COOK CHILL SYSTEMS Cook/Chill S stems
SECT. XIV PAGE 55
0907
COMPRESSED AIR SYSTEMS
& REFRIGERATED AIR DRYERS
COMPRESSED AIR SYSTEMS
Cleveland Standard Features
IAir Compressor mounted on A.S.M.E. rated Receiver Tank
IBaldor high efficiency Motor
IMagnetic Starter with Thermal Overloads completely wired
and mounted
IBalanced Pump external and internal
ICast Iron Cylinders
IForged Crankshaft and Pistons
IHigh quality cast iron Piston Rings
ICast aluminum Finned Inner Coolers
IInner Cooler Safety Valve
IManual Drain for Air Receiver Tank
IAutomatic Start and Stop Control
I14 gauge Belt Guard
I1/2" Combination Filter/Pressure Regulator/Guage
I80 gallon Receiver Tank for CAS-5 & CAS-7.5
I120 gallon Receiver Tank for CAS-10 CAS-15 & CAS-20
IAccepted for use in U.S.D.A. Inspected Facilities
Options & Accessories
ËVibration Isolation Pads (set of four)
Ë3/4" Diameter Stainless Steel Flex Hose
ËRefrigerated Air Dryer with 37˚F Dew Point
ËProgrammable Automatic Drain Valve for Receiver Tank
ËLarger models availabe on request
Shall be CLEVELAND Mo el CAS-_____, COMPRESSED
AIR SYSTEM, consisting of Air Compressor & Receiver
Tank, ___ H.P. (horse power); High efficiency Bal or Motor
with magnetic Starter, Automatic Start an Stop Control;
balance External an Internal Pump; 14 gauge Steel; Belt
Guar ; 1/2" combination Filter / Pressure Regulator;
____ gallon Receiver Tank.
Short Form Specifications
REFRIGERATED AIR DRYERS
Cleveland Standard Features
INon-Cycling Dryer with double pass flooded Evaporator
IRated at 37°F (+20°F) Pressure Dew Point
IHigh efficiency Shell and Tube designed Heat Exchangers
for Compact Unit size and weight
ILow and High Refrigerant protection with Automatic
Shut-Down Device
IInternal Thermal Overload Protection
IFloat operated Drain Valve
IPower “on/off” Switch with Control Light
ILow ambient Fan Control
IAir cooled compact design cabinet type
IElectrical Supply Cord
IDesigned for wallmounting
IAccepted for use in U.S.D.A. Inspected Facilities
Shall be CLEVELAND Mo el CAS-AD__, _____, REFRIGERATED
AIR DRYER for Series “CAS” Compresse Air Systems. Rate at
37
° F (+20 ° F) Pressure Dew Point; Air coole cabinet type; com-
pact esign with Shell an Tube Heat Exchanger; Automatic High
an Low Pressure Shut-Down evice; Thermal Overloa
Protection; Non-Cycling Dryer with ouble pass floo e
Evaporator; low ambient Fan Control; Float operate Drain Valve.
Short Form Specifications
CAS-10
CAS-7.5
MODELS:  CAS-5 (VERTICAL)
 CAS-7.5 (VERTICAL)
 CAS-10 (HORIZONTAL)
 CAS-15 (HORIZONTAL)
 CAS-20 (HORIZONTAL)
MODELS:  CAS-ADA-25
 CAS-ADA-40
 CAS-ADA-60
 CAS-ADA-80

SECT. XIV PAGE 56
0907
Litho in USA
Cleveland Range reserves right of design improvement or modification, as warranted.
AIR FLOW AIR FLOW
PLAN VIEW
C
A
B
AIR OUTLET
AIR INLET
DRAIN (D)
FRONT VIEW BACK VIEW
CORD
& PLUG
ADA-25
(for CAS-5)
FRONT VIEW
CORD
& PLUG
REAR VIEW
18"
19"
AIR OUTLET
AIR INLET
18"
DRAIN (D)
PLAN VIEW
D
A
BYPASS
BYPASS
AIR DRYER AND/OR
AFTERCOOLER LINE FILTER
COMPRESSED AIR SYSTEM AND AIR DRYER
RECOMMENDED PIPING DIAGRAM
D
B
A
C
PLAN VIEW
C
CAS-10, CAS-15 & CAS-20
CAS-5 & CAS-7.5
E
A
E
B
D
APD
16.5”
20”
42”
16.5”
A
AA
A
A
PLAN VIEW
69"
APD (AUTO PROGRAMMABLE
DRAIN "OPTIONAL")
FRONT VIEW FRONT VIEW
120V/1PH - 5 AMPS
ADA-40 for CAS-7.5 & CAS-10
ADA-60 for CAS-15
ADA-80 for CAS-20
(for floor or shelf mounting only)
ABC
ADA-40 28 30 20
ADA-60 28 40 18
ADA-80 28 40 18
DIMENSIONS
AIR COMPRESSOR
CAPACITY AIR 208/3PH
MODE S ABCDEAT 100 PSIG OUT ET DRAIN E ECTRICA
CAS-5 37" 74" 26" 40 1/2" - 19 CFM 2" NPT 1" NPT 15 AMPS
CAS-7.5 37" 79" 26" 40 1/2" - 26 CFM 2" NPT 1" NPT 22 AMPS
CAS-10 69" 55" 30" 16" 13 1/2" 40 CFM 2" NPT 1" NPT 28.5 AMPS
CAS-15 69" 55" 30" 16" 13 1/2" 47.3 CFM 2" NPT 1" NPT 48.3 AMPS
CAS-20 69" 55" 30" 16" 13 1/2" 58.4 CFM 2" NPT 1" NPT 62.1 AMPS
REFRIGERATED AIR DRYER 120/1PH
E ECTRICA AIR SHIPPING
MODE S AIR DRAIN CORD & P UG F OW WEIGHT
ADA-25 (for CAS-5) 1/2" 1/4" 1/4 HP – 10 AMPS 25 SCFM 85 LBS
ADA-40 (for CAS-7.5 & CAS-10) 1/2" 1/4" 1/3 HP – 7.5 AMPS 40 SCFM 128 LBS
ADA-60 (for CAS-15) 1" 1/4" 1/2 HP – 10 AMPS 60 SCFM 183 LBS
ADA-80 (for CAS-20) 1" 1/4" 3/4 HP – 15 AMPS 80 SCFM 194 LBS
D 1D 2
B
D 1D 2
B
D 1D 2
B
D 1D 2
B
D 1D 2
B
D 1D 2
B
(NOT TO SCALE)
