COBHAM DIGImini Series User manual

Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page | I
The most important thing we build is trust
DIGImini
EMEA/APAC/AUSTRALIA
Digital Multi-band Series
User Manual – 00030UMCD Rev. 5.0

DIGIMINI EMEA/APAC/AUSTRALIA DIGITAL REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless Date: 11-Oct-15 Cobham Wireless – Coverage
Page | II Rev. 5.0 Document number: 00030UMCD
THIS DOCUMENT IS VALID FOR THE FOLLOWING REPEATER MODELS:
DIGImini EMEA/APAC Repeaters
Single Band DIGImini 2009, DIGImini 2018, DIGImini 2021
Dual Band DIGImini 700/1800, DIGImini 900/2100, DIGImini 1800/2600, DIGImini 900/1800
DIGImini 1800/2100, DIGImini 850/1800, DIGImini 850/2100
Quad-band DIGImini 4 bands Accessory upgrade kit D-MINI 4B-AK

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page | III
Copyright © 2015 Axell Wireless Limited trading as Cobham Wireless
All rights reserved.
No part of this document may be copied, distributed, transmitted, transcribed, stored in a retrieval system, or
translated into any human or computer language without the prior written permission of Axell Wireless Limited
trading as Cobham Wireless.
The manufacturer has made every effort to ensure that the instructions contained in this document are
adequate and free of errors and omissions. The manufacturer will, if necessary, explain issues which may not be
covered by this document. The manufacturer's liability for any errors in the document is limited to the correction
of errors and the aforementioned advisory services.
This document has been prepared to be used by professional and properly trained personnel, and the customer
assumes full responsibility when using them. The manufacturer welcomes customer comments as part of the
process of continual development and improvement of the documentation in the best way possible from the
user's viewpoint. Please submit your comments to the nearest Cobham Wireless sales representative.
Contact Information
Headquarters Axell Wireless trading as Cobham Wireless
Aerial House, Asheridge Road
Chesham, Buckinghamshire
HP5 2QD, United Kingdom
Tel: [phone]
Fax: [phone]
Commercial inquiries [e-mail]
Website www.cobham.com/wireless
Support issues [e-mail]
Technical Support Line, English speaking [phone]
About This Manual
This Product Manual provides the following information:
•Description of the Repeater unit
•Procedures for setup, configuration and checking the proper operation of the unit
•Maintenance and troubleshooting procedures
For whom it is intended
This Product Manual is intended for experienced technicians and engineers. It is assumed that the customers
installing, operating, and maintaining Cobham Wireless Repeaters are familiar with the basic functionality of
Repeaters.
Notice
Confidential - Authorized Customer Use
This document may be used in its complete form only and is solely for the use of Cobham Wireless employees
and authorized Cobham Wireless channels or customers. The material herein is proprietary to Cobham Wireless.
Any unauthorized reproduction, use or disclosure of any part thereof is strictly prohibited.
All trademarks and registered trademarks are the property of their respective owners.
Disclaimer of Liability
Contents herein are current as of the date of publication. Cobham Wireless reserves the right to change the
contents without prior notice. The information furnished by Cobham Wireless in this document is believed to be
accurate and reliable. However, Cobham Wireless assumes no responsibility for its use. In no event shall
Cobham Wireless be liable for any damage resulting from loss of data, loss of use, or loss of profits and Cobham
Wireless further disclaims any and all liability for indirect, incidental, special, consequential or other similes
damages. This disclaimer of liability applies to all products, publications and services during and after the
warranty period.

DIGIMINI EMEA/APAC/AUSTRALIA DIGITAL REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless Date: 11-Oct-15 Cobham Wireless – Coverage
Page | IV Rev. 5.0 Document number: 00030UMCD
Safety Instructions and Warnings
Throughout this manual, important safety warnings and admonishments are included to warn of possible
hazards to persons or equipment. A safety warning identifies a possible hazard and then describes what may
happen if the hazard is not avoided. The safety warnings –in the form of Dangers, Warnings and Cautions must
be followed at all times. These warnings are flagged by the use of a warning icon, usually the triangular alert
icon seen below. The exclamation point within the triangular alert icon is intended to warn the operator or
service personnel of operation and maintenance from factors relating to the product and its operating
environment, which could pose a safety hazard.
Guarantees
•All antennas must be installed with lightning protection. Damage to power modules, as a result of lightning
are not covered by the warranty.
•Switching on AC or DC power prior to the connection of antenna cables is regarded as faulty installation
procedure and therefore not covered by the Cobham Wireless warranty.
General Safety Warnings Concerning Use of This System
Always observe standard safety precautions during installation, operation and maintenance of this
product.
Exclusive Remedies
The remedies provided herein are the Buyer’s sole and exclusive remedies. Cobham Wireless shall not be viable
for any direct, incidental, or consequential damages, whether based on contract, tort, or any legal theory.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page | V
General Safety Warnings Concerning
Always observe standard safety precautions during installation, operation and maintenance of this
product.
Caution labels!
Throughout this manual, there are "Caution" warnings. "Caution" calls attention
to a procedure or practice, which, if ignored, may result in injury or damage to the
system, system component or even the user. Do not perform any procedure
preceded by a "Caution" until the described conditions are fully understood and
met.
Danger: Electrical Shock
To prevent electrical shock when installing or modifying the system power wiring,
disconnect the wiring at the power source before working with un insulated wires
or terminals.
Caution: RF Exposure
RF radiation, (especially at UHF frequencies) arising from transmitter outputs
connected to AWL’s equipment, must be considered a safety hazard.
This condition might only occur in the event of cable disconnection, or because a
‘spare’ output has been left un-terminated. Either of these conditions would
impair the system’s efficiency. No investigation should be carried out until all RF
power sources have been removed. This would always be a wise precaution,
despite the severe mismatch between the impedance of an N type connector at
50 ohm, and that of free space at 377ohm, which would severely compromise
the efficient radiation of RF power. Radio frequency burns could also be a
hazard, if any RF power carrying components were to be carelessly touched!
Antenna positions should be chosen to comply with requirements (both local &
statutory) regarding exposure of personnel to RF radiation. When connected to
an antenna, the unit is capable of producing RF field strengths, which may
exceed guideline safe values especially if used with antennas having appreciable
gain. In this regard the use of directional antennas with backscreens and a strict
site rule that personnel must remain behind the screen while the RF power is on,
is strongly recommended.
Where the equipment is used near power lines or in association with temporary
masts not having lightning protection, the use of a safety earth connected to the
case-earthing bolt is strongly advised.
Caution: Safety to
personnel.
Before installing or replacing any of the equipment, the entire manual should be
read and understood.
The user needs to supply the appropriate power to the repeater. Incorrect power
settings can damage the repeater and may cause injury to the user.
Please be aware that the equipment may, during certain conditions become very
warm and can cause minor injuries if handled without any protection, such as
gloves
Caution: Safety to
equipment
When installing, replacing or using this product, observe all safety precautions
during handling and operation. Failure to comply with the following general safety
precautions and with specific precautions described elsewhere in this manual
violates the safety standards of the design, manufacture, and intended use of
this product.
Cobham Wireless assumes no liability for the customer's failure to comply with
these precautions. This entire manual should be read and understood before
operating or maintaining the repeater.
Attention: Electrostatic
Sensitivity
Observe electrostatic precautionary procedures.
ESD = Electrostatic Discharge Sensitive Device.
Static electricity can be conducted to the semiconductor chip from the centre pin
of the RF input connector, and through the AC connector pins. When unpacking
and otherwise handling the repeater, follow ESD precautionary procedures
including use of grounded wrist straps, grounded workbench surfaces, and
grounded floor mats.

DIGIMINI EMEA/APAC/AUSTRALIA DIGITAL REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless Date: 11-Oct-15 Cobham Wireless – Coverage
Page | VI Rev. 5.0 Document number: 00030UMCD
The Class 2 identifier, if present on the equipment label, denotes that this equipment utilizes a
frequency band that is not harmonized throughout the European community.
If installed outside the intended area, restrictions may be placed on the use of this equipment. It is
the responsibility of the purchaser to check with the national authority of the area of use whether
any such restrictions apply.
This applies to European products that support 2100Mhz. These type of products are Class 2. This
band can also be used by fixed service on a national basis.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page | VII
Table of Contents
1SYSTEM DESCRIPTION..............................................................................................1-1
1.1 Features and Capabilities.................................................................................................... 1-2
1.2 Models and Ordering Information........................................................................................ 1-3
1.3 Single Unit and Dual-Unit Installations ................................................................................ 1-3
1.4 Single Band Unit Upgradeable to Dual-band........................................................................ 1-3
1.5 Smart-ALC Function............................................................................................................ 1-3
1.6 DMCU - Optional.................................................................................................................. 1-4
1.7 DIGImini Interfaces.............................................................................................................. 1-4
1.7.1 Front Panel Interfaces................................................................................................1-5
1.7.2 Side Panel Interfaces.................................................................................................1-6
1.7.3DIGImini Power Supply..............................................................................................1-6
2ANTENNA AND REPEATER INSTALLATION REQUIREMENTS.....................................2-1
2.1 Base (Donor) Antenna Requirements .................................................................................. 2-1
2.1.1 Required Antenna Information....................................................................................2-1
2.1.2 Donor Antenna specifications .....................................................................................2-1
2.1.3 Installation Criteria.....................................................................................................2-1
2.2 Service Antenna Requirements ........................................................................................... 2-2
2.2.1 Required Antenna Information....................................................................................2-2
2.2.2 Recommended Antennas...........................................................................................2-2
2.2.3 Service Antenna Installation Criteria............................................................................2-2
2.3 Repeater Pre-Installation Requirements .............................................................................. 2-3
2.3.1 Safety Guidelines......................................................................................................2-3
2.3.2 Required BTS Information..........................................................................................2-3
2.3.3 Criteria for Repeater Installation Location ....................................................................2-3
2.3.4 RF Cable Installation Guidelines.................................................................................2-3
3SINGLE UNIT REPEATER INSTALLATION...................................................................3-1
3.1 Overview............................................................................................................................. 3-1
3.2 Required Tools and Materials.............................................................................................. 3-1
3.3 DIGImini Single Unit Kit....................................................................................................... 3-2
3.4 Mounting the Repeater........................................................................................................ 3-3
3.5 Before Connecting the Antennas or Power.......................................................................... 3-5
3.5.1 Verifying Donor and Service Antennas Isolation ...........................................................3-6
3.5.2 Verifying Link between the BTS and the Repeater........................................................3-6
3.6 Antenna Connections.......................................................................................................... 3-7
3.7 Power Up ............................................................................................................................ 3-8
3.8 What Next?.......................................................................................................................... 3-8
4QUAD-BAND REPEATER INSTALLATION ...................................................................4-1
4.1 Overview............................................................................................................................. 4-1
4.2 View of the Dual Unit Installation......................................................................................... 4-2
4.3 Required Tools and Materials.............................................................................................. 4-2
4.4 DIGImini Tri/Quad-band Kit.................................................................................................. 4-3
4.4.1 Top Layer Items........................................................................................................4-3
4.4.2 Middle layer Items.....................................................................................................4-4
4.4.3 Bottom Layer Items ...................................................................................................4-4
4.4.4 Additional Items ........................................................................................................4-5
4.5 Upgrading to a Quad-Band System...................................................................................... 4-5

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless
Page | VIII Cobham Wireless – Coverage
Document number: 00030UMCD Date: 11-Oct-15 Rev. 5.0
4.5.1 Assemble the DIGImini Units......................................................................................4-5
4.5.2 Choosing the Appropriate Plate ................................................................................ 4-10
4.5.3 Connect SMA Jumper Cables................................................................................... 4-13
4.5.4 Mount and Secure Quad-Band Assembly .................................................................. 4-14
4.6 Before Connecting the Antennas or Power........................................................................4-16
4.7 Antenna Connections........................................................................................................4-16
4.8 Power Up...........................................................................................................................4-17
4.9 What Next?........................................................................................................................4-17
5SETUP AND CONFIGURATION................................................................................... 5-1
5.1 Open a Direct Local Web Session to the Repeater............................................................... 5-1
5.1.1 Connect the Computer to the Repeater........................................................................5-2
5.1.2 Configure the Computer’s Network Parameters............................................................5-3
5.1.3 Login to the Repeater ................................................................................................5-5
5.2 Navigating the Web GUI Application.................................................................................... 5-6
5.2.1 Band Pane and Tabs.................................................................................................5-7
5.2.2 Operation Buttons .....................................................................................................5-7
5.3 Signal Levels and Channel Configuration............................................................................ 5-7
5.3.1 RF Gain Setting Criteria.............................................................................................5-8
5.3.2 Bandwidth and the Number of Available Sub-Bands .....................................................5-8
5.3.3 Adjusting the Signal Levels and Configuring Channels..................................................5-9
6ADMINISTRATION, MONITORING AND TROUBLESHOOTING...................................... 6-1
6.1 Administrative Operations................................................................................................... 6-1
6.1.1 License File Upload...................................................................................................6-1
6.1.2 Dual-band Support ....................................................................................................6-2
6.1.3 Connection to an Ethernet Network.............................................................................6-3
6.1.4 Connection to an External Modem ..............................................................................6-4
6.2 Monitoring and Troubleshooting .........................................................................................6-5
6.2.1 Repeater Alarms and Troubleshooting.........................................................................6-5
6.2.2 DIGImini LED Troubleshooting....................................................................................6-7
Appendix A: Specifications...................................................................................................1
Appendix B: EGSM 900 Frequency VS Channel Number ........................................................1
Appendix C: GSM 1800 Freq VS Channel Number..................................................................1
Appendix D: Declarations of Conformity ...............................................................................1

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page | 1-1
1 SYSTEM DESCRIPTION
Cobham Wireless’ new DIGImini repeater (digital mini repeater) is an innovative flexible multiband
coverage solution optimized for in-building applications.
Cobham Wireless’ DIGImini offers a completely new range of possibilities. With multi technology (e.g
GSM/WCDMA/LTE) applications, multiple filters are required in the operation bands. The DIGImini is
designed to provide high performance digital filters with a competitive price when compared to
legacy analogue mini repeaters.
Up to four different frequency bands can be implemented in two dual band DIGImini repeaters.
Each DIGImini repeater is available in a range of single-band and dual-band models, where specific
single-band models can be updated to dual-band (requires license).
Easy “plug and play” allows our customers to add services as needed, thus minimizing their CAPEX.
Software Defined Filtering of up to 8 sub-bands in each dual band configuration and up to 16 sub-
bands for quad band configuration.
Individual Gain and ALC settings for each sub-band for multi-technology applications (e.g. GSM/
WCDMA/LTE), as well as for single and multi-operator applications.
A state-of-the-art Interference Mitigation and Oscillation Prevention (IMOP) algorithm is used to
measure the isolation between the antennas and gain is reduced immediately to prevent oscillation.
The DIGImini is connected to one donor antenna placed on the roof of the building and the radiating
coaxial cable or antennas in the area to be covered. Configuration and monitoring of the DIGImini
can be done through an intuitive web management GUI. Remote management is done via optional
wireless modem.
With the Cobham Wireless advanced supervision and control software -AEM, the entire fleet of digital
multiband repeaters can be monitored.
Figure 1-1. Cobham Wireless DIGImini Repeater

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless
Page | 1-2 Date: 11-Oct-15
Rev. 5.0 Cobham Wireless – Coverage Document number: 00030UMCD
1.1 Features and Capabilities
•Supported bands:
•Single band - 900 MHz, 1800 MHz, 2100 MHz
•Dual-band - 700Upper/1800MHz, 700Lower/1800MHz, 900/2100MHz, 900/1800MHz,
1800/2100MHz, 1800/2600MHz ,850/1800 or 850/2100MHz.
•Basic RF parameters:
•Composite downlink Output power: +20 dBm
•Composite uplink Output Power: +20 dBm
•RF Gain: 73 dB
•Sub-bands configuration:
•Up to eight software selectable non-contiguous sub-bands per (single or dual-band)
module – the number of sub-bands depends on the configuration (refer to section
5.3.2)
•Highly accurate frequency selection and dedicated gain and power settings
•Variable bandwidth settings from 200KHz to 25 MHz
•SmartALC™ technology per sub-band:
•Automatically sets optimum gain
•Prevents oscillations and balances coverage
•Ensures transparent network operation
•Supports multi-operator functionality
•Lightweight and compact footprint for easy installation
•Continuously monitors and adapts to the RF environment via Auto gain feature
•Easy commissioning and setup via web-based browser
•Optional DIGImini External modem– provides complete remote control and monitoring
capabilities:
•WCDMA/GPRS modem support
•SMS messages
•Ethernet network connection and SNMP traps
•Battery backup – “last gasp” error reporting to AEM
•Optional upgrades via a purchased license file* (relevant for specific models):
•Single band models can be upgraded to support dual-band.
•Upgrade to support basic remote monitoring options via direct Ethernet connection to
the network (supports SNMP traps) or connection to an external modem. *
* Upgrade options for single-band to dual-band software upgrade and for remote monitoring (Ethernet network or external
modem) are implemented using two different licenses.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page |1-3
1.2 Models and Ordering Information
The following models are available.
ORDERING INFORMATION for DIGImini EMEA , APAC and Australia Repeaters
Identification Description Part Number
DIGImini 900 DIGImini single band 900MHz 20dBm D-MINI-2009
DIGImini 1800 DIGImini single band 1800MHz 20dBm D-MINI-2018
DIGImini 2100 DIGImini single band 2100MHz 20dBm D-MINI-2021
DIGImini 700/1800 DIGImini 700/1800 20/20dBm upper
part of 700Mhz
D-MINI-2007-2018
DIGImini 700/1800 DIGImini 700/1800 20/20dBm lower part
of 700Mhz
D-MINI-2007-2018-L
DIGImini 900/2100 DIGImini 900/2100 20/20dBm D-MINI-2009-2021
DIGImini 1800/2600 DIGImini 1800/2600 20/20dBm D-MINI-2018-2026
DIGImini 1800/2600
DIGImini 1800/2600 20/17dBm for
Australia D-MINI-2018-1726-AUS
DIGImini 900/1800 DIGImini 900/1800 20/20dBm D-MINI-2009-2018
DIGImini 1800/2100 DIGImini 1800/2100 20/20dBm D-MINI-2018-2021
DIGImini 850/1800 DIGImini 850/1800 20/20dBm D-MINI-2008-2018-AUS
DIGImini 850/2100 DIGImini 850/2100 20/20dBm D-MINI-2008-2021
DIGImini GPRS Modem External GPRS modem (900/1800MHz) DMCU
DIGImini WCDMA Modem
External WCDMA (Telit 864) modem
(2100MHz) DMCU-WCDMA
DIGImini Accessory kit DIGImini 4 bands accessory upgrade kit D-MINI-4B-AK
1.3 Single Unit and Dual-Unit Installations
DIGImini installation varies depending on whether one or two units are installed:
•Single DIGImini unit (supports single-band or dual-band) – details in Chapter 3.
•Dual DIGImini assembly (up to four bands) – details in Chapter 4
1.4 Single Band Unit Upgradeable to Dual-band
Single-band units can be upgraded to support two bands by acquiring the appropriate license file
from Cobham Wireless support team.
1.5 Smart-ALC Function
The Smart Automatic Level Control (Smart-ALC) is an innovative algorithm for automatic repeater
gain adjustment per sub-band.
Combined with advanced control algorithms, SALC is capable of learning the traffic load
characteristics and adjusting the Repeater RF Gain to the desired value.
Smart ALC eliminates the need to perform initial settings for maximal traffic load conditions and on-
site gain adjustments.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless
Page | 1-4 Date: 11-Oct-15
Rev. 5.0 Cobham Wireless – Coverage Document number: 00030UMCD
Smart-ALC maintains the Uplink/Downlink gain balance for system transparency. In addition, Smart-
ALC prevents oscillations that may occur due to insufficient isolation while maintaining the gain in a
linear range operation by adjusting the repeater paths’ gain accordingly.
IMOP (Isolation Measurement and Oscillation Prevention) algorithm effectively reduces oscillation
problems.
The repeater’s power amplifier includes power-monitoring circuits with Automatic Level Control (ALC)
that prevents excessive output power while maintaining the power amplifier linearity.
1.6 DMCU - Optional
The DMCU (DIGImini Control Unit) provides complete remote control and monitoring capabilities over
WCDMA/GPRS, including Remote control via SMS.
The DMCU is an optional control unit that is ordered separately. The DMCU is installed externally,
where one DMCU can support a single DIGImini unit as well as an a DIGImini Quad-band assembly.
NOTE: Refer to the DMCU User Manual for the complete description of the DMCU and the
configuration and management capabilities provided by the unit.
1.7 DIGImini Interfaces
The DIGImini is supplied in two physical configurations: Single unit supporting (one or) two bands;
two cascaded units supporting up to four bands. Power supplies
dedicated to each unit are
connected externally.
An optional DMCU supporting an external modem is also connected externally, where a single DMCU
can serve two cascaded units.
The interfaces are located on the
front and on the side panels.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page |1-5
1.7.1 Front Panel Interfaces
The image below shows the unit (the wallmount bracket is not shown).
Figure 1-2: DIGImini Dual-Band Front Panel
The following table provides a description of the front panel connectors.
Port Description
MOBILE Service antenna connections.
BASE Donor antenna connections.
DC Power (12V) Circular, 4-PIN.
RJ 45 Used for setup.
ATTENTION!! Do not connect to the network unless you have purchased
either the DMCU or the external modem support license file.
If the support for external modem License file is acquired, the Ethernet port
can also be connected to the network or used to connect to an external
modem.
*Not in use. Termination is NOT required.
The following table provides a description of the front panel LED indicators (see 6.2.2 for more info).
LED Description
Band specific LED
(e.g. 850, 1900, etc) Downlink path status and RSSI indication:
MNG Relevant only if connected to DMCU:
CCD Operation status
MODEM Relevant only if connected to DMCU:
DMCU Modem operation status
Status LEDs
N/A*
Power Mobile N/A* Base ETH
RJ45

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless
Page | 1-6 Date: 11-Oct-15
Rev. 5.0 Cobham Wireless – Coverage Document number: 00030UMCD
1.7.2 Side Panel Interfaces
The DIGImini side panel supports the DMCU interfaces and the side bolts used for hanging the unit
on the wall bracket. For DMCU interfaces descriptions refer to the DMCU User Manual.
Figure 1-3. DIGImini Side Panel
Side Connector Description
Modem DMCU Modem Antenna connection - relevant for installation with
a DMCU.
RS485 RS485 connection to DMCU option.
1.7.3 DIGImini Power Supply
The power supply requires assembly only during an upgrade procedure from a dual-band to a triple-
band or quad-band solutions in which two DIGImini units are cascaded. Otherwise, it is
preassembled.
Figure 1-4: Repeater Power Supply
Connect to 110/240
VAC power source
Connect to Front
panel DC power
(12V) connector
DMCU Antenna
connection
DMCU RS485
connection

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page | 2-1
2 ANTENNA AND REPEATER INSTALLATION
REQUIREMENTS
This chapter provides information on the specifications of the donor and service antennas suitable for
operation with this repeater, on the installation requirements of the antennas and on the Repeater
installation site and cable requirements.
2.1 Base (Donor) Antenna Requirements
The Base (Donor) antenna is usually installed outdoors and is either a directional antenna such as a
Yagi or a Panel antenna.
2.1.1 Required Antenna Information
You will require the following antenna information
•Antenna type and characteristics
•Height
•Length and type of coaxial cable required for connecting the Donor antenna to the Repeater and
the attenuation.
2.1.2 Donor Antenna specifications
•Yagi type or similar – 8 to 13 dBi gain, very sharp beam pointed to the BTS.
•Cable and jumper loss is at least 2dB.
•Example of antenna's typical specifications:
Gain: 8 dBd (=10.1 dBi)
VSWR: < 1:5:1
Impedance: 50 ohm
2.1.3 Installation Criteria
Installation requirements:
•Select a location for the Donor antenna and verify that there is enough signal strength at that
location.
•Install the Donor Antenna at the designated height.
•The antenna should point to the direction of the base station for maximum input power.
•Verify that the antenna is in the base stations line of sight (raise the antenna if necessary).
•Install the donor antenna at a higher level (i.e. floor) than the mobile antenna.
•Must be installed at a minimum distance of 20cm from any personnel within the area.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless
Page | 2-2 Date: 11-Oct-15
Rev. 5.0 Cobham Wireless – Coverage Document number: 00030UMCD
2.2 Service Antenna Requirements
The Service antenna is installed indoors, where the type of antenna depends on the application.
2.2.1 Required Antenna Information
The following antenna requirements, specifications and site considerations should be met.
•Service area type and size
•Antenna type and characteristics
•Height
•Length and type of coaxial cable required for connecting the antenna to the Repeater and the
attenuation.
2.2.2 Recommended Antennas
The following describes the requirements for an omni-directional mobile used for indoor applications.
Specifications:
•One or a combination of the following antennas can be used: Ceiling Mount Patch antenna, Wall
Mount Patch antenna, Corner Reflector.
•Omni directional antenna with a 0 to 2 dBi typical gain, or wide beam with up to 10 dBi gain.
•Example of omni-directional antenna specifications:
Gain: 0 to 2 dBi
VSWR: < 2:1
Impedance: 50 ohm
•Choose an antenna with high side lobe attenuation which enables maximum isolation from the
service/ mobile antenna.
2.2.3 Service Antenna Installation Criteria
Determine the antenna installation configuration, according to the transmission requirements and the
installation site conditions.
Installation requirements:
•An indoor antenna should be installed at a convenient location. It should be free of metallic
obstruction.
•Install the Service Antenna at the designated height and tune it roughly toward the Service
coverage area.
•Installation of this antenna must provide a minimum separation distance of 20cm from any
personnel within the area.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page |2-3
2.3 Repeater Pre-Installation Requirements
2.3.1 Safety Guidelines
Before installing the Repeater, review the following safety information:
•Follow all local safety regulations when installing the Repeater.
•Only qualified personnel are authorized to install and maintain the Repeater.
•Ground the Repeater with the grounding bolt located on the external lower side of the Repeater).
•Do not use the grounding bolt to connect external devices.
•Follow Electro-Static Discharge (ESD) precautions.
•Use low loss cables to connect the antennas to the Repeater.
2.3.2 Required BTS Information
Required BTS Information
•BTS channels
•BTS output power per channel
•BTS antenna gain
•BTS antenna height
•Distance from Repeater site to BTS
2.3.3 Criteria for Repeater Installation Location
The following criteria should be considered when selecting the Repeater installation site location:
•Application type
•General surroundings
•Available installation
•Install the Repeater in a shielded, ventilated, and easy-to-reach area.
•Verify that there is a minimum of a 50 cm (20”) radius of space around the Repeater, enabling
easy access to the repeater for maintenance and on-site inspection.
•Distance from antenna site - It is recommended that the installation location be as close as
possible to the antenna site in order to maintain the cable loss to a minimum.
•The Repeater is convection cooled so airflow and alternation should be possible.
•Follow Electro-Static Discharge (ESD) precautions.
•Install the Repeater close to the service area to monitor the output power.
•Use low loss cables to connect the antennas to the Repeater.
2.3.4 RF Cable Installation Guidelines
Required:
•For all coaxial connections to/from the Repeater - high performance, flexible, low loss 50Ω
coaxial communications cable.
•All cables shall be weather-resistant type.
•Cable length - determined by the Repeater installation plan. When calculating the cable length,
take into account excess cable slack so as not to limit the insertion paths.

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless –Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UMCD Rev. 5.0 Page | 3-1
3 SINGLE UNIT REPEATER INSTALLATION
This installation is relevant for a single DIGImini unit supporting either a single-band or a dual-band.
3.1 Overview
NOTE: The Donor and Mobile antennas can be positioned and installed ( without being connected
to the Repeater ) at any time either before or after mounting and grounding the Repeater.
1. Unpack the Repeater kit.
2. Mount the Bracket on the wall, hang the Repeater and Power Supply on the bracket (do not
connect power).
3. Perform the required isolation and link tests.
4. Connect the antennas.
5. Power-on the Repeater.
6. If a DMCU is available, mount the unit (adjacent to the Repeater, on the wall and connect to the
Repeater according to the DMCU User Manual).
3.2 Required Tools and Materials
The following is required in order to install the Repeater:
•Standard professional tool box
•A computer (i.e. laptop for running the setup)

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless
Page | 3-2 Date: 11-Oct-15
Rev. 5.0 Cobham Wireless – Coverage Document number: 00030UMCD
3.3 DIGImini Single Unit Kit
Upon receiving the Repeater, perform the following:
1. Examine the shipping container for damage before unpacking the unit.
2. Perform a visual inspection to reveal any physical damage to the equipment.
3. Verify that all of the equipment (listed below) is included. Otherwise contact Cobham Wireless.
DIGImini Repeater Kit
Description Image
DIGImini Repeater
Wallmount Bracket
Repeater Power Supply (12V)
2 x Ties for securing power supply
CD with documentation
Ethernet Cross-cable
4 x Repeater Mounting Bolts
