TPBoost LB-1-3-8B User manual

Tri-Band Home Repeater Kit
a
s
s
u
r
a
t
y
n
l
i
c
a
u
e
Q
10 1010
yearsyearsyears
LB-1-3-8B
Model Number Network standard Uplink Downlink
1920-1980MHz
1710-1785MHz
890-915MHz
1850-1910MHz
1710-1755MHz
824-849MHz
2110-2170MHz
1805-1880MHz
935-960MHz
1930-1990MHz
2110-2155MHz
869-894MHz
Band 1
Band 3
Band 8
Band 2
Band 4
Band 5
C e l l S i g n a l B o o s t e r
TPBOOST
LB-2-4-5B
Outdoor Antenna
Cable
Power Adapter
Up to 1,000m sq Voice/3G/4G
AGC/ALC
Antenna
DC 5V
LCD Display
Black or White Colour

Cable
Outdoor Antenna
Indoor Signal Amplier
Power Cable
Cellphone
Mobile Repeater Installation Scheme
Above 30 feet horizontal or
vertical for best performance
Product features
Installation Steps
1. Install the outdoor antenna and ensure that the position can receive a better signal.
2. Use the outdoor antenna to connect the Indoor Signal Amplifier through coaxial line.
3. Adjust the Indoor Signal Amplifier position and ensure that the distance between the
Indoor Signal Amplifier and the outdoor antenna is more than 30 feet horizontal or vertical.
4. Connect the Power Supply on the side of the Indoor Signal Amplifier.
5. Reboot the telephone to check whether the signal situation becomes good or not. If not,
please adjust the position of the outdoor antenna.
6. Try to make call to see whether the communication signal by phone is clear and fluent or not.
Adjust the indoor and outdoor antenna position depending on the circumstances.
Base station
◆ Small size, easy installation
◆ Higher uplink / downlink isolation
◆ Faster data downloads
◆ Reasonable heat dissipation
◆ Receiving amplifier tube with the ultra low noise
◆ Automatic level control technology
◆ Improved indoor cellular voice and data signal
◆ Up to 2 hours additional talk time in weak-signal areas
Outdoor Antenna
Indoor Signal Amplier
Power Cable
Normal：Screen displays values.
Product self excitation：Screen flicker，The outdoor
antenna is too close to the Indoor Signal Amplier

Booster
Antenna LocationAntenna Location
Antenna Location Antenna Location
Antenna Location
15' to 25' 15' to 25'
15' to 25'
15' to 25'
15' to 25'
Wall
Antenna
√×
×
Never face to face
Never face to Back
Antenna
15' to 25'
Back to Back

Lanbowan Technology Ltd.
Bldg. #3, NO.60 LangBao Xi Road, ChanCheng, Foshan, China
Tel: [phone] Fax: [phone] http://www.tpboost.com
Technical Parameters
Items Uplink Downlink
Max.Gain ＞55 dB ＞55dB
Automatic Gain Control ＞20dB
Bandwidth Wide Band
Ripple in Band ≦10dB
Max. Input Power Without Damage -10 dBm
Output Power 10 ~ 15 dBm 10 ~15 dBm
Intermodulation Products 9KHz~1GHz
1GHz~12.75GHz
≦-36 dBm
≦-30 dBm
≦-36 dBm@Po≦15dBm
≦-30 dBm@Po≦15dBm
Spurious Emission 9KHz~1GHz
1GHz~12.75GHz
≦-36 dBm
≦-30 dBm
≦-36 dBm
≦-30 dBm
Spurious Emission Mask
Modulation Accuracy
Peak Code Domain Error
Noise Figure @ max. gain
Return loss
Time Delay
MTBF
Power Supply
Power Consumption
Impedance 50 ohm
< 10W
AC：110-240V, 50/ 60Hz；DC：5V 2A
＞50000 hours
≦0.5μs
≦-10 dB
≦8 dB（Typical）
Complies with 3GPP
Complies with 3GPP
Complies with 3GPP
Specifications
Dimensions (D x W xH )
Weight
Installation Type
Environment Conditions
Humidity
Operating Temperature
235*185*70mm
1.3Kg
Desktop Installation
IP40
< 90%
-10℃~55℃
Warning:
1. Please read the installation instructions and precautions before installation. Misuse can
result in equipment damage.
2. All device interfaces are charged. Don't touch water!
3. Outdoor antenna is our special product. Never attempt to add another antenna.
4. Reconstruction or connection to other brands of the power adapter without permission is
prohibited !
Installation Notes
A、When installing the outdoor antenna, it's position should be able to receive a good signal.
B、The re-transmission signal of indoor amplifier can't be received by outdoor antenna.
Ensure that the distance between the Indoor Signal Amplifier and the outdoor antenna
greater than 30 feet horizontal or vertical.
C、Indoor amplifier is for indoor use only .Please avoid moisture and water.
C e l l S i g n a l B o o s t e r
TPBOOST
