CITROEN DS4 DSign User guide

OWNER'S HANDBOOK

ON-LINE OWNER'S HANDBOOK
Referring to the owner's handbook on-line also gives you
access to the latest information available, easily identified by
the bookmark, associated with this symbol:
If the "MyCitroën" function is not available on the CITROËN public
website for your country, you can find your handbook at the following
address:
http://service.citroen.com
Select:
You can find your handbook on the CITROËN website, under
"MyCitroën".
This personal and customisable space allows you to establish direct
and special contact with CITROËN.
The Vehicle documentation link in the home page (no registration is
needed),
the language,
the vehicle, its body style,
the print edition of your handbook appropriate for the date of registration
of your vehicle.
You have access to your handbook on line, together with the latest
information, identified by the symbol:

CITROËN has a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.
Your vehicle is fitted with only some of the
equipment described in this document,
depending on the trim level, version and the
specifications for the country in which it is sold.
The fitting of electrical equipment or
accessories which are not recommended
by CITROËN may result in a failure of your
vehicle's electronic system. Please note this
specific warning and contact a CITROËN
dealer to be shown the recommended
equipment and accessories.
At the wheel of your new vehicle,
getting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.
Happy motoring!
We draw your attention to the following...

Contents
Contents
6FAMILIARISATION
34 ECO-DRIVING
388 VISUAL
SEARCH
394 ALPHABETICAL
INDEX
MONITORING
38 Instrument panels
42 Rev counter
43 Warning and indicator lamps
54 Indicators
57 Manual test
60 Customisation
Key
safety warning
additional information
contributes to the protection of the environment
programming a function with the
configuration menu
001
001
refer to the page indicated

MULTIFUNCTION
SCREENS
COMFORT ACCESS VISIBILITY
64 Monochrome screen C
68 Colour screen
70 Trip computer
78 Ventilation
80 Manual air conditioning
82 Dual-zone digital air
conditioning
86 Front demist - defrost
87 Rear screen demist - defrost
88 Front seats
93 Rear seats
94 Steering wheel adjustment
95 Mirrors
100 Remote control key
109 Alarm
112 Doors
114 Boot
115 Electric windows
117 Fuel tank
120 Misfuel prevention (Diesel)
124 Lighting controls
125 Daytime running lamps
128 Automatic illumination of
headlamps
129 Welcome lighting
130 Headlamp adjustment
131 Directional lighting
133 Wiper controls
134 Automatic rain sensitive
wipers
138 Courtesy lamps
139 Interior mood lighting
140 Boot lamp
004
004
005
005
002
002
003
003

SAFETY DRIVINGFITTINGS CHILD
SAFETY
196 Electric parking brake
204 Manual parking brake
205 Manual gearbox
206 Electronic gearbox
210 Automatic gearbox
214 Hill start assist
215 Gear shift indicator
216 Tyre under-inflation detection
218 Stop & Start
221
Lane departure warning system
222 Blind spot sensors
226 Speed limiter
228 Cruise control
230 Parking space sensors
232 Parking sensors
178 Direction indicators
178 Hazard warning lamps
179 Horn
179 Emergency or assistance
call
180 Braking assistance systems
181 Trajectory control systems
(ESP)
183 Front seat belts
187 Airbags
162 Child seats
164 Deactivating the passenger's
front airbag
171 ISOFIX child seats
175 Child lock
144 Interior fittings
150 Front armrest
155 Boot fittings
008
008
009
009
006
006
007
007

CHECKS PRACTICAL
INFORMATION
TECHNICAL
DATA
AUDIO AND
TELEMATICS
237 Bonnet
238 Running out of fuel (Diesel)
239 Petrol engines
240 Diesel engines
241 Checking levels
244 Checks
250 Temporary puncture repair
kit
255 Changing a wheel
262 Snow chains
263 Changing a bulb
270 Changing a fuse
276 12 V battery
280 Energy economy mode
281 Changing a wiper blade
281 Very cold climate screen
282 Fitting roof bars
283 Towing the vehicle
285 Towing a trailer
287 Accessories
292 Petrol engines
293 Petrol weights
294 Diesel engines
295 Diesel weights
296 Dimensions
297 Identification markings
301 Emergency or assistance
303 eMyWay
357 Audio system
012
012
013
013
010
010
011
011

Familiarisation
Familiarisation

Exterior
Parking sensors
This system measures the size of a free
parking space between two vehicles or
obstacles.
Stop & Start system
This system puts the engine temporarily into standby during
stops in the traffic (traffic lights, traffic jams, etc...). The engine
restarts automatically as soon as you want to move off. The
Stop & Start system reduces fuel consumption and exhaust
emissions, as well as noise levels when stationary.
230
218
Directional lighting
This lighting automatically provides
additional visibility when cornering.
131
Panoramic windscreen
This large glazed area provides
incomparable visibility and light in the
passenger compartment.
12
Cornering lighting
At low speed, this lighting comes on
automatically to improve vision when
cornering, at intersections, when parking
parking... making use of the front foglamp on
the side in question.
132

9
Familiarisation
Exterior
Welcome lighting
This additional exterior and interior lighting,
controlled remotely, makes your approach to
the vehicle easier when the light is poor.
Temporary puncture repair kit
This kit is a complete system, consisting of a
compressor and a sealant cartridge, for the
temporary repair of a tyre.
129
250
Under-inflation detection
This system continuously monitors the
pressures of the tyres and alerts you in the
event of under-inflation.
216
Blind spot sensors
In certain conditions, this system
detects the presence of a vehicle in
the blind spot. It informs you by means
of a warning lamp in the corresponding
door mirror.
222
Exterior customising
stickers
When washing your vehicle using a jet
wash, keep the end of the lance at least
30 cm from the stickers.

100
Opening
A. Folding/unfolding the key
(first press this button).
3-button remote
control
When a sensor detects a low level of light,
the remote switching on of the dipped beam
headlamps, the sidelamps and the side spotlamps
makes your approach to the vehicle easier.
Welcome lighting
Complete or selective unlocking of
the vehicle
(rapid flashing of the direction
indicators).
Opening the windows
(hold until the desired position is reached).
Selective unlocking of the boot.
Normal locking
(press once; fixed lighting of the
direction indicators).
Closing the windows
(hold until the desired position is reached).
129
In the same way, the passenger compartment
lighting, such as the courtesy lamps and the
footwell lamps, comes on.

11
Familiarisation
117, 120
A. Opening the fuel filler flap.
Capacity of the fuel tank: approximately 60 litres.
Fuel tank
Opening
101, 114
1. Selective unlocking of the boot.
2. Opening the boot.
Boot

Panoramic windscreen
Blind
To open it, take the blind by its central
grip A, and pull it rearwards, guiding it to
the desired position.
To close it, take the blind by its central
grip A, and pull it forwards, guiding it to the
desired position.
The sun visor should be in the folded position
before moving the blind.
This includes a panoramic area in tinted glass to increase lighting and vision in the passenger compartment.
Fitted with a blind on each side to improve temperature control and a sun visor to avoid dazzle.
Sun visor
Fitted with a courtesy mirror and a ticket holder.
To avoid dazzle from the front, lower the
sun visor.
To avoid dazzle from the side, disengage
the sun visor from its central fixing and turn
it towards the side window.
Do not attach to or suspend heavy
objects from the blind and its guide
rails.

13
Familiarisation
Interior
Electronic gearbox
This system offers driving combining a fully
automatic mode and a manual mode.
Interior mood lighting
This dimmed lighting of the passenger
compartment improves visibility inside the
vehicle when the light is poor.
Audio and communication
systems
These systems benefit from the following
technologies: radio, CD player, USB player,
Bluetooth system, satellite navigation system
with colour screen, auxiliary sockets.
Radio
206
139
357
303
Electric parking brake
It combines the functions of automatic
application on switching off the engine and
automatic release when moving off.
Manual application and release remains
possible.
196
eMyWay satellite navigation system
Massage function
This system gives a lumbar massage for a
period of 60 minutes. The massage is done in
6 cycles of 10 minutes each.
91

Instruments and controls
1. Cruise control / speed limiter controls.
2. Controls for optional functions.
3. Steering wheel adjustment control.
4. Lighting and direction indicator control
stalk.
5. Instrument panel.
6. Driver's airbag.
Horn.
7. Controls for audio and telematic system.
8. Controls for Bluetooth system or telephone.
9. Bonnet release.
10. Door mirror controls.
Electric window controls.
11. Fusebox.
12. Manual headlamp height adjustment
Lower side switch panel.
13. Fuel filler flap opening switch.
Upper side switch panel.
14. Side adjustable air vent.
15. Front side window demisting vent.

15
Familiarisation
Instruments and controls
1. Steering lock and ignition.
2. Steering mounted control paddles for the
electronic gearbox.
3. Wiper / screenwash / trip computer control
stalk.
4. Speaker (tweeter).
5. Windscreen demisting vent.
6. Sunshine sensor.
7. Passenger's airbag.
8. Glove box / Audio/video sockets /
Passenger's airbag deactivation switch.
9. Heated seat control.
10. Lumbar massage control.
11. Electric parking brake.
12. Gear lever for manual gearbox or selector
lever for electronic or automatic gearbox.
13. Large multifunctional storage unit.

Roof consoles - Centre consoles
A. Rear view mirror.
B. Microphone for audio and telematic
system.
C. Interior mood lighting.
D. Emergency call / Assistance call.
E. Courtesy lamp / Map reading lamps.
1. Central adjustable air vents.
2. Monochrome screen and seat belt and
front airbag warning lamp screen or colour
and mapping screen.
3. eMyWay Audio or satellite navigation
system.
4. Central switch panel.
5. Heating / air conditioning controls.
6. USB port/auxiliary Jack socket and
cigarette lighter / 12 V accessory socket.
7. Gear lever or selector.
8. Manual or electric parking brake
9. Portable ashtray.
10. Front armrest.

17
Familiarisation
Sitting comfortably
Manual adjustment 88
Driver's seat
Forwards-backwards Height
Electric adjustment
Seat back angle
89

Sitting comfortably
Head restraint height and angle
Front seats
Other functions available...
Lumbar massage.
Storing driving positions (driver's
electric seat).
Heated seats.
90
1. Release the adjustment mechanism.
2. Adjust for height and reach.
3. Lock the adjustment mechanism.
Steering wheel adjustment
94
As a safety precaution, these
operations must only be carried out
when stationary.
Lumbar
91
