Cobra 18 WXST II Operating instructions

1
Contents
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
The CB Story . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A1
Licensing/Warning/Included Accessories. . . . . . . A1
Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . A2
OurThanks to You. . . . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . A3
Operating Your CB Mobile Radio
Installation/Connection. . . . . . . . . . . . . . . . . . . . . . . . . . 2
Turning On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
CB Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Microphone Connector . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Squelch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Setting Squelch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Channel Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Channel 9/19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CB/Weather. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DualWatch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Scan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Soundtracker System . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Activating Soundtracker System. . . . . . . . . . . . . . . . . 11
S/RF Power Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
RX/TX Indicator LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Antenna Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
External Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Ignition Noise Interference. . . . . . . . . . . . . . . . . . . . . . 14
Temporary Mobile Operation. . . . . . . . . . . . . . . . . . . . 14
Operation to Receive/Transmit . . . . . . . . . . . . . . . . . . 15
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Frequency Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
If You Think You Need Service . . . . . . . . . Back Cover
Featuresof ThisProduct
• 40CBRadio Channels
• 10WeatherChannels
• SoundtrackerTMSystem
• InstantChannel19 and9
• 40ChannelScan
• DualWatch
• FrontFiringSpeaker
• ChannelSaverCircuitry
• DynamicMicrophone
• 9Foot MicCord
• FrontPanelMicrophone
Connector
How to Use Your
Cobra 18WXST II
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 1

3
4Connect the redlead of DC power cord to an
accessory 12 voltfuse.
5Connect the orange lead toa constant12v fuse
(ie:cigarette lighter or direct to battery)
6Connect the black leadto thenegativesideof
the automobile.This is usually the chassis.Any
convenient locationwith good electricalcontact
(remove paint)maybe used.
7Mount the microphone bracket on rightsideof
the transceiver ornear it usingtwo screws sup-
plied.When mounting in an automobile,place
the bracket under thedash so the microphone
isreadilyaccessible.
8Attach the 4-pin microphone cable to recepta-
cle on front of unit and install unit in bracket-
securely.
Mounting and
Connections
Note
Before installingtheCBradio,
visuallycheckthevehicle bat-
teryconnectionstodetermine
whichbatteryterminal,posi-
tiveornegative(positive is the
largerofthetwo)isgrounded
totheengineblock
(orchassis).
Operation
2
Mounting andConnections
Select a locationfor the transceiver and micro-
phonebracketthat is convenientforoperation.
Inautomobiles,thetransceiver is usually mounted
totheunderneathof the dash panel,with the
microphone bracket besideit.
1Hold theradio with mountingbracket in the
exactlocationdesired.Remove the mounting
bracket and use it as atemplateto mark the
location for the mounting screws.
2Drill necessary holes and securemounting
bracket in location.
3Connect theantenna cable plug tothe recepta-
clemarked“ANT”on the back of the unit.
Mounting and
Connections
Note
Thetransceiverisheld in the
universalmountingbracketby
two thumbscrews,permitting
adjustmentatthemost conve-
nientangle.
Auniversalmountingbracket
issuppliedalongwith self tap-
pingscrewsandstarwashers.
Tomountthetransceiver:
OperationInstallation Installation
CB Transceiver
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 2

5
MicrophoneConnector
Allows for convenientremoval of the microphone
plug when storageisrequired.Themicrophone
MUSTbe connected to the unit at all times when in
use,for properoperation.
Squelch
This controlis used to cut off or eliminate receiver
background noisein theabsence of an incoming
signal. Adjust untilthe receiver noise disappears.
This will require theincomingsignal to beslightly
stronger than average receivernoise.Further clock-
wise rotation will increase the threshold level
which a signal must overcome inorder tobe heard.
Only strong signals will beheard at a maximum
clockwise setting.
Microphone
Connector
Operation
Squelch
4
Turningon
Turn volume control clockwiseto turn power on
and set the desired listening volume.
CB Antenna
Only a properly matched antenna system will
allow maximum power output.
In mobile installations (cars,trucks,boats,etc.),
an antennasystem that is non-directional should
be used.
When installed in a boat,thetransceiver will not
operate at maximum efficiency without a ground
plate unless the vessel has asteel hull.Before
installing the transceiver in a boat,consult your
dealerforinformation regarding an adequate
grounding system.
Turning on
Your Radio
Operation
CB Antenna
Note
Cobraloaded-typeantenna
modelsHGA1000,HGA1500,
andHGA2000arehighlyrec-
ommendedformostinstalla-
tions. ConsultyourCobradeal-
erforfurtherdetails(orsee
orderformatthebackof
thisbook).
3-WayCombinationAntennas
areavailablewhichallowoper-
ationofallthreebands(AM-FM
&CB),usingasingleantenna.
However,useofthistypeof
antennausuallyresultsinless
than normaltransmit and
receiverangewhencompared
to astandard-type"Single
Band" antenna designedfor
CBonly.
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 4

7
3. To achieve the DesiredSquelch Setting(DSS),
turnthe Squelchcontrolcounterclockwiseuntil
you hear noise. Now turn the control clockwise
just untilthe noise stops. This is the DSS setting.
Operation
Gateset to Desired
SquelchSetting (DSS)
6
Operation
Gateopen
Gateclosed
Setting
Squelch
Setting Squelch
Squelch is the “control gate”for incoming signals.
1. Fullclockwise rotation closes the gate
allowing only very strong signals to enter.
2. Fullcounterclockwise rotation opens the“gate”
allowing all signals in.
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 6

9
DualWatch
Thisfeatures allows the user to scan between two
selectedchannels.
1. Select first channel,CB mode.
2. Press andhold DW until LEDbegins flashing and
beepsonce.
3. Select second channel.Press DWuntil LEDlights
steady and radio beeps twice. Twochannelsare
now stored inDW memory.
Scan
Press and release SCANbutton to activateCB scan
mode.If the radio is squelched,radio begins toscan.
When scanisinterrupted by a signal,scan stops and
holds until loss of signal.Press PTT on mic tostop
scanfunction. Press Scan to restart CB scan.
Channel
Selection
Operation
8
Set CB orWX Mode
Set on CB mode. Rotate channel knobclockwise
until desiredchannel is displayed.
Channel 9/Channel 19
PressCH9/19toobtaininstantaccess toemergency
channel 9.Press again forinformation CH 19.
CB/Weather
CBmode is for normal CB operation.Press
CB/WeatheragainandselectactiveWeatherchannel
inyourarea.
Operation
PRESS AND RELEASE
Channel 9/
Channel 19
CB Weather
Dual Watch
Note
Theradioneedstobe
squelchedbeforeDWcan
monitorbothchannels.
Scan
Note
Onsomechannelssquelch
settingmighthavetobe re-set.
PRESS AND HOLD
PRESS AND RELEASE
PRESS AND RELEASE
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 8

11
Activating Soundtracker
1. Press the SoundTracker button on the upper
left side of front panel.A red indicator will
illuminate when the SoundTracker system is
engaged.
Activating
Soundtracker
Operation
10
The SoundTracker System reduces noise while
leaving the signal intact in the reception mode.
In the transmission mode, it strengthens the sig-
nal,providing you with a significant reduction in
noise on reception and transmission.
How SoundTracker works
On Reception– “CutsNoiseComingIn”
With a normal CB,distant signals fall below the
squelch level and are unintelligible.With a
SoundTracker CB,the noise level is cut by up to
90%,which increases the signal-to-noise ratio
and dramatically improves signal clarity.This also
allows you to significantly reduce the squelch
level,which greatly expands your listening range.
OnTransmission– “Strengthens Signals Going Out”
A SoundTracker CB strengthens the transmit sig-
nal by more effectively using the available RF
power output of the CB.The result is improved
transmission signal clarity and an expanded
transmission range.
Soundtracker
System
Operation
PUSH AND RELEASE
USPat.No.6,038,429
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 10

13
Rear Panel
AntennaConnector.This female connector per-
mits connection of the transmission line cable
male connector to the transceiver.
ExternalSpeaker.The External Speaker Jack is
used for an external speaker.The external speak-
er should have 8-ohm impedance and be rated
to handle at least 4.0 watts.When the external
speaker is plugged in,the internal speaker is
automatically disconnected.
Power:This cable is permanently attached to the
radio.If you wish to remove the radio after instal-
lation,disconnect at fuse holder and ground
connector.
Antenna
Connector
Operation
12
S/RF Power Meter
Shows relativetransmitterRF outputpower and
input signal strengthwhenreceiving.TheLED
(LightEmitting Diode) segments glowgreen to
amberto red...this indicatesreceiveor transmit
activity.
RX/TXIndicatorLED
RX indicator will light when in the receivemode.
TXindicatorlightswhenin transmitmode.
When weather channelis selected,WXindicatoris
illuminated, and the channelis displayed.
S/RF
PowerMeter
Operation
RX/TX
Indicator LED
External
Speaker
Power
Note
Cobraexternalspeakersare
rated15 watts
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 12

15
Operating Procedure to Receive
1. Be sure that power cord, antenna and microphone are connected to the
proper connectors before proceeding further.The weather switch should
be in the "CB" position.
2. Turn the radio ON by rotating the VOLUME CONTROL clockwise.
3. Rotate SQUELCH CONTROL counterclockwise until incoming signal is
heard.
4. Select the desired channel.
5. Set VOLUME CONTROL to a comfortable listening level.
6. Engage the SoundTracker system by depressing the button labeled ST.
Listen to the background noise from the speaker.Turn the SQUELCH CON-
TROL slowly clockwise until the noise JUST disappears (no signal should be
present).Leave the control at this setting.The squelch is now properly
adjusted.The receiver will remain quiet until a signal is actually received.Do
not advance the control too far, or some of the weaker signals will not be
heard.The revolutionary SoundTracker system allows you to reduce
unwanted background noise (static) and increase the signal for better
reception.
Operating Procedure to Transmit
1. Select the desired channel.
2. The receiver and transmitter are controlled by the press-to-talk switch on
the microphone. Press the switch and the transmitter is activated;release
switch to receive.When transmitting (on a clear channel),hold the micro-
phone two inches from the mouth and speak clearly in a normal voice.
Be sure the antenna is properly connected to the radio before transmit-
ting.Prolonged transmitting without an antenna,or a poorly matched
antenna,could cause damage to the transmitter.
Operation
14
Ignition Noise Interference
Use of a mobile receiver atlow signal levels isnor-
mally limited by the presence of electricalnoise.
Undermostoperatingconditions,whensignal
levelisadequate,the background noise does not
presenta serious problem.Also,whenextremely
low level signals are being received, the transceiver
may be operated withvehicle engineturnedoff.
The unit requiresvery little currentandtherefore
will not significantly discharge thevehiclebattery.
Even though this radiohas an automatic noise lim-
iter,insomeinstallationsignitioninterference may
be high enough tomakegood communications
impossible.Consult your COBRAdealer ora2-way
radio technician for helpin locating and correcting
the source of severenoise.
TemporaryMobileOperation
Fortemporary mobile operation,youmaywantto
purchase an additional cigarette lighter adapter
fromyourCOBRAdealer.This adapter and a mag-
netic mount antennaallow you to quickly "install"
yourtransceiverfortemporaryuse.
Operation
Ignition Noise
Interference
Temporary
Mobile
Operation
Note
Redand Orange wires arecon-
nectedtopositivesideofsocket
centertip.Blackwireisconnect-
ed tonegative sidecontacts.
Note
Radioresets toCH 9 whencon-
nected tocigarettelighterplug.
Note
Whenusingtheunitwithcig-
aretteadapter,turnoffwhen
notinusetoavoiddraining
the battery.
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 14

16
Maintenance/
Adjustment
Maintenance
Maintenance and Adjustment
Your COBRA CB transceiver is specifically
designed for the environment encountered in
mobile installations.The use of all solid state cir-
cuitry and its light weight result in high reliabili-
ty.Should a failure occur,however, review the fol-
lowing,then if necessary,replace parts only with
identical parts. Do not substitute.
1. Check connections to the source of power and
make sure it is the 13.8 VDC required to oper-
ate your radio.
2. Check the fuses in the DC power cord.The
main power lead (red & orange wire) has a 2
amp 3AG type fuse in its holder.Use only the
above specified type and size fuse for maxi-
mum protection. Failure to do so,will void the
warranty.
3. Make certain the microphone is properly
plugged in.
4. Make certain the antenna is properly assem-
bled and connected.
If you are unable to correct the problem, refer to
the SERVICE INSTRUCTIONS at the end of this
manual for the correct procedure for warranty
and post-warranty service from COBRA.
Permitted:"A tornado sighted six miles of town."
Not Permitted : "This is observation post number 10.
No tornado sighted."
Warning
17
Channel 9
Emergency
Messages
Replacement Warning
Replacement or substitution of certain parts with
replacements other than those recommended by
Cobra may be a violation of the technical regula-
tions of Part 95 of the FCC rules, or of Type
Acceptance requirements of Part 2 of said rules.
When making adjustments,be sure to re-read
applicable portions of this instruction manual to
makecertain you are following correct procedure
and that the radio was properly installed,etc.
A Few Rules That Should Be Obeyed
1. You are not allowed to carry on a conversation with
another station for more than five minutes at a time with-
out taking a one-minute break to give others a chance to
use the channel.
2. You are not allowed to blast others off the air by overpow-
ering them with illegally amplified transmitter power or
illegally high antennas.
3. You can't use CB to promote illegal activities.
4. You are not allowed to use profanity.
5. You may not play music in your CB.
6. You may not use your CB to sell merchandise or profes-
sional service.
Use Channel 9 For Emergency Messages Only
The FCC gives the following examples of permit-
ted and prohibited types of communications for
use on Channel 9. These are guidelines and are
not intended to be all-inclusive.
A Few Rules
You Should
Know
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 16

19
Accessories
18
Specifications
Specifications
GENERAL
CHANNELS. . . . . . . . . . . . . . . . . . . . . . . CB - 40 CH
WEATHER – 10CH
FREQUENCY RANGE. . . . . . . . . . . . . . . CB - 26.965 TO 27.405 MHZ
WEATHER – 161.650 TO 163.275
FREQUENCYTOLERANCE. . . . . . . . . . 0.005 %
FREQUENCY CONTROL . . . . . . . . . . . . PLL (PHASE LOCK LOOP) SYNTHESIZER
OPERATING TEMPERATURE
RANGE. . . . . . . . . . . . . . . . . . . . . . . . . . . -30° C TO + 65° C
MICROPHONE . . . . . . . . . . . . . . . . . . . . PLUG-IN DYNAMIC
INPUT VOLTAGE . . . . . . . . . . . . . . . . . . 13.8VDC nom.(negative ground)
CURRENT DRAIN TRANSMIT:AM FULL MOD.,1.4A (MAXIMUM)
RECEIVE:SQUELCHED, 0.9 A;
FULL AUDIO OUTPUT, 1.2A (NOMINAL)
SIZE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7/8”D X 6-3/4”W X 1-7/8”H
WEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . .4.25 LBS.
ANTENNA CONNECTOR . . . . . . . . . . . .UHF;SO-239
METER . . . . . . . . . . . . . . . . . . . . . . . . . . .LED;INDICATES RELATIVE POWER
OUTPUT AND RECEIVED SIGNAL STRENGTH
TRANSMITTER
POWER OUTPUT . . . . . . . . . . . . . . . . . .4WATTS
MODULATION . . . . . . . . . . . . . . . . . . . .AM (AMPLITUDE MODULATION)
FREQUENCY RESPONSE . . . . . . . . . . . .300 TO 3000 HZ
OUTPUT IMPEDANCE . . . . . . . . . . . . . .50 OHMS,UNBALANCED
RECEIVER
SENSITIVITY . . . . . . . . . . . . . . . . . . . . . . .LESS THAN 1 µV FOR 10dB (S+N)
SELECTIVITY . . . . . . . . . . . . . . . . . . . . . .6 dB @ 7 KHZ,60 DB @ 10KHZ
IMAGE REJECTION . . . . . . . . . . . . . . . . .60 dB,TYPICAL
ADJACENT-CHANNEL REJECTION . . .50 dB,TYPICAL
ATOMATIC NOISE LIMITER . . . . . . . . . .BUILT-IN
WEATHER
SENSITIVITY . . . . . . . . . . . . . . . . . . . . . . .LESS THAN 1 µV FOR 12 dB SINAD
IF-FREQUENCY . . . . . . . . . . . . . . . . . . . .DUAL CONVERSION
AUDIO OUTPUT . . . . . . . . . . . . . . . . . . .MAXIMUM 1 W AT 10% DISTORTION
FREQUENCY RESPONSE . . . . . . . . . . . .300 – 3000 HZ AT -6 dB
Frequency Ranges
The COBRA18WXSTIItransceiverrepresentsoneof
themostadvancedAMtwo-wayradiosusedasaClass
DstationintheCitizensRadioService.Thisunitfeatures
advancedPhaseLockLoop(PLL)circuitryproviding
completecoverage ofall 40 CB channelsandall 10
weatherchannelsasshownbelow.
1 26.965 21 27.215
2 26.975 22 27.225
3 26.985 23 27.255
4 27.005 24 27.235
5 27.015 25 27.245
6 27.025 26 27.265
7 27.035 27 27.275
8 27.055 28 27.285
9 27.065 29 27.295
10 27.075 30 27.305
11 27.085 31 27.315
12 27.105 32 27.325
13 27.115 33 27.335
14 27.125 34 27.345
15 27.135 35 27.355
16 27.155 36 27.365
17 27.165 37 27.375
18 27.175 38 27.385
19 27.185 39 27.395
20 27.205 40 27.405
Channel Channel
CB Freq. CB Freq.
Channel In MHz Channel In MHz
Weather
Weather Freq.
Channel In MHz
1 162.550
2 162.400
3 162.475
4 162.425
5 162.450
6 162.500
7 162.525
8 161.650
9 161.775
10 163.275
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:25 PM Page 18

20
Accessories
ReplacementMounting
Bracket
251-199-9-001 $4.50
ReplacementThumb Screws
634-081-9-001 $0.60
ReplacementMicrophone
Bracket
741-080-9-001 $0.45 38”BaseLoadedMagnet
MountAntenna
HGA1500 $46.95
54”Base Loaded Magnet
MountAntenna
HGA2000
$99.95
21”BaseLoaded Magnet
MountAntenna
HGA1000 $28.95
DynamicExternalSpeaker
HGS100 $21.95 NoiseCancelingExternal
Speaker
HGS300 $28.95
DynamicNoiseCanceling
With TalkBack External
Speaker
HGS500 $32.95
Fiberglass Whip
ReplacementAntenna
3Foot HGA300 $28.95
Black,Red,White,Gold
4Foot HGA400 $29.95
Black,Red,White
41/2Foot HG A450 $30.95
Black,Red,White,Gold
Accessories
62”Center-Load
ReplacementAntenna
HGA6000 $89.95
Black/Clear,Black,Red,White,Gold
21
4-PinPowerMicrophone
HGM75 $25.95
4-PinNoiseCanceling
Microphone
HGM77 $30.95
4-PinReplacementDynamic
Microphone
HGM73 $19.95
4PinPremium Noise-
CancellingMicrophone
HGM84 $74.95
4PinPremiumNoise-
CancellingMicrophone
WoodGrain
HGM84W $74.95
5PinPremium Noise-
CancellingMicrophone
HGM85 $74.95
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:26 PM Page 20

23
Limited Two Year War
ranty
LimitedWarranty
COBRA ELECTRONICS CORPORATION warrants that its
COBRA CB Transceiver, and the component parts thereof, will
be free of defects in material and workmanship for a period
of two (2) years from the date of consumer purchase.This
warranty may be enforced by the first consumer purchaser,
provided that the product is utilized within the U.S.A.
COBRA will,without charge, repair or replace,at its option, a
defective CB Transceiver upon delivery to the COBRA factory
Service Department,accompanied by proof of the date of
first consumer purchase,such a duplicated sales receipt.
You must pay initial shipping charges required to ship the
product for warranty service,but the return charges will be
at COBRA’S expense,if the product is repaired or replaced
under warranty.
Exclusions:This limited warranty does not apply; 1) to any
product damaged by accident;2) in the event of misuse or
abuse of the product or as a result of unauthorized alter -
ations or repairs;3) if the serial number has been altered,
defaced or removed;4) if the owner of the product resides
outside the U.S.A.
Allimpliedwarranties,including warranties of mer-
chantability and fitnessfora particularpurpose are limited
in duration to the length of thiswarranty.
COBRA shall not be liable for anyincidental,consequential
or other damages;including,without limitation,damages
resulting from lossof use or costof installation.
Some statesdo not allowlimitations on how long an
implied warranty lasts and/or donot allow the exclusionor
limitation of incidental or consequential damages,so the
above limitations may not apply toyou.
CobraElectronics
Corporation
6500WestCortlandStreet
Chicago,Illinois60707
Tax Table
Illinois residents add 7%
Cook Co.residents add .75% (7.75% total)
Chicago residents add 1% (8.75% total)
Indiana residents add 5%
For credit card orders fill out order form
and fax to: 1.773.622.2269
or call 1.773.889.3087
(Press 1 from the main menu)
8:00 am - 8:00 pm,M-F,CST.
Make check or moneyorder (no stamps)
payable to:
Cobra Accessories Dept.
6500 West CortlandSt.Chicago,IL 60707
Prices subject to change without notice.
Please print clearly
Name___________________________________________________
Address (No P.O.Box)_____________________________________
City____________________________________State____________
Zip_____________Telephone (____)__________________________
Credit Card No._________________________Exp.Date_________
Customer Signature__________________________________
Circle One: Visa MasterCard Discover
Subtotal
(Tax if applicable)
Shipping/handling
Total
Michigan residents add 4 %
Ohio residents add 6%
Wisconsin residents add 5%
Shipping& Handling
Amount of Shipping/
Order Handling
$25.00 and under $4.75 minimum
$25.01-$40.00 $6.95
$40.01-$80.00 $9.00
$80.01-$120.00 $10.00
$120.01-$160.00 $11.50
$160.01 and up $14.25
For AK,HI and PR please add
anadditional$15.00for UPS
shipments.
Accessory Order Form
22
251-199-9-001 Replacement Mounting Bracket $4.50
634-081-9-001 ReplacementThumb Screws $0.60
741-080-9-001 Replacement Microphone Bracket $0.45
HG A1000 21”BaseLoadedMagneticMountAntenna $28.95
HG A1500 38”BaseLoadedMagneticMountAntenna $46.95
HG A2000 54”BaseLoadedMagneticMountAntenna $99.95
HG M84 4PinPremiumNoise-CancellingMicrophone $74.95
HG M84W 4PinPremiumNoise-CancellingMicWoodgr $74.95
HG M85 5PinPremiumNoise-CancellingMicrophone $74.95
HG M73 Replacement Dynamic Microphone $19.95
HG M75 Power Microphone $25.95
HG M77 Noise Canceling/Power Microphone $30.95
HG S100 Dynamic External Speaker $21.95
HG S300 Noise Canceling External Speaker $28.95
HG S500 Dynamic Noise Canceling
With Talk Back External Speaker $32.95
HG A300 FiberglassWhipReplacementAntenna $28.95
Black,Red,White,Gold
HG A400 FiberglassWhipReplacementAntenna $29.95
Black,Red,White,Gold
HG A450 FiberglassWhipReplacementAntenna $30.95
Black,Red,White,Gold
HG A6000 62”Center-LoadReplacementAntenna
Black/Clear,Black,Red,White, Gold $89.95
Item # Description Cost Ea. Qty. Amount
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:26 PM Page 22

The Cobra line of quality products
also includes:
• High Gear™Accessories
• Radar Detectors
• SafetyAlert™
TrafficWarning Systems
• Family Radio Service (FRS)
2-Way Radios
Nothing comes close to a Cobra™
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:26 PM Page 24

Cobra Electronics Corporation
6500 West Cortland Street
Chicago, IL 60707
Cobra Electronics Corp.© 2000
Printed in China
Part No. 480-315-P-001
Fortechnicalassistance,pleasecallourAutomatedHelpDeskwhichcanassist
youbyansweringthemostfrequentlyaskedquestionsaboutCobraproducts.
[phone]
24hoursa day,7 daysa week.
A Consumer Service Representative can be reached through this same number
8:00 am - 6:00 pm,Monday through Friday,CentralStandard Time.
Technicalassistance is alsoavailableon-line intheFrequently AskedQuestions(FAQ)
sectionatwww.cobraelectronics.com or bye-mailto pr[email protected]
If you think you need service call 1.773.889.3087
Ifyour productshouldrequire factory service please call Cobra first before sending in your unit.
This willensurethefastest turn-around timeonyour repair.
You may be asked to send your unit to the Cobra factory.It will be necessary to furnish the follow-
ing in order to have the product serviced and returned.
1. For Warranty Repair include some form of proof-of-purchase,such as a mechanical reproduction
or carbon of a sales receipt. If you send the original receipt it cannot be returned.
2. Send the entire product.
3. Enclose a description of what is happening with the unit.Include a typed or clearly print name
and address of where the unit is to be returned.
4. Pack unit securely to prevent damage in transit. If possible, use the original packing material.
5. Ship prepaid and insured by way of a traceable carrier such as United Parcel Service (UPS) or First
Class Mail to avoid loss in transit to: Cobra Factory Service,Cobra Electronics Corporation,6500
W.Cortland St., Chicago,IL 60707.
6. If the unit is in warranty,upon receipt of your unit it will either be repaired or exchanged
depending on the model. Please allow approximately 3 to 4 weeks before contacting us for
status.If the unit is out of warranty a letter will automatically be sent informing you of the
repair charge or replacement charge.If you have any questions, please call 1.773.889.3087
for assistance.
If You Think You Need Service
“IngeniousProductsforEasierCommunication.”
18 WX ST II
Mobile Radio
with System
Operating Instructions for your
18WXSTII
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:26 PM Page 26

A1
The Citizens Band Story
4
5
21
3
TheCitizens Band lies between theshortwave broadcast
and 10-meter Amateurradio bands,and was established
bylaw in 1949. The Class D two-waycommunications
servicewas opened in1959.(CB alsoincludesa Class A
citizens band and ClassC remotecontrol frequencies.)
FCCRegulations
FCCregulationspermit only "transmissions" (one-party
to another) rather than" broadcast" (to awide audience).
Thus,advertising is notallowed on CBchannels because
thatis"broadcasting".
FCCWarnings
All transmitteradjustments other than those supplied
bythemanufacturerasfrontpanel operatingcontrols,
mustbemade by,or underthe supervision of,theholder
ofan FCC-issuedgeneralRadio-Telephone Operator’s
License.
Replacement orsubstitution of transistors,regular di-
odes or other parts of aunique nature,withparts other
than thoserecommended by Cobra,maycauseviolation
ofthetechnicalregulationsof Part 95of the FCC Rules,
or violation ofTypeAcceptancerequirements of Part 2
ofthe Rules.
You shouldreadandunderstand Part 95(includedwith
thisunit)ofthe FCC Rulesand Regulations,before oper-
ating your Cobraradio,eventhoughtheFCCnolonger
requires youto obtain an operator’s license.
What’s included with yourCBRadio:
1. CB transceiver 6. FCC rules
2. Microphone .(notpictured)
3. Transceiverbracket 1.
4. Microphonebracket
5. Operating Manual
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:26 PM Page 28

A2
Controls and Indicators
Thank you for purchasing the Cobra 18 WX ST II
CB Radio Transceiver.Properly used,this Cobra
product willgive you many years ofreliable service.
“Cuts Static coming in,adds Punch going out!”
Technology that dramatically improves the
transmission and reception of CB radio signals.
The revolutionary SoundTrackerTM System recon-
figures the transmission signal which allows it to
be transferred more effectively through cluttered
airwaves.
At the same time,it significantly reduces the
amount of static on all incoming CB signals.
The end result is a clearer,cleaner sounding
reception of signals and a more powerful
transmission which dramatically improve
CB communications.
Customer Support
Should you encounter any problems with this
product,or not understand its many features,
please refer to this owner’s manual.If,after refer-
ring to the manual, you still need help, call Cobra
Customer Service at 773.889.3087.
CobraCustomer Service
Liveoperatorsare
available
M-F8:00am–6:00pm
CentralStandardTimeat
773.889.3087
AutomatedTechnical
Assistanceavailable24
hoursaday,sevendaysa
week.E-mail questions to:
productinfo@
cobraelectronics.com
Cobraonthe WorldWide
Web:FrequentlyAsked
Questions(FAQ)canbe
foundat:
www.cobraelectronics.com
A3
1
7
12 6
2 3 4 5
Our Thanks to You
13
14
8
11
15
1. MicrophoneConnector.
2. Off/On/Volume.
3. Squelch.
4. Channel 9/Channel19
5. CB/Weather
6. Channel SelectorButton.
7. LEDChannelDisplay.
8. S/RFPowerMeter.
9. WXIndicatorLED.
10. TXIndicatorLED.
11. RXIndicatorLED.
12. ScanButton.
13. SoundTracker™Button.
14. DualWatchButton.
15. Microphone
Back Side
16. AntennaConnector
17. ExternalSpeakerConnector
18. PowerCord
9
10
16
17
18
18 WX ST.NEW LAYOUT(4279)2a 8/9/00 4:26 PM Page 30
