COMBI OVEN-STEAMER
Short Form Specifications
Coo ing Modes:
I
IHot Air I IRetherm I I"Delta T" slow cooking
I
ISteam I I"Cook & Hold" I I"Crisp & Tasty"
I
ICombi
Cleveland Standard Features:
I
I
"Advanced closed system" with "Cr sp & Tasty" de-moisturizing feature
I
IHigh efficiency, power burner heating system for hot air and steam
generator saves energy and provides fast heat up times
I
IFully insulated steam generator and cooking compartment for
maximum energy savings
I
I
Polished cooking compartment with coved corners for easy cleaning
I
ITen (10) 12" x 20" wire shelves
I
IHinged fan guard and hinged removable pan racks
I
I
Two (2) speed auto reversing convection fan for even heat distribution
I
ISpace saving, easy to close "D sappear ng Door"
I
IDoor latch with safety vent position and wear-free door switch
I
IVented, double glass door with integrated door stop
I
ITrolley with self draining condensate drip pan
I
IEasy to change, press-fit door seal
I
IOven light with shock resistant safety glass
I
IMultipoint core temperature probe
I
IEasy to use electronic controls for all operational functions
I
ISelf diagnostic system with full text message display
I
IEasy to understand menu icons with bright graphics display
I
IUser friendly selector dial
I
IExclusive "Smart Key" for selecting option settings
I
IDigital controls for temperature, time and core probe settings
I
IEight (8) "Press & Go" one step, recipe start buttons
I
ICook book library for up to 250 stored recipe programs, each
recipe capable of 20 steps
I
I
RS 232 connection for controlling one unit with a PC (personal computer)
I
IMemory module automatically saves unit settings and recipes
I
I
Manual program override feature for operational settings
I
ISmooth action hand shower for compartment cleaning
Gas Fired Steam Generator
I
IQuiet, high efficiency, power burner heating system
I
IBuilt-in automatic rinse system
I
IAutomatic fill and water level control
I
IAutomatic generator drain
Shall be Cleveland Model: OGB-20.10 Combination Convection Oven /
Steamer with sim le to o erate electronic rogrammable controls for Hot Air,
Convection Steam, and Combination cooking modes, "Cook & Hold" and
"Delta T" slow-cooking ca abilities, "Advanced Closed System" with "Crisp
& Tasty" de-moisturizing feature. Multi le cooking stage rograms, stored
reci e library, multi oint core tem erature robe, "Press & Go", one-ste
reci e start buttons, "Smart Key" for selecting o tion settings, Two (2) s eed
auto reversing convection fan. Quiet, high efficiency ower burner heating
system; steam generator with automatic drain. "Disappearing Door".
Ca acity for twenty (20) 12" x 20" x 2 1/2" ans.
MODEL:OGB-20.10
CAPACITY: Twenty 20) - 13” by 18” by 1” half size sheet pans or
Twenty 20) - 12” x by 20” by 2 1/2” steam table pans
Options and Accessories
ËConvoClean automatic compartment washing system
ËPC-HACCP software for establishing "HACCP controls" and automatic
documentation of the cooking process
Ëockable cover over operating controls for prison installations
ËUSB or RS 485 connection for networking and controlling up to 32
units with a personal computer
ËPropane gas option
ËPan rack with trolley
ËPlate rack with trolley for banquet operations
ËThermal cover for plate or pan rack
ËConvoClean compartment cleaning solution
ËConvoCare concentrate for compartment rinse cycle
Ë"Dissolve" generator descaling solution
ËChicken Grill Rack
Ë12" x 20" Wire Baskets for frying products
ËAdditional 12" x 20" Wire Shelves
ËPre-heat bridge
ËKleensteam II Water Filters
GAS Fired – with Steam Generator

NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers.
SECT. IIA PAGE 20
0108
The "Advanced Closed System" offers the following advantages:
I
ISaves energy
I
IAutomatic moisture level adjustment
I
Iow heat and steam emission to the kitchen
I
IAutomatically regulated steam injection
I
IEnables immediate change into the steam mode
I
I"Crisp & Tasty" demoisturizing function
M del: OGB-20.10
Pan Capacity [ Unit has 7 slide rails at 2.64" (67mm) apart ]:
6(12" x 20" x 2 1/2") steam table pans 7(12" x 20" x 1") steam table pans
7(13" x 20") half size wire racks 7(13" x 18") half size sheet pans
6(12" x 20") frying baskets - (no wire racks needed)
F r Banquet Operati ns: Optional Plate Rack holds 61 plates
Unit Dimensi ns: Width - 42.61", Depth - 36.47", Height - 78.43"
Shipping Dimensi ns: Width - 49", Depth - 42", Height - 86"
(including packaging)
Shipping Weight: 750 Lbs (including trolley)
Required Clearances: Rear - 2", Left Side - 4", Right Side - 2 1/2"
• Allow for sufficient distance if a "high heat source" (i.e. Broiler) is located
next to the unit.
• Allow for sufficient clearance on left side for service access (contact the
factory service department for recommendations).
• Installation must comply with all local fire and health codes.
Agency Appr vals: UL - Gas, UL - Sanitation ( SF Standards)
Electrical Requirements: 120 volt, 21.7 amps, 60 Hz, single phase
Do not connect to a G.F.I. outlet
Gas C nnecti n: 3/4" PT
Gas Type: atural Gas (Propane optional)
Gas Flow Pressure: atural Gas - Min. 5.5" WC / Max. 14" WC
Propane Gas - Min. 11" WC / Max. 14" WC
Total Connected Load: 151,500 BTU (136,000 BTU Propane)
Steam Generator: 113,600 BTU (102,000 BTU Propane)
Hot Air: 151,500 BTU (136,000 BTU Propane)
Water C nnecti ns: Cold Water (drinking water quality)
Flow Pressure: 30 - 60 PSI
Water Inlets: 3/4" GHT-F (Female Garden Hose Connection)
Treated Water for Steam Generator
Untreated Water for Condenser and Hand Shower
Drain C nnecti n: 2" Tube
Venting: Exhaust Hood required
Gas Exhaust for Hot Air Heating
Gas Exhaust for Steam Generator
Air Vent
*C nnecti n f r Cleaning S luti n
*C nnecti n f r Rinse Cycle
L w Pressure Safety Valve
*Available as an option
A = Water hook up soft water G"
B = Water hook up cold water G"
C = drainage hook up DN50
D = power hook up
E = Potential equaliser
F = Final rinse hook up
G = Cleaner hook up
H = Air vent pipe
I = Low pressure safety
OEB 20.10
A = Water hook up soft water G"
B = Water hook up cold water G"
C = drainage hook up DN50
D = power hook up
E = Potential equaliser
F = Final rinse hook up
G = Cleaner hook up
H = Air vent pipe
I = Low pressure safety
OES 20.10
OGB 20.10
A Water hook up soft water G"
B Water hook up cold water G"
C Drainage hook up DN50
D Power hook up
E Potential equaliser
F Final rinse hook up
G Cleaner hook up
H Air vent piper
I Low pressure safety
J Gas hook up R"
K Exhaust pipe gas (Hot air heating)
L Exhaust pipe gas (Steam generator)
OGS 20.10
A = Water hook up soft water G"
B = Water hook up cold water G"
C = Drainage hook up DN50
D = Power hook up
E = Potential equaliser
F = Final rinse hook up
G = Cleaner hook up
H = Air vent pipe
I = Low pressure safety
J = Gas hook up R"
K = Exhaust pipe gas
