Primax PHS-5 User manual

Confidential
UserGuide
for
Bluetooth HeadsetPHS-5Variants
By
Primax Electronics Ltd.

ConfidentialUserGuide
PrimaxElectronicsLtd. 2
ChangeHistory
Version Date Author Status Comment
0.1 08.04.2006 River.Yang Draft InitialDraft
0.2 11.05.2006 River.Yang Draft Modified theUI
0.3 28.Jun.2006 River.Yang Draft The UIupdateto
v1.0
0.4 27.Jul.2006 River.Yang Draft Add FCC/Industry
Canada notice

ConfidentialUserGuide
PrimaxElectronicsLtd. 3
TableofContents
1. INTRODUCTION ............................................................................................4
2. GETTING STARTED .....................................................................................6
3. CHARGING THEBATTERY .......................................................................6
4. PAIRINGTHEBLUETOOTHHEADSETWITHACOMPATIBLE
PHONE..............................................................................................................6
5. DISCONNECTINGTHEBLUETOOTHHEADSETFROMTHE
PHONE..............................................................................................................7
6. RECONNECTINGTHEPAIREDBLUETOOTHHEADSETTOTHE
COMPATIBLEPHONE.................................................................................7
7. POWERING UP ..............................................................................................8
8. MAKING CALLS ............................................................................................8
9. ANSWERINGANDENDING ACALL ......................................................8
10. REJECTINGACALL ................................................................................8
11. REDIALINGTHELASTDIALEDNUMBER ........................................8
12. MUTINGANONGOING CALL................................................................8
13. VOICEDIALING..........................................................................................9
14. ADJUSTINGTHEEARPHONEVOLUME ...........................................9
15. SWITCHINGTHECALLBETWEENPHONEAND HEADSET......9
16. ERASE ALLPAIREDDEVICEINFORMATION .................................9
17. FCC/INDUSTRYCANADANOTICE......................................................9

ConfidentialUserGuide
PrimaxElectronicsLtd. 4
1.Introduction
ThanksforpurchasingPHS-5variants(Including PHS-5,HS-68W,HS-84W,HS-
88W).YourPHS-5variantsisastylishheadsetthatenablescomfortablehandsfree
communication withcompatiblephonethat supportsBluetoothtechnology.
The PHS-5variantscontainsthe following parts, asshowninFigure1.
Figure1
1.Power/Send/End key(1)
Switchesthe headseton andoff
Answerincoming call
End activecall
Reject incoming call
1-Power/Send/Endkey
2-Indicationlight
3-Volumeupkey
4-Volumedownkey
5-Chargerconnector
6-Earpiece

ConfidentialUserGuide
PrimaxElectronicsLtd. 5
2.IndicatorLight (2):
Poweron –Blue light constanton for1secondsand beep once.
Pairing state –Blue/Redlight flashingalternatively, the flashing
continuesforapproximately3minutesoruntiltheheadsetis
connectedtoacompatiblephone. If the headset can’t be
connected tothe phone duringthistime, the headset enter
connectablestatus.
Connectable –Blue light flashingonceevery5seconds.
Connection active –Bluelight flashing twiceevery8seconds
Incoming call –Blue light flashing3timesevery1second.
Activecall –Blue/Red light flashingalternativelyevery5seconds.
Poweroff –Red lightconstant on for1secondsand beep once.
Lowbattery –TheLed frequenceistentimesof the Led current
status,and beep on every20 seconds
3.Volumeup (3): Increasethe earpiecevolume
4.Volumedown(4): Decreasethe earpiecevolume
5.Chargerconnector(5):Forheadsetbatterycharging
6.Earpiece(6): Relaythe caller’svoice.

ConfidentialUserGuide
PrimaxElectronicsLtd. 6
2.Gettingstarted
Takeoutallcomponentsfromthe package.
1. PHS-5variantsHeadset
2. Charger
3.Userguide
4.Quick reference(optional)
5.Carcharger(Optional)
3.Chargingthebattery
BeforeusingPHS-5variants,youmustcharge the productforapproximately2hours.
Whenthebatteryisfullycharged,itprovidesup to9hoursoftalktimeand upto240
hoursof standbytime.
1. Connect the chargercabletoPHS-5variants
2.Plug theACadapterintoawall outlet. When PHS-5variantsischarging,red
indicatorlight willdisplay.
3.When thebatteryisfullycharged,the Redlightisoff. Unplug the chargercable
fromthe wall outletand PHS-5variants.
4.PairingtheBluetoothheadsetwithacompatiblephone
Pairingistheprocess oflinkingtheheadsetwithyourBluetoothenabledmobile
phone.Afterthisprocess iscompleted,you can usethe PHS-5variants onlywiththis
paired mobilephone.Ifyou wanttousePHS-5variants withanothermobilephone,
you must repeat the pairing process again. ThePHS-5variants can be paired withup
to8compatiblephonesbut connected toonlyone phone at atime.
1.Makesurethatthe compatiblephone isturned on andwithin10 metersofthe
headset.
2.TurnonPHS-5variantsandmakesurethe headsetischarged.Press and hold
volumeup keyand volumedownkeytogetherforabout2seconds. The blueand red
LEDswillflashalternatively.Releasebothbuttonsand the headsetisnowinpairing
mode.
3.Activatethe Bluetoothconnection fromthe phone.You mayneed toconsultwith
userguideof yourphone regarding howtodo that.
4.Setthephone tostartsearchingforBluetoothdevicesasinstructedinuserguide
of yourphone.
5. Selectthe PHS-5variantsfromthe list.

ConfidentialUserGuide
PrimaxElectronicsLtd. 7
6. Enterthepincode0000toconnect(or “pair”)PHS-5variantstothephone.
PHS-5variantsbeepsonceand anactiveBluetoothconnection isdisplayed bya
blinkingblue indicatorlight.
If PHS-5variantsisturned on within10 metersofseveralpairedphones,theheadset
willtrytoconnecttothe lastconnected phone within20 seconds.Ifthe headset
cannotconnecttothe lastconnected phone(forexample,phone isturned off orit
rejectsthe connection),itremainsconnectableuntiluseraction orHeadset’sbattery
runsout.whichisdisplayed bytheblinking blue indicatorlight.
7. Start usingthe headset.
5.DisconnectingtheBluetoothheadsetfromthephone
Todisconnect PHS-5variantsfromthe phone, do one of the following:
1Turnoff PHS-5variants.
2. Disconnect PHS-5variantsinthe phone menu.
3. Movethe headset morethan 10metersawayfromthe phone.
Notethat youdo not needtodeletethepairingwiththe headset todisconnectit.
Whenyou reconnect apaired headset, you willnotbe askedforitspincodeagain.
6.ReconnectingthepairedBluetoothheadsettothecompatible
phone
ToreconnectPHS-5variants tothe lastconnected phone,you can useanyone of
the following actions:
1.Restart PHS-5variants bypowering off and poweron again.
2.Makethe connection inthe phone menu asinstructed intheuserguideofyour
phone.
3.Press the Power/send/endkeyand Volumeup keytogetherforabout 2second
4.Press the Power/send/end keyand Volumedownkeytogetherforabout2
second.
5.Takethe headset10metersawaythe connectedphone,headsetwill
disconnectfromthe phone,comeback within10minutesand the headsetwill
autoreconnect withthe phone.

ConfidentialUserGuide
PrimaxElectronicsLtd. 8
7.PoweringUp
Toturnon PHS-5variants
Press and holdthe powerkeyfor2seconds.PHS-5variantsbeepsand the blue
indicatorlight startsblinking.(Firsttimeuserequirespressing it for5seconds.)
Toturnoff PHS-5variants
Press and holdthepowerkeyfor2second,PHS-5variantsbeepsandthe red
indicatorlightisdisplayedbriefly.
8.Makingcalls
WhenPHS-5variantsisconnected tothe phone, makeacallbyusing the phonein
the normalway. Notethatthe callfunctionsdepend onthe phone that youuse.
9.Answering andendingacall
Whenyou receiveacall,you heararingingtone through theheadset.
Short press the power/send/endkeytoanswerthe callortoend thecurrentlyactive
call.You canalsoanswerand endthe callusing the phone.
Note: SomephonesofferAutoAnswerfunctionand maybe used withHeadset or
Handsfree,but thisisaphone dependent feature. Pleasecheck out the manualof
yourphone about howtousethat function.
10.Rejectingacall
Whenyou receiveanincoming callthat you donot want toanswer, doublepress the
power/send/end key
11.Redialingthelastdialednumber
Press the volumeup keyand holdit for2secondswhen no callisinprogress.
12.Mutinganongoingcall
You can muteorunmutethe ongoingcallbypressing thepower/send/end and
volumeup keys togetherfor2secondswhen acallisinprogress. Atone plays
every5secondstoindicatethe callinmutestate.

ConfidentialUserGuide
PrimaxElectronicsLtd. 9
13.Voicedialing
Whenno callisinprogress,press volumedownkeyand holditfor2secondsuntil
thereisatonethat indicatesthatyou can startsayingthe voicetag.Thephoneplays
the voicetagand dialsthe relatedphonenumber.
Note: Thisisaphonedependentfeature. Pleasecheck outthe manualof yourphone
about howtousethat function.
14.Adjustingtheearphonevolume
Press the volumeup keytoincreaseorthevolumedownkeytodecreasethevolume.
15.Switchingthecallbetweenphoneandheadset
Press the power/send/end and volumedownkeys togetherfor2secondsorusethe
corresponding function inyourphone.
16.Erase all paireddevice information
WhenPHS-5variantsinConnectablestate, press the Volumeup keyand holdfor5
seconds, afterheardatoneplayed,releasethekey
17.FCC notice
ThisdevicecomplieswithPart 15 of the FCC Rules.Operation issubject tothe
followingtwoconditions: 1.Thisdevicemaynot causeharmfulinterference; and2.
Thisdevicemust accept anyinterferencereceived,including interferencethat may
causeundesired operation.Thisequipment hasbeen tested and found tocomply
withthe limitsforaClass Bdigitaldevice,pursuant toPart 15 ofthe FCC Rules.
Theselimitsaredesignedtoprovide reasonableprotection against harmful
interferenceinaresidentialinstallation. Thisequipment generates,usesandcan
radiateradiofrequency energyand,if notinstalledand used inaccordancewiththe
instructions, maycauseharmfulinterferencetoradiocommunications. However,
thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation. If this
equipment doescauseharmfulinterferencetoradioortelevision reception, whichcan
be determined byturning theequipment off andon, theuserisencouragedtotryto
correct the interferencebyone ormoreof the followingmeasures: Reorientor
relocatethe receiving antenna.Increasetheseparationbetween the equipment and
receiver. Connect the equipment intoanoutleton acircuitdifferent fromthat towhich
the receiverisconnected.Consult thedealeroran experienced radio/TVtechnician
forhelp. NOTE: FCC Radiation ExposureStatement: Thisequipment complieswith
FCC radiationexposurelimitsset forthforan uncontrolledenvironment. This
transmittermust not be co-located oroperatinginconjunctionwithanyotherantenna
ortransmitter. NOTE: Modificationsnot expresslyapprovedbyPRIMAX couldvoid
the user'sauthoritytooperatethe equipment.
