iCatch LZW-RT02512-IN User manual

This equipment has been followed with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or teleiCATCH reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and correct
the interferene by one of the following measures:
-Reorient or relocate the receiving antenna,
-Increase the separation between the equipment and receiver,
-Connect the equipment into and outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undersired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Limited Warranty
ICATCH Guarantees that every wireless repeater is free from physical defects in material
and workmanship under normal usage for one year from the date of purchase. If the
product proves defective during this one-year warrany period, ICATCH will replace it free of
charge. ICATCH does not issue any refunds. This warnnty is extended to the original end
user purchase only and is not transferable. This warranty does not apply to : (1) damage to
units caused by accident, dropping or abuse in handling, or any negligent usage; (2) units
which have been repaired, taken apart, or modified by an unauthorized personnel; (3) units
not used in accordance with instruction; (4) damanges exceeding the cost of the produt; (5)
transit damage, initial installation costs, removal cost, or reinstallation cost.
For information on addional devices, plesae visit us at www.icatchinc.com
Installation & Operation Manual
LZW-RT02512-IN
LZW-RT02512-MY
LZW-RT02512-EU
LZW-RT02512-RU
LZW-RT02512-US
LZW-RT02512-IL
LZW-RT02512-KR
LZW-RT02512-HK
LZW-RT02512-BR
LZW-RT02512-JP
Z-Wave Repeater
Federal Communications Commission Statement
LZW-RT02512
V1
20150803
-3-

Introduction
Thanks for choosing the ICATCH’s repeater of the home automation device. This module is
a Z-Wave™ enabled device (interoperable, two-way RF mesh networking technology) and
is fully compatible with any Z-Wave™ enabled networkand it’s security firmware. Every
main powered Z-Wave enabled device acts as a signal repeater and multiple devices result
in more possible transmission routes which helps eliminate “RF dead-spots”
Z-Wave™ enabled devices displaying the Z-Wave™ logo can also be used with it regardless of the manufacturer, and ours can also be used in other manufacturer’s Z-Wave™ enabled networks. This device take existing Z-WAVE signal, repeat and send it
to a longer range where it is too far away for the controller (supporting FLiRS devices).
When the device is secure included into Z-Wave network, above communication will be
encrypted.
Product Description and Specification
*** For indoor use only ***
Specification:
Package Content:
Protocol: Z-Wave™(ZM4102)
Frequency Range:
865.22MHz (LZW-RT02512-IN)
868.10MHz (LZW-RT02512-MY)
868.42MHz (LZW-RT02512-EU)
869.00MHz (LZW-RT02512-RU)
908.42MHz (LZW-RT02512-US)
916.00MHz (LZW-RT02512-IL)
919~923MHz (LZW-RT02512-KR)
919.80MHz (LZW-RT02512-HK)
921.42MHz (LZW-RT02512-BR)
922-926MHz(LZW-RT02512-JP)
Operating Range: Up to 200 meters
Operating Temp.: -10°C~ 60°C (14°F ~140°F)
Operating Voltage: 5V/DC
Current Consumption: 300mA (±50mA)
1pc
1pc
1pc
1pc
LZW-RT02512 Repeater module
LZW-RT02512 Repeater Bracket
Adapter (Optional)
Installation & Operation Manual
Z-Wave™Command Class:
COMMAND_CLASS_ASSOCIATION_GRP_INFO
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_SECURITY
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_ZWAVEPLUS_INFO
※Note: Suitable adapter specification:
-Micro USB Power Input
-Operating Voltage: 5V/DC
-Current Consumption: 500mA
Installation
Notice: If you are installing the entire Z-Wave™ system for the first time, please refer to the installation guide of Z-Wave™ Interface Controller before installing LZW-RT02512 Repeater Module.
1. Fix the repeater under the vertical way as high as possible then insert the suitable Micro USB
Power Adaptor to the LZW-RT02512 then it will go to the Learning Mode automatically. (The
LED will start flash which means the repeater has not been “Include”yet.)
2. For “Inclusion” in (adding to) a network: Put the Z-Wave™ Interface Controller into“inclusion” mode and following its instruction to add the LZW-RT02512 to your controller. To get into the
“inclusion” mode, the distance betweenmodule and controller is suggested to be in one meter.
Press the program switch on the LZW-RT02512 once to be included. The LED should stop
flashing, if not, please try again.
For “Exclusion” from (removing from) a network: Put the Z-Wave™ InterfaceController into
“exclusion” mode, and following its instruction to delete the LZW-RT02512 from your controller.
Press the program switch on the LZW-RT02512 once to be excluded.
Note: LED setting light will flash continuously in Exclusion condition.
For “Association”: Support one association group (5 nodes).
3. Use “Power Level Set”command for setting the strength of RF during one period.
4. Use “Power Level Test Node Set”command to test the direct signal for fixed node.
5. Support Repeaters for routing (FLiRS included)
6. Support Explorer Frame function
7. Press Program Switch for 5 seconds, the LZW-RT02512 will reset back to factory default.
(Remark: This is to be used only in the case of primary controller being inoperable or otherwise
unavailable.)
8. Support OTA Firmware update from controller. Please refer to your controller manual.
5. Security enabled_ Z-Wave controller must be used to fully utilize the product.
6. Lifeline group used command : {COMMAND_CLASS_DEVICE_RESET_LOCALLY,
DEVICE_RESET_LOCALLY_NOTIFICATION}
★The LZW-RT02512 operating range will be up to 200 meters open site
under the correct installation!!
(2)
(1)
Micro USB Power Input
Program Switch
Release the bracket:
(1) Press
(2) Slide down to release the bracket
-1-
-2-
