Clare Controls GD00Z-5 Instruction Manual

Doc ID –1042 • Rev 08 1 / 12
Linear Garage Door Opener
Integration Release Notes
For model GD00Z-5
Content
Preface...1
Introduction...1
Installing GD00Z-5 devices...2
Pairing and removing the Linear using ClareHome or FusionPro...2
Installing the GD00Z-5 transceiver and tilt sensor...11
Using the garage door opener in the ClareHome app...11
Incompatible openers...12
Contact information...12
Last modified: 08/17/20
Preface
For information on Z-Wave and ClareHome, see Installing Z-Wave with
ClareHome.
Notes
•When installing Z-Wave devices, ensure that there is nothing inhibiting their
signal. Z-Wave relies on radio signals. Metal or thick walls may limit their
signal strength.
•We recommend having 2 or more repeating Z-Wave devices.
Introduction
The Linear GD00Z-5 Garage Door Opener Remote Transceiver provides
position-aware garage door integration to ClareHome via the Z-Wave network. It
is compatible with most automatic garage door openers connected to a sectional
garage door. Installers only need to pair (adding) the unit into the ClareHome
Z-Wave network, mount the unit, and then connect two wires.

Doc ID –1042 • Rev 08 2 / 12
The GD00Z-5 provides both audible and visual warnings prior to remotely
activating door movement. The GD00Z-5 ships with a wireless tilt sensor that
attaches to the inside of the garage door, which reports the open, closed, and
motion indication status to the controller.
By integrating the GD00Z-5 into a ClareHome control system, your customers
can control the garage door from their Android or iOS devices.
Installing GD00Z-5 devices
Only qualified installation technicians should install the GD00Z-5. Follow the
installation instructions that came with your GD00Z-5 equipment. We recommend
that you pair the GD00Z-5 with the ClareHome Z-Wave controller before
installing it in the garage.
Pairing and removing the Linear using ClareHome or
FusionPro
After installing the garage door, add it to the account.
Note: The garage door can be added using ClareHome and FusionPro.
To pair the garage door opener using ClareHome:
1. Tap the ClareHome app’s Devices page.

Doc ID –1042 • Rev 08 3 / 12
2. Tap + Add Device.
3. Tap Add Devices.
4. Select the device category, Access.
5. Select the device type, Z-Wave Device - Access.

Doc ID –1042 • Rev 08 4 / 12
6. Read through the displayed information, and then tap Add Z-Wave Device.
7. Read the Z-Wave information, and then tap Start Discovery Mode.
8. When prompted, press the pairing button on the Linear.

Doc ID –1042 • Rev 08 5 / 12
9. Once paired in, the Edit Device page displays.
Customize the device name and location as desired, tapping Save when
done.
Note: For scenes, notifications, schedules, and automations configuration,
see ClareHome App Guide (DOC ID 1750).
To remove the garage door opener in the ClareHome app:
1. Access the ClareHome app, and then tap the Devices icon .

Doc ID –1042 • Rev 08 6 / 12
2. Tap Access.
3. Tap the 3 dots next to the garage door opener, and then tap Remove.
4. Read through the displayed information, and then tap Start Removal Mode.
5. Use the manufacturer’s instructions for garage door removal.

Doc ID –1042 • Rev 08 7 / 12
To add the garage door opener in FusionPro:
1. Click Accounts in the side menu.
2. Locate the desired account in the list, and then click View.
The Account sub-menu is now available.
3. Click the Devices tab, and then click Add Devices.

Doc ID –1042 • Rev 08 8 / 12
4. Select the device category (Access) and then the device type (Z-Wave
Device –Access).
5. Click Add a Z-Wave Device, and then click Start Discovery Mode.
A popup displays waiting for a notification from the device, pair the Z-Wave
device according to the manufacturer’s instructions for each device.

Doc ID –1042 • Rev 08 9 / 12
6. Once the device is added, change the name and area as desired.
7. Once all desired changes are made, tap Save.
To remove the garage door opener with FusionPro:
1. Click Accounts in the side menu.

Doc ID –1042 • Rev 08 10 / 12
2. Locate the desired account in the list, and then click View.
The Account sub-menu is now available.
3. Click the Devices tab, and then click Remove Z-Wave.
4. Click Start Removal Mode.
5. Use the manufacturer’s instructions for garage door removal.

Doc ID –1042 • Rev 08 11 / 12
Installing the GD00Z-5 transceiver and tilt sensor
To install the GD00Z-5 transceiver and tilt sensor:
1. Install the GD00Z-5 transceiver and tilt sensor according to the
manufacturer’s instructions.
2. Next, follow the manufacturer’s system operations to synchronize the system.
3. Access your ClareHome app and verify that the Linear garage door opener is
now available in the Device tab.
Using the garage door opener in the ClareHome app
Once added, the user can add the Linear device to their Favorites, and then tap
the garage door tile to display and operate the garage door’s controls.
Figure 1: Linear display
Table 1: Garage door state icons
Icon color
Garage door status
The garage door is closed.
The garage door status is unknown.
The garage door is open.

Doc ID –1042 • Rev 08 12 / 12
Incompatible openers
The GD00Z-5 is compatible with most sectional garage door openers
manufactured after 1993; however, a few are known to be incompatible. The
following lists the incompatible openers. This is not intended to be a complete
list, but identifies some recent models commonly found in the retail marketplace.
Chamberlain MyQ Models:
•WD962KEV, KPEV and MLEV WD832KEV
•HD 930EV and 420EV LW500EV
•PD752D and KPV
Genie Series III Models:
•PowerMax 1500
•TriloG 1200 and 1500
•IntelliG 1000 and 1200
LiftMaster MyQ Models:
•8355, 8360, 8500, 8550, 8557, and 8587
Craftsman AssureLink / MyQ Models:
•3043 and 30437
