Clarson PUBLIC III User manual

PUBLIC III
Headset, wired
Operating and Installation
Instructions
Notes:
Clarson Apparatebau GmbH
Zeppelinstr. 4 78083 Dauchingen
Postfach 11 63 78080 Dauchingen
Tel.: [phone]
Fax: [phone]
Email: [email protected]
Internet: http://www.clarson.de
Technical modifications reserved 12/2009

Activation / Deactivation of HEADSET Interface
Activate headset mode:
 Switch the system OFF (button )
 Push and hold until LED
above the button flashes once
Switch the system ON (button )
Headset mode is now activated
Microphone and loudspeaker
service side are deactivated
LED above button flashes
(0,5 sec on - 0,5 sec off)
indicating headset mode
Deactivate headset mode/
Back to standard mode:
 Switch the system OFF (button )
 Push and hold until LED
above the button flashes once
 Switch the system ON (button )
 System again in standard mode
or
Briefly disconnect the unit
from the power supply
Activate headset mode:
 Switch the system OFF (button )
Push and hold until LED
above the button flashes twice
Switch the system ON (button )
Headset mode is now activated
Microphone and loudspeaker on
public side are deactivated
LED above button flashes
(1 sec an - 0,2 sec aus)
indicating headset mode
Deactivate headset mode /
Back to standard mode:
Switch the system OFF (button )
Push and hold until LED
above the button flashes twice
 Switch the system ON (button )
 System again in standard mode
or
Briefly disconnect the unit
from the power supply
Service Side Public Side
Installation of Components
Link the microphone loudspeaker unit 40.054.301 (jack 2)
with the central unit 40.054.311 (HEADSET jack) via patch cable.
Connect the headset to jack of the microphone loudspeaker unit.
Microphone loudspeaker
unit Ref. 40.054.301
Headset, monaural
Ref. 40.030.011
HEADSET
jack
RJ 45
8-pin
RJ 45
8-pin


Headset, binaural
Ref. 40.030.007
Central unit
Ref. 40.054.311
RJ 45
8-pin
Patch cable, 3 m
with RJ45 connector (8/8-pin)
Ref. 40.054.327
RJ 10
4-pin
RJ 10
4-pin
