networking Guide at http://support.citrix.com/article/CTX132369.
LCD Keypad Setup
To set up the appliance by using the LCD keypad on the front panel of the appliance,
enter the following initial settings in the following order:
1. subnet mask
2. NSIP
3. gateway
The NSIP and the default gateway should be on the same subnet.
The subnet mask, NSIP, and gateway values are saved in the configuration file. You can
then use the NSIP to connect to the appliance remotely. For more information, see the
Citrix NetScaler Hardware Installation and Setup Guide at http://support.citrix.com/
article/CTX132365.
Note: For information about deploying a high availability (HA) pair, see the Citrix
NetScaler Networking Guide at http://support.citrix.com/article/CTX132369.
System Specifications
The following table summarizes the specifications of the NetScaler MPX 7500/MPX 9500
appliances.
Specifications MPX 7500/MPX 9500
Processors 1 dual-core
Memory 8 GB
Number of power supplies 1 with second optional
AC power supply input voltage,
frequency, and current
100-240VAC
50-60 Hz
3-1.5A
Quick Installation and Configuration
10

Specifications MPX 7500/MPX 9500
DC power supply input voltage and
current
260 W
Maximum power consumption 887 BTU per hour
Heat dissipation 23 with one power supply
Weight (lbs.) 1U
Height EIA 310-D for 19-inch racks
Width 21.75 in/
55 cm
Depth 0-40
Operating temperature (degree Celsius) 5%-95%
Humidity range (non-condensing) CSA
Safety certifications FCC (Part 15 Class A), CE, C-Tick, CCC,
KCC, NOM, PCT, VCCI, SASO, SABS
EMC & susceptibility RoHS, WEEE
Environmental compliance RoHS, WEEE
Additional Information
A complete set of documentation is available on the Documentation tab of your
NetScaler and from http://support.citrix.com/. (Most of the documents require Adobe
Reader, available at http://adobe.com/.)
To view the documentation
1. From a Web browser, log on to the NetScaler.
2. Click the Documentation tab.
3. To view a short description of each document, hover your cursor over the title. To
open a document, click the title.
If you have support questions, please contact Citrix Technical Support at 1-800-4-CITRIX
(1-800-424-8749). For additional contact information, see Support Phone Numbers at
Citrix® NetScaler® 10 Quick Start Guide: MPX 7500/9500 Platform
11

http://support.citrix.com/. If you have comments or feedback on this documentation,
please email to [email protected].
Quick Installation and Configuration
12
