CLEANCUT STEP
INSTALLATION GUIDE
COPYRIGHT © 2017 SAFEWAY SAFETY STEP, LLC
(DBA “CleanCut”) All Rights
Reserved
Reproduction or Distribution of this Installation Manual is Strictly Prohibited
VIDEO INSTRUCTIONS CAN BE VIEWED AT
cleancutbath.com

Page 2of 9
IMPORTANT – PLEASE WATCH VIDEO PRIOR TO READING
DIRECTIONS AND BEFORE BEGINNING INSTALLATION
IT IS VERY IMPORTANT THAT ALL INSTRUCTIONS IN THE
INSTALLATION MANUAL ARE FOLLOWED THOROUGHLY.
VIDEO INSTRUCTIONS CAN BE VIEWED AT
cleancutbath.com
INSTALLATION OF THE CLEANCUT STEP REQUIRES USE OF
POTENTIALLY DANGEROUS TOOLS.
SAFEWAY SAFETY STEP, LLC (DBA “CLEANCUT”) ACCEPTS NO
RESPONSIBILITY FOR ANY TYPE OF INJURY, LOSS OR DAMAGE OCCURRED
DURING INSTALLATION OR SUBSEQUENT USE OF THE CLEANCUT STEP.
FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS INSTALLATION MANUAL
SHALL VOID ANY WARRANTY GIVEN WITH RESPECT TO THE CLEANCUT STEP.
IMPORTANT REMINDER - PLEASE RETURN THE PACKET THAT INCLUDES
WARRANTY REGISTRATION INFORMATION.
ADDITIONAL QUESTIONS?
CLEANCUT REPRESENTATIVES ARE AVAILABLE TO ANSWER
QUESTIONS MONDAY-FRIDAY FROM 9AM-4PM EST.
FOR QUESTIONS, PLEASE CALL (877) TUB-STEP (882-7837).
MSDS SHEET FOR ENCLOSED ADHESIVE
AVAILABLE UPON REQUEST.

Page 3of 9
Thank you for your interest in the CleanCut Step. This installation manual includes an
overview of the CleanCut Step installation kit as well as instructions pertaining to the step-by-
step instructions for CleanCut Step installation.
CleanCut Step Installation Kit
The CleanCut Step installation kit includes the following items:
• One CleanCut Step (large/wide, medium or small/narrow)
• One CleanCut Step Support Box Structure (large & small box)
• Template to be used for cutting the tub
• Two tubes of required adhesive and angled extension
Tools & Materials
In addition to the items included in the installation kit, the following tools and materials are
recommended to have on hand for installation.
Additional Tools & Materials
Butane Torch
Card Paper
Caulking Gun (High Torque Ratio)
Chisels
Deburring Tool (i.e., file, knife)
Denatured Alcohol
Drain Screens
Drill & Drill Bits
Drop Cloths
Drywall plane or Rasp
Dust Masks
Dust Pan & Brush
Ear Protection
Extension Cord
Fire Extinguisher
Gloves
Hammer
Mirror (small)
Paper Towels
Jigsaw with 2” Blade
Masking Tape
Pliers
Pressure Treated 2 X4’s
Protective Eye Wear
Reciprocating Saw with Metal Blades
Scissors
Screw Driver
Screws- Assorted Sizes
Side Grinder with 4.5” Diamond Blade*
Red Sharpie Marker
Utility Knife
Vacuum with Attachment*
Wood Shims
* These items are available for purchase
from CleanCut

Page 4of 9
Preparing the Tub
1. Before beginning any work, it is important to inspect the tub for existing chips, markings or other types of
damage. It is always wise to make the owner or manager aware of any existing damage prior to beginning the
installation process.
2. Prior to beginning the installation, remove any personal items from the bathroom area to create extra
space during the installation and to prevent possible damage or exposure to dust and debris that may result
during the installation process.
3. One method to minimize the areas where dust can settle is to use a 2-ply drop cloth with the paper side up
to catch and trap dust and other shavings. In particular, a drop cloth should be taped into the bottom of the
tub. This will help to collect debris as well as to help prevent accidentally scratching the bottom surface of
the tub. The drain of the tub should be completely covered to prevent any shaving from going down into the
drain. Make sure that there is no water or dampness in or around the tub.
Due to the significant amount of dust created when cutting a cast-iron tub, it is recommended that all walls
and surfaces are covered, including the floor, before cutting the tub. See other considerations for cutting cast-
iron tubs in the following section.
4. Once the tub area is prepared for installation, it is necessary to mark the tub to determine the section that
will be cut to make room for the CleanCut Step. First, measure the length of the tub and determine the
midpoint of the tub and measure back, half the distance of the CleanCut Step itself. Using the template that
was included in the installation kit, place the template flush against the tub and begin tracing, Use a red
sharpie marker so as to make the lines that are traced easily visible. Flip the template over and now trace the
outside of the tub. Keep in mind that it may not be possible to place the CleanCut Step directly in the center
of the tub due to obstructions in the tub area such as the placement of sinks, vanities or commodes and the
use of shower seats may warrant moving the opening forward as well.
Cutting the Tub
The tub has been marked and is ready to cut. Safety is of highest importance and it is critical to remember to
use the proper safety equipment when cutting the tub.
Protective eye and ear wear and filter mask are required.
The CleanCut Step can be installed in fiberglass, steel or cast-iron tubs. On fiberglass or steel tubs, use a side
grinder with the diamond blade to make necessary entry points for the reciprocating saw. For cast-iron tubs,
the side grinder with the diamond blade is the only cutting tool used. If you are cutting a cast-iron tub,
please read the special considerations noted below before beginning to cut.
1. The first corner notches will be made with the side-grinder as illustrated in Figure 1 below.
2. Using the reciprocating saw on fiberglass and steel tubs, cut out the bottom markings on each
side of the tub.
FIGURE 1

Page 5of 9
3. Then cut all four downward cuts. Finish by cutting the two adjoining top pieces.
4. The opening for the CleanCut Step is now completed and you can remove the cut-out section. Use caution
when removing the cut-out section as there may be sharp or jagged edges both on the cut-out segment and
along the edges of where the cuts were made on the sides of the tub. It is helpful to spend a moment to file
down any potential hazard areas. This prevents potential snags with fitting the CleanCut Step and reduces
the risk of injury.
5. After the cut out section of the tub has been removed, take a few moments to clean the area in around the
tub. Using a dust pan and broom, sweep all dust and shavings. Complete the clean-up by thoroughly
vacuuming the entire area. Wash your hands before you start any work on the step itself. This will
eliminate transferring any dirt or dust to the step.
SPECIAL CONSIDERATIONS FOR CUTTING CAST-IRON TUBS
Due to the significant amount of dust created when cutting a cast-iron tub, it is recommended that you cover
all tub and exposed bathroom walls and surfaces (including the floor) with a 2-ply drop cloth to minimize the
amount of dust that can settle. Also, it is recommended that the installer wears protective coveralls and shoe
covers, in addition to protective wear outlined earlier, to minimize the clean-up after cutting out a cast-iron
tub.
Please note that there are several differences when cutting out a cast-iron tub compared to a fiberglass or
steel tub. The side-grinder with a 4.5” diamond blade is the only tool used when cutting a cast-iron tub. Cast-
iron tubs are a bit more challenging to cut. Vacuum the dust and shavings as you cut the tub with the use of
the Dust Buddie that contains a cover plate and vacuum attachment. The Dust Buddie connects directly to the
grinder to minimize dust output when cutting the cast-iron.
Follow the same pattern when cutting a cast-iron tub as described for the fiberglass and steel tubs. Begin by
cutting the bottom lines of your template, followed by the downward vertical cuts leaving the top adjoining
pieces for last.
Be cognizant of potential safety issues when cutting the tub such as sparks generated during cutting as
well as items that may be located within the tub wall such as water lines, electrical lines, insulation or
other items.
Measuring & Cutting the CleanCut Step
Once you have completed cutting out a section of the tub, you can begin to fit the CleanCut Step into the tub
opening. The first step is to determine which size CleanCut Step you will need to complete the installation.
The CleanCut Step is manufactured in three (3) sizes to fit tubs of varying widths. First, measure the top rail
width measurement as well as the width measurement approximately 9.75” down the tub (bottom
measurement). Based on these measurements, please consider the following:
• Small/Narrow CleanCut Step
• The maximum top rail measurement to order a small/narrow CleanCut Step is 4.0”.
• The maximum bottom measurement to order a small/narrow CleanCut Step is 4.75”.
• Medium CleanCut Step
• The maximum top rail measurement to order a medium CleanCut Step is 4.5”.
• The maximum bottom measurement to order a medium CleanCut Step is 5.75”.
• Large/Wide CleanCut Step
• The maximum top rail measurement to order a large/wide CleanCut Step is 6.0”.
• The maximum bottom measurement to order a large/wide CleanCut Step is 7.25”.

Page 6of 9
1. Take a stack of heavy card stock paper. This is the paper used to trace the cut- out section of the tub onto
the CleanCut Step. Place the card paper onto the left end and trace the outline of the pattern onto the
paper. Once completed, mark this tracing as “Left”, so as to remember which side was traced. It is also
helpful to place an arrow on the template to indicate which direction is the inside of the tub.
2. Repeat the process for the right side of the tub. Mark this tracing “Right”.
3. Cut out the proper templates with scissors making sure to keep to the inside of the tracings.
4. It is time to transfer the shape of our cut tub onto the CleanCut Step. Before continuing, it is
recommended that a drop cloth approximately 3’ x 4’ size be placed on the floor to prevent any dust or
other debris from transferring onto the CleanCut Step.
5. Place the right end of the CleanCut Step on the ground in order to trace the left side of the CleanCut
Step. Place the top of the paper template approximately ½” from the top of the CleanCut Step (Figure
3). Place the tracing on the step so the slope is similar to that of the tub. Trace the outline of the paper
onto the CleanCut Step with a continuous line. Continue the lines with a straight edge down and around
the corners. Repeat the same procedure for the right end of the CleanCut Step. Remember to place the
paper template approximately ½” down from the top of the CleanCut Step before beginning to trace.
Continue the lines with a straight edge down and around the corners.
6. Place step as shown and connect each side of the outside tub line using a yard stick (Figure 4).
FIGURE 4
PATTERN MARKS - - - - - - - INDICATE
THE AREA TO BE CUT OUT ON THE
LEFT END OF THE STEP
FIGURE 3 – SIDE VIEW OF
LEFT END OF STEP

Page 7of 9
7. Use a tape measure and transfer the shape of the inside of the tub edge to the step. The inside of the tub
may be irregular in shape, so measurements for the inside line must be made every 3” from one end of
the CleanCut Step to the other. Once completed, use your yard stick and marker to connect the markings
for the inside line.
**Alternate Method: You may use card stock paper such as done with the sides to create a bottom template
8. Cut the CleanCut Step to fit the cut-out tub opening using a jigsaw (Figure 5). Fasten Velcro-stripping on
both sides of the jigsaw to prevent making any unwanted marks on the CleanCut Step. It is important that
a 2” blade is used to cut out the CleanCut Step so as to prevent accidentally cutting through the top of the
CleanCut Step. Snap off any excess length on the stock jigsaw blade beyond 2”.
USE THE JIGSAW TO CUT THE LINES TRACED ON THE STEP.
FIGURE 5
It is required that proper eye protection be worn while using the jigsaw. Cut directly on the center of the
traced lines. Upon reaching the corners while cutting, tilt the jigsaw outward to prevent cutting past
your lines on the vertical ends of the CleanCut Step. Remember to tilt your blade on each corner,
cutting all areas that have been marked.
9. Place the CleanCut Step into position. Remember, the straight face of the CleanCut Step is on the
outside of the tub. Use a small pocket mirror and look for areas on the CleanCut Step that may be
catching and prohibiting the CleanCut Step from freefalling onto the tub. Use the jigsaw or drywall
plane to trim the CleanCut Step where necessary.
10. Continue this process and repeat as necessary until a desirable close fit is achieved. The CleanCut Step
should free fall onto the tub without catching or binding. Once final adjustments have been made, use a
drywall plane or deburring tool (a common potato peeler works well) to clean up the remaining edges.
11. Having completed use of the jigsaw, take a moment to tidy the tub and work area.
Support Structure Installation
Once the CleanCut Step has been cut and a satisfactory fit into the tub opening has been achieved, it will be
necessary to assemble the support box structure to provide support to the CleanCut Step. An example of the
CleanCut Step and the support structure is illustrated in Figure 6.
The CleanCut Support box structure consists of one small and one large Support Box. The large support box
will compress over the top of the small box to the necessary height to provide support to the CleanCut Step.

Page 8of 9
It is important to understand that each tub has variations and modifications maybe necessary in the field.
1. It may be necessary to adjust the Support Box structure according to the conditions present during your
installation. For example, for wooden sub- floors, begin by screwing or gluing a treated 2x4 directly to
the sub-floor to serve as the base for our support structure. For concrete floors, a treated 2x4 is adhered
directly to the concrete floor with adhesive. The 2x4 might need to be cut into several sections if there is
a support brace in the cut out channel.
2. Build the Support Box structure to appropriate height. If working with a concrete sub-floor,
thoroughly inspect and clean the floor in the tub cut out channel prior to securing the treated 2x4.
Remove any materials from the concrete that may cause an uneven surface. Apply adhesive
directly to the concrete floor. Insert the 2x4’s and thoroughly spread the adhesive on the concrete.
3. If wood sub-floor is present, screw the 2x4 directly to the sub-floor.
4. Prior to inserting the small Support Box, it is first necessary to secure a 22 ½” long 2x4 into the channel
of the small Support Box. Place a bead of adhesive around the inside of the Support Box and insert the
2x4. Place several screws into the small Support Box to properly adhere the 2x4 into proper position.
Small Support Box
FIGURE 7
5. Insert the small box in the channel. At this point, do not adhere the small support box to anything. Place
the large support box into the channel and over the top of the small box. Place the CleanCut Step into
position and compress the CleanCut Step downward to determine the proper height and placement for
the support box structure.
6. Once the support of the CleanCut Step has been achieved, remove the Step and mark both the left and
right ends of the small box where the large box is compressed while the boxes are in the tub opening
channel. Once properly marked, remove both support boxes and label the markings “Left” and “Right”
to avoid potential confusion. Uncompress the two support boxes from one another and begin the process
to permanently adhere the boxes in proper position.
7. Apply adhesive around the perimeter of the large box. Compress the small and large support box
structures back together to the appropriate markings made earlier on the small box. Place the support
structure back into the channel and insert the CleanCut Step to verify that proper placement has been
achieved. Secure both sides of the support structure by placing two screws in each side (Figure 8).
FIGURE 8
1 ¼” Dry Wall Screws
CLEAN CUT STEP
SUPPORT BOX STRUCTURE – LARGE SUPPORT
BOX COMPRESSED ON SMALL BOX
BASE 2X4 AFFIXED TO FLOOR, IF NECESSARY
Dry Wall Screws Holding 2x4s (each side)
FIGURE 6

Page 9of 9
8. Apply adhesive to the tops of the 2x4’s that are already in place in the channel, if they are needed for
height adjustment and insert the support box structure.
9. Place the CleanCut Step into position once more to inspect the fit and position. This is the final
opportunity to make any adjustments if necessary.
10. Apply adhesive to the top of the large support box. It is recommended that an extra bead of adhesive be
placed on the ends of the large support box as the Step curves up toward the ends. Place a substantial
bead of adhesive on the top left and right side of the tub where the CleanCut Step will be seated.
Adhesive on the top of the tub reinforces the CleanCut Step.
11. Prior to placing the CleanCut Step into the channel, it is necessary to gently pass a low flame several
times along the perimeter of the cut out where the tub is met. This will help promote bonding between
the step and the bath tub once adhesive is applied. Use caution when using the torch and do not hold
heat on area of the product as it may discolor or melt.
12. Place the CleanCut Step into the channel and gently press into place.
Completing the Installation
1. Before finalizing the installation, first make sure the CleanCut Step is in proper position and fully
compressed. Press firmly and evenly on the CleanCut Step to ensure proper placement. Thoroughly wipe
the tub area with isopropyl alcohol where the adhesive will bond, and allow enough time to flash off
before applying the adhesive. DO NOT apply the isopropyl alcohol directly on the adhesive as it will
prevent the adhesive from drying or curing. DO NOT use to clean or smooth your final bead as well.
2. It is necessary to caulk around the entire perimeter of the CleanCut Step. Begin by using the
recommended adhesive along the sides of the CleanCut Step. Begin on the left side and complete the
process, before moving to the right side and bottom. It is recommended that you wear gloves during this
step to avoid direct exposure to the adhesive.
3. Run your gloved finger along the beads and wipe the excess on a folded paper towel. Try to smooth the
beads one-time only.
4. Underneath the bottom edges of the CleanCut Step are a bit more difficult to see and the angled tip
should be used in completing this step. Use the small mirror to inspect the bead and to verify that all
surfaces have been properly sealed.
5. It is also recommended to remove the stopper from the tub upon completion of the installation to prevent
from accidentally filling the tub with water and, if desired, replace trip lever with a blank cap.
6. Spend a few minutes at the end of the job to once again clean up the tub and the bathroom area. Upon
completion, place a sign on the CleanCut Step warning not to use the tub for 2 days while the
adhesive cures.
IMPORTANT REMINDER – if completing the install on behalf of another, please leave the customer
packet that includes warranty registration information with the end-user at the conclusion of the
installation.
The CleanCut Step installation is now complete. CleanCut sincerely thanks you for your interest in the CleanCut Step and looks
forward to assisting you in any way possible. Visit our website at www.cleancutbath or call us toll-free at (877) TUB-STEP (822-
7837) with any questions or concerns you may have.
