Econoco PSOR User manual

PIPE FLANGE
4X
SHORT PIPE
4X
TOP
UPRIGHT
2X
LEVELER
2X
LOOSE 3-WAY
FITTING
2X
BOTTOM
UPRIGHT
2X
ALLEN KEY
TAPE MEASURE
BUBBLE LEVEL
STEP LADDER
8X
1/4"-20 x 27mm LONG
SOCKET SET SCREW
2X
1/4"-20 x 8mm LONG
SOCKET SET SCREW
#10 WALL ANCHORS
(STYLE DEPENDENT ON
WALL STRUCTURE)
POWER DRILL
16X
#10 x 19mm LONG
WOOD SCREW
(FOR WALL MOUNTING
WITH APPROPRIATE
STRUCTURE)
PIPE OUTRIGGER
ITEM# PSOR
PARTS LIST
2
INCLUDED HARDWARE
INCLUDED TOOLS
NOT INCLUDED TOOLS
PSOR
SHEET 1 OF 3
PSOR

LEVELER
LOOSE 3-WAY
FITTING
TOP UPRIGHT
BOTTOM UPRIGHT
TAB
SLOT
LONG SET
SCREWS
FINE
THREADS
COARSE
THREADS
- INSTALL LEVELER WITH
APPROXIMATELY 3/8" OF THREAD
EXPOSED INTO BOTTOM UPRIGHT.
- LAY THE UPRIGHT HALVES ON THE
FLOOR AND JOIN TOGETHER AS SHOWN.
- SECURE WITH 4 LONG SET SCREWS AS
SHOWN AND TIGHTEN WITH ALLEN KEY.
NOTE:
THE SCREWS SHOULD BE
TIGHTENED WHILE A HELPER HOLDS
THE TWO HALVES TOGETHER TIGHTLY.
1
ASSEMBLE OUTRIGGER POST
2
INSTALL SHORT PIPES AND PIPE FLANGES FOR WALL MOUNTING
- INSTALL SHORT PIPE AND PIPE FLANGE
AS SHOWN AS TIGHT AS POSSIBLE.
- REPEAT STEPS 1 AND 2 FOR THE
REMAINING POST.
PSOR
SHEET 2 OF 3
PSOR

AG
90.0°
DETAIL AU
SCALE 1 : 5
IDEAL FLANGE
ORIENTATION
AV
P
R
ON CENTER DISTANCE
MUST MATCH ACCESSORIES
LOOSELY
SECURED
SHORT SET
SCREW
(PRE-INSTALLED)
- WITH AT LEAST 2 PEOPLE, POSITION
THE ASSEMBLED UPRIGHT AGAINST THE
WALL.
- ADJUST THE LOWER CONNECTOR TO
AVOID ANY WALL MOLDINGS AND
SECURE THE HEIGHT BY TIGHTENING
THE INSTALLED SHORT SET SCREW.
- USING A LEVEL, CHECK THAT THE POST
IS PLUMB.
-MARK AND SECURE THE WALL FLANGES
TO THE WALL AS REQUIRED WITH
APPROPRIATE HARDWARE.
NOTE: FOR MAXIMUM STRENGTH, THE
PIPE FLANGE SHOULD BE ORIENTED AS
SHOWN ABOVE.
- BE SURE THE LEVELER IS FIRMLY
CONTACTING THE FLOOR. IF NOT,
UNTHREAD UNTIL IT IS.
- THE REMAINING UPRIGHT MUST BE
POSITIONED SO THE DESIRED
ACCESSORIES CAN BE USED.
- FOLLOW THE PRIOR STEPS TO
ASSEMBLE AND INSTALL ANY REMAINING
POSTS.
NOTE:
STANDARD ACCESSORY SIZES ARE
24" AND 48" O.C.
- IT IS RECOMMENDED TO LOOSELY
SECURE THE NEXT POST TO THE WALL SO
AN ACCESSORY CAN BE TESTED.
- IF IT IS DIFFICULT TO INSTALL OR
REMOVE, THE UPRIGHT MAY NEED TO BE
ADJUSTED.
- IF THE ACCESSORY IS NOT LEVEL, THE
UPRIGHT LEVELERS MAY NEED TO BE
ADJUSTED.
- IF ACCESSORIES ARE NOT AVAILABLE,
USE A TAPE MEASURE TO CHECK THE ON
CENTER DISTANCE.
RECOMMENDED BUT
NOT MANDATORY
3
SECURE FIRST POST TO THE WALL
4
SECURE REMAINING POSTS WHERE THEY ARE REQUIRED
SECURING LOWER
CONNECTOR
PSOR
SHEET 3 OF 3
PSOR
