Citronic SM-FX500 Ultima User manual

™
171.129

™
The SM-FX500 Ultima Professional Mixing Desk
The new SM-FX500 Ultima is a 4-Channel 19” Rack mixer with a built-in DSP. Its compact 5U design houses
features that you would normally only find in much higher priced units. Designed with both small installations
and mobile DJ’s in mind it also has a few little extras to protect your system and maintain a high quality sound
production.
The SM-FX500 Ultima has 3 microphone inputs, two of which are controlled with the dedicated Mic channel and
one assigned to the 4th channel as a switchable option. Mic’s 1 & 2 share a 3-band EQ and Mic override system.
Each of the 4 music channels has an individual gain control and 3-band EQ offering +10dB of Boost and –30dB
of Kill. Each channel is also easily assignable to the crossfader A or B.
The unit has a built in digital signal processor offering 8 effects which are assignable to each music channel,
microphone channel, master or crossfade A or B. The effects are linked to the mixers built in BPM counter to
allow the DJ to ‘Beat-Sync’ the effects at the touch of a button, Alternatively the effects can be manually
adjusted using the independent parameter time control and the parameter ratio control. The SM-FX500 Ultima
also has effects specifically for the crossfade, when selected 3 different effects can be activated and controlled
by moving the crossfade from A-B using the effects to mix from one channel to the next.
The crossfade on the SM-FX500 Ultima is VCA controlled as well as being able to assign effects the user can
adjust the curve of the fader from a smooth mix to sharp mix. It also has fader start, this will start a compatible
CD-Player and also stop it return it to the Cue point, this can be a very creative tool when combined with the
effects.
The SM-FX500 Ultima also has a few installer friendly options. The user can easily replace the channel faders
and crossfader by removing just a few screws. For the outputs there is a choice of balanced XLR or
Unbalanced Phono, the unit also offers a booth output, record output and digital output all recessed into the rear
of the unit. There is also a master trim level on the rear; this allows the installer to set the maximum output of
the mixer.
Features
• 4 Channel 10 Input Digital Mixer
• 4 Line – 3 Phono/Aux(shared) – 3 Microphone
• Built in DSP with 8 Digital Effects
• 3 Assignable Effects to the VCA Crossfade
• Fully Assignable Crossfade
• Crossfade Curve Adjustable
• Separate Gain Controls on All Channels
• 3 band EQ with –30dB CUT Per Music Channel
• Microphone Channel with 3 Band EQ shared with 1 & 2
• Booth Output
• Full Cue editing Facilities including effects Cue
• Split Cue
• Easily Replacable Crossfade and Channel Faders
• Master and Cue selectable LED Monitor
• Digital Output
• Crossfader start for CD-players
• Installer Output Trim Feature
• Built in Rumble Filter

™
Important Safety Information
Warnings:
All the safety and operating instructions should be read before the appliance is operated.
To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
To reduce the risk of electric shock, do not remove the cover (or back). There are no serviceable parts inside. Always
refer servicing to qualified service personnel.
Cautionary Notes:
Handle the power supply cord carefully. Do not damage or deform the power supply cord. If it is damaged or deformed,
it may cause electric shock or malfunction when used. When removing from wall outlet, be sure to remove by holding
the plug attachment and not by pulling the cord.
In order to prevent electric shock; do not open the top cover. If a problem occurs, contact your dealer.
Do not place metal objects or spill liquid inside the mixer. Electric shock or malfunction may result.
Any use of the controls, or any adjustment, or the performance of any procedure other than those specified herein may
result in serious damage to your health.
The mixer should not be opened or repaired by anyone except properly qualified service personnel.
Double insulated - when servicing, use only identical replacement parts.
WARNING: - THIS MIXER MUST BE EARTHED FOR SAFETY AND GOOD GROUNDING PRACTICES IN
MIXING.
In the event of ground - loop problems in the audio system, DO NOT disconnect the AC supply earth to any
equipment before consulting equipment instruction manuals. For example most power amplifiers have audio
ground lift switches, or are designed specifically to avoid ground - loop problems connected to ‘earthed’ mixers.
Ensure the mixer has a ‘clean’ AC supply from a wall socket that is not used for other equipment that would lead
to interference - such as lights, refrigerators etc.
The SM-FX500 Ultima is available in AC supply standard:
200 - 240V AC - UK, EUROPE, KOREA & CHINA
General Do’s & Don’ts
There are a few general Do’s and Don’ts thoughts that you should become familiar with if you have not had a
great deal of experience with professional audio systems.
Cables & Connectors - Always use good quality cables and connectors. It might seem expensive when you first
look at it, but the first time you have a problem in front of an audience you’ll curse the day you didn’t make that
small investment. Over 30 years in the business has taught us that over 75% of all problems with DJ systems
are simple connector ones. Don’t get caught out.
Switching on your system - Get into the habit of turning on the mixer and all the inputs to it before you turn on
the amplifiers. Play safe; always turn on your amplifiers last.
Power Supply - The power supply for your SM-FX500 Ultima is built into the mixer and will be fitted with a mains
plug specifically for the mains supply in your country. If it does not match the power socket you wish to use
check with your dealer before you plug it in. It is possible you could damage your mixer if it is not the correct
version for your mains power supply. Worse still, it could be unsafe. Don’t take chances with Mains Power - it
can kill.
Crossfader - The crossfader is the most used feature on your mixer and great care has been taken in the choice
of components for this function. Even so, it is the most likely thing to wear out first on your mixer, so we’ve made
it quick and easy to replace. Don’t get caught out, always carry a spare.

™
Front Panel Illustration
Features & Functions Top Panel
Microphone Section
1. Microphone Input
Two combination XLR & ¼” jack sockets are mounted on the front face of the mixer for connecting your
balanced microphones.
Balanced Input wiring:
Tip: Pin2: Positive (HOT)
Ring: Pin3: Negative (COLD)
Sleeve: Pin1: Ground (SHIELD)
Input Impedance 2.2K Ohm
Input Sensitivity –55.4dBV (1.7mV)
2. Microphone EQ – Hi
This control allows 12dB of cut or boost to the high frequencies and is shared between Mic 1 & Mic 2.
3. Microphone EQ – Mid
This control allows 12dB of cut or boost to the mid frequencies and is shared between Mic 1 & Mic 2.
4. Microphone EQ – Lo
This control allows 12dB of cut or boost to the low frequencies and is shared between Mic 1 & Mic 2
5. Microphone On/Off & Override Switch
This switch is used to activate or deactivate Mic 1 and 2. When switched to ‘o’ride’ position the sound level for
everything other than Mic 1 & 2 will decrease by 14dB.
6. Microphone 2 Level Control
This controls the gain of microphone 2 giving the user maximum control. Set the gain to the desired level then
use the On/Off or O’ride switch (5) to activate the mic.
7. Microphone 1 Level Control
This controls the gain of microphone 1 giving the user maximum control. Set the gain to the desired level then
use the On/Off or O’ride switch (5) to activate the mic.

™
Music Channels 1-4 Section
8. Input Select Control
This control selects the input source for its respective channel. Channel 1, 2 & 3 are Line or Phono/Aux
switchable, (rear panel) Channel 4 is Microphone 3 or Line.
9. Input Gain Controls
Each main input channel has a gain control offering infinity to +10dB gain range allowing compensation for
differing input levels.
10. Music EQ Control – Hi
This control allows 10dB of boost and –30dB of Kill to the high frequencies.
11. Music EQ Control – Mid
This control allows 10dB of boost and –30dB of Kill to the mid frequencies.
12. Music EQ Control – Lo
This control allows 10dB of boost and –30dB of Kill to the low frequencies.
13. Cue Switches
The pre-fade input signal from each of the four main music channels can be routed to the headphone and when
selected the VU display section of the mixer.
14. Channel Fader
45mm quality faders control each channel program level to the EQ and crossfader.
Replacement of the Channel Faders
When a channel fader has worn out it is very easy to replace. The SM-FX500 Ultima has been fitted with a quick
access panel, which can be changed in a matter of seconds, even while the mixer is in use. Follow these simple
steps:
1. Remove the knobs from all the channel faders
2. Unscrew the 4 pozi-head screw on each corner of the removable panel
3. Lift out the removable panel to expose the channel faders
4. Remove the 2 pozi-head screws from the worn fader
5. lift out the fader from its hotswap plug
6. Plug in the new fader taking care not to damage the circuit
Replace the screws, panel, screws and knobs
Output Controls Section
15. Master Balance
This control is used to adjust the left and right balance from the master output.
16. Master Stereo/Mono Switch
This switch is is used to switch the Stereo output of the mixer to Mono. When switched to Mono is gives a true
mono mix of the main mixer channels that are presented onto both the balanced and unbalanced outputs.
17. Booth Level
This rotary knob controls the overall output of the unbalanced Booth Output. The program content of the booth
Output is the same as the master output but unaffected by the master volume control or master balance control.
Music Monitoring Section
18. Monitor Selector Switch
This switch is used to select either L/R Stereo master output level or CUE PGM Split between Cue level and
Output level.
19. LED Monitor
This 12 –bar LED monitor allows the user to view the output levels of the master or master/cue
20. Monitor Pan Control (Cue Mix)
Varies the mix between the cued input and main output, ideal for accurate beat mixing. Full left will give cued
input, full right will give main output program.
21. Split Cue
Disables the CUE PAN CONTROL and gives a mono sum of cued I/P’s to the left and a mono sum of the O/P
mix to the right, channels of the headphones and led display.
22. Headphone Level Control
Sets desired level to headphones. Headphone program depends on the position of the monitor pan control and
split cue switch.

™
23. Headphone Socket
(Standard Stereo 1/4" Jack)
L/H Channel - Tip
R/H Channel - Ring
Ground - Sleeve
Minimum Load Impedance - 32 Ohms
Power Output - 316 mW
24. See Separate DSP Section
Crossfader Section
25. Crossfade Assign B
This button will assign the selected channel to the right hand side ‘B’ of the crossfade. The button will illuminate
blue when selected.
26. Crossfade Assign A
This button will assign the selected channel to the left hand side ‘A’ of the crossfade. The button will illuminate
blue when selected.
27. VCA X-Fade
This smooth action crossfader is VCA (Voltage Control Ampilfier) controlled this allows the user to adjust the
curve of fade from one side to the other.
Replacement of the Crossfader
When the crossfader has worn out it is very easy to replace. The SM-FX500 Ultima has been fitted with a quick
access panel, which can be changed in a matter of seconds, even while the mixer is in use. Follow these simple
steps:
1. Remove the crossfader panel using a Pozi-head screw driver
2. Lift out the removeable panel
3. Disconnect the crossfader assembly
4. Refit the connector to the new crossfader
5. Replace the panel and re-fit the screws
28. Fader Indicators
When the X-Fade effect switch (43) is in the ‘X-FADER’ or ‘AUTO’ position, these LED’s will light indicating
which side of the crossfade is supplying the output signal. As the crossfade is moved toward the opposite side
the LED will begin to flash, just before the music output changes to the opposite side the LED will flash quickly.
29. Fader Start Selector
This switch will allow a compatible CD-Player to be started using the crossfader. The control cables need to be
connected from (50) to the back of the CD-Player. If crossfade ‘A’ is switched on, when the fader is moved from
‘B’ to ‘A’ the CD will play, when the crossfader is moved back from ‘A’ to ‘B’ the CD will return to its Cue point.
Therefore moving the fader left to right quickly will give a stutter effect.
30. X-Fade Curve Control
This rotary knob controls the curve of the VCA crossfade. The Curve can be set from a smooth fade for mixing
to a sharp cut for scratching.
Selecting this symbol gives a sharp curve on the crossfade. With the crossfader in the ‘B’ position
moving the crossfade 2mm to the left will bring in the channel assigned to ‘A’ at full volume, this is ideal for
scratching.
Selecting this symbol gives a fade without any drop in sound level. At the centre point both channel
will be a their full volume. There will be a slight increase in volume at the centre point as the two outputs
overlap.
Selecting this symbol gives a fade with a drop in the music level of 2dB at the centre point the music
from the opposite channel will come in at this level also. This should give a mix with no increase in the master
volume if the gains from both channels are at an equal dB.
31. Power Switch
Use this switch to turn the power on/off to the mixer.
Note: Be sure to switch on the power to your mixer before the amplification system.

™
BEAT SYNC SELECT
X-FADE EFFECTS
-
+
X PAR AMET ER Y PAR A MET ER IN PUT EF FEC T S
MIC-1
MIC-2
CH-1
CH-2 CH-3 CH-4
XF-A
XF-B
MASTER
TIME LEVEL/DEPTH SELECT SELECT
ECHO
AUTO
PAN
FLANGER
MANUAL
FILTER
AUTO
FILTER
REVERB
TRANS
PITCH
SHIFT
X-FADER AUTO
OFF EFFECTS
CUE
EFFECTS
ON/OFF
39
40
41
38 37 36 35
42 44 43 34 33 32
DSP Effects Section
32. TAP Button
Should the auto-BPM feature not pick up the correct BPM of a certain style of music the user can manually
‘TAP’ in the BPM in using this button
33. Effects ‘FX’ On/Off
Use this button to turn the main effects on (illuminated) of Off.
34. Effects Cue
This button gives a pre-fade indication of the selected effect in the headphones proir to the user switching the
effects on using the Effects ON/OFF button (33).
35. Effects Selector Switch
This switch is used to select the desired effect choose between:
Echo – This will give a delay-based effect in which copies of the music are heard trailing off to silence; similar to
shouting from a mountaintop and hearing your voice repeat.
Auto Pan – This will move the stereo sound automatically from the left to the right speaker repeatedly.
Flanger – This is an effect that generates a swirling sound by adding a slightly delayed copy of the signal in
which the copy's delay time fluctuates.
Manual Filter – The Filter effect removes certain frequencies from the music. Use the Time and Level/Depth
knobs to manually fade through the removal of each frequency.
Auto Filter - The Filter effect removes certain frequencies from the music automatically.
Reverb – This is an effect in which the ambience of a physical space is simulated.
Trans – This effect gives the impression of the sound dropping out, making it stutter.
Pitch Shift – This effect allows you to increase or decrease the pitch of the music without increasing or
decreasing the tempo.
36. Input Select Switch
This switch allows the user to select the input source for the effects to be added to.
37. Level/Depth Control
This rotary knob is used to adjust the ‘Y Parameter’ (mix ratio, resonance or feedback) of the selected effect.
38. Time Array Control
This rotary knob is used to adjust the ‘X Parameter’ (Time) of the selected effect.
39. LCD Display Screen
This screen gives the user a visual display of the selections that have been made within the DSP module.
Working from the top left hand corner it shows the input that is selected, the effect that is selected, the BPM of
the track playing, the ‘X Parameter’ and finally the ‘Y Parameter’.

™
40. Beat-Sync Select
These buttons are used to select which beat the effect will be on i.e. if the ½ button is selected the effects time
parameter will will match in time with the music every 2 beats.
X-Fade Effects Section
41. Echo Select
This button will assign an echo effect to the crossfade, so if the music assigned to X-Fade ‘B’ is playing moving
the x-fade to the left will take a sample of the music playing add an echo and fade it into the the music playing
on X-Fade ‘A’.
42. Platter Effect
This button will assign a platter effect to the crossfade, so if the music assigned to X-Fade ‘B’ is playing moving
the X-Fade to the feft will give the same effect as switching a turntable off as the fader is moved across the
musics pitch will drop.
43. Stutter Effect
This button will assing a stutter effect to the crossfade, so if the music assigned to X-Fade ‘B’ is playing moving
the x-fade to the left will take a sample and stutter it the more the X-Fade it moved to the left the faster the
stutter will become.
44. X-Fader Effects Select Switch
This switch is used to enable the X-Fade effects:
X-Fader – When the switch is in the X-Fader position the effects will be assigned to the crossfader as explained
in 41,42 & 43).
Off – this disables the X-Fader effects
Auto – This enables the X-fade effects to be activated in syncronisation with the Beat Sync Select buttons (40).
Assign the crossfade (e.g. CH1 – X-Fade A and CH4 – X-Fade B) with the crossfader in position A or B press
the desired effect button (41, 42 or 43) the effect will then be played in the time selected by the Beat Sync
Select buttons (40) once the effect is complete the output will automatically change to the opposite channel of
the crossfade without the crossfade physically being moved.

™
Rear Panel Section
45. AC Mains Socket
The SM-FX500 is supplied with an IEC type mains lead with a 3A fuse.
46 & 47. Master Balanced Outputs
Main stereo program output provided by 3 pin Male XLR sockets:
Output wiring (Balanced) Pin 1 - Ground (Unbalanced) - Ground (sleeve)
Pin2-Positive -Positive
Pin 3 - Negative - Connect to Ground
Nominal Output Level: Balanced & Unbalanced - 0dB (775mV)
Impedance: Output <50 Ohm - Minimum Load 600 Ohm
48. Output Trim
This knob can be used to decrease the master output to protect the connected system from excessive input.
49. Digital Output
This RCA Jack provides digital output data for digital recording.
50. Fader Control Connectors
These 3.5mm stereo mini cord jacks are used to connect to a compatible CD-Player i.e. CD-6 & CD-S6 allowing
the function of fader start (29).
51. Master Unbalanced Outputs
Main stereo program output provided by standard unbalanced phono sockets:
Level = 0dB (775mV)
Output Impedance = <50 Ohm
Load Impedance (MIN) = 5K Ohm
52. Booth Output
Stereo program output that is not affected by the master level control, design for monitoring in the DJ booth.
Level = 0dB (775mV)
Output Impedance = <50 Ohm
Load Impedance (MIN) = 5K Ohm
53. Record Output
Output for recording is provided by standard unbalanced RCA sockets at a level of 380mV RMS.
54. Phono/Aux Inputs
These Stereo unbalanced RCA jack inputs are for a Phono (RIAA) or Aux line level (selectable)
55. Phono/Aux Select Switch
This switch selects whether the input (54) is for Phono (Turntables) or Aux line level (CD-Player etc)
56. Line Inputs
These stereo inputs are used for any line level device such as a CD-Player.
57. Earth Stud
Star point earth connection for turntable ground wires to prevent hum.
58. Microphone 3 Input
This ¼” jack input is for the 3rd microphone which is selectable on music channel 4
59. Microphone 2 Input
This ¼” jack input is for the 2nd microphone which has a separate gain (6) and a shared EQ with Mic 1

™
Technical Specification
Parameter Mic 1 Mic 2/3 Phono CD/Line Aux
Sensitivity -55.4dBV -55.4dBV -49.4dBV -9.4dBV -9.4dBV
(1.7mV) (1.7mV) (3.4mV) (340mV) (340mV)
Input Impedance 2.2k 3K 47K 20K 47K
S/N Ratio* -60dB -60dB -64dB -82dB** -82dB**
T.H.D.*** <0.05% <0.05%
* Measured 0dBV, 1KHz, max Gain
** Measured with effects on
***Measured 0dBV, 25-20KHz, Max Gain
Microphone Equalisation
Hi = ±12dB @ 13KHz
Mid = ±12dB @ 1KHz
Lo = ±12dB @ 70Hz
MicrophoneTalkover = -14dB, ±1.5dB
Music Channel Equalisation
Hi = + 10dB @ 13KHz
- 30dB @ 13KHz
Mid = + 10dB @ 1KHz
- 30dB @ 1KHz
Lo = + 10dB @ 70Hz
-30dB @ 70Hz
Outputs
Balanced Master XLR = 9.5dBV (3.5dBV single to GND)/200Ω
Unbalanced Master phono = 3.8dBV (1.55V)/100Ω
Digital Output = 0.5V/75Ω
Headphones = 3V @ 32 Ohms
Power Consumption = 35VA max
Weights & Dimensions
Width = 482mm(19”)
Height = 221mm(5U)
Depth = 87.5mm
Weight = 5.25Kg
Cutout Required
Width = 442mm
Height = 215mm
Power Requirements
Power Supply = AC240, 50Hz
N.B. Citronic reserves the right to alter these specifications at any time and for any reason without liability. Errors and Omissions Excepted.

™
CD-6 Ultima Dual CD-Player – 170.651
The new CD-6 Ultima dual CD-Player is the ultimate DJ machine, with built in DSP technology the interactive touch sensitive jog wheels
allows you to scratch in real time just like vinyl. The unit also has built in effects allowing the creative DJ to open a whole new world of
possibilities, along with all the standard features you would expect from today’s CD-Player making the CD-6 Ultima an awesome mixing
machine.
Features
• Interactive Touch Sensitive Jog Wheels
• Effects – Echo, Filter, Brake, Flanger, Phase, Pan, Transform
• 10 Seconds of Anti-Shock Memory Per Deck
• Instant Start
• Seamless Loop
• Pitch Range Selectable ±4, 8, 16 & 100%
• Auto/Manual BPM (effects Linked)
• Reverse Play
• Master Tempo
• 3 Memory banks for Sampler & Cue
• S/PDIF Digital Audio RCA Coaxial Output
• Relay Play Allows Consecutive Playback between Two Decks
• Single/Continuous Play
• Selectable Elapsed, Remain and Total Time Display
• Auto Cue Function
• 6 Effect-sync Parameter Sets
• Volume Balance Between Music & Sampler
Technical Specification
Power Source: AC 230V, 50Hz, 25W
Dimensions: Main Unit: 482(W) x 262(D) x 88.8(H)mm
Control Unit: 482(W) x 177(D) x 65.5(H)mm
Weight: Main Unit: 5.6Kg
Control Unit: 3kg

™
To see more products in the range visit….
www.citronic.com
