THE "mini" COMBI
OVE -STEAMER
Featuring the
"Adva ced Closed
System"
Cooki g Modes:
I
ISteam (86 - 248°F) I ICombi (212 - 482°F)
I
IHot Air (86 - 482°F) I IRetherm (248 - 320°F)
I
I"Delta T" slow cooking I I"Cook & Hold"
I
I"Crisp & Tasty"
Clevela d Sta dard Features:
I
I"Advanced Clo ed Sy tem" with "Cri p & Ta ty" de-moisturizing
feature
I
I"Pre & Go" one step, recipe start buttons
I
IRequires minimum space - fits anywhere saving expensive floor
space
I
IBoilerless injection system for steam
I
IVented, double glass door with integrated door stop and self
draining condensate drip pan
I
ITray Timer (time-delayed loading for each level)
I
IEasy to understand menu icons with bright graphics display
I
IEasy to use electronic controls for all operational functions
I
IContinuous self diagnostic system with full text message display
I
IDigital controls for temperature, time and core probe settings
I
IAdvanced programming for preselected start cooking time
I
IProgram up to 250 recipes with up to 20 steps each
I
IExclusive "Smart Key" for selecting cooking option settings
I
ICO VOTHERM Cookbook with pre-programmed recipes
I
ICook & Hold and Delta-T cooking
I
IStores all device settings and recipes in an additional memory
module (ID module)
I
IMultipoint core temperature probe
I
IHeavy duty stainless steel design
I
IReliable door contact switch with long life
I
IHeavy duty skid resistant 4" adjusable legs with flanged feet
I
IEasy to clean removable door gasket
I
ICondensate drip tray on oven
I
IOven light with shockproof glass cover
I
ISlamable rotary lever door lock
ELECTRIC HEATED – Boilerless
SECT. IIA PAGE 59
0408
Optio s a d Accessories
ËOpen base stand with adjustable legs (CST310OB)
ËSmooth action hand shower for compartment cleaning (CSH310)
ËPressure spray bottle for manual cleaning (CPSB)
Ë12" x 20" wire basket for frying products (CWR10)
ËConvoGrill grilling rack (CGR10)
ËChicken grill rack (CCGR10)
Short Form Specificatio s
Shall be Cleveland Model: OES3.10 Combination Convection Oven / Steamer
with imple to operate electronic programmable control for Hot Air,
Convection Steam, and Combination cooking mode , "Cook & Hold" and
"Delta T" low-cooking capabilitie , "Advanced Closed System" with "Crisp
& Tasty" de-moi turizing feature. Multiple cooking tage program , tored
recipe library, multipoint core temperature probe, "Press & Go", one- tep
recipe tart button , "Smart Key" for electing option etting , boilerle .
Capacity for three (3) – 12" x 20" by 2 1/2" team table pan .
MODEL:OES3.10
CAPACITY: Three (3) – 13" by 18" half ize heet pan * or
Three (3) – 12" x 20" by 2 1/2" team table pan or
Three (3) – 12" x 20" wire fry ba ket
*The "mini" will hold ix 13" x 18" half ize bake pan but i
de igned for optimal cooking re ult for three pan .
the
Shown with optional Hand Shower (CSH08).

NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers.
SECT. IIA PAGE 60
0408
ELECTRICAL CONNECTIONS
The 3 phase 208-240 volt units will be supplied with a 10 AWG,SOOW, 4
conductor 6 foot long cord. The customer will have to provide the EMA plug
( EMA # 15-30P or L15-30P). Unit current rating 24 amps.
The 1 phase 208-220 volt units will be supplied with a 10 AWG, SOOW, 3
conductor 6 foot long cord. The customer will have to provide the EMA plug
( EMA # 6-30P or L6-30P). Unit current rating 24 amps.
The 1 phase 240 volt units will be supplied with a 10 AWG, SOOW, 3
conductor 6 foot long cord. The customer will have to provide the EMA plug
( EMA # 6-50P or L6-50P). Unit current rating 25.5 amps.
These units cannot be hard wired to the circuit box. They must have a EMA
plug to be connected to a mating EMA receptacle (customer supplied) to
comply with the U.L. and EC electrical standards.
COLD WATER CONNECTION
One 3/4" GHT (Garden Thread Hose) connection. Use SF approved hose.
35 PSI minimum, 60 PSI maximum.
DRAIN CONNECTION
1 1/2" tube.
Do not connect other units to this drain.
Drain line must be vented.
SERVICE CLEARANCES
3" left, 3" right, 3" rear, allow 20" on top for service.
APPROVALS
UL and UL Sanitation.
SHIPPING WEIGHT
190 lbs.
35.06”
31.23”
20.28”
2.52”
29.27”
27.74”
4.06”
11.89”
6.46”
5.63”
5.69” 16.93”
23.04”
2.44”
