-1- PU-2134A
PU-2136A
Published by Service Dept.
Printed in Japan
Model
Service Manual
ClarionCo.,Ltd.
ExportDivision -22-3,Shibuya2-chome, Shibuyaku, Tokyo,150Japan Tel: [phone]
ServiceDept.- 50kamitoda,Toda-shi,Saitama,335Japan Tel:[phone] FAX:[phone]-5611-00 Oct.1997 P
SAAB Automobile Genuine
FM/AM Radio Cassette Stereo
PU-2134A
■SPECIFICATIONS
Radio section
Tuning system: PLL Frequency synthesizer system
Receive range: FM 87.9 to 107.9MHz(PU2134A)
87.5 to 108.0MHz(PU2136A)
AM 530 to 1,710kHz(PU2134A)
531 to 1,602kHz(PU2136A)
WB 162.4 to 162.55MHz(PU2134A)
Intermediate frequency:
FM 10.7±0.2MHz
AM 450±3kHz
Quieting sensitivity:FM Less than 15dBμ(at 30dB S/N)
AM Less than 35dBμ(at 20dB S/N)
Separation: FM More than 20dB
Auto tuning stop sensitivity:
FM 25±8dBμ
AM 30±10dBμ
CD section
Separation: More than 65dB
S/N ratio: More than 80dB
Dynamic range: More than 90dB
Distortion: Less than 1％
( )
Genuine No. 47 10 349
For U.S.A./Canada
PU-2136A
Genuine No. 47 10 364
For Asia/Oceania
( )
Model
PU-2134A
General
Load impedance: 4Ω/CH
Output power: More than 13W×4
Power supply voltage:
DC13.2V(10.8V to 15.6V)
Negative ground
Consumptive current:
Less than 10A
Dimensions(mm): 188(W)×104(H)×171(D)
Weight: 1.8kg
※Specifications and design are subject to change with-
out notice for further improvement.
■COMPONENTS
PU-2134A-A / PU-2136A-A
Main unit 1
■ANTI-THEFT SYSTEM
This unit has a built-in Anti-Theft System.

-2-
PU-2134A
PU-2136A
■ADJUSTMENTS
FM S-meter SSG
Milli volt meter
Item Procedure Measuring
instrument
6. Cautions in handling flexible PWB
Before working with a soldering iron,make sure that
the iron tip temperature is around 270℃.Take care
not to apply the iron tip repeatedly(more than three
times)to the same patterns.Also take care not to ap-
ply the tip with force.
7. Turn the unit OFF during disassembly and parts
replacement.Recheck all work before you apply power
to the unit.
8. Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface
through the lens of the optical pickup. When checking
that the laser optical diode lights up,keep your eyes
more than 30cms away from the lens.Prolonged view-
ing of the laser within 30cms may damage your eye-
sight.
9. Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged
by electrostatic charge caused by your clothes and
body.Make sure to avoid electrostatic charges on your
clothes or body,or discharge static electricity before
handling the optical pickup.
9-1. Laser diode
The laser diode terminals are shorted for trans-
portation in order to prevent electrostatic
damage.After replacement,open the shorted
circuit.When removing the pickup from the
mechanism,short the terminals by soldering
them to prevent this damage.
9-2. Actuator
The actuator has a powerful magnetic circuit.If
a magnetic material is put close to it.its charac-
teristics will change.Ensure that no foreign sub-
stances enter through the ventilation slots in the
cover.
9-3. Cleaning the lens
Dust on the optical lens affects performance.To
clean the lens,apply a small amount of
isopropylalcohol to lens paper and wipe the
lens gently.
■To engineers in charge of repair
or inspection of our products.
Before repair or inspection,make sure to fol-
low the instructions so that customers and
Engineers in charge of repair or inspection can
avoid suffering any risk or injury.
1. Use specified parts.
The system uses parts with special safety features
against fire and voltage.Use only parts with equiva-
lent characteristics when replacing them.
The use of unspecified parts shall be regarded as re-
modeling for which we shall not be liable.The onus of
product liability (PL) shall not be our responsibility in
cases where an accident or failure is as a result of
unspecified parts being used.
2. Place the parts and wiring back in their original posi-
tions after replacement or re-wiring.
For proper circuit construction,use of insulation
tubes,bonding,gaps to PWB,etc,is involved.The wir-
ing connection and routing to the PWB are specially
planned using clamps to keep away from heated and
high voltage parts.Ensure that they are placed back
in their original positions after repair or inspection.
If extended damage is caused due to negligence dur-
ing repair,the legal responsibility shall be with the
repairing company.
3. Check for safety after repair.
Check that the screws,parts and wires are put back
securely in their original position after repair.Ensure
for safety reasons there is no possibility of secondary
ploblems around the repaired spots.
If extended damage is caused due to negligence of
repair,the legal responsibility shall be with the repair-
ing company.
4. Caution in removal and making wiring connection to
the parts for the automobile.
Disconnect the battery terminal after turning the igni-
tion key off.If wrong wiring connections are made with
the battery connected, a short circuit and/or fire may
occur.If extensive damage is caused due to negligence
of repair,the legal responsibility shall be with the re-
pairing company.
5. Cautions regarding chips.
Do not reuse removed chips even when no abnormal-
ity is observed in their appearance.Always replace
them with new ones.(The chip parts include
resistors,capacitors,diodes,transistors,etc).The nega-
tive pole of tantalum capacitors is highly susceptible
to heat,so use special care when replacing them and
check the operation afterwards.
1. Input a 98.1MHz/30dBμ(Mod freq:1kHz,Mod rate MONO:22.5kHz Dev)
signal.
2. Adjust VR1 of tuner pack so that an output of TP101 is 3.2±0.1V.

PU-2134A
PU-2136A PU-2134A
PU-2136A
■EXPLODED VIEW・PARTS LIST
Main section
NO. PART NO. DESCRIPTION Q'TY
NO. PART NO. DESCRIPTION Q'TY
1 380-5395-00 KNOB(VOL) 1
2 380-5396-00 KNOB(B/T/F) 3
3 371-3846-00 TRIM PLATE(VOL) 1
4 371-3847-00 TRIM PLATE(B/T/F) 1
5 346-0072-02 LEATHER SHEET 1
16 303-0461-00 UPPER COVER 1
17 305-0258-00 SIDE COVER(R) 1
18 305-0257-00 SIDE COVER(L) 1
19 309-0685-01 FRONT PLATE 1
20 039-1037-00 MAIN PWB 1
21 307-0583-00 REAR PLATE 1
22 076-0515-14 CONNECTOR 1
23 722-0332-00 MUT(M6) 4
24 016-3100-00 VR(B/T/F) 3
25 331-2113-00 ANT HOLDER 1
26 331-2038-01 IC HOLDER 1
27 051-2014-00 IC 1
28 074-0850-08 DIN CONNECTOR 1
29 331-2039-00 DIN HOLDER 1
30 039-1035-00 ISO PWB 1
31 074-1155-00 ISO CONNECTOR 1
32 313-1682-01 HEAT SINK 1
33 929-0065-83 CD MECHANISM 1
34 331-2040-00 CD BRACKET(FRONT) 1
35 331-2041-00 CD BRACKET(REAR) 1
36 816-2438-00 FLAT WIRE(FOR CD) 1
37 016-0500-00 VR(VOL) 1
38 076-0324-06 OUTLET SOCKET 1
39 854-4318-30 EXTENSION LEAD 1
40 331-2112-01 SHIELD CASE 1
41 854-4322-30 EXTENSION LEAD(9P) 1
42 854-4323-30 EXTENSION LEAD(2P) 1
43 076-0349-02 PLUG(2P) 1
44 076-0349-09 PLUG(9P) 1
45 854-4319-30 EXTENSION LEAD 1
46 060-0057-56 AUTO FUSE(10A) 1
47 731-2608-80 TAP TIGHT 2
48 740-2600-11 FLAT WASHER 2
49 714-3005-81 MACHINE SCREW 11
50 714-3008-81 MACHINE SCREW 2
51 714-3010-81 MACHINE SCREW 5
52 714-2303-81 MACHINE SCREW 4
53 880-2079G TUNER PACK(FM/AM) 1
54 880-2201A TUNER PACK 1
(WB/PU-2134A only)
55 347-5287-00 INSULATOR 1
56 347-5288-02 INSULATOR 1
57 347-5289-01 SHIELD SHEET 1
58 940-7818-01 ES-ASS'Y(PU-2134A) 1
940-7822-01 ES-ASS'Y(PU-2136A) 1
59 335-5604-00 ANT CLIP 1
60 286-8759-00 SET PLATE(PU-2134A) 1
286-8759-04 SET PLATE(PU-2136A) 1
-5 - -6 -
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
6 335-4759-00 DISC GUIDE 1
7 335-5281-00 ILLUMI PLATE 1
8 345-8011-00 RUBBER SWITCH 1
9 039-1034-00 SWITCH PWB 1
10 074-1105-14 OUTLET SOCKET 1
11 345-3814-44 LAMP CAP 6
12 017-0449-00 PILOT LAMP 6
13 716-0872-01 PAD SCREW 9
14 001-0569-04 DIODE 1
15 304-0446-01 LOWER COVER 1

PU-2134A
PU-2136A PU-2134A
PU-2136A
CD mechanism section：929-0065-83
-7 - -8 -

-9- PU-2134A
PU-2136A
1 HBS-433-100 DRIVE UNIT 1
1-1 013-7100-00 LIMIT SWITCH 1
1-2 620-0198-03 CLAMPER PLATE 1
1-3 620-0491-03 SPRING PLATE 1
1-4 620-0690-00 RATTLE PLATE 1
1-5 621-0205-02 CLAMPER PLATE 1
1-6 621-0251-02 LOCK LINK 1
1-7 621-0252-03 DISC STOPPER 1
1-8 621-0253-01 MOTOR HOLDER 1
1-9 621-0255-02 SECOND GEAR 1
1-10 621-0257-05 SCREW HOLDER 1
1-11 621-0357-02 PICKUP GUIDE 1
1-12 621-0358-02 LS-HOLDER-F 1
1-13 621-0359-02 LS-HOLDER-R 1
1-14 622-1073-02 CLAMPER ROLLER 1
1-15 714-2003-81 MACHINE SCREW (M2X3) 10
1-16 716-0675-00 SCREW 2
1-17 716-1468-00 SCREW 2
1-18 716-1555-00 WAVE SCREW 1
1-19 716-1733-00 SCREW 2
1-20 732-2004-11 SEMS SCREW 2
1-21 739-1735-17 PRECISION SCREW 2
1-22 750-3097-03 CLAMPER SPRING 1
1-23 750-3098-00 L-LINK SPRING 1
1-24 750-3099-00 ES-SPRING 1
1-25 746-0761-00 WASHER 2
1-26 816-2372-00 VINYL COAT WIRE(BLU) 1
1-27 816-2373-00 VINYL COAT WIRE(WHT) 1
1-28 966-0314-01 STOP LINK ASS'Y 1
1-29 966-0447-04 DR-PLATE ASS'Y 1
1-30 966-0448-00 SIDE PLATE ASS'Y 1
1-31 966-0449-01 CLAMP LINK ASS'Y 1
1-32 969-0005-00 PICKUP UNIT ASS'Y 1
1-33 HBS-432-100 LS-GEAR ASS'Y 1
1-34 SMA-146-100 MOTOR ASS'Y(SLED) 1
1-35 SMA-151-100 MOTOR ASS'Y(SPINDLE) 1
2 966-0308-09 CHASSIS ASS'Y 1
3 966-0309-04 L-DISC-G-ASS'Y 1
4 966-0310-06 SFT-P-CH-ASS'Y 1
5 966-0312-06 SHIFT-P-ASS'Y 1
6 966-0358-01 DRIVE-L-PL-ASS'Y 1
7 966-0359-03 SIDE-L-PL-ASS'Y 1
8 013-3879-01 CHUCKING SWITCH 1
9 039-0586-01 CHUCKING SW PWB 1
10 039-0588-01 SENSOR PWB 1
11 060-0252-01 PHOTO TR (PT4850F) 3
12 345-7513-01 CLAMPER SHEET 1
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
13 345-7514-00 S-PEB-SHEET 1
14 620-0485-03 FRONT PLATE 1
15 620-0488-01 S-L-LINK PLATE 1
16 620-0489-01 MOTOR PLATE 1
17 620-0492-01 MOTOR BRACKET 1
18 620-0697-01 MECHA BRACKET 1
19 621-0402-00 U-DISC GUIDE 1
20 621-0243-02 ROLLER SLEEVE 2
21 621-0248-06 RACK GEAR 1
22 621-0249-02 ROLLER GEAR 1
23 621-0250-01 DAMPER HOLDER 4
24 621-0258-03 LOADING ROLLER 2
25 622-1072-05 ROLER SHAFT 1
26 622-1219-01 SHIFT ROLLER 1
27 629-0058-00 DAMPER-DL 4
28 714-2003-81 MACHINE SCREW(M2X3) 8
29 714-2603-81 MACHINE SCREW(M2.6X3) 5
30 716-1468-00 SCREW 2
31 716-1507-00 SCREW 2
32 716-1670-00 SCREW 6
33 716-1677-00 SCREW 1
34 716-1704-00 SCREW 1
35 716-1742-00 SCREW 1
36 743-1500-10 E-RING 3
37 746-0712-03 WASHER 1
38 746-0762-00 WASHER 1
39 746-0877-02 WASHER 2
40 750-3090-02 RO-SPRING-L 1
41 750-3091-03 RO-SPRING-R 1
42 750-3092-03 SHIFT SPRING 1
43 750-3094-00 S-ARM SPRING 1
44 750-3096-01 DR-SPRING-R 1
45 750-3098-00 L-LINK SPRING 1
46 750-3164-00 DR-SPRING-LR 1
47 750-3188-00 DR-SP-F-B 1
48 750-3189-00 SIDE-L-SPRING 1
49 750-3201-00 DR-SPRING-F-R 1
50 750-3202-00 CENTER SPRING-B 1
51 800-4904-60 VINYL COAT WIRE(BLK) 1
52 800-4910-60 VINYL COAT WIRE(BLK) 1
53 801-4910-60 VINYL COAT WIRE(BRN) 1
54 802-4904-60 VINYL COAT WIRE(RED) 1
55 802-4910-60 VINYL COAT WIRE(RED) 1
56 804-4910-60 VINYL COAT WIRE(YEL) 1
57 HBS-430-100 GEAR-SUB-ASS'Y 1
58 HBS-461-100 PWB ASS'Y 1
59 SMA-147-100 MOTOR ASS'Y(LOADING) 1

-10-
PU-2134A
PU-2136A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
■ELECTRICAL PARTS LIST
Main PWB section(B1)
C 101 182-1053-63 50V1μF
C 102 176-1801-00 18pF CH
C 103 176-2201-00 22pF CH
C 104 178-1032-78 0.01μF
C 105 178-2232-78 0.022μF
C 106 178-1032-78 0.01μF
C 107 184-1083-22 10V1000μF
C 108 178-2232-78 0.022μF
C 109 178-4732-78 0.047μF
C 110 178-2232-78 0.022μF
C 111 182-1053-63 50V1μF
C 112 178-1032-78 0.01μF
C 113 178-2722-78 2700pF
C 114 178-1532-78 0.015μF
C 115 178-1532-78 0.015μF
C 116 182-4763-23 10V47μF
C 117 178-1032-78 0.01μF
C 118 182-1056-62 50V1μF NP
C 119 178-1032-78 0.01μF
C 120 184-1083-22 10V1000μF
C 122 178-1032-78 0.01μF
C 123 182-1053-63 50V1μF
C 124 182-1053-63 50V1μF
C 125 182-3343-63 50V0.33μF
C 126 178-1022-78 1000pF
C 128 178-4732-78 0.047μF
C 137 178-2232-78 0.022μF
C 146 178-1032-78 0.01μF
C 147 178-1032-78 0.01μF
C 201 182-1063-33 16V10μF
C 202 182-1063-33 16V10μF
C 203 182-1063-33 16V10μF
C 204 182-1063-33 16V10μF
C 205 182-1063-33 16V10μF
C 206 182-1063-33 16V10μF
C 207 176-5601-00 56pF CH
C 208 178-1042-78 0.1μF
C 209 176-5601-00 56pF CH
C 210 176-5601-00 56pF CH
C 211 176-5601-00 56pF CH
C 212 176-5601-00 56pF CH
C 213 176-5601-00 56pF CH
C 214 182-1063-33 16V10μF
C 215 182-1073-13 6.3V100μF
C 216 178-1032-78 0.01μF
C 401 176-5601-00 56pF CH
C 402 176-5601-00 56pF CH
C 403 176-5601-00 56pF CH
C 404 176-5601-00 56pF CH
C 405 178-1032-78 0.01μF
C 407 184-1073-22 10V100μF
C 408 184-1073-22 10V100μF
C 409 184-1073-22 10V100μF
C 410 184-1073-22 10V100μF
C 411 172-1041-11 0.1μF
C 412 172-1041-11 0.1μF
C 501 182-1046-62 50V0.1μF NP
C 502 182-1046-62 50V0.1μF NP
C 503 182-1046-62 50V0.1μF NP
C 504 182-1046-62 50V0.1μF NP
C 505 182-1053-63 50V1μF
C 506 182-4763-33 16V47μF
C 507 178-1022-78 1000pF
C 508 178-1022-78 1000pF
C 509 178-1022-78 1000pF
C 510 178-1022-78 1000pF
C 511 178-4742-78 0.47μF
C 512 042-0570-00 16V3300μF
C 513 172-1041-11 0.1μF
C 514 182-4753-63 50V4.7μF
C 601 178-4732-78 0.047μF
C 602 176-5601-00 56pF CH
C 603 176-5601-00 56pF CH
C 604 182-4753-53 35V4.7μF
C 605 182-4753-53 35V4.7μF
C 606 176-1511-00 150pF CH
C 607 176-1511-00 150pF CH
C 608 178-8232-78 0.082μF
C 609 178-8232-78 0.082μF
C 612 182-1063-33 16V10μF
C 613 182-1063-33 16V10μF
C 614 182-4753-53 35V4.7μF
C 615 182-4753-53 35V4.7μF
C 616 182-2253-63 50V2.2μF
C 617 182-2253-63 50V2.2μF
C 618 178-5632-78 0.056μF
C 619 178-5632-78 0.056μF
C 620 178-5622-78 5600pF
C 621 178-5622-78 5600pF
C 622 178-5622-78 5600pF
C 623 178-5622-78 5600pF
C 626 178-1032-78 0.01μF
C 627 182-1063-33 16V10μF
C 630 178-1032-78 0.01μF
C 632 172-1241-11 0.12μF
C 633 178-3932-78 0.039μF
C 640 178-2222-78 2200pF
C 641 178-1032-78 0.01μF
C 642 178-3332-78 0.033μF
C 644 182-1056-62 50V1μF NP
C 646 182-1073-13 6.3V100μF
C 647 184-1073-22 10V100μF
C 648 178-1032-78 0.01μF
C 650 182-1056-62 50V1μF NP
C 652 178-3332-78 0.033μF
C 654 172-1241-11 0.12μF
C 655 178-3932-78 0.039μF
C 662 178-2222-78 2200pF
C 663 178-1032-78 0.01μF
C 664 178-1242-78 0.12μF
C 665 178-1242-78 0.12μF
C 666 178-1242-78 0.12μF
C 667 178-1242-78 0.12μF
C 701 178-1042-78 0.1μF
C 702 176-2201-00 22pF CH
C 703 176-2201-00 22pF CH
C 704 178-1042-78 0.1μF
C 705 184-4773-12 6.3V470μF
C 706 178-1032-78 0.01μF
C 707 178-1032-78 0.01μF
C 708 176-1011-00 100pF CH
C 709 176-1011-00 100pF CH
C 710 176-1011-00 100pF CH
C 711 176-1011-00 100pF CH
C 713 178-1042-78 0.1μF
C 714 176-1007-00 10pF CH
C 715 178-1042-78 0.1μF
C 716 178-1022-78 1000pF
C 717 178-1022-78 1000pF
C 718 178-1022-78 1000pF
C 801 184-1073-22 10V100μF
C 802 184-2273-22 10V220μF
C 803 178-2242-78 0.22μF
C 805 184-1073-22 10V100μF
C 806 182-1073-33 16V100μF
C 808 184-1073-22 10V100μF
C 809 042-0171-00 16V47μF
C 810 178-1032-78 0.01μF
C 811 172-1031-11 0.01μF
C 812 182-1063-53 35V10μF
C 813 184-4763-52 35V47μF
C 814 178-1032-78 0.01μF
C 816 172-2241-11 0.22μF
C 817 178-1032-78 0.01μF
C 819 184-1083-32 16V1000μF
C 820 172-1031-11 0.01μF
C 821 172-1031-11 0.01μF
C 822 178-1032-78 0.01μF
C 990 182-2253-63 50V2.2μF
C 991 172-1041-11 0.1μF
C 992 182-3363-23 10V33μF
C 2001 183-1063-32 16V10μF
C 2003 176-1007-00 10pF CH
C 2004 176-1007-00 10pF CH
C 2005 183-1043-62 50V0.1μF
C 2006 176-1501-00 15pF CH
C 2007 176-1501-00 15pF CH
C 2008 178-1042-78 0.1μF
C 2009 178-1042-78 0.1μF
C 2011 178-1032-78 0.01μF
C 2015 183-1063-32 16V10μF
C 2020 178-1032-78 0.01μF
C 2021 183-1053-62 50V1μF
C 2022 178-1032-78 0.01μF
C 2023 042-0171-00 16V47μF
C 2024 178-1032-78 0.01μF
C 2025 172-1841-15 0.18μF
C 2026 183-1063-32 16V10μF
C 2027 176-1007-00 10pF CH
C 2028 178-1022-78 1000pF
C 2031 178-1032-78 0.01μF
C 2032 178-1032-78 0.01μF
D 101 001-0466-00 S5688B
D 102 001-0330-00 1SS119
D 106 001-0376-20 MTZJ3.9A
D 401 001-0376-41 MTZJ7.5B
D 402 001-0376-41 MTZJ7.5B
D 403 001-0376-41 MTZJ7.5B
D 404 001-0376-41 MTZJ7.5B
D 701 001-0330-00 1SS119
D 702 001-0330-00 1SS119
D 703 001-0330-00 1SS119
D 704 001-0330-00 1SS119
D 705 001-0330-00 1SS119
D 706 001-0330-00 1SS119
D 707 001-0330-00 1SS119
D 708 001-0330-00 1SS119
D 709 001-0330-00 1SS119(PU-2134A)
D 709 001-0454-00 MA700(PU-2136A)
D 711 001-0454-00 MA700
D 712 001-0454-00 MA700
D 713 001-0454-00 MA700
D 714 001-0516-00 MA111
D 715 001-0569-04 MAA3371X
D 801 001-0466-00 S5688B
D 802 001-0330-00 1SS119
D 803 001-0376-47 MTZJ9.1B
D 805 001-0376-32 MTZJ5.6B
D 806 001-0376-46 MTZJ9.1A
D 807 001-0330-00 1SS119
D 808 001-0334-30 RL202
D 810 001-0376-46 MTZJ9.1A
D 811 001-0421-31 MTZJ18
D 812 001-0330-00 1SS119
D 813 001-0330-00 1SS119
D 2001 001-0376-59 MTZ13JA
D 2002 001-0330-00 1SS119
D 2003 001-0330-00 1SS119
D 2004 001-0330-00 1SS119
IC 201 051-0556-01 NJM2058M
IC 401 051-0556-01 NJM2058M
IC 501 051-2014-00 TDA7384A
IC 601 051-5008-00 M62419FP

-11- PU-2134A
PU-2136A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
IC 603 051-5814-00 LC7527E
IC 604 051-0350-55 NJM4558M
IC 701 051-9402-05
IC 702 052-1142-00 μPD178016GC-
523-3B9
IC 801 051-1834-00 LM2936
IC 802 051-1556-05 S-80740AN-D4-X
IC 803 051-1556-05 S-80740AN-D4-X
IC 2001 052-3141-00 μPD78013GC-784-
AB8
IC 2002 051-1822-05 S-80732AN-DW-X
IC 2003 051-6608-00 μPD72005GC(A)-
3BH
IC 2004 051-6607-08 PCA82C250T-T
IC 2005 051-1834-00 LM2936
L 101 010-2330-17 5.6μH J
L 701 010-2330-12 2.2μH J
L 2001 010-3025-00
L 2002 010-2330-00 0.22μH J
Q 101 102-2712-00 2SC2712
Q 102 125-2004-03 RN1403
Q 103 125-2004-03 RN1403
Q 104 100-1162-00 2SA1162
Q 105 102-2712-00 2SC2712
Q 106 100-1162-00 2SA1162
Q 107 100-1162-00 2SA1162
Q 401 100-1162-00 2SA1162
Q 501 102-2712-51 2SC2712G.L
Q 502 125-2004-02 RN1402
Q 601 103-1306-00 2SD1306
Q 602 103-1306-00 2SD1306
Q 603 103-1306-00 2SD1306
Q 604 103-1306-00 2SD1306
Q 701 125-0002-02 RN2402
Q 702 125-0002-02 RN2402
Q 703 125-2004-02 RN1402
Q 801 103-1858-00 2SD1858
Q 802 103-1858-00 2SD1858
Q 803 103-1858-00 2SD1858
Q 805 100-1297-00 2SA1297
Q 806 125-2004-02 RN1402
Q 808 100-1297-00 2SA1297
Q 809 125-2004-02 RN1402
Q 810 103-1858-00 2SD1858
Q 811 103-1858-00 2SD1858
Q 812 125-0002-02 RN2402
Q 813 102-3420-00 2SC3420
Q 814 125-0002-02 RN2402
Q 815 125-2004-02 RN1402
Q 817 100-1298-00 2SA1298
Q 818 100-0885-00 2SA885-QRS
Q 819 102-2712-00 2SC2712
Q 820 125-2004-02 RN1402
Q 821 101-1018-00 2SB1018 Q,Y
Q 992 108-0669-00 2SK669
Q 2001 100-1162-00 2SA1162
Q 2002 102-2712-00 2SC2712
Q 2003 100-1297-00 2SA1297
Q 2004 125-2004-02 RN1402
Q 2005 100-1431-00 2SA1431
R 101 117-4721-10 1/10W 4.7kΩ
R 102 117-4721-10 1/10W 4.7kΩ
R 103 111-3301-91 1/4WS 33Ω
R 104 117-1001-10 1/10W 10Ω
R 106 117-2221-10 1/10W 2.2kΩ
R 107 117-5631-10 1/10W 56kΩ
R 108 117-2221-10 1/10W 2.2kΩ
R 109 117-1031-10 1/10W 10kΩ
R 110 117-1231-10 1/10W 12kΩ
R 111 117-1821-10 1/10W 1.8kΩ
R 112 117-1041-10 1/10W 100kΩ
R 113 117-1041-10 1/10W 100kΩ
R 114 117-1031-10 1/10W 10kΩ
R 115 117-4721-10 1/10W 4.7kΩ
R 116 117-1031-10 1/10W 10kΩ
R 117 117-1821-10 1/10W 1.8kΩ
R 118 117-8231-10 1/10W 82kΩ
R 119 117-1031-10 1/10W 10kΩ
R 120 117-1031-10 1/10W 10kΩ
R 121 117-1521-10 1/10W 1.5kΩ
R 124 117-2231-10 1/10W 22kΩ
R 125 117-5621-10 1/10W 5.6kΩ
R 126 117-5621-10 1/10W 5.6kΩ
R 127 117-2231-10 1/10W 22kΩ
R 128 117-3311-10 1/10W 330Ω
R 130 117-5621-10 1/10W 5.6kΩ
R 131 117-5621-10 1/10W 5.6kΩ
R 132 117-1231-10 1/10W 12kΩ
R 135 117-8221-10 1/10W 8.2kΩ
R 136 117-8221-10 1/10W 8.2kΩ
R 138 117-5631-10 1/10W 56kΩ
R 139 117-1031-10 1/10W 10kΩ
R 201 117-1021-10 1/10W 1kΩ
R 202 117-1021-10 1/10W 1kΩ
R 203 117-2731-10 1/10W 27kΩ
R 204 117-1021-10 1/10W 1kΩ
R 205 117-2731-10 1/10W 27kΩ
R 206 117-1021-10 1/10W 1kΩ
R 207 117-2231-10 1/10W 22kΩ
R 208 117-2231-10 1/10W 22kΩ
R 209 117-1031-10 1/10W 10kΩ
R 210 117-1031-10 1/10W 10kΩ
R 211 117-1011-10 1/10W 100Ω
R 212 117-1031-10 1/10W 10kΩ
R 213 117-1031-10 1/10W 10kΩ
R 214 117-2231-10 1/10W 22kΩ
R 215 117-2231-10 1/10W 22kΩ
R 216 117-1031-10 1/10W 10kΩ
R 217 117-1031-10 1/10W 10kΩ
R 218 117-1031-10 1/10W 10kΩ
R 219 117-1231-10 1/10W 12kΩ
R 401 117-1031-10 1/10W 10kΩ
R 402 117-1031-10 1/10W 10kΩ
R 403 117-1831-10 1/10W 18kΩ
R 404 117-5621-10 1/10W 5.6kΩ
R 405 117-5621-10 1/10W 5.6kΩ
R 406 117-1831-10 1/10W 18kΩ
R 407 117-1031-10 1/10W 10kΩ
R 408 117-1031-10 1/10W 10kΩ
R 409 117-1831-10 1/10W 18kΩ
R 410 117-5621-10 1/10W 5.6kΩ
R 411 117-5621-10 1/10W 5.6kΩ
R 412 117-1831-10 1/10W 18kΩ
R 413 111-2201-91 1/4WS 22Ω
R 414 111-2201-91 1/4WS 22Ω
R 415 111-2201-91 1/4WS 22Ω
R 416 111-2201-91 1/4WS 22Ω
R 417 111-4721-91 1/4WS 4.7kΩ
R 418 111-4721-91 1/4WS 4.7kΩ
R 419 117-1031-10 1/10W 10kΩ
R 421 117-1021-10 1/10W 1kΩ
R 501 117-1021-10 1/10W 1kΩ
R 502 117-1021-10 1/10W 1kΩ
R 503 117-4721-10 1/10W 4.7kΩ
R 504 117-4721-10 1/10W 4.7kΩ
R 505 117-1031-10 1/10W 10kΩ
R 506 117-1031-10 1/10W 10kΩ
R 507 117-1031-10 1/10W 10kΩ
R 508 117-1031-10 1/10W 10kΩ
R 509 117-1031-10 1/10W 10kΩ
R 510 117-1031-10 1/10W 10kΩ
R 511 117-1051-10 1/10W 1MΩ
R 601 117-3931-10 1/10W 39kΩ
R 602 117-3931-10 1/10W 39kΩ
R 603 117-6831-10 1/10W 68kΩ
R 604 117-6831-10 1/10W 68kΩ
R 605 117-6821-10 1/10W 6.8kΩ
R 606 117-6821-10 1/10W 6.8kΩ
R 609 117-3331-10 1/10W 33kΩ
R 610 117-3331-10 1/10W 33kΩ
R 611 117-1831-10 1/10W 18kΩ
R 612 117-1831-10 1/10W 18kΩ
R 613 117-6821-10 1/10W 6.8kΩ
R 614 117-6821-10 1/10W 6.8kΩ
R 617 117-6821-10 1/10W 6.8kΩ
R 618 117-6821-10 1/10W 6.8kΩ
R 619 117-1021-10 1/10W 1kΩ
R 620 117-1021-10 1/10W 1kΩ
R 621 117-1021-10 1/10W 1kΩ
R 622 117-1021-10 1/10W 1kΩ
R 624 117-2231-10 1/10W 22kΩ
R 625 117-2231-10 1/10W 22kΩ
R 626 117-4721-10 1/10W 4.7kΩ
R 627 117-4721-10 1/10W 4.7kΩ
R 628 117-4721-10 1/10W 4.7kΩ
R 629 117-4721-10 1/10W 4.7kΩ
R 703 117-4731-10 1/10W 47kΩ
R 707 117-1041-10 1/10W 100kΩ
R 708 117-1041-10 1/10W 100kΩ
R 709 117-1041-10 1/10W 100kΩ
R 710 117-1031-10 1/10W 10kΩ
R 711 117-4721-10 1/10W 4.7kΩ
R 712 117-4721-10 1/10W 4.7kΩ
R 714 117-4731-10 1/10W 47kΩ
R 715 117-6831-10 1/10W 68kΩ
R 716 117-1021-10 1/10W 1kΩ
R 720 117-1031-10 1/10W 10kΩ
R 721 117-1031-10 1/10W 10kΩ
R 722 117-2231-10 1/10W 22kΩ
R 723 117-1021-10 1/10W 1kΩ
R 724 117-1021-10 1/10W 1kΩ
R 725 117-1031-10 1/10W 10kΩ
R 726 117-1021-10 1/10W 1kΩ
R 727 117-1021-10 1/10W 1kΩ
R 728 117-1031-10 1/10W 10kΩ
R 729 117-1031-10 1/10W 10kΩ
R 730 117-1021-10 1/10W 1kΩ
R 731 117-3321-10 1/10W 3.3kΩ
R 732 117-3321-10 1/10W 3.3kΩ
R 733 117-1021-10 1/10W 1kΩ
R 734 117-1031-10 1/10W 10kΩ
R 735 117-1031-10 1/10W 10kΩ
R 736 117-1021-10 1/10W 1kΩ
R 738 117-1031-10 1/10W 10kΩ
R 739 117-1021-10 1/10W 1kΩ
R 740 117-1031-10 1/10W 10kΩ
R 741 117-1031-10 1/10W 10kΩ
R 742 117-1031-10 1/10W 10kΩ
R 743 117-1031-10 1/10W 10kΩ
R 744 117-1031-10 1/10W 10kΩ
R 801 111-1091-91 1/4WS 1Ω
R 802 111-1091-91 1/4WS 1Ω
R 803 111-1091-91 1/4WS 1Ω
R 805 111-2211-81 1/2WS 220Ω
R 806 111-1521-91 1/4WS 1.5kΩ
R 807 117-1031-10 1/10W 10kΩ
R 809 111-8211-81 1/2WS 820Ω
R 810 117-5621-10 1/10W 5.6kΩ
R 811 111-1091-91 1/4WS 1Ω
R 812 111-1091-91 1/4WS 1Ω
R 813 111-2211-91 1/4WS 220Ω
R 814 111-1811-81 1/2WS 180Ω
R 817 117-2221-10 1/10W 2.2kΩ
R 818 117-1031-10 1/10W 10kΩ
R 819 111-1001-81 1/2WS 10Ω
R 820 111-2201-91 1/4WS 22Ω
R 825 117-2231-10 1/10W 22kΩ
R 826 117-2221-10 1/10W 2.2kΩ
R 827 117-6821-10 1/10W 6.8kΩ
R 828 111-3311-91 1/4WS 330Ω
R 829 117-2231-10 1/10W 22kΩ
R 830 117-4741-10 1/10W 470kΩ

-12-
PU-2134A
PU-2136A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R 831 117-2741-10 1/10W 270kΩ
R 832 111-6811-81 1/2WS 680Ω
R 833 117-1031-10 1/10W 10kΩ
R 834 114-2291-11 1W 2.2Ω
R 835 117-5641-10 1/10W 560kΩ
R 836 117-4741-10 1/10W 470kΩ
R 838 117-1031-10 1/10W 10kΩ
R 990 117-3311-10 1/10W 330Ω
R 991 111-1021-91 1/4WS 1kΩ
R 992 117-4711-10 1/10W 470Ω
R 2001 117-1021-10 1/10W 1kΩ
R 2002 117-1031-10 1/10W 10kΩ
R 2003 111-2221-91 1/4WS 2.2kΩ
R 2004 114-3301-11 1W 33Ω
R 2005 117-1031-10 1/10W 10kΩ
R 2006 117-1041-10 1/10W 100kΩ
R 2007 117-1031-10 1/10W 10kΩ
R 2008 117-1031-10 1/10W 10kΩ
R 2009 117-1031-10 1/10W 10kΩ
R 2010 117-1031-10 1/10W 10kΩ
R 2011 117-1031-10 1/10W 10kΩ
R 2012 117-1031-10 1/10W 10kΩ
R 2013 117-1031-10 1/10W 10kΩ
R 2014 117-1031-10 1/10W 10kΩ
R 2015 117-1031-10 1/10W 10kΩ
R 2016 111-2221-91 1/4WS 2.2kΩ
R 2017 111-1001-91 1/4WS 10Ω
R 2018 117-1031-10 1/10W 10kΩ
R 2019 117-1231-10 1/10W 12kΩ
R 2020 111-2201-91 1/4WS 22Ω
RY 101 014-0497-00
SUP101 060-0122-20 DSP-141N-S00B
T 801 009-9006-60 0.23mH
TH 801 002-0224-01
VR 701 016-3100-00
VR 702 016-3100-00
VR 703 016-3100-00
X 701 061-1064-00 4.5MHz
X 2001 061-3022-50 8.38MHz
X 2002 061-3031-00 4.00MHz
ISO PWB section(B2)
F 101 060-0057-56 10A VR 101 016-0500-00
PL 101 017-0449-00 14V65mA
PL 102 017-0449-00 14V65mA PL 103 017-0449-00 14V65mA PL 104 017-0449-00 14V65mA
Switch PWB section(B3)
PL 105 017-0449-00 14V65mA
PL 106 017-0449-00 14V65mA
Mech PWB section(CD mechanism)(B4)
C 10 178-1032-78 0.01μF
C 11 182-1063-32 16V10μF
C 12 178-1042-78 0.1μF
C 13 182-1073-12 6.3V100μF
C 14 178-1032-78 0.01μF
C 15 182-2263-12 6.3V22μF
C 16 178-1032-78 0.01μF
C 17 178-1042-78 0.1μF
C 18 178-1042-78 0.1μF
C 19 176-1501-00 15pF CH
C 20 178-1042-78 0.1μF
C 21 182-2263-12 6.3V22μF
C 22 176-2096-00 2pF CJ
C 23 178-1042-78 0.1μF
C 24 178-1022-78 1000pF
C 25 176-1007-00 10pF CH
C 26 176-1007-00 10pF CH
C 27 182-1073-12 6.3V100μF
C 28 178-1042-78 0.1μF
C 29 182-1073-12 6.3V100μF
C 30 178-1042-78 0.1μF
C 31 176-1007-00 10pF CH
C 32 178-2212-78 220pF
C 33 178-1042-78 0.1μF
C 34 178-2212-78 220pF
C 35 178-1032-78 0.01μF
C 36 178-4732-78 0.047μF
C 37 178-1522-78 1500pF
C 38 178-1032-78 0.01μF
C 39 042-0230-00 35V0.47μF
C 40 178-1032-78 0.01μF
C 41 178-1042-78 0.1μF
C 42 178-2222-78 2200pF
C 100 182-4763-12 6.3V47μF
C 101 182-4763-12 6.3V47μF
C 102 178-1032-78 0.01μF
C 103 182-1073-32 16V100μF
D 1 001-0563-00 GL380
D 2 001-0563-00 GL380
D 3 001-0563-00 GL380
IC 1 051-1014-10 TA7291S
IC 2 051-6015-05 BA6392FP
IC 3 051-6314-05 TC9404FN
IC 4 051-1971-00 CXA1610M
IC 5 051-6313-00 CXD2545Q
L 1 010-2155-03 10μH
Q 1 101-1237-00 2SB1237
R 10 111-2711-91 1/4WS 270Ω
R 11 117-8231-10 1/10W 82kΩ
R 12 117-1031-10 1/10W 10kΩ
R 14 117-5631-10 1/10W 56kΩ
R 15 117-1021-10 1/10W 1kΩ
R 16 117-2211-10 1/10W 220Ω
R 17 117-2211-10 1/10W 220Ω
R 18 117-1031-10 1/10W 10kΩ
R 19 117-2231-10 1/10W 22kΩ
R 20 117-1831-10 1/10W 18kΩ
R 21 117-1031-10 1/10W 10kΩ
R 22 117-4711-10 1/10W 470Ω
R 23 117-1011-10 1/10W 100Ω
R 24 117-1021-10 1/10W 1kΩ
R 25 117-1001-10 1/10W 10Ω
R 26 117-3331-10 1/10W 33kΩ
R 27 117-3631-10 1/10W 36kΩ
R 28 117-1241-10 1/10W 120kΩ
R 29 117-3631-10 1/10W 36kΩ
R 30 117-1041-10 1/10W 100kΩ
R 31 117-1031-10 1/10W 10kΩ
R 32 117-6821-10 1/10W 6.8kΩ
R 33 117-3321-10 1/10W 3.3kΩ
R 34 117-1051-10 1/10W 1MΩ
R 35 117-1041-10 1/10W 100kΩ
R 36 117-1031-10 1/10W 10kΩ
X 1 060-1014-00 16.9344MHz
Limit switch PWB section(CD mechanism)(B5)
M1 SMA-151-100 SPINDLE M 2 SMA-146-100 SLED S 1 013-7100-00 limit
Chucking switch PWB section(CD mechanism)(B6)
M3 SMA-147-100 LOADING S 2 013-3879-01 CHUCKING
Sensor PWB section(CD mechanism)(B7)
Q 101 060-0252-01 PT4850F Q 102 060-0252-01 PT4850F Q 103 060-0252-01 PT4850F
