SERVICE MANUAL
Mini Excavators
CX16B and CX18B

00104 9-88670 GB
INTRODUCTION

00104 9-88670 GB
INTRODUCTION
TO THE READER
•This manual has been written for a skilled
technician, in order to give him the information
necessary to repair this machine.
-Read this manual carefully for correct
information about repair procedures.
-For any question or comment, or in case you
noticeamistakeinthismanualcontent,please
contact:
CNH FRANCE S.A.
18, place des Nymphéas ZI Paris Nord II
93420 Villepinte France
ADDITIONALREFERENCEMANUALS
•In addition to this Workshop Manual, refer also to
the following:
-Operation and maintenance instruction
manual
-Spare parts catalog
DESCRIPTION OF THE COMPLETE
WORKSHOP MANUAL
•The complete repair manual consists of two
volumes:
CX16B and CX18B
Workshop Manual "Excavator"
•"Excavator" and "Engine" Workshop Manuals
contain the technical information necessary for
machine/engine service and repair, service
equipment, information on maintenance standards,
remove and install procedures, disassembly and
assembly procedures.
•The complete Workshop Manual for the excavator
models CX16BandCX18B consists of the following
volumes identified by print number as shown
herebelow:
VOLUME
- Workshop Manual - "Excavator"
MACHINE TYPE
CX16B
CX18B
PRINT NO.
9-88670

00104 9-88670 GB
INTRODUCTION
AVOID ACCIDENTS
Most accidents, whether they occur in industry, on the farm, at home or on
the highway, are caused by the failure of some individuals to follow simple
and fundamental safety rules or precautions. For this reason MOST
ACCIDENTS CAN BE PREVENTED by recognising the real cause and
doing something about it before the accident occurs.
Regardless of the care used in the design and construction of any type of
equipment there are conditions that cannot be completely safeguarded
against without interfering with reasonable accessibility and efficient
operation.
Carefully read indications, cautions and safety warning quoted in the
“SAFETY RULES” section.
A careful operator is the best insurance against an accident.
The complete observance of one simple rule would prevent many thousand
serious injuries each year.
That rule is:
Never attempt to clean, oil or adjust a machine while it is in motion.
ATTENTION
On machines having hydraulically, mechanically and/or cable
controlled equipment (such as showels, loaders, dozers, scrapers
etc.)becertaintheequipmentisloweredtothegroundbeforeservicing,
adjusting and/or repairing.
If it is necessary to have the equipment partially or fully raised to gain
access to certain items, be sure the equipment is suitably supported
bymeansotherthanthehydraulicliftcylinders,cableand/ormechanical
device used for controlling the equipment.
COPYRIGHT BY CNH FRANCE S.A.
Rue des Meuniers - 60330 LE PLESSIS-BELLEVILLE FRANCE
All rights reserved. Reproduction of text and illustrations in whole or in part, is
strictly prohibited.
