Clear Systems Andino 4G / LTE User manual

Clear Systems GmbH - Schweinthal 25 - 91349 Egloffstein - Phone: [phone]-andino.systems - Page 1/8
Updated: 01/06/2023
These operatinginstructions are an integral part of the product. It contains important information on commissioning and operation! Pay
attention to this, even if you pass the product on to third parties! Therefore, keep these operating instructions for future reference!
Andino 4G / LTE
4G modem with DIN rail mounting
Instruction manual

Clear Systems GmbH - Schweinthal 25 - 91349 Egloffstein - Phone:[phone]-andino.systems - Page 2/8
Updated: 01/06/2023
Table of contents
Safety instructions ............................................................................................................................
Further information..........................................................................................................................
Product description ..........................................................................................................................
Application areas ..............................................................................................................................
Intended use.....................................................................................................................................
Technical data...................................................................................................................................
Radio parameters - 4G modem (SIMCOM 7600E) .......................................................................
Data transfer rates.......................................................................................................................
Tested according to standards..........................................................................................................
Andino 4G / LTE ...........................................................................................................................
SIMCom 7600E.............................................................................................................................
Simplified EU Declaration of Conformity..........................................................................................
Scope of delivery ..............................................................................................................................
Explanation of symbols.....................................................................................................................
Disposal ............................................................................................................................................

Clear Systems GmbH - Schweinthal 25 - 91349 Egloffstein - Phone:[phone]-andino.systems - Page 3/8
Updated: 01/06/2023
The applicable VDE regulations must be observed for all devices that require an electrical voltage for their operation.
The VDE directives VDE 0100, VDE 0550/0551, VDE 0700, VDE 0711 and VDE 0860 are particularly relevant for
this product . Please also observe the following safety instructions:
• Do not continue to use the Andino 4G / LTE if it is damaged.
• Assemblies and components do not belong in children's hands!
• Devices that are operated with a supply voltage greater than 24 V may only be connected
by a qualified person.
• Use only approved and suitable antennas .
• Never operate the device without an antenna . It will be damaged.
• The electromagnetic radiation emitted by this device complies with the legal requirements. However, avoid
prolonged direct contact with the antenna while the device is in operation.
• When handling products that come into contact with electrical voltage, the applicable VDE regulations must be
observed.
• In commercial facilities, the accident prevention regulations of the German Federation of Institutions for Statutory
Accident Insurance and Prevention (Verband der gewerblichen Berufsgenossenschaften) for electrical systems and
equipment must be observed.
• Components, assemblies or devices may only be put into operation if they have been installed in a housing in such a
way that they are safe to touch. They must be disconnected from the power supply during installation.
• Do not drop the product or subject it to strong mechanical pressure, as the effects may damage it.
• The device must be protected from moisture, splash water and heat exposure.
• Ensure sufficient air circulation during operation and avoid ambient temperatures of more than 50°C
• Do not operate the device in an environment where flammable gases, vapors or dust are present.
• In schools, training facilities, hobby and do-it-yourself workshops, the operation of assemblies must be responsibly
supervised by trained personnel.
• If the unit needs to be repaired, only original spare parts may be used! The use of deviating spare parts can lead to
serious damage to property and personal injury! Repair of the device may only be carried out by a qualified
electrician!
• This appliance is not intended to be used by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and/or knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
More information, application examples, frequently asked questions (FAQ) can be found on the product
page:
https://andino.systems/ andino-lte-4g-modem
Safety instructions
Further information
!

Clear Systems GmbH - Schweinthal 25 - 91349 Egloffstein - Phone:[phone]-andino.systems - Page 4/8
Updated: 01/06/2023
Andino 4G / LTE offers the possibility to connect to the Internet via 4G / LTE.
Andino 4G / LTE offers the following services:
 Mounting on a top-hat rail in an electrical distribution / 2 partial units (TE)
 Based on the SIMCOM 7600E-H PCIe module
 Internal Mini PCIe slot with adaptation to USB.
 SIM card slot accessible from the outside
 Antenna connector for 4G/LTE and GSM led out on SMA sockets
 USB connection to the host CPU (e.g. Raspberry Pi)
 Device drivers widely available (e.g. included in Debian)
Data transmission to/from e.g.:
- remote measuring applications
- SPS-controlled systems
- computer systems
- remote access applications
- vending machines
- wind turbines
The Andino 4G / LTE is designed for mounting in electrical distribution boards.
The device is supplied with 5 volts via USB. It consumes about 3.5 watts.
A sufficiently stable power supply must be ensured.
Any other use than specified is not permitted! Changes can be made to the
damage to this product, furthermore this is associated with hazards such as short
circuit, fire, electric shock etc.. The operator, not the manufacturer, is responsible for
any personal injury or damage to property resulting from improper use. Please note
that operating and/or connection errors are beyond our control. Understandably, we
cannot accept any liability for damage resulting from this.
Product description
Fields of application
Intended use
!
!

Clear Systems GmbH - Schweinthal 25 - 91349 Egloffstein - Phone:[phone]-andino.systems - Page 5/8
Updated: 01/06/2023
Operating voltage: +5VDC
Current consumption: at 5V max. 1.6A
Temperature range (operating): 50°C, max. 80% rel. humidity (non-condensing)
Dimensions (HxWxD): 36 mm x 107 mm x 95 mm
Weight: approx. 80g
Radio parameters - 4G modem (SIMCOM 7600E)
Frequency Band(s):
GPS: 1559MHz - 1610 MHz(RX)
GSM900: 880-915MHz(TX), 925-960MHz(RX)
GSM1800: 1710-1785MHz(TX), 1805-1880MHz(RX)
WCDMA：
Band1 1920-1980MHz(TX), 2110-2170MHz(RX)
Band8 880-915MHz(TX), 925-960MHz(RX)
LTE：
Band1 1920-1980MHz(TX), 2110-2170MHz(RX)
Band3 1710-1785MHz(TX), 1805-1880MHz(RX)
Band7 2500-2570MHz(TX), 2620-2690MHz(RX)
Band8 880-915MHz(TX), 925-960MHz(RX)
Band20 832-862MHz(TX), 791-821MHz(RX)
Band38 2570-2620MHz(TX), 2570-2620MHz(RX)
Band40 2300-2400MHz(TX), 2300-2400MHz(RX)
Transmit Power Range(s):
GSM900：31.74dBm
GSM1800：27.95dBm
WCDMA：
Band1 23.8dBm
Band8 23.6dBm
LTE：
Band1 22.2dBm
Band3 22.5dBm
Band7 23.1dBm
Band8 22.3dBm
Band20 21.8dBm
Band38 23.3dBm
Band40 23.0dBm
Modulation Type(s): GPRS: GMSK; EGPRS: 8PSK; WCDMA: QPSK, 16QAM; LTE: QPSK, 16QAM; GPS: BPSK
Data transfer rates
Download Upload
LTE: 150 Mbps 50 Mbps
HSPA+ (3GPP) 42 Mbps .76 Mbps
WCDMA (3G) Kbps 384 Kbps
GPRS / EDGE 236 Kbps 236 Kbps
Technical data

Clear Systems GmbH - Schweinthal 25 - 91349 Egloffstein - Phone:[phone]-andino.systems - Page 6/8
Updated: 01/06/2023
Andino 4G / LTE
Radiated field strength / conducted emissions
DIN EN 55022: 2011according to VDE 0875 part 22 of 12.2011
Interference emission: Class B (residential) (stricter limits)
Interference immunity: Class A (industrial area) referred to. (higher irradiation)
EMC
Immunity ESD
DIN EN 61000-4-2: 2009 according to VDE 0847
part 4-2 of 12.2009
Immunity radiated
electromagnetic field
DIN EN 61000-4-3: 2006+A1:2008+ A2: 2010
according to VDE 0847 part 4-3 of 04.2011
Immunity Burst
DIN EN 61000-4-4: 2012 according to VDE 0847
part 4-4 of 04.2013
Immunity Surge
DIN EN 61000-4-5: 1995 +A1: 2014 according to
VDE 0847 part 4-5 of 03.2015
Immunity magnetic fields
DIN EN 61000-4-8: 2010 according to VDE 0847
part 4-8 of 11.2010
SIMCom 7600E
Safety
EN/IEC 62368-1:2020
Health
EN IEC 62311:2020
EMC
ETSI EN 301 489-1 V2.2.3 (2019-11)
Draft ETSI EN 301 489-19 V2.2.0 (2020-09)
Draft ETSI EN 301 489-52 V1.1.2 (2020-12)
EN 55032 2015
EN 55035 2017
Radio
ETSI EN 303 413 v1.1.1
ETSI EN 301 908-1 V13.1.1
ETSI EN 301 511 V12.5.1 (2017-03)
ETSI EN 301 908-13 V13.1.1
ETSI EN 301 908-2 V13.1.1
Tested according to standards

Clear Systems GmbH - Schweinthal 25 - 91349 Egloffstein - Phone:[phone]-andino.systems - Page 7/8
Updated: 01/06/2023
Hereby, "Clear Systems GmbH" declares that the radio equipment type "Andino 4G / LTE - V2.3" is in
compliance with Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at
the following internet address:
https://andino.systems/andino-lte-4g/andino-lte-4g-modem/emc/
 Andino 4G / LTE
Instruction
The symbol with the exclamation mark in the triangle indicates important instructions in this
operating manual that must be followed. Furthermore, if there is danger to your health, e.g. due to
electric shock.
Electrical and electronic equipment that falls under the "ElektroG" law is marked with the adjacent label and
may no longer be disposed of with the residual waste, but can be handed in free of charge at the municipal
collection points, e.g. recycling centers.
As the end user, you are required by law (Battery Ordinance) to return used batteries and rechargeable
batteries. Batteries/rechargeable batteries containing harmful substances are marked with the adjacent
label. Disposal with household waste is prohibited.
Used batteries / rechargeable batteries can be returned free of charge to the municipal collection points,
e.g. recycling centers or anywhere where batteries / rechargeable batteries are sold!
Simplified EU Declaration of Conformity
Scope of delivery
Explanation of symbols
Disposal
!
