Optronis CamRecord CL4000CXP User manual

CamRecord
CL4000CXP
CoaxPress Camera
User Manual
Ref. 1867-SU-01-B

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 1
Contents
Revision 3
General 4
Declaration of conformity 4
RoHS compliance 4
Scope of delivery 5
Optronis customer service 5
Remark, Attention 6
Precautions 6
Camera Power 6
Environmental Conditions 6
General Precautions 6
Camera 8
Electrical Interface 9
Auxiliary (Aux.) connector pinout 9
Camera Power 11
Indicator Lamp (LED) 12
CoaxPress Data Channels 12
Lens mount and handling 13
Nikon F-Mount adapter 13
C-Mount adapter 15
Important features 15
Frame format 16
Minimum Frame rate (@ internal synchronisation) 16
Maximum Frame rate (@ internal synchronisation) 16
Max. Frame Rate Examples: 17
Frame Rate (@ external synchronisation) 18
Technical Data 19
General 19
Spectral Response / Transmittance 20
Mechanical Dimensions 21
F-Mount Lens (/CM) 21
Synchronisation Input schematics 23
Synchronisation Output schematics 23
Internal Synchronisation Timing 24
Synchronisation Output 24
External Synchronisation Timing 25
Synchronisation Input “level detection” 25
Synchronisation Output “level detection” 25
Focal Length Calculation 26
Full Sensor Resolution 26
Reduced Sensor Resolution 26
Distance Washer 28
Camera firmware update 29
Camera mapping 31

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 2
Gen<i>Cam 32

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 3
Revision
Cameramodel Date Description
CL4000CXP
SNr. 1867-ST-xxx
29.11.2011 Firmware CXP9

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 4
General
Declaration of conformity
Manufacturer: Optronis GmbH
Address: Honsellstr. 8, 77694 Kehl, Germany
We certify and declare under our sole responsibility that the
following apparatus
Product: CL4000CXP
conform with the essential requirements of the EMC Directive
2004/108/EC, based on the following specifications applied:
Specifications: EN 61000-6-3 Emission
EN 61000-6-1 Immunity
Kehl, 20.11.2011
Optronis GmbH
Dr. Patrick Summ
Managing Director
RoHS compliance
CamRecord CL4000CXP cameras are Pb free manufactured.

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 5
Scope of delivery
CL4000CXP CoaxPress camera
Options: /C: Color sensor (Bayer Pattern)
(IR Cutoff Filter, Specification: 1830-SS-10)
/M: Monochrome sensor
Lens mount: /CM: CMount
/FM: FMount
/FMG: FMount for Nikon G-Lens series
CoaxPress: up to 6,25GBit/channel, 4 channels
Power supply: +24Volt / 0,5Amp., 100 .. 240VAC/47-63Hz
Synchronisation Adapter cable
Programming cable (USB2) for firmware update
User Manual (CD-ROM)
Optronis customer service
Optronis GmbH
Honsellstrasse 8
77694 Kehl
Germany
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
For any questions or problems, please do not hesitate to ask our customer
service. Please prepare the following information:
•Camera type: CL4000CXP
•Serial-Number: see label at the bottom side of the camera
•Frame Grabber
•Operating System (Windows XP/Vista/32bit/64bit …)
•Short description of the problem

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 6
Remark, Attention
This user manual is compliant with the firmware version CXP9 of the camera.
The following signs are used in the user manual
Remarks and additional information
Attention
Precautions
Camera Power
Please use the CL4000CXP camera power supply (Scope of delivery) or Power
over CoaxPress.
Environmental Conditions
Temperature range during operation: < + 40°C (ambient temperature)
> 0°C (ambient temperature)
Humidity during operation < 80% non-condensed
At high ambient or housing temperatures the camera lifetime will be
reduced. Avoid camera operation beyond temperature limits.
General Precautions
Read the user manual carefully before using the camera.

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 7
Do not orientate the optical input of the camera to direct sunlight.
Keep the camera free protected from dirt, dust, grease and water.
Make sure that all the connecting cables are in good condition. Defective
cables have to be replaced.
Always unplug the camera before cleaning it. Do not use cleaning liquids or
sprays. Instead, use a dry and soft duster.
There are no serviceable parts inside the camera. Do not open the
housing of the camera.
Warranty becomes void if the camera housing is opened.

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 8
Camera
1: Camera housing 2: Mounting plate 4x M4x6mm 1x ¼ ``x6mm
3: Lens mount (Nikon-F) 4: Nikon lens
5: electrical interface 6: Indicator Lamp (LED)
7: CoaxPress Channel 8: Power Connector
9: Auxiliary Connector
1
3
2
4
5
6
7
8
9

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 9
Electrical Interface
Auxiliary (Aux.) connector pinout
Auxiliary (Aux.) connector pinout
Pin
Nr. Description
1 Sync. In
External Synchronisation Input
TTL level: <0,8Volt (low)
> 2 Volt (high)
2 reserved -
3 GND Sync. Ground
4 Sync. Out
External Synchronisation Output
(TTL level @ high impedance,
0 to 2 Volt @ 50 Ohms )

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 10
To operate SyncIn correctly, a SyncIn driver circuit has to be used.
Minimum Sink Current (TTL Low Level) of the SyncIn Driver has to be
5mA. At 5mA Sink Current the input level at the SyncIn camera input
drops below 0,8Volts.
Source Current (TTL High Level).of the SyncIn Driver is neglible (0mA)
Easiest driver circuit is a Transistor working in open collector
configuration.
SyncIn input voltage limit ranges from – 5 Volts to + 30 Volts. Voltages
applied beyond these limits may damage the SyncIn Input.
SyncOut has a built in 50 Ohm driver.
At 50 Ohm termination, the driver voltage is in between 0 (low level) to
~2 Volts (high level). At high impedance termination, the driver voltage
is in between 0 (low level) to ~4 Volts (high level).
SyncOut voltage limit ranges from 0 Volt to + 5 Volts. Voltages applied
beyond these limits may damage the SyncOut Output.
The Auxiliary connector may also be used to update the firmware of the
camera. Please use the USB2 programming adapter cable.

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 11
Camera Power
Figure: CL4000CXP side view
Camera (Pwr.) connector type: Lemo EGG.0B.303CLL
Cable Connector: Lemo FGG0B303.CLAD56Z
Power (Pwr.) connector pinout
Pin
Nr. Description
1 VCC
DC Power
+24Volt +/-5% (Ripple < 200mV)
Inrush Current ~0,6A
2 GND Power Ground
3 reserved -
Alternatively Power over CoaxPress (PoCXP) can be used.

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 12
Indicator Lamp (LED)
State Indication
No power Off
System booting Solid orange
Powered, but nothing connected
(only for power over power connector)
Slow pulse red
Link detection in progress,
PoCXP active
Fast flash green
Linkt detection in progress,
PoCXP not in use
Fast flash orange
Camera / Grabber incompatible,
PoCXP active
Slow flash alternate red / green
Camera / Grabber incompatible,
PoCXP not in use
Slow flash alternate red / orange
Camera connected, but no data being
transferred
Slow pulse green
Camera connected, waiting for event
(e.g. trigger, exposure pulse)
Slow pulse orange
Camera connected, transferring
frames
Solid green
Error during data transfer 500ms red pulse
System error Fast flash red
CoaxPress Data Channels
To operate the camera, all 4 CoaxPress Channels (Labeling: BNC 4x) have to
be used. Channel 1 is Master link. Channel 2, Channel 3 and Channel 4 are
Extension links. Channel 1 uses Power over CoaxPress (PoCXP). Speeds of
the Downlink are 6,25Gbit/s, 5,00Gbit/s or 3,125Gbit/s depending on the speed
transfer capabilities of the frame grabber.

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 13
Lens mount and handling
Nikon F-Mount adapter
Figure: Camera with Nikon F-Mount adapter
To mount the lens, it has to be positioned on the lens-holder in a way, that the
back surface of the lens is completely attached to the surface of the lens-
holder.
The lens-reference has to be positioned in face to the lens-holder reference as
shown in the figure below. Then, the lens has to be turned anti-clockwise until
the silver clip on the lens-holder locks.
lens-holder
silver clip
Camera housing
Nikon F-Mount
adapter

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 14
lens unlocked lens locked
To unmount the lens, pull back first the silver clip in order to unlock the lens as
shown below. Then (the silver clip has still to be pulled back) turn the lens
clockwise until the lens is unmounted completely.
lens-reference
lens-holder reference lens-reference
lens-holder reference
pull silver clip back

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 15
C-Mount adapter
Figure: Camera with C-Mount adapter
To mount the C-Mount lens, unscrew the protective cover anti-clockwise and
mount the C-Mount lens into the lens holder.
To unmount the lens, unscrew the C-Mount lens anti-clockwise.
Important features
The CamRecord CL4000CXP CoaxPress cameras are a high resolution, high
frame rate CMOS area scan camera that are designed for industrial use. The
image sensor and the camera offer exceptional high performance:
•excellent image quality
•excellent sensitivity
•low noise
•monochrome and color
•internal and external synchronisation

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 16
•Region of Interest (ROI)
Frame format
The Frame format (frame resolution) of the camera is 2304 active Pixels in
horizontal (x) direction and 1720 active Pixels in vertical (y) direction at full
resolution. The frame format can be reduced by factor of 128 Pixel in horizontal
direction and factor of 4 Pixel in vertical direction.
The frame format can be reduced by selecting a region of interest (ROI).
Minimum Frame rate (@ internal synchronisation)
Minimum frame rate is limited to 50 fps in free run mode.
Maximum Frame rate (@ internal synchronisation)
The minimum frame interval (maximum frame rate) that can be reached by the
camera internal synchronisation mode depends on the CoaxPress Speed (Bit
Rate).
Compliance
labeling
Bit Rate (Gbps) Maximum frame
rate
Discovery Rate
CXP6 6,250 506 No
CXP5 5,000 452 No
CXP3 3,125 253 Yes
Figure: Supported high speed link bit rates

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 17
Max. Frame Rate Examples:
CoaxPress labeling Pixel resolution x
(Pixel)
Pixel resolution y
(Pixel)
Max. Frame Rate
(fps)
CXP6, BNC 4x 2304 1720 500
CXP6, BNC 4x 2048 1536 560
CXP6, BNC 4x 2048 1152 750
CXP6, BNC 4x 1920 1080 800
CXP6, BNC 4x 2304 4 87000
CXP5, BNC 4x 2304 1720 446
CXP5, BNC 4x 2048 1536 498
CXP5, BNC 4x 2048 1152 667
CXP5, BNC 4x 1920 1080 712
CXP5, BNC 4x 2304 4 77430
CXP3, BNC 4x 2304 1720 250
CXP3, BNC 4x 2048 1536 280
CXP3, BNC 4x 2048 1152 375
CXP3, BNC 4x 1920 1080 400
CXP3, BNC 4x 2304 4 43500
(Max. Frame Rate values are rounded values)

CamRecord CL600x2CXP Ref. 1867-SU-01-B Page 18
Frame Rate (@ external synchronisation)
For external synchronisation please apply a TTL signal to the Sync In and Sync
Out BNC adapter of the adapter cable (scope of delivery). External
synchronisation may be operated in level detection mode. Please see the
external synchronisation timing for more information about resulting frame rates
and exposure times.
Alternatively SyncIn can be applied directly between Pin 1 and Pin 3 on the
camera power (Pwr.) connector, Sync Out between Pin 4 and Pin 3. The
synchronisation output can be used to synchronise other devices as e.g.
additional cameras or external light flashes.
The External synchronisation frame rate range can reach any value
between 50 fps and maximum Frame Rate @ internal synchronisation.
