clare ClareVision CLR-V200-4D28W User manual

ClareVision Video
Surveillance
Value and Performance
Series Fixed Lens Dome Camera
Installation Guide
1 | ClareVision Value and Performance Dome Cameras

Box Contents
For Setting up cameras and complete user
manuals, please scan these QR codes:
https://bit.ly/34bIlND
Quick Start Guide
https://bit.ly/34eKmsq
User Manual
• Camera
• Mounting template
• Mounting kit
• Accessory kit
Required Equipment
• Phillips head screwdriver
• Power source: Ethernet cable
• Drill with ¼” drill bit
2 | ClareVision Value and Performance Dome Cameras

Inspection
Ensure that the device is in good condition and
all the assembly parts are included.
• Make sure that all equipment is powered o
during installation.
• Ensure the mounting surface is strong enough
to withstand three times the weight of the camera
and the mount.
• If the product does not function properly, please
contact technical support. Do not disassemble
the camera for repair or maintenance.
WARNING: This product can expose you
to chemicals including cadmium, which
which is known to the State of California to cause
cancer. For more information, go to
www.p65warnings.ca.gov.
3 | ClareVision Value and Performance Dome Cameras

Overview
Before installing, familiarize yourself with
the parts of the camera.
4 | ClareVision Value and Performance Dome Cameras

Installation
1. Drill a cable hole and ¼” pilot holes, using
the supplied template.
2. Using the provided hex-key, loosen the
cover screws on the outer cover assembly.
Remove the outer cover assembly.
Note: The outer cover assembly is attached
to the chassis assembly via a small cord.
5 | ClareVision Value and Performance Dome Cameras

Installation
3. Connect an ethernet cable that is
connected to the desired POE enabled
network into the camera’s ethernet adapter.
6 | ClareVision Value and Performance Dome Cameras
4. Insert the drywall anchors. Secure the
chassis assembly to the mounting surface
using provided screws.

Installation
5. Adjust the viewing angle by rotating
the sphere.
6. Resecure the upper cover assembly to the
chassis assembly.
7 | ClareVision Value and Performance Dome Cameras

Support
Need help? Contact Tech Support!
If you need further clarification, please
contact our support staff.
Integrator/Dealer Support:
Phone: [phone]
Email: [email protected]
For more information, instructional videos, or
support documentation, visit our Help Center
and view your item’s product page:
https://www.clarecontrols.com/helpcenter
8 | ClareVision Value and Performance Dome Cameras

Contact Information
Clare Controls, LLC.
7519 Pennsylvania Ave, Suite 104
Sarasota, FL 34243
General: 941.328.3991
Fax: [phone]
www.clarecontrols.com
Warranty Information
Clare Controls offers a two (2) year limited
warranty on original Clare Controls
components, from the date of shipment
from Clare Controls. To view complete
limited warranty details, including limitations
and exclusions, please visit:
www.clarecontrols.com/warranty
9 | ClareVision Value and Performance Dome Cameras

Camera Information
Please provide this guide to the customer
and notate the camera installation location.
This guide includes important camera details.
Installattion Location: __________________
Camera Details:
Product
Label
10 | ClareVision Value and Performance Dome Cameras
Doc ID: 2021-01-2060-05
