CITROEN C3 Picasso 2013 User guide

4
4
FAMILIARISATION
EXTERIOR
Guide-me-home lighting
After the ignition has been switched off,
the headlamps remain on briefl y to make
your exit from the vehicle easier when
the light is poor.
69, 70
ASR and ESP systems
These systems are linked to assure the
directional stability of the vehicle, within
the limits of the laws of physics.
96
Glass panoramic roof
This roof provides incomparable visibility
and light in the passenger compartment.
64
Rear parking sensors
This equipment warns you if an obstacle
is detected behind the vehicle when
reversing.
110

5
5
FAMILIARISATION
OPEN
Remote control key
A. Unfolding/Folding of the key.
Locking
(press; fi xed lighting of the di-
rection indicators).
Panoramic glass roof
Lift the handle of the blind concerned
and release.
Each blind is fi tted with a roller in which
it is stored when you release it.
Unlocking of the vehicle
(rapid fl ashing of the direction
indicators).
55 64
Fuel tank
65
1. Opening of the fuel fi ller fl ap.
2. Opening and hooking of the fuel
tank cap.
Capacity of the tank: approximately
50 litres (petrol) or 48 litres (Diesel).

6
6
FAMILIARISATION
OPEN
Boot Movable boot fl oor
This movable boot fl oor with two posi-
tions allows you to:
- maximise the volume of the boot,
- partition the boot (storing of the rear
shelf...),
- obtain a fl at fl oor from the boot
opening to the front seats, when the
rear bench seat is in the retracted
position.
1. Unlocking of the vehicle.
2. Opening of the boot.
63 84
A. Interior release lever.
B. Exterior safety catch.
C. Bonnet stay.
113
Bonnet

7
7
FAMILIARISATION
INTERIOR
Dual-zone digital air conditioning
This system allows you to set a different
level of comfort for the driver and front
passenger. It then controls this level
automatically relative to the ambient
conditions.
46
Speed limiter/cruise control
These two functions allow you to
control the speed of the vehicle in
accordance with the value that you
have programmed.
106/108
Scented air freshener
This air freshener diffuses the fragrance
that you have selected throughout the
passenger compartment by means of
its location in the ventilation system.
48
Audio and communication systems
These systems benefi t from the latest
technology: MP3 compatible audio
system, MyWay audio and navigation
system, auxiliary sockets.
151

8
8
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Cruise control/speed limiter switch.
2. Steering wheel adjustment control.
3. Lighting and direction indicator
control stalk.
4. Instrument panel.
5. Driver's airbag.
Horn.
6. Gear lever.
7. Bonnet release.
8. Door mirror controls.
Electric window controls.
Rear electric windows and doors
deactivation control.
9. Fusebox.
10. Manual headlamp height
adjustment.
11. Front side window demisting vent.
12. Speaker (tweeter).
13. Windscreen demisting vent.

9
9
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Steering lock and ignition.
2. Audio equipment steering mounted
control stalk.
3. Wipers/wash-wipe/trip computer
control stalk.
4. Central adjustable air vents.
5. Storage tray.
Scented air freshener.
6. Sunshine sensor.
7. Passenger air bag.
8. Side adjustable air vent.
9. Passenger airbag deactivation
switch.
10. Glove box.
11. Dynamic stability control
(ESP/ASR) button.
Parking sensors button.
Central locking button.
Hazard warning lamps button.
12. Heating/air conditioning controls.
13. Audio equipment.
14. 12 V socket (100 W max).
15. USB socket/auxiliary socket.
16. Cup holder.
17. Heated seat controls.
18. Parking brake.

10
10
FAMILIARISATION
SITTING COMFORTABLY
Driver's seat adjustment
Forwards-backwards
49
Seat back angleHeight

11
11
FAMILIARISATION
Steering wheel adjustment
1. Unlocking the adjustment mechanism.
2. Adjustment for height and reach.
3. Locking the adjustment mechanism.
SITTING COMFORTABLY
Front seat additional adjustments
Head restraint height
54
Armrest
A. Releasing the armrest.
B. Adjusting the armrest.

12
12
FAMILIARISATION
SITTING COMFORTABLY
Door mirror adjustment
This operates when the ignition is on.
From the driver's seat, select the mirror
by moving the control 1, to the left or to
the right, then adjust the mirror in the
four directions using the control 2.
The demisting/defrosting of the mirrors
is linked with that of the rear screen.
Rear view mirror adjustment
1. Selection of the "day" position of the
mirror.
2. Mirror orientation.
Front seat belt
1. Fastening.
2. Height adjustment.
54 97
Folding the mirrors
When parked, the mirrors can be folded
manually or electrically.
53

13
13
FAMILIARISATION
SEEING CLEARLY
Lighting
Ring A
Ring B
Raise or lower the lighting stalk passing
the point of resistance; the correspon-
ding direction indicators will fl ash for as
long as the stalk remains in this posi-
tion.
Direction indicators
Switching on "AUTO" mode
 Press the stalk down and release it.
Ring B: rear wiper
67 72
Lights off.
Automatic illumination of head-
lamps.
Sidelamps.
Dipped/main beam headlamps.
Rear foglamp.
or
Front and rear foglamps.
Park.
Intermittent wipe.
Wash-wipe.
Control stalk A: windscreen wipers
71
Wipers
Switching off "AUTO" mode
 Push the stalk up and return it to po-
sition "0".
73
94
"Motorway" function
Press the lighting stalk up or down once,
without passing the point of resistance;
the corresponding direction indicators
will fl ash three times.
You can use this function at any speed,
but it is particularly useful when chan-
ging lane on high-speed roads.

–
14
14
FAMILIARISATION
Digital air conditioning: we recommend use of the fully automatic mode by pressing the "AUTO" button, after selecting the
level of comfort required.
VENTILATION
Recommended interior settings
I require...
Heating or Manual Air Conditioning
Air distribution Air fl ow Air recirculation/Intake
of outside air Temperature Manual A/C
HOT
COLD
DEMISTING
DEFROSTING

15
15
FAMILIARISATION
MONITORING
Translucent digital instrument panel Switch panel
A. With the ignition on, the level of fuel
remaining is displayed on the digital
indicator.
B. With the ignition on, the oil level in-
dicator should display "OIL OK" for
a few seconds.
If the levels are not correct, top up the
levels which are low.
Lighting of the indicator lamp indicates
the status of the corresponding function.
A. Deactivation of the ESP/ASR system.
96
B. Deactivation of the rear parking sen-
sors.
111
C. Central locking.
62
With the ignition on, the orange and red
warning lamps come on.
With the engine running, these warning
lamps should switch off almost immedi-
ately, with the exception of the warning
lamp C (passenger's front airbag acti-
vated) which switches off after approxi-
mately one minute.
If warning lamps remain on, refer to the
relevant page.
Warning lamps
18 19

16
16
FAMILIARISATION
PASSENGER SAFETY
Passenger's front airbag Electric child lock
1. Insert the key.
2. Select the position:
"OFF" (deactivation), with "rear fac-
ing" child seat,
"ON" (activation), with front passen-
ger or "forwards facing" child seat.
3. Remove the key keeping the switch
in the new position.
Lighting of the warning lamp Aindicates
activation of the electric child lock.
A. Front and/or rear seat belts not fas-
tened/unfastened warning lamp.
B. Front left seat belt warning lamp.
C. Front right seat belt warning lamp.
D. Rear right seat belt warning lamp.
E. Rear centre seat belt warning lamp.
F. Rear left seat belt warning lamp.
G. Passenger's front airbag deactivated
warning lamp.
H. Passenger's front airbag activated
warning lamp.
Seat belts and passenger's front
airbag
98102 93

17
17
FAMILIARISATION
DRIVING SAFELY
Speed limiter "LIMIT" Display on the instrument panel
1. Limiter mode Selection/Off.
2. Decreasing of the programmed value.
3. Increasing of the programmed value.
4. Speed limiter On/Off.
The cruise control or speed limiter mode
appears on the instrument panel when
it is selected.
1. Cruise control mode Selection/Off.
2. Programming a speed/Decreasing
of the programmed value.
3. Programming a speed/Increasing of
the programmed value.
4. Cruise control Off/Resume.
Cruise control "CRUISE"
108106
In order to be programmed or activated,
the vehicle speed must be higher than
25 mph (40 km/h), with at least fourth
gear engaged on the manual gearbox.
The values must be set with the engine
running.
Cruise control
Speed limiter

192
1
2
2
2
2
1
2
2
1
2
3
3
1
2
2
2
2
2
2
1
2
2
2
2
2
2
2
2
1
2
2
1
2
3
2
3
08
1
1
1
1
1
1
1
1
RADIO-CD
DISPLAY ADJUST
YEAR
MONTH
DAY
HOUR
MINUTES
12 H/24 H MODE
SCREEN MENU MAPS
MAIN FUNCTION
* The parameters vary according to vehicle.
CHOICE A
Choice A1
Choice A2
CHOICE B...
LANGUAGE
FRANCAIS
ITALIANO
NEDERLANDS
PORTUGUES
PORTUGUES-BRASIL
DEUTSCH
ENGLISH
ESPANOL
Press the OK dial for access to short-cut
menus according to the display on the
screen:
monochrome A
monochrome C
RADIO
activate/deactivate RDS
activate/deactivate REG mode
activate/deactivate radiotext
RANDOM PLAY
RDS SEARCH
REG MODE
CD REPEAT
VEHICLE CONFIG *
REV WIPE ACT
GUIDE LAMPS
OPTIONS
DIAGNOSTICS
consult
abandon
UNITS
TEMPERATURE: °CELSIUS/°FAHRENHEIT
FUEL CONSUMPTION: KM/L - L/100 - MPG
CD/MP3 CD
activate/deactivate Intro
activate/deactivate track repeat
(the entire current folder for MP3 CD)
activate/deactivate random play (the entire current folder
for MP3 CD)
USB
activate/deactivate track repeat (of the current folder/
artist/genre/playlist)
activate/deactivate random play (of the current folder/
artist/genre/playlist)

193
1
1
2
3
4
3
4
3
4
2
3
4
3
4
2
3
4
2
4
4
3
3
4
4
1
2
2
08
2
2
3
4
4
1
2
3
3
3
4
4
4
2
3
4
2
3
3
AUDIO FUNCTIONS
FM BAND PREFERENCES
alternative frequencies (RDS)
activate/deactivate
regional mode (REG)
activate/deactivate
radio-text information (RDTXT)
activate/deactivate
PLAY MODES
album repeat (RPT)
activate/deactivate
track random play (RDM)
activate/deactivate
ENTER DISTANCE TO DESTINATION
LOG OF ALERTS
STATUS OF FUNCTIONS
PERSONALISATION-CONFIGURATION
* The parameters vary according to vehicle.
DEFINE THE VEHICLE PARAMETERS *
DISPLAY CONFIGURATION
video brightness adjustment
normal video
inverse video
brightness (- +) adjustment
date and time adjustment
day/month/year adjustment
hour/minute adjustment
choice of 12 h/24 h mode
choice of units
l/100 km - mpg - km/l
°Celsius/°Fahrenheit
CHOICE OF LANGUAGE
BLUETOOTH TELEPHONE
MANAGE THE TELEPHONE CALL
Terminate the current call
Activate private mode
BLUETOOTH CONFIGURATION
Connect/Disconnect a device
Telephone function
Audio Streaming function
Consult the paired device
Delete a paired device
Perform a Bluetooth search
CALL
Calls list
Directory
SCREEN MENU MAPS
TRIP COMPUTER
Pressing the MENU button displays:
monochrome C

4
4
FAMILIARISATION
EXTERIOR
Guide-me-home lighting
After the ignition has been switched off,
the headlamps remain on briefl y to make
your exit from the vehicle easier when
the light is poor.
69, 70
ASR and ESP systems
These systems are linked to assure the
directional stability of the vehicle, within
the limits of the laws of physics.
96
Glass panoramic roof
This roof provides incomparable visibility
and light in the passenger compartment.
64
Rear parking sensors
This equipment warns you if an obstacle
is detected behind the vehicle when
reversing.
110

5
5
FAMILIARISATION
OPEN
Remote control key
A. Unfolding/Folding of the key.
Locking
(press; fi xed lighting of the di-
rection indicators).
Panoramic glass roof
Lift the handle of the blind concerned
and release.
Each blind is fi tted with a roller in which
it is stored when you release it.
Unlocking of the vehicle
(rapid fl ashing of the direction
indicators).
55 64
Fuel tank
65
1. Opening of the fuel fi ller fl ap.
2. Opening and hooking of the fuel
tank cap.
Capacity of the tank: approximately
50 litres (petrol) or 48 litres (Diesel).

6
6
FAMILIARISATION
OPEN
Boot Movable boot fl oor
This movable boot fl oor with two posi-
tions allows you to:
- maximise the volume of the boot,
- partition the boot (storing of the rear
shelf...),
- obtain a fl at fl oor from the boot
opening to the front seats, when the
rear bench seat is in the retracted
position.
1. Unlocking of the vehicle.
2. Opening of the boot.
63 84
A. Interior release lever.
B. Exterior safety catch.
C. Bonnet stay.
113
Bonnet
