Clear One Ceiling DocCam II Installation instructions

The new ClearOne Ceiling DocCam™II is a complete ceiling-
mounted document camera system that displays images on monitors,
plasma screens, video projectors and videoconferencing systems.
PRODUCT BRIEF
SHARE DOCUMENTS WITH CEILING DOCCAM II KEY BENEFITS
The Ceiling DocCam II can zoom in on an area roughly the size of a postage stamp.
Easy to Install
The Ceiling DocCam II uses a single Cat. 5 cable for video, control
and power signals which significantly simplifies installation.
Superior Image Quality
The high-quality CCD image sensor delivers 480 TV lines of full-
motion video resolution with superb image clarity and color
handling for easy viewing and more effective meetings.
Easy to Use
The Ceiling DocCam II features six camera presets to allow users to
quickly adjust for different document types and a positioning laser
to guide users when placing documents or images.
Complete Ceiling Installation Kit
The Ceiling DocCam II includes a plenum-rated enclosure, trim
ring, single tile support rail and hardware, a 50'/15.24 m
unshielded plenum-rated Cat. 5 cable, a 25'/7.6 m S-video cable, a
wall plate and power supply.
Ceiling DocCam™II
Professional Cameras
The Ceiling DocCam II, from ClearOne the leader in professional
audio conferencing, is the perfect solution for adding document and
image sharing capabilities to your presentations, videoconferences
and other meetings.
This camera is installed in the ceiling above a conference table and
includes a laser positioning guide, making it easy to properly place
documents for display. Superior, 480 TV line image resolution
ensures that documents are clearly presented for easy viewing.
With its wide field of view, the Ceiling DocCam II is ideal for
sharing large documents like blueprints or CAD drawings. And its
powerful zoom capability — up to 300X — ensures every detail is
clearly shown.
Power, video and control are run through a single Cat. 5 cable,
which significantly simplifies installation. The Ceiling DocCam II
outputs both composite and S-video signals concurrently for dual-
monitor display in large rooms. It also features an RS-232 port
with VISCA™control protocol for easy connection to a control
system such as AMX or Crestron and for use with video codecs
with far-end camera control.
Using the IR remote control, you can program the Ceiling DocCam
with six preset zoom settings to allow users to quickly adjust the
camera for different types of documents. The Ceiling DocCam II can
also be configured to allow the zoom function to be controlled
through the video codec remote control.

Dimensions (Height x Diameter)
Enclosure: 4.5" x 6.5" (11.43 x 16.51 cm)
Ceiling cutout: 3.5" (8.9 cm) diameter
Trim ring: 5.5" (14 cm) diameter white
Weight
4 lb (1.81 kg)
Power
Power Supply: 15 VDC, 100-240 VAC, 50/60 HZ
Consumption: 1.0 mA
Operating Temperature
32° F to 122° F (0° C to 50° C)
Video Format
NTSC or PAL
Image Sensor
1/6 Type Super HAD CCD
Pixels
Effective: Approx. 688,000
Horizontal Resolution
480+ TV lines
Sensitivity
2.5 Lux
SNR (Min)
49 dB
Focal Range
Infinity to 800mm (Telescopic)-35mm (Wide)
Lens (Horizontal Angle)
45 degrees (wide end) to
2.0 degrees (telescopic end)
Zoom
Optical 25X zoom, f=2.4 mm (wide) to 60 mm
(telescopic), F1.6 to F2.7
Digital 12X (300X total with optical zoom)
Camera Features
White balance: Auto
Brightness: Auto/Manual
Backlight compensation: Auto
Iris: Auto, Shutter: Auto exposure
Focus: Auto/Manual
6 Presets
Laser (momentary-on for document positioning)
Image Freeze, Image Flip
Black and White (color off)
Pos/Neg - Negative Art
Video Output
S-video and composite video (concurrent)
Control
VISCA/RS-232
22-button ClearOne IR remote
User Accessible Dip Switches to allow control of
zoom functions from the following products:
Polycom ViewStation
Polycom ViewStation FX
Polycom ViewStation VS-4000
Polycom iPower 9000, 900, 600
Polycom VSX-7000
Tandberg 2500
Tanderg 6000
Sony PCS-1
Sony PCS-1600
Sony PCS-6000
Sony EVI-D100, EVI-D70
Aethra Codecs
ClearOne V-There
Control Interface
VISCA (TTL Signal Level; Baud rate: 9.6 Kbps,
19.2 Kbps; Stop Bit: 1/2 Selectable)
Wall Plate
S-video, composite video, power, RS-232
Enclosure
Plenum-rated
Cables
50' (15.24 m) plenum Cat. 5 cable with RJ-45
connectors (can use custom 10' – 200' cable)
25' (7.62 m) S-video cable
Models
910-171-066
910-171-066-PAL
PRODUCT BRIEF
PRODUCT SPECIFICATIONS

Laser positioning guide to ensure accurate document
placement

Single Cat. 5 cable carries video, RS-232 control and power
to greatly simplify installation

IR remote with increased functionality, including brightness
control, presets and laser operation

VISCA/RS-232 control of automatic iris, white balance,
gain control, shutter and image stabilization to counter
vibration in the ceiling

Powerful zoom with 25x optical and 12x digital (300x total
zoom) for sharp focus and zoom detail

Pre-mounted in a plenum-rated, low-profile enclosure

User accessible DIP switches from the front of the camera
allow the Ceiling DocCam II's zoom functions to be
controlled by different video codec remotes
