CNC-Step High-Z S-400T User manual

Operating instructions
CNC-portal system
S-400 T
S-720 T
S-1000 T
www.cnc-router.com
Erstellt am : 15.02.2014
Geändert am : 27.09.2014

Operating instructions
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 2
15.02.2014
CNC-portal system
High-Z T-Series
Short description
The machine includes the complete mechanics for three-dimensional movement. The
linear carriage-movement takes place via threaded spindles, powered by step motors. Two
drives are used on the x-axis. The activation of the step motors, in order to operate every
single axis, is done by using further interfaces. This operating description will show you how
to install, operate and service a CNC- portal system.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 3
15.02.2014
Content
1GENERAL............................................................................................................ 6
1.1 Symbol description.................................................................................................................................... 6
1.2 Limitation of Liability............................................................................................................................... 7
1.3 Copyright................................................................................................................................................... 7
1.4 Customer service....................................................................................................................................... 7
2SAFETY ............................................................................................................... 8
2.1 Intended use............................................................................................................................................... 8
2.2 Fundamental dangers ............................................................................................................................... 8
2.2.1 Hazards from electrical power ............................................................................................................ 9
2.2.2 Dangers by mechanics....................................................................................................................... 10
2.2.3 Dangers by high or very low temperatures........................................................................................ 12
2.2.4 Risk of fire ........................................................................................................................................ 12
2.2.5 Radiation hazards.............................................................................................................................. 13
2.2.6 Hazards of chemicals ........................................................................................................................ 13
2.2.7 General work-related dangers ........................................................................................................... 14
2.3 Responsibility of the operator................................................................................................................ 15
2.4 Staff requirements................................................................................................................................... 16
2.4.1 Qualification...................................................................................................................................... 16
2.4.2 Instruction ......................................................................................................................................... 17
2.5 Personal protective equipment............................................................................................................... 17
2.6 Safety installations .................................................................................................................................. 18
2.6.1 Description of the installed safety installations................................................................................. 18
2.6.2 Safety installations, which have to be updated by the owning operator............................................ 19
2.7 Behaviour in case of fire or accidents.................................................................................................... 20
2.8 Environmental protection ...................................................................................................................... 20
2.9 Signage ..................................................................................................................................................... 21
2.9.1 Mandatory signs................................................................................................................................ 21
2.9.2 Prohibition signs................................................................................................................................ 22
2.9.3 Warnings........................................................................................................................................... 23
2.9.4 Fire protection signs.......................................................................................................................... 23
2.9.5 Exit signs........................................................................................................................................... 24
3TECHNICAL SPECIFICATIONS........................................................................ 25
3.1 General information................................................................................................................................ 25
3.2 Power values............................................................................................................................................ 27
3.3 Operating conditions............................................................................................................................... 27
3.4 Working materials .................................................................................................................................. 27
3.5 Emissions ................................................................................................................................................. 27
3.6 Type plate................................................................................................................................................. 28
4STRUCTURE AND FUNCTIONS....................................................................... 29
4.1 Overview.................................................................................................................................................. 29
4.2 Brief description of the application range............................................................................................. 30
4.3 Module Description................................................................................................................................. 31
4.3.1 Z-axis with carriage........................................................................................................................... 31
4.3.2 Y-axis with carriage.......................................................................................................................... 32
4.3.3 X-axis with carriage.......................................................................................................................... 33

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 4
15.02.2014
4.3.4 Tool holder........................................................................................................................................ 34
4.4 Controls.................................................................................................................................................... 34
4.5 Connections.............................................................................................................................................. 35
4.5.1 Control signals (ST) ............................................................................................................................ 35
4.5.2 Motor connector (X1,X2,Y,Z) .......................................................................................................... 36
4.5.3 MiniXLR pin socket (Pin15)............................................................................................................. 36
4.6 Work and danger areas .......................................................................................................................... 37
4.6.1 Working area..................................................................................................................................... 37
4.6.2 Danger zone ...................................................................................................................................... 37
5TRANSPORT, PACKAGING AND STORAGE.................................................. 38
5.1 Safety instructions for transport............................................................................................................ 38
5.2 Transport inspections ............................................................................................................................. 39
5.3 Packaging................................................................................................................................................. 39
5.4 Symbols on packaging............................................................................................................................. 40
5.5 Transport................................................................................................................................................. 41
5.6 Storage ..................................................................................................................................................... 42
6INSTALLATION AND COMMISSIONING.......................................................... 43
6.1 Safety instructions for the installation and commissioning................................................................. 43
6.2 Preparations ............................................................................................................................................ 44
6.2.1 Install machine .................................................................................................................................. 44
6.2.2 Install worktop .................................................................................................................................. 45
6.3 Installation............................................................................................................................................... 45
6.3.1 Connecting the computer .................................................................................................................. 45
6.3.2 Connecting the stepper motor and control cable ............................................................................... 46
6.3.3 Installing Accessories........................................................................................................................ 47
6.4 Initial start-up ......................................................................................................................................... 48
7OPERATION ...................................................................................................... 49
7.1 Safety guidelines for operation............................................................................................................... 49
7.2 Operations before usage ......................................................................................................................... 49
7.3 Switching on............................................................................................................................................. 50
7.4 Activities during operation..................................................................................................................... 51
7.4.1 Operating machine ............................................................................................................................ 51
7.4.2 Change tool ....................................................................................................................................... 54
7.5 Switching off............................................................................................................................................ 54
7.6 Activities after use................................................................................................................................... 55
7.7 Emergency Shutdown............................................................................................................................. 55
8MAINTENANCE................................................................................................. 56
8.1 Safety Instructions for maintenance...................................................................................................... 56
8.2 Spare parts............................................................................................................................................... 57
8.3 Maintenance Schedule ............................................................................................................................ 58
8.4 Maintenance ............................................................................................................................................ 59
8.4.1 Cleansing of the machine.................................................................................................................. 59
8.4.2 Lubricate machine............................................................................................................................. 59
8.5 Measures after maintenance .................................................................................................................. 65

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 5
15.02.2014
9FAILURES.......................................................................................................... 66
9.1 Cautions for Troubleshooting................................................................................................................ 66
9.2 Diagnosis Chart....................................................................................................................................... 68
9.3 Problem resolution.................................................................................................................................. 69
9.3.1 Cancel the emergency stop................................................................................................................ 69
9.3.2 Check axes for perpendicularity........................................................................................................ 70
9.3.3 Description of process for aligning the machine with respect to perpendicularity............................ 70
9.4 Commissioning after fault has been rectified ....................................................................................... 71
10 DISMANTLING AND DISPOSAL.................................................................... 72
10.1 Safety regulations for the disassembling and disposal......................................................................... 72
10.2 Disassembling.......................................................................................................................................... 72
10.3 Disposal.................................................................................................................................................... 73
11 APPENDIX ...................................................................................................... 74
11.1 Accessories............................................................................................................................................... 74

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 6
15.02.2014
1General
This instruction provides guidelines which enable a safe and efficient handling of the
machine. The manual is an integral part of the machine and must be kept in the
immediate vicinity of the machine and accessible at any time for the personnel.
Before starting all tasks, personnel must carefully read and understand these
instructions.
Adherence to all the specified safety instructions and instructions for actions in this
operating manual is a fundamental requirement for working safely.
Furthermore, the local accident prevention regulations and general safety conditions for
the application of the machine are also applicable.
Illustrations in this manual are intended to facilitate basic understanding, and may differ
from the actual design.
Further guidelines regarding built-in components are found in the appendix of this
description.
1.1 Symbol description
Safety instructions are designated by symbols. In addition, there is always a signal word
heading the information indicating the severity of the danger or hazard that may be
encountered.
HINT:
Indicates a potentially hazardous situation which, if not avoided, could result
in property damage or environmental contamination.
WARNING:
This signal word and symbol indicates a risk which can lead to severe injury or
even death, if not avoided.
ATTENTION:
This signal word and symbol indicates a risk which can lead to small injuries,
if not avoided.
Danger:
This signal word and symbol indicates a risk which can lead to severe injury or
even death, if not avoided.
Prohibition for people with pacemakers
This sign stands for activities involving risks for people with pacemakers. These
areas are prohibited for people with pacemakers!!
Warning of hazardous electrical voltage
This sign stands for activities on all components carrying live voltage.
Danger due to hot surface
This sign stands for activities involving contact with hot objects.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 7
15.02.2014
1.2 Limitation of Liability
All data and notes in these instructions were prepared with consideration to the statutory
standards and regulations, the present state of technology, as well as our many years of
knowledge and experience.
Under the following circumstances the manufacturer will not assume any liability:
Non-compliance with these instructions
Used other than for the intended purpose
Unauthorized or unapproved personnel
Unauthorised rebuilds or modifications
Unauthorized technical changes
The use of unauthorized replacement parts or non-original accessories
The actual scope of delivery can, by special designs, deviate from the explanations and
presentations given here, because of the utilization of additional order options, or
because of the most recent technical changes.
The responsibilities agreed in the delivery contract, the General Terms and Conditions as
well as the delivery conditions of the manufacturer and the statutory regulations valued
at the time of conclusion of the contract are effective.
1.3 Copyright
The contents of this instruction are copyrighted. It is to be used for the purpose of operating
the machine, only. Any other use without a written permission is forbidden.
1.4 Customer service
Our customer service is pleased to provide further technical information:
Additionally, our members of staff are permanently interested in receiving new
information and experiences resulting from the use of our products, which could be of
great value for future improvements.
Address
CNC-STEP
CNC Maschinenbau Frank Hylewicz
Siemensstraße 13-15
D-47608 Geldern
Phone
+49 (0)2831/91021-50 (Mo. - Fr. 07.00am –3.00pm)
Mobile
[phone]
In urgent cases (Mo. - Thu. 3.30pm - 6.00pm )
Telefax
+49 (0)2831/91021-99
E-Mail
[email protected]
Internet
www.cnc-router.com

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 8
15.02.2014
2Safety
This section gives an overview of all important safety aspects for optimum protection of the
personnel, as well as for the safe and fault-free operation. Other task-based guide-lines are
included in the sections regarding the individual phases of life.
2.1 Intended use
The CNC-Portal system is exclusively used for holding provided tools that serve to process
various materials and surfaces.
The machine is meant to be built into a complete system and does not have its own
control unit.
Intended use also includes compliance with instructions specified by the manufacturer
concerning operation, servicing and maintenance.
Every application in excess of the intended use and/or other use, can lead to hazardous
situations and is considered misuse.
WARNING:
Danger due to misuse!
Improper use of the CNC-portal machine can cause dangerous situations.
Operation outside the values specified in the section „Technical
data“.
Bypassing the safety devices.
Remodelling, refitting or changing of the device or parts of it, with
the intention to alter functionality or usability.
If machining process involves flammable cooling lubricants.
Processing light alloys such as aluminium, magnesium and titanium
alloys without extraction attachments and corresponding safety
measures.
Operating the machine, although it is not in perfect condition from a
technical point of view.
Operating the machine in potentially explosive environment.
The manufacturer shall not be held liable for any and all damage due to misuse of this
equipment.
2.2 Fundamental dangers
In following section, all residual risks are named that can still result from the machine,
even when the appliance is used as intended.
In order to minimize personal injuries and property damage and avoid dangerous
situations, all here mentioned safety-guidelines and those mentioned in further sections
must be followed.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 9
15.02.2014
2.2.1 Hazards from electrical power
Electric current
DANGER:
Life Hazard through electrical shock!!
Touching conductive parts causes a direct danger to due to electrical
shock. Damage to the insulation or individual components can mean
danger to life.
Any work required at the electrical system may only be carried out
by a qualified electrician in compliance with electro-technical
regulations.
In case of damage to the insulation, switch off the power supply
immediately and have repairs carried out.
Before starting to work on active parts of electrical systems and
equipment, establish a voltage-free state throughout the duration
of the work, this must take place according to the 5 following safety
regulations:
Activation.
Secure it from being switched on again.
Determine voltage free status.
Earth and short circuit.
Provide protection by covers or barriers for any neighbouring live
parts.
Never attempt to bypass or de-activate fuses or cut-outs. When
replacing fuses or circuit breakers make sure to adhere to the correct
ampere rating. Keep moisture away from live parts.
Stored charge
Danger:
Risk of death due to stored voltage!
Electronic charges could be stored in electric components that still exist
after switching off and disconnecting from power-supply. Contact with
these components can lead to severe injury or even death.
Before starting work disconnect mentioned components from
power-supply. Wait 10 minutes, in
order to assure that the internal capacitors discharge completely.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 10
15.02.2014
2.2.2 Dangers by mechanics
Rotating tools
WARNING:
Risk of injury from rotating tools!
Clamped tools such as milling spindles can lead to severe personal injury
or material damage.
Before the start of any work, ensure that all covers and protective
devices are correctly installed and function correctly.
Never touch moving tool during operating process!
Before exchanging tools, always pull power plug of the milling motor
or turn off the machine and secure against restarting.
Axis motion
WARNING:
Risk of injury by axis motion!
Collision by people with components of the machine (Y-bridge, Units,
turntable with work piece, tools) can cause severe injuries.
Body parts are kept away from moving components and axis limit
switches.
Do not reach into gaps between trapezoidal screws and adjacent
components.
Do not reach into gaps between unit and Y-bridge.
Only work on the machine when it is idle.
Only work with personal safety equipment.
Falling materials
WARNING:
Injuries by falling materials!
During operation chips, tools (or parts of it) could be thrown out
uncontrollably or cause severe injuries to skin and eyes.
Wear face shield or fully closed and tight-fitting goggles, protective
clothing, protective gloves and safety shoes.
If particles enter your eyes, immediately get medical attention!

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 11
15.02.2014
Unexpected start-up of the machine
WARNING:
Risk of injury caused by unexpected start-up of the machine
The machine and the used tools can start-up unexpectedly, change their
direction or stop. Limps can get trapped.
It must be ensured that, no body parts get in the danger zone of
the machine.
Protect working area against unintentional access.
Tools
ATTENTION:
Risk of injuries by negligent handling of tools!
By handling tools negligent, lacerations and crushing injuries can be
caused.
Tools must be handled with care and used in accordance with the
regulations.
Take weight into account when transporting tools.
Wear safety shoes and protective gloves.
Sharp edges and corners
ATTENTION:
Risk of injuries by sharp edges and corners!
Sharp edges and corners can cause abrasions and cuts on your skin.
Working near sharp edges and corners should be done with great
caution.
If in doubt wear protective gloves.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 12
15.02.2014
2.2.3 Dangers by high or very low temperatures
Hot surfaces
ATTENTIONS:
Risks by hot surfaces!
Tools, work pieces and chips can heat up during operation. Skin contact
with hot surfaces causes serious burns of the skin.
As a matter of principle, for all tasks with tools, work pieces and
chips, protective clothing and gloves must be worn.
Before all tasks, make sure that all surfaces have cooled down to
the ambient temperature.
2.2.4 Risk of fire
Highly flammable materials
ATTENTION:
Risk of fire by highly flammable materials!
Organic dust produced by coal or wood or inorganic dust from magnesium,
aluminium, zinc or titanium can catch fire and cause severe injuries and
death.
Do not smoke within the danger zone and the immediate vicinity.
Refrain from contact with open flames or sources of ignition.
Keep a fire extinguisher at hand in the immediate vicinity of the
work area.
Do not process light alloys such as magnesium, aluminium, zinc
and titanium without an extraction system and relevant security
measures.
Suspend any work activities in case of fire. Leave the danger zone
until the all clear signal is given

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 13
15.02.2014
2.2.5 Radiation hazards
Magnetic fields
DANGER:
Danger to life by magnetic fields!
Magnetic fields of step motors can cause severe injuries or death, as well
as serious damage to materials.
Persons with pacemakers must keep away from the machine! It
can effectively provoke a dysfunction of the pacemaker.
Persons with metallic implants must not be allowed in the area of
the machine. Implants can heat themselves up or be drawn-in.
Take off all metal objects (Jewellery, watches, pens etc.) before
starting maintenance operation.
No electronica equipment is to be taken into the magnetic source
area. These could get damaged.
No storage media, credit cards etc. are to be taken into the
magnetic source area. Containing data may be deleted.
2.2.6 Hazards of chemicals
Cooling emulsion
WARNING:
Danger of serious damage to health by polluted cooling emulsion!
Polluted cooling emulsion can cause inflammations when coming in
contact with skin.
Cooling emulsion must be checked at regular intervals.
When handling with polluted cooling emulsion protective clothing
and chemical-resistant safety-gloves must be worn.
Avoid direct skin contact. Cleanse skin, especially before breaks
and when finishing work.
Eat and drink in relevant break room only!

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 14
15.02.2014
ATTENTION:
Health risks due to contact with cooling emulsion!
Contact with cooling emulsion may lead to health risks.
Avoid contact with your skin.
Remove cooling emulsion from the skin immediately.
Do not inhale the vapours.
Oil and fat
ATTENTION:
Risk of health due contacting with oil and fat!
Contact with oil and fat may lead to health risks.
Avoid skin contact.
Remove oil and fat immediately from skin.
Do not inhale vapours.
2.2.7 General work-related dangers
Noise
ATTENTION:
Risk of injury by noise!
The noise levels occurring in the operating area may cause severe hearing
damage.
Always wear hearing protection when working.
Only stay in the danger area when required.
Dirt and objects lying around
Attention:
Risk of tripping by dirt and objects lying around!
Soiling and objects left lying around are sources of slipping and stumbling
and can cause considerable injuries.
Always keep the work area clean.
Remove any objects which are no longer required from the working
area, especially those near ground.
Designate tripping positions with yellow-black marker band.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 15
15.02.2014
2.3 Responsibility of the operator
Operator
Operator is the person who operates the machine for commercial or economic purposes,
or leaves the use / application to a third party and bears responsibility during the
operation of the product for the protection of the user, the staff and third party.
Operator obligations
The machine is used in the commercial sector. The operator of the machine is therefore
subject to the legal obligations concerning occupational safety. Apart from the safety
instructions given in this manual, it is necessary to meet all safety, accident prevention
and environmental protection requirements applicable to the equipment's field of use
and operating site.
The following principles apply in particular:
The operating company must inform itself about the effective industrial
regulations and determine additional hazards in a risk assessment that result
through the special working conditions at the place of operating the machine. He
must implement this in the form of operating instructions for the operation of the
machine.
During the complete usage time of the machine, the owner must check whether
the operating instructions created by him correspond with the current status of
the regulations and must adapt them if necessary.
The owner must clearly regulate and specify the responsibilities for installation,
operation, maintenance and cleaning
The operator of the machine must ensure that all persons having access to it,
have read and understood these instructions. In addition he must at regular
intervals train the employees in how to deal with the machine and inform them
about potential hazards.
The operating company must provide the required safety equipment for the
personnel and order to wear protective equipment.
Moreover, the equipment operator is responsible for ensuring that the equipment is in
proper technical condition at all times.
Thus, following applies:
The operating company must make sure that any and all maintenance intervals
described in this instruction are carried out.
The owner must arrange for all safety equipment to be checked regularly for
functionality and completeness.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 16
15.02.2014
2.4 Staff requirements
2.4.1 Qualification
The different Tasks contained in this instruction require different qualifications auf
persons that are intrusted with these tasks.
WARNING:
Risks caused by insufficient qualifications of persons!
Insufficient qualified persons cannot assess the extent to which they
represent a risk handling with the machine and therefor run the risk of
injuries or death for themselves and others.
Work on or in the unit must be done only by duly qualified staff and
in full compliance with the appropriate instructions and pertinent
regulations...
Keep insufficiently qualified persons away from the work area.
Only persons of whom it may be expected that they perform their work reliably are
permitted as personnel. Persons whose responsiveness is affected, e.g. by drugs, alcohol
or medicines are not authorized.
In this instruction all required qualifications, for the different people, with different tasks
are named:
Operator
The operator was instructed by the operating company in a briefing about the tasks
assigned to them and instructed about possible hazards because of improper conduct.
Tasks, die which are carried out beyond the normal operation, only are allowed to be
carried out by an operator if this is mentioned in this instruction and the operating
company has assigned the operator expressly.
Electrician
An electrician whose technical training, skills and experience together with their
knowledge of pertinent regulations and documentation means that they are capable of
assessing the work to be carried out and detect and prevent any possible dangers.
An electrician is trained especially for its working environment, and knows the relevant
standards and regulations.
Qualified personnel
Qualified personnel based on their professional training, know-how and experience as
well as knowledge of the applicable standards and regulations is able to perform
assigned work activities and to detect and to avoid possible dangers on their own.
Manufacturer
Curtain maintenance work is only allowed to be carried out by authorized and skilled
personnel. Other personnel is not authorised to carry out these tasks. In order to carry out
this maintenance work, please call our customer service!

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 17
15.02.2014
2.4.2 Instruction
The owner must train staff regularly. For record-keeping purposes, a log of training
conducted must be kept with following minimum contents:
Date of training
Name of trained person
Contents of training
Name of trainer
Signature of trained person and trainer
2.5 Personal protective equipment
Personal protective equipment prevents from impairments with respect to the safety of
personnel during work.
Personnel have to wear personal protective equipment while working on the machine,
which are mentioned in different sections of this instruction.
Description of personal
protective equipment
Protective clothing
Protective clothing is close fitting, with low resistance to tearing, with narrow
sleeves and without protruding parts.
Chemical resistant safety gloves
Suitable chemical resistant safety gloves have to worn to protect your skin
from aggressive chemicals.
Hearing protection
Hearing protection prevents irreversible damage to hearing.
Industrial protection helmet
Industrial protection helmet prevents from injuries by falling or suspended
objects.
Safety glasses
Safety glasses prevent injuries in eyes from parts flying around or squirts of
fluids.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 18
15.02.2014
2.6 Safety installations
WARNING:
Malfunctioning safety installations may pose a fatal risk!!
Malfunctioning or deactivated safety installations may cause severe
injuries and even death!
Before starting to work, check all safety installations regarding their
functional efficiency and correct installation.
Never deactivate or bypass safety equipment.
Take care to ensure that safety installations are always accessible.
2.6.1 Description of the installed safety installations
Emergency-stop-
button
Abb.1: Emergency-stop-
button
By pressing the emergency-stop-button (Abb. 1) the machine is shut down by immediately
switching off the energy supply to the machine drives. After pressing the emergency-off-
button, it has to be turned to be able to turn the machine on again.
Protective gloves
Protective gloves protect the hands from rubbing, abrasions, cuts or more
profound injuries, as well as when touching hot surfaces.
Protective cover
Wear protective cove to protect long hair from being caught, wrapped up in,
or drawn into moving parts.
Employees are required to wear protective covers, if their hair is longer than
the extent of the shaft and its moving parts.
Safety boots
Safety shoes protect the wearer's feet against falling objects, from being
crushed, slippery surfaces and being run over by vehicles.

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 19
15.02.2014
WARNING:
Danger to life when unintentional switching the machine back on!
Unintentional start-up of the machine can lead to severe injuries and
death.
Before switching on the machine make sure, that the cause of
the emergency-stop is eliminated and all safety installations are
correctly installed and functional.
Only unlock the emergency-stop-button (Abb. 2 u. 3) when there
is no risk.
Position of emergency-stop-button
Abb. 2:Emergency-stop-button on
Y- bridge
Abb. 3: Emergency-stop-button on step-motor controller
2.6.2 Safety installations, which have to be updated by the owning operator
Extraction
When processing light metal alloy such as magnesium, aluminium and titanium an
extraction system has to be installed.
HINT: Risks to human health and environment!
Wrong handling and no extraction system can cause production of particulate
matter.
Particulate matter damages mostly the airways, because it gets inhaled.
Following health effects related to particulate matter concentrations are
generally known:
Temporary impairments of the repertory
Higher medication requirements for asthma patients
Increased hospital admissions
Increased mortality caused by cardiovascular problems and
respiratory diseases

Operating instruction
High-Z T-Series
Siemensstrasse 13-15
D-47608 Geldern Tel. [phone]
Page 20
15.02.2014
2.7 Behaviour in case of fire or accidents
Preventive measures
Always be prepared for accidents or fires!
Keep first aid facilities (first aid box, blankets etc.) and fire extinguishers
accessible at all times.
Familiarise personnel with accident reporting, first aid and rescue equipment.
Keep access routes clear for rescue vehicles.
Measures for fire and accidents
Cause emergency-stop by pressing emergency-stop-button immediately.
If there is no risk for own health, remove all persons from the danger zone.
Instigate first aid measures, if necessary.
Call the fire brigade and/or rescue service.
Fire: Fight fire with fire-extinguishers, if there is no risk for own health. Continue
fire-fighting until fire-brigade arrives.
Inform responsible persons at the place of action...
Clear access routes for emergency vehicles.
Instruct rescue vehicles.
2.8 Environmental protection
HINT: Risk for environment caused by carelessly handled hazardous
substances!
Handling with hazardous substances can be dangerous for the
environment if handled carelessly, especially when disposed wrong. This
can cause severe damages to the environment.
Please pay attention to the correct handling and disposal of
below mentioned hazardous substances.
If environmentally hazardous substances are accidentally
released into the environment, take suitable measures
immediately. In case of doubt inform the responsible local
authority of the damage
