CLIQSTUDIOS RTA Three Drawer Base Cabinet User manual

RTA – Assembly Instructions
Three Drawer Base Cabinet

THREE DRAWERS BASE CABINET
ASSEMB Y INSTRUCTIONS
RIGHT/LEFT SIDE PANEL 2
BOTTOM PANEL 1
BACK PANEL 1
FRONT FACE 1
TOE KICK PLATE 2
DRAWER LEFT/RIGHT SIDE PANEL 6
DRAWER FRONT PANEL 3
DRAWER BACK PANEL 3
DRAWER BOTTOM PANEL 3
DRAWER SLIDE-CABINET MEMBER 6
DRAWER SLIDE-DRAWER MEMBER 6
1. Lay cabinet Front Face on a soft working surface with dovetail
grooves facing upward. The grooves will be for the Bottom Panel.
2. nsert the Side Panels into the dovetail grooves on Front Face
making sure clips are lined up and fully engaged.
3. nsert Bottom Panel into the grooves on Side Panels.
© CliqStudios.com

THREE DRAWERS BASE CABINET ASSEMB Y INSTRUCTIONS
4. nsert Back Panel into the grooves on Bottom Panel and Side Panels until ush making sure dovetails are fully engaged.
5. Stand the cabinet upright, place each of the 4 corner braces in each top corner of the cabinet and use screws to secure the
braces to the panels.
6. Attach Back/Front Toe Kick Plate to Side Panels making sure clips are lined up and fully engaged.
7. Lay Drawer Front Panel on a soft working surface with grooves facing upward. The grooves will be for the Drawer Bottom Panel.
Tap with mallet if necessary.
8. nsert the Drawer Side Panels to the dovetail grooves on the Drawer Front Panel with all the dovetails engaged until ush.
Tap with mallet if necessary.
9. Slide the Drawer Bottom Panel, nished surface faces upward, into the grooves on Drawer Side Panels and Drawer Front Panel.
10. Attach Drawer Back Panel to Drawer Side Panels with all the dovetails engaged until ush. Tap with mallet if necessary.
11. Attach Drawer Slide - Drawer Members, to Drawer Side Panels through pre-drilled holes with screws and tighten them.
12. nstall Drawer Slide - Cabinet Members, by inserting the slide sockets barbed dowels into cabinet Back Panel pre-drilled holes
and use screws to attach the sockets to the Back Panel.
13. Attach Drawer Slide - Cabinet Members through pre-drilled holes to the Side Panel of the cabinet using screws.
14. Slide drawers into drawer guides through the front of the cabinet.
15. Repeat the step with other drawers.
