clarsen K044 User manual

Lightweight Carpet Cleaner
K044 v01: 21/07/21
Please read and retain these instructions for future reference
ASSEMBLY INSTRUCTIONS / INSTRUCTIONS FOR USE:
Unpack the components carefully. Please check all parts have been removed from the packaging.
Contents:
1x Carpet Washer
1x Handle
1x Instruction Manual
WARNINGS AND SAFETY INSTRUCTIONS:
•READ ALL INSTRUCTIONS BEFORE USE
Dimensions
108 x25 x42cm
-600W
-2.5L CLEAN WATER TANK
-1.5L DIRTY WATER TANK
-6M POWER CORD
•PRODUCT WEIGHT: 5.7kg
•DETATCHABLE TANK
•LARGE TANK CAPACITY, SO YOU WON'T HAVE
TO KEEP STOPPING TO REFILL OR EMPTY THE
CLEANER.
•THE CLEANER IS EASY TO MOVE AROUND YOUR
HOME THANKS TO ITS LIGHTWEIGHT DESIGN
AND LONG POWER CORD.
Technical data
Rated Voltage
220-240V a.c. 50/60Hz
Power Consumption
600 Watts

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
•FOR DOMESTIC INDOOR USE ONLY.
•BEFORE USE, CHECK THOROUGHLY FOR ANY DEFECTS AND DO NOT USE IF DEFECTS ARE FOUND. TAKE
CARE NOT TO DROP THE APPLIANCE AS HEAVY IMPACTS MAY CAUSE INTERNAL DAMAGE.
•BEFORE CONNECTING THE APPLIANCE, CHECK IF THE VOLTAGE INDICATED ON THE BOTTOM OF THE
APPLIANCE IS IN ACCORDANCE WITH THE MAINS VOLTAGE IN YOUR HOME.
•DO NOT PLACE ON OR NEAR HEAT SOURCES.
•USE ON A LEVEL, STABLE SURFACE.
•THERE ARE NO USER SERVICEABLE PARTS. IF A FAULT DEVELOPS, STOP USING THIS IMMEDIATLEY AND
DESTROY SAFELY. IF FAULT IS WITHIN THE GAURANTEE CONDITIONS THEN PLEASE RETURN TO THE
RETAILER FOR REPLACEMENT OR REFUND.
•ROUTE THE POWER CABLE SO THAT IT WILL NOT GET WALKED ON OR PULLED TO AVOID TRIP HAZARDS.
•DO NOT ALLOW CHILDREN TO PLAY WITH THIS UNIT. IT IS NOT A TOY.
•THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8 YEARS AND ABOVE, AND PERSONS WITH
REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE
ONLY IF THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE
IN A SAFE WAY AND UNDERSTAND THE HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY WITH THE
APPLIANCE. CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY CHILDREN WITHOUT
SUPERVISION.
•CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS CONTINUOUSLY SUPERVISED.
•THE UNIT IS NOT INTENDED TO BE OPERATED BY MEANS OF AN EXTERNAL TIMER, DIMMER SWITCH OR
SEPARATE REMOTE-CONTROL SYSTEM.
•DO NOT COVER THE ITEM IN ANY WAY WHEN IN USE AS THIS MAY CAUSE OVERHEATING.
•DO NOT USE THIS APPLIANCE FOR ANY OTHER USE THAN THE INTENDED USE IT IS DESIGNED FOR.
•TO PROTECT AGAINST ELECTRIC SHOCK, DO NOT IMMERSE POWER CABLE, PLUG OR APPLIANCE, IN
WATER OR ANY OTHER LIQUID. DO NOT ALLOW THE UNIT TO GET WET.
•UNPLUG FROM OUTLET WHEN NOT IN USE AND BEFORE CLEANING.
•DO NOT OPERATE ANY APPLIANCE WITH A DAMAGED POWER CABLE OR PLUG OR AFTER THE APPLIANCE
MALFUNCTIONS, OR HAS BEEN DAMAGED IN ANY MANNER. WE RECOMMEND THAT THE POWER CABLE
IS NOT KINKED OR STORED IN A TWISTED MANNER, AND THAT YOU REGULARLY CHECK ITS CONDITION.

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
Parts
1. Handle
10. Dirty Water Tank
2. Carry Handle
11. Brush Bar
3. On / Off Switch
12. Clean Water Release Trigger
4. Clean Water Tank Cap
13. Power cord tidy
5. Clean Water Tank release handle
14. Power cord Holder Upper
6. Clean Water Tank
15. Power Cord
7. Dirty Water Tank Locking Latch
16. Power Cord Holder Lower
8. Dirty Water Tank Handle
17. Handle Release pedal
9. Exhaust Filter

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
Assembly
Note: Do not plug the power cord into an electrical outlet until the machine is fully
assembled.
1. Carefully unpack all components and set aside the packaging.
2. Lift the carpet washer to the upright position.
3. Align the handle with the groove and insert onto body. If necessary, use thumb
and finger pressure to slide handle into position.
4. Once the handle is in place, secure the handle to the body with the two screws
supplied (Fig. 1)
Caution: Do not over tighten. Over tightening could strip the screw holes. Do not
operate the vacuum without the handle screws in place.
CARPET PREPARATION
IMPORTANT: Do not use the carpet washer as a dry vacuum.
1. Vacuum your carpet thoroughly. Ensure it is cleaned before you shampoo.
2. Remove as much furniture from the room as possible. If unable to remove the furniture, place plastic or
foil under and around
HELPFUL HINTS FOR CLEANING CARPET:
1. Use only Low Foaming Cleaning solution with this carpet washer.
2. Do not over saturate the carpet with cleaning solution while using the carpet washer.
3. For heavily soiled areas, additional applications may be necessary.
4. Allow plenty of time to dry the carpet thoroughly.
5. Wipe the cleaning solution from woodwork and furniture to prevent any damage.
6. Try not to walk on the carpet until after the carpet is thoroughly dry, vacuum the carpet using a vacuum
cleaner with a revolving brush bar.
7. Before cleaning, determine where to start and end, making sure not to walk over previously cleaned
areas.
CHECK FOR COLOUR FASTNESS:
Before cleaning the carpet, test for colour fastness. Dampen a white cloth with solution and test a small area
in a closet. Gently rub the cloth over the area. Check each colour for colour bleeding. If the cloth remains
clean, it should be safe to clean the carpet.
AFTER CLEANING:
Allow the carpet to dry completely. Try not to walk on the carpet until it is dry. If it is necessary to walk on
the carpet, place white towels on the areas to be walked on. If the carpet is not dry and the furniture must
be placed back in the room, use plastic or foil under the furniture to prevent staining the carpet. Thoroughly
clean the dirty water tank with warm (max 40ºC) tap water.
Figure 1

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
OPERATION
Operating Instructions
1. Hold the clean water tank and lift the Water Tank
Release Handle’ upwards. Tilt the Water Tank away from
the carpet washer and remove.
2. Unscrew the filler cap and add cleaning solution and
water. Use only 1 capful of cleaning solution per full tank.
IMPORTANT: Use only suitable Carpet Cleaner solution.
Using incorrect cleaning solutions may cause excess
foaming. Excessive foam will prevent the machine from
working effectively
3. Fill remainder of clean water tank with warm (max 40°C)
tap water. Replace cap.
4. Place Clean Water Tank back to original position and
press down release handle for security.
Caution: Do not use the Carpet Washer without the Clean
Water Tank in position

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
Carpet Cleaner Use
1. Plug cord into electrical socket. Turn on the machine by
using the on/off switch located on the side of the
machine.
IMPORTANT: Never leave unit unattended with power on.
Turn off when emptying and filling tanks. Do not over-
saturate the carpet.
Step on the handle release pedal to lower the machine
into the cleaning position While pressing the trigger,
pull carpet washer in a backward motion. Release the
trigger and push the unit forward in the same path to
agitate and remove dirty water and solution from the
carpet. (For heavily soiled areas, repeat if necessary).
IMPORTANT:
•For best cleaning results use a steady, moderate, forward and backward motion. Always work from back
to front across the room to avoid stepping on wet carpet and lowering the pile.
•Do not make the carpet too wet! Use no more than two sets of forward and backward strokes while
releasing solution. Always follow with dry strokes; the more the better
•Allow carpet to dry. Avoid walking on the carpet until it is dry. Increased air circulation (open doors,
turn on fans, etc.) or use of a dehumidifier will help carpet dry thoroughly and prevent the growth of
mould or mildew.
•Vacuum the carpet thoroughly before washing the carpet and after it has dried.
Emptying the Recovery Tank
An automatic shut-off device prevents the extractor from picking up more dirty water than it can hold in
the recovery tank. You will know the tank needs to be emptied:
•When the motor sound rises in pitch.
•You do not see dirty solution coming up through the recovery tank lid.
•The float inside the recovery tank has risen to the top of the tank and is visible through the transparent
tank.
1.Unplug the appliance from the electrical outlet.
2.Unlock the Recovery tank by lifting the dirty water tank
latch and remove from the base unit using the handle

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
1. Twist the outlet cap to the left and remove, empty, rinse
and replace.
Maintenance of Filters
1. Always disconnect from the power supply when not in
use. Always empty and rinse out the solution tank and
recovery tanks after use. Remember to refit the filler
cap to the solution tank. Do not allow water to sit in
any of the tanks when not in use.
2. Remove the dirty water tank, rinse with warm water
and allow it to dry before storage. Also, remove the
exhaust filter (as shown) rinse with warm water and
allow it to dry thoroughly before storing.
IMPORTANT: Do not use chemicals when cleaning this
filter and clean after each use.
3. Remove the recovery tank, to access the motor filter. Remove
the motor filter and rinse with warm water. Dry thoroughly
before replacing.
MAINTENANCE
Regular maintenance of your appliance will keep it safe and in proper operational order.

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
Before Cleaning
When not in use or before cleaning, always disconnect the appliance from the mains supply.
Never immerse the motor unit in water or any other fluid, not rinse it under the tap. Use only a moist cloth
to clean the motor unit.
Cleaning
•Regularly clean the outside of the appliance with a soft damp cloth and dry it with a dry towel.
•Do not use harsh solvents to clean the plastic.
•Do not store the cleaner with solution in the clean water tankor dirty water in the dirty water tank.Mineral
deposits and mildew can form which will affect the performance of the carpet washer on next use.
•After cleaning, let them dry by air, and then store your appliance and all its accessories and instruction
manual in a safe and dry place
CARPET CLEANING SOLUTION
Use any commonly availably low foaming carpet cleaner, shampoo or detergent suitable for use in carpet
extraction cleaning machines and follow the manufacturer’s instructions on the bottle.
CAUTION: Do not use any solvents, cleaners with strong acidic or strong alkali formulas or any type of
cleaning solution not specifically for use in carpet extraction cleaning machines.
CAUTION: Keep Carpet Cleaning Solution out of reach of children.
In case of contact with eyes, rinse immediately with plenty of water and seek medical advice. As with all
detergents, people with sensitive or damaged skin should avoid prolonged contact with the product.
TROUBLESHOOTING
Problem
Solution
Cleaner won’t run
1. Check electrical plug.
2. Check the fuse or breaker.

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
Lower suction during floor cleaning
1. Empty the recovery tank; it may be full and the automatic
shut-off engaged.
2. Make sure recovery tank is properly installed.
Cleaning solution won’t dispense
1. Make sure solution tank is fully inserted and securely in
place.
2. Refill the solution tank if it is empty
PLUG WIRING (UK & IRELAND)
This appliance is fitted with a BS 1363 13-amp plug. If you have to replace the fuse, only those that are ASTA
or BSI approved to BS1362 and with a rated current of 13-amps should be used. If there is a fuse cover fitted,
this cover must be re-fitted after changing the fuse. If the fuse cover is lost or damaged the plug must not be
used. Spare fuse holders and fuses are available from electrical outlets. If the socket outlets in your home or
office are not suitable for this product’s plug, the plug must be removed and disposed of safely. Attempts to
insert the plug into the wrong socket is likely to cause electric hazard. A replacement plug should be wired
according to the following instructions:
The cable
A mains electricity cable contains two or three inner wires. Each has a core of copper and an outer layer of
flexible plastic. This product is double insulated; the wires in the cord set are colour coded in the following
way:
BLUE NEUTRAL
BROWN LIVE
GREEN & YELLOW EARTH
The diagram shows the key features of a correctly wired
three-pin mains plug.
DISPOSAL
•Coopers of Stortford use recyclable or recycled packaging where possible.
•Please dispose of all packaging, paper, cartons, packaging in accordance with your local
recycling regulations.
•Plastics, polybags –Contains the following recyclable plastic.

Lightweight Carpet Cleaner K044 Instructions for Use
Please read and retain these instructions for future reference v001: 21/07/21
Code & Symbol
Type of Plastic
ABS
Commonly used for
CD’s, crisp packets, various flexible packaging, baby bottles, sunglass lenses
Notes
Not often or widely recycled
•At the end of the product’s lifespan please check with your local council authorised household waste
recycling centre for disposal.
