Clever Acoustics CS 46WP User manual

USER MANUAL
CS 46WP
100V 4” 6W Weather Resistant
Ceiling Loudspeaker
Order code: CRSP06
www.cleveracoustics.co.uk

1
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
INPUT VOLTAGE OF 70-100V
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modications to this equipment are not
subject to warranty.

2
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modication to the
equipment.
• Never let the loudspeaker cable come into contact with other cables. Handle the loudspeaker
cable and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Do not expose to ammable sources or gases.
• Make sure that the speaker-cable is never crimped or damaged. Check the equipment and
the speaker-cable periodically.
• If the equipment is dropped or damaged, disconnect the supply immediately.
Have a qualied engineer inspect the equipment before operating again.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight dealer
for service.
• Repairs, servicing and power connection must only be carried out by a qualied
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.

The 100V ceiling loudspeakers are designed specically for use in permanent audio
installations, where reliability and premium sound quality are a must. Highly rugged
construction and high efciency design make this ceiling loudspeaker perfect for continuous
duty applications.
This ceiling loudspeaker is warranted from defects for one year from the date of purchase.
Should your ceiling speaker require service, either within or beyond that warranty period,
please contact your Prolight Dealer.
Features:
• 4” full range driver
• 3W and 6W power taps at 100V line
• Metal grille with ABS bafe and enclosure
• Fitted with ying leads
• Spring clip mounting for easy installation
• Supplied with template to aid installation
Cutout size:
3
125mm
125mm
Specications
Input: 70V, 100V
Power taps @ 100V: 3W, 6W
Power taps @ 70V: 1.5W, 3W
Impedance: 1.7kΩ, 3.3kΩ
Sensitivity (1W/1m): 91dB (±3dB)
Maximum SPL (Rated W/1m): 99dB
Frequency response: 150Hz-18kHz
Drivers: 4" full range
Connections: Flying leads
Cutout: 125mmØ
Dimensions: 130 x 140mmØ
Weight: 0.9kg
IP rating: IP66
Cable colour coding: Black = COM, Green = 3.3KΩ, White = 1.7KΩ
Order code: CRSP06

4
Identication:
1. Loudspeaker grille
2. Spring clips - Use these clips to install and mount the unit into the ceiling.
3. Housing
4. Loudspeaker cable - Use this cable to attach to your mixer amplier.
Ceiling Installation
Before installing the loudspeaker, make sure that the installation area can hold a minimum point
load of 10 times the installations weight.(e.g.12kg x 10 = 120kg point load).
The durability of the installation depends very much on the material used at the installation area
(building material), such as wood, concrete and brick etc.
This is why the xing material must be chosen to suit the ceiling material. Always ask a specialist
for the correct plug/screw combination indicating the maximum load and building material.
125mm
cutout

5
MAINS
CD PLAYER
AM/FM TUNER
24V DC INPUT
(Optional)
MIC 1

6
Dispersion characteristics:

www.cleveracoustics.co.uk
Cleaning and Maintenance
We recommend a frequent cleaning of the product. Please use a soft lint free and moistened
cloth. Never use alcohol or solvents.
There are no serviceable parts inside the product except for the fuse. Maintenance and service
operations are only to be carried out by authorised dealers.
CAUTION - DANGER TO LIFE
SWITCH OFF AMPLIFIER AND DISCONNECT
THE SPEAKER BEFORE
STARTING MAINTENANCE
