Abocom Harley RS232/USB Modem Moudle AFM-100 User manual

AFM-100
Harley RS232/USB Modem Moudle
Specification
Interface RS232 interface for Smart Phone Systems
RS232 Connector Type Assign by Systems
Controller Conexant Harley with Smart DAA
Number of line 1
Telephone Jack Type Assign by Systems
Dialing AA mode DTMF Tone
Command AT Command set
Line Speed Data Mode
56000/53300/50667/49333/46667/45333/42667/41333/38667/37333/34667/3333
3/
30667/29333/33600/31200/28800/26400/24000/21600/19200/16800/14400/1200
0/
9600/7200/4800/2400
Terminal Speed 230400/115200/57600/38400/19200/12000/9600/7200/4800/2400/1200/300bps
Operation Asynchronous
Protocols ITU-T:V.92/V.90/V.34/V.32bis/V.32/V.22bis/V.22/V.21, BELL:212A/103, K56flex
Operating Mode Originate/Answer
Transmit Level -6dBm to - 15dBm –10dBm(default)
Receive Level -10dBm to -35dBm
Error Correction MNP4 & V.42
Data Compression MNP5, V.42bis & V.44
Flow Control Xon/Xoff, RTS/CTS
Temperature Operating: -10 ～70℃
Humidity Operating: 0 ～85%
