dr. Mercola SSB - 1000 Operating and maintenance manual

1

Fig. # 5 Fig. # 6
2
Model SSB-1000, is to be installed for use with room temperature
water only. Procedures of Assembly
Installation:
A. Turn off the valve that supplies water to the toilet tank.
(Fig.#1)
B. Empty the toilet tank by flushing it.
C. Remove the hose connecting the water supply valve with the
toilet tank, (Fig.#2)
D. Install the Metal T Connector (Part #2) to the connection on
the water supply valve (Fig. #3)
E. Connect the long Flexible Hose to the middle of the Metal T
Connector (Fig #6). Reconnect the original line to the top of
the T Connector (Fig #4) OR use the flexible hose (Part #1)
included in the box if needed.
F. Once you have finished with the connections of the T
Connector, proceed to install the long flexible hose (Part #4)
to the connection in the bidet (Fig #5).

3
A. Using a Flat Screwdriver, and a wrench if needed, remove
the bolts and nuts to take off the toilet seat and cover (Fig.
#7)
B. On each bolt hole, place a large Black Rubber Washer (Part
#3)(Fig #8), and place the Bidet on top of the holes and
washers (Fig #9), aligning the Sliding Seat Adjusters (Bidet
Figure) with the holes. Before proceeding, align the Bidet as
desired on the sliding holes.
A. “Nozzle” has three positions for better water direction.
Choose the one that fits you better. (Fig. # 11)
B. Seated on the toilet, slowly turn the control knob to the right,
until reaches comfortable pressure for required cleanness.
Adjust pressure to the comfort level.
Warning: Be careful to turn the “Water Pressure & Nozzle
Cleaning Knob” very slowly, until the comfortable pressure
is being reached.
C. Reinstall toilet seat and cover with the bolts and nuts. Fasten
them with the Wrench and the Flat Screwdriver. (Fig. # 10)
D. Open the water supply valve.
Fig. # 7 Fig. # 8 Fig. # 9 Fig. # 10
Bidet Installation:
Instructions for use:

4
