Clever Acoustics SP 30 User manual

USER MANUAL
SP 30
100V 30W Music Horn Speaker
Order code: CRSP02
www.cleveracoustics.co.uk

1
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
INPUT VOLTAGE OF 70-100V
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modications to this equipment are not
subject to warranty.

2
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modication to the
equipment.
• Never let the speaker cable come into contact with other cables. Handle the speaker cable
and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Do not expose to ammable sources or gases.
• Make sure that the speaker-cable is never crimped or damaged. Check the equipment and
the speaker-cable periodically.
• If the equipment is dropped or damaged, disconnect the supply immediately.
Have a qualied engineer inspect the equipment before operating again.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight dealer
for service.
• Repairs, servicing and power connection must only be carried out by a qualied
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.

This 100V music horn speakers are designed specically for use in permanent audio
installations, where reliability and premium sound quality are a must. Highly rugged
construction and high efciency design make this horn speaker perfect for continuous
duty applications.
This horn speaker is warranted from defects for one year from the date of purchase. Should
your horn speaker require service, either within or beyond that warranty period, please
contact your Prolight Dealer.
This unit includes a host of features, along with an impressive list of specications, which
are detailed over the next pages. Please take the time to read this document completely
prior to installation of this product.
Features:
• Waterproof horn speaker for outdoor applications
• Extreme wide vertical and horizontal sound dispersion angle
• Ideal for human voice announcement and background music
• IP rating: IP66
• Built-in 100V/70V transformer
• 5” full range waterproof plastic cone
• 15 and 30W power taps
• ABS enclosure
• Wall mount bracket is supplied
• Suitable for sports grounds, schools, industrial and commercial applications and outdoor
areas (train station, shopping mall, parking area and factory) where background music,
announcements and paging is required.
3
15W, 30W
7.5W, 15W
ȍ670Ω
113dB ±3dB
128dB
300Hz-18kHz
[5”)XOO5DQJH
IP66
370 x 175 x 275mm
3.1kg
Power Taps @ 100V:
Power Taps @ 70V:
Impedance:
Sensitivity (1W/1M):
Max. SPL (Rated W/1M):
Frequency response:
Speaker driver:
IP rating:
Dimensions:
Weight:

4
Identication:
1. Connection cable - Use this to connect to your mixer amplier using the 70V or 100V
connections. To maintain weatherproof rating the connection should be terminated within an IP
rated enclosure
2. Mounting bracket - Use this bracket to mount the unit onto surfaces.
3. Mounting screw/bolt holes - Use this to attach the unit to the desired surface.
4. 5” Transducer
5. Horn Grill
6. Horn speaker housing
Wall Installation
The Horn Speaker can be installed on a wall, if the original speaker is equipped with an appropri-
ate mounting point.
Before attaching the speaker, make sure that the installation area can hold a minimum point load
of 10 times the installations weight.(e.g.12Kg 130Kgs point load).
The durability of the installation depends very much on the material used at the installation area
(building material), such as wood, concrete and brick etc.
This is why the xing material must be chosen to suit the wall material. Always ask a specialist for
the correct plug/screw combination indicating the maximum load and building material.

5
MAINS
CD PLAYER
AM/FM TUNER
24V DC INPUT
(Optional)
POWER AMPLIFIER
CASSETTE
EQUIPMENT
CONNECT WITH AUDIO
PROCESSOR EQUIPMENT, USE
THE METAL JUMPER BARS WHEN
NOT CONNECTED FOR THE AMP
TO WORK
RECORDER EQUIPMENT
MIC 1 MIC 2 MIC 3 MIC 4

6
Direction diagram:

www.cleveracoustics.co.uk
Cleaning and Maintenance
We recommend a frequent cleaning of the product. Please use a soft lint free and moistened
cloth. Never use alcohol or solvents.
There are no serviceable parts inside the product except for the fuse. Maintenance and service
operations are only to be carried out by authorised dealers.
CAUTION - DANGER TO LIFE
SWITCH OFF AMPLIFIER AND DISCONNECT
THE SPEAKER BEFORE
STARTING MAINTENANCE
