CLIVET CEILING & FLOOR-SL 2 User manual

TECHNICAL MANUAL
LIGHT COMMERCIAL R32
CEILING & FLOOR-SL 2 70M-160M
2XWGRRUXQLW6/ 2 70M-160T
Note: for size 53M, see dedicated Technical Manual
18/01/2019
TM19A064GB-00

Table of Contents Page
1. Specifications ................................................................................................ 4
1. Model Reference
2. General Specifications
3. Dimensional Drawings
4. Centre of Gravity
5. Electrical Wiring Diagrams
6 Refrigerant Cycle Diagrams
7. Capacity Tables
8. Capacity Correction Factor for Height Difference
9. Noise Data
10. Electrical Characteristics
2. Product Features ........................................................................................... 65
1. Operation Modes and Functions
2. Remote Controller Functions
3. Installation .................................................................................................... 74
1. Installation Overview
2. Location Selection
3. Indoor Unit Installation
4. Outdoor Unit Installation
5. Drainage Pipe Installation
6. Refrigerant Pipe Installation
7. Vacuum Drying and Leakage checking
8. Additional Refrigerant Charge

Table of Contents Page
9. Engineering of Insulation
10. Engineering of Electrical Wiring
11. Test Operation

Contents
1. Model Reference....................................................................................................5
2. General Specifications...........................................................................................6
3. Dimensional Drawings ........................................................................................10
4. Centre of Gravity .................................................................................................13
5. Electrical Wiring Diagrams..................................................................................16
6 Refrigerant Cycle Diagrams ................................................................................30
7. Capacity Tables ....................................................................................................36
8. Capacity Correction Factor for Height Difference .............................................53
9. Noise Data............................................................................................................58
10. Electrical Characteristics......................................................................................64
Specifications

Specifications
Page 5 
1. Model Reference
Refer to the following table to determine the specific indoor and outdoor unit model number of your purchased
equipment.
Indoor Unit Model Outdoor Unit Model Capacity (Btu/h) Power Supply
1Φ, 220-240V~, 50Hz
IF2-XY 70M MC2-Y 70M 24K
IF2-XY 105M MC2-Y 105M 36K
IF2-XY 105M MC2-Y 105T 36K
3Φ, 380-410V~, 50Hz
IF2-XY 140M MC2-Y 140T 48K
IF2-XY 160M MC2-Y 160T 55K

Specifications
Page 6 
2. General Specifications
Indoor model IF2-XY 70M IF2-XY 105M
Outdoor model MC2-Y 70M MC2-Y 105M
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50
Power Supply (Outdoor)V-Ph-Hz 220~240-1-50 220~240-1-50
Max. input consumption W 2950 4700
Max. current A 13.5 21.5
Indoor fan motor
Model ZKFN-55-8-1 ZKFN-90-8-1
Qty 1 2
Insulation class E E
IP rating IPX4 IPX4
Input W 100.0 96.0
Capacitor uF / /
Speed(Hi/Mi/Lo) r/min 1200/1080/890 1200/1050/850
Indoor coil
Number of rows 3.0 3
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37
Fin spacing mm 1.3 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube
Coil length x height x width mm 795x294x40.11 1300x294x40.11
Number of circuits 7 8
Indoor air flow (Hi/Mi/Lo) m3/h 1208/1066/853 2160/1844/1431
ESP
Rated Pa / /
Range Pa / /
Indoor sound pressure level dB(A) 49/46/41 50/46/42
Indoor sound power level dB(A) 59 61
Indoor unit
Dimension(W*D*H) mm 1068x675x235 1650x675x235
Packing (W*D*H) mm 1145x755x313 1725x755x313
Net/Gross weight Kg 26.8/31.9 41.5/48
Design pressure MPa 4.2/1.5 4.2/1.5
Drainage water pipe diameter mm ODΦ25mm ODΦ25mm
Refrigerant piping Liquid side/ Gas side mm(inch) Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8")
Controller Remote contorl Remote contorl
Operation temperature °C 17-30 17-30
Room temperature
Cooling °C 17~32 17~32
Heating °C 0~30 0~30
Qty’per 20’ /40’ /40’HQ Indoor unit 102/220/252 72/147/167
Compressor
Model KTF235D22UMT KTF310D43UMT
Type ROTARY ROTARY
Brand GMCC GMCC
Capacity W 7650 10010
Input W 2065 2765
Rated current(RLA) A 9.4 5.38
Refrigerant oil/oil charge ml RB74A F/670 VG74/1000
Outdoor fan motor
Model ZKFN-50-8-2 ZKFN-120-8-2
Qty 1 1
Insulation class E E
IP rating IPX0 IPX4
Output W 115.0 150.0
Capacitor uF / /
Speed r/min 850 1050

Specifications
Page 7 
Outdoor coil
Number of rows 2.0 2.0
Tube pitch(a)x row pitch(b) mm 25.4x22 25.4x22
Fin spacing mm 1.4 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ9.52,Inner groove tube Φ9.52,Inner groove tube
Coil length x height x width mm 730x660x44 995x762x44
Number of circuits 4 4
Outdoor air flow m3/h 2700 4000
Outdoor sound pressure level dB(A) 59 63
Outdoor sound power level dB(A) 64 67
Throttle type EXV+Capillary EXV+Capillary
Outdoor unit
Dimension(W*D*H) mm 845x363x702 946x410x810
Packing (W*D*H) mm 965x395x765 1090x500x875
Net/Gross weight Kg 49.4/52.8 66.8/73.4
Refrigerant type
Type - R32 R32
GWP - 675 675
Charged quantity Kg 1.5 2.4
Design pressure MPa 4.2/1.5 4.2/1.5
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8")
Max. refrigerant pipe length m 50 65
Max. difference in level m 25 30
Ambient temperature
Cooling °C -15~50 -15~50
Heating °C -15~24 -15~24
Qty’per 20’ /40’ /40’HQ Outdoor unit 102/215/216 44/96/144
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.

Specifications
Page 8 
Indoor model IF2-XY 105M IF2-XY 140M IF2-XY 160M
Outdoor model MC2-Y 105T MC2-Y 140T MC2-Y 160T
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Power Supply (Outdoor)V-Ph-Hz 380~415-3-50 380~415-3-50 380~415-3-50
Max. input consumption W 5600 6200 7500
Max. current A 10.0 11.2 14
Indoor fan motor
Model ZKFN-90-8-1 ZKFN-90-8-1 ZKFN-160-8-1-2
Qty 2 2 2
Insulation class E E E
IP rating IPX4 IPX4 IPX0
Input W 96.0 96.0 90.0
Capacitor uF / / /
Speed(Hi/Mi/Lo) r/min 1200/1050/850 1300/1100/850 1350/1050/850
Indoor coil
Number of rows 3 3 3
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.3 1.3 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube Φ7,Inner groove tube
Coil length x height x width mm 1300x294x40.11 1300x294x40.11 1300x294x40.11
Number of circuits 8 8 8
Indoor air flow (Hi/Mi/Lo) m3/h 2160/1844/1431 2329/1930/1417 2454/1834/1426
ESP
Rated Pa / / /
Range Pa / / /
Indoor sound pressure level dB(A) 50/46/40 54/50/46 54/47/42
Indoor sound power level dB(A) 57 66 69
Indoor unit
Dimension(W*D*H) mm 1650x675x235 1650x675x235 1650x675x235
Packing (W*D*H) mm 1725x755x313 1725x755x313 1725x755x313
Net/Gross weight Kg 41.5/48 41.2/47.6 41.4/47.8
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Drainage water pipe diameter mm ODΦ25mm ODΦ25mm ODΦ25mm
Refrigerant piping Liquid side/ Gas side mm(inch) Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8")
Controller Remote contorl Remote contorl Remote contorl
Operation temperature °C 17-30 17-30 17-30
Room temperature
Cooling °C 17~32 17~32 17~32
Heating °C 0~30 0~30 0~30
Qty’per 20’ /40’ /40’HQ Indoor unit 72/147/167 72/147/167 72/147/167
Compressor
Model KTF310D43UMT KTQ420D1UMU KTQ420D1UMU
Type ROTARY ROTARY ROTARY
Brand GMCC GMCC GMCC
Capacity W 10010 13700 13700
Input W 2765 3700 3700
Rated current(RLA) A 5.38 7.02 7.02
Refrigerant oil/oil charge ml VG74/1000 VG74/1400 VG74/1400
Outdoor fan motor
Model ZKFN-120-8-2 ZKFN-85-8-22 ZKFN-85-8-22-2
Qty 1 2 2
Insulation class E E E
IP rating IPX4 IPX4 IPX4
Output W 150.0 126.0 126.0
Capacitor uF / / /
Speed r/min 1050 850 850

Specifications
Page 9 
Outdoor coil
Number of rows 2.0 1.6 2.0
Tube pitch(a)x row pitch(b) mm 25.4x22 25.4x22 25.4x22
Fin spacing mm 1.3 1.4 1.4
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ9.52,Inner groove tube Φ9.52,Inner groove tube Φ9.52,Inner groove tube
Coil length x height x width mm 995x762x44 990x1270x22+500x1270x22 990x1270x44
Number of circuits 4 8 8
Outdoor air flow m3/h 4000 7500 7500
Outdoor sound pressure level dB(A) 61 66 65
Outdoor sound power level dB(A) 64 72 74
Throttle type EXV+Capillary EXV+Capillary EXV+Capillary
Outdoor unit
Dimension(W*D*H) mm 946x410x810 952x415x1333 952x415x1333
Packing (W*D*H) mm 1090x500x875 1095x495x1480 1095x495x1480
Net/Gross weight Kg 81.5/87.0 106.7/119.9 111.3/124.3
Refrigerant type
Type - R32 R32 R32
GWP - 675 675 675
Charged quantity Kg 2.4 2.8 2.95
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8")
Max. refrigerant pipe length m 65 65 65
Max. difference in level m 30 30 30
Ambient temperature
Cooling °C -15~50 -15~50 -15~50
Heating °C -15~24 -15~24 -15~24
Qty’per 20’ /40’ /40’HQ Outdoor unit 44/96/144 22/48/48 22/48/48
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.

Specifications
Page 10 
3. Dimensional Drawings
3.1 Indoor Unit
Model Unit A B C D
70M
mm 1068 675 235 983
inch 42.05 26.57 9.25 38.7
105M-160M mm 1650 675 235 1565
inch 64.96 26.57 9.25 61.61

Specifications
Page 11 
3.2 Outdoor Unit
Single Fan Outdoor Unit
Model unit W D H W1 A B
MC2-Y 70M
mm 845 363 702 914 540 350
inch 33.27 14.29 27.64 35.98 21.26 13.78
MC2-Y 105M
mm 946 410 810 1030 673 403
inch 37.24 16.14 31.89 40.55 26.50 15.87
MC2-Y 105T
mm 946 410 810 1030 673 403
inch 37.24 16.14 31.89 40.55 26.50 15.87

Specifications
Page 12 
Double Fan Outdoor Unit
Model unit W D H W1 A B
MC2-Y 140T
mm 952 415 1333 1045 634 404
inch 37.48 16.34 52.48 41.14 24.96 15.9
MC2-Y 160T
mm 952 415 1333 1045 634 404
inch 37.48 16.34 52.48 41.14 24.96 15.9

Specifications
Page 13 
4. Centre of gravity
MC2-Y 70M

Specifications
Page 14 
MC2-Y 105M, MC2-Y 105T

Specifications
Page 15 
MC2-Y 140T, MC2-Y 160T

Specifications
Page 16 
5. Electrical Wiring Diagrams
5.1 Indoor unit
Abbreviation Paraphrase
Y/G Yellow-Green Conductor
CAP1 Indoor Fan Capacitor
FAN Indoor Fan
PUMP PUMP
L LIVE
N NEUTRAL
TO CCM Comm.Bus Central Controller
T1 Indoor Room Temperature
T2 Coil Temperature of Indoor Heat Exchanger
P1 Super High Speed
P2 High Speed

Specifications
Page 17 
IF2-XY 70M
CN26
Y/G
T2
T1
CN64MIDDLE PIPE TEMP.
ROOM TEMP.
BLACK
WHITE
INDOOR UNIT
MAINBOARD
ON/OFF
Remote Control
CN23 CN33
ALARM
Alarm Output
CN5
DISPLAY
BOARD
TO WIRE
CONTROLLER
10
CN10(CN10A)5
CN7
CN25 RED
RED
Y/G
Y/G
RED(BROWN)
BLACK(BLUE)
CN3
RED(BROWN)
CN1
BLACK(BLUE
)CN2
Y/G
FILTER-BOARD
CN1
CN2
CN7
CN5
CN3
CN21
CN22
5
5
M
5
5
SWING
M
VSWING
CN24 5M
N
L
CN13
NEWFAN
CN14 CN11
2
Y/G
PUMP
Y/G
L(L1)N(L2)
Ferrite bead
CN19 CN16
BLUE
BLACK
GRAY
WHITE
To CCM
Comm.Bus
To outdoor
Comm.Bus
S1 S2 XY
(E)
Ferrite bead
Y/G
Y/G
DC Motor
CN1
This symbol indicates the element is
optional, the actual shape shall prevail.
NOTE:
TO POWER
FOR SEPARATE
POWER SUPPLY
TO OUTDOOR
FOR OUTDOOR
POWER SUPPLY
L(L1)N(L2)L(L1)N(L2)
Magnetic
Ring

Specifications
Page 18 
IF2-XY 105M, IF2-XY 140M, IF2-XY 160M
CN23
ON/OFF
CN33
ALARM
Alarm
Output
Remote
Control
CN21/CN22
VSWING
CN24
M
M
M
5
5
5
5SWING
INDOOR UNIT MAINBOARD
DC MOTOR
DRIVER MODLE
CN13
CN3
3
CN15
5
Ceiling-Floor Type
CN5 C.S
CN3
CN2
CN1
CN29 CN28
BLUE
BLACK
YELLOW
GRAY
To CCM
Comm.BusTo outdoor
Comm.Bus
WHITE
S1 S2
XY
(E)
NOTE:
This symbol indicates the elementis
optional,the actual shape shall prevail.
Y/G
Y/G
CN7
T2
T1
CN6
4
T2B
OUTER PIPE TEMP. SENSOR
BLACK
WHITE ROOM TEMP. SENSOR
DISPLAY
BOARD
10
CN10/CN10A TO WIRE
CONTROLLER
5
CN8
CN18
RED
RED
CN16
DC MOTOR
DRIVER MODLE
CN13 5
CN3
3
CN40
TO WIRE
CONTROLLER
4
Y/G
BLACK(BLUE)
RED(BROWN)
FILTER-BOARD
CN1CN2
CN7
Y/G
CN5CN3
RED(BROWN)
BLACK(BLUE)
Y/G
CN26
Y/G
Magnetic
Ring
TO POWER
Magnetic
Ring

Specifications
Page 19 
5.2 Some connectors introduce:
A For remote control (ON-OFF) terminal port CN23
1. Remove the short connector in CN23 when you use ON-OFF function;
2. When remote switch off (OPEN), the unit would be off;
3. When remote switch on (CLOSE), the unit would be on;
4. When close/open the remote switch, the unit would be responded the demand within 2 seconds;
5. When the remote switch on. You can use remote controller/wire controller to select the mode
what you want; when the remote switch off, the unit would not respond the demand from remote
controller/wire controller.
When the remote switch off, but the remote controller/wire controller are on, CP code would be
shown on the display board.
6. The voltage of the port is 12V DC, design Max. current is 5mA.

Specifications
Page 20 
B For ALARM terminal port CN33.
1. Provide the terminal port to connect ALARM, but no voltage of the terminal port , the power from
the ALARM system (not from the unit).
2. Although design voltage can support higher voltage, but we strongly ask you connect the power
less than 24V, current less than 0.5A.
3. When the unit occurs the problem, the relay would be closed, then ALARM works.
