Cobra microTalk PR 170 User manual

Mod /Pow r Button
Press and release to enter
mode functions to change
channels or privacy codes.
The channel numbers or
privacy code numbers will
blink when that mode is
selected. Use the Up/Down
buttons to select a channel
or privacy code.
Us r’s Guid
TWO-WAY RADIO MODEL
PR170
IMPORTANT NOTICE: FCC LICENSE REQUIRED
This two-way radio operates on GMRS (General Mobile Radio Service) frequencies
which require an FCC (Federal Communications Commission) license. A user must
be licensed prior to operating on Channels 1 through 7 or 15 through 22, which
comprise the GMRS channels of this radio. Serious penalties could result for
unlicensed use of GMRS channels, in violation of FCC rules. Operation of this
radio is subject to additional rules specified in 47 C.F.R. Part 95.
Licensed users will be issued a call sign by the FCC, which should be used for
station identification when operating this radio. GMRS users should also cooperate
by engaging in permissible transmissions only, avoiding channel interference with
other GMRS users, and being prudent with the length of their transmission time.
For licensing information and application forms, please call the FCC Hotline at
800-418-FORM. Request form #159 and form #605. Questions regarding the
license application should be directed to the FCC at 888-CALL-FCC. Additional
information is available on the FCC’s website at www.fcc.gov.
Saf ty Information for microTALK®Radios
Your wireless handheld portable transceiver contains a low power transmitter.
When the talk button is pushed, it sends out radio frequency (RF) signals.
The device is authorized to operate at a duty factor not to exceed 50%.
n August 1996, the Federal Communications Commissions (FCC) adopted
RF exposure guidelines with safety levels for handheld wireless devices.
Important:
FCC RF Exposure Requirements: For body-worn operation, this radio has
been tested and meets the FCC RF exposure guidelines when used with Cobra
accessories supplied or designated for this product. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines. Use only the
supplied antenna. Unauthorized antennas, modifications, or attachments
could damage the transmitter and may violate FCC regulations.
Normal Pos t on:
Hold the transmitter approximately two inches from your face and
speak in a normal voice, with the antenna pointed up and away.
Product Service Questions
f you have any questions about operation or installing your new Cobra product,
or if you are missing parts…
Pl as call Cobra first! DO NOT RETURN THIS PRODUCT TO THE STORE!
S custom r assistanc abov .
For Products Purchased n the U.S.A.
f your product should require factory service, please call Cobra first before
sending your radio, charger or battery pack(s). This will ensure the fastest turn-
around time on your repair. You may be asked to send your products to the Cobra
factory. t will be necessary to furnish the following to have the product serviced
and returned. 1) For warranty repair include some form of proof-of-purchase,
such as a mechanical reproduction or carbon of a sales receipt. f you send the
original receipt, it cannot be returned. 2) Send the entire product. 3) Enclose
a description of what is happening with the product. nclude a typed or clearly
printed name and address of where the product is to be returned. 4) Pack product
securely to prevent damage in transit. f possible, use the original packing material.
5) Ship prepaid and insured by way of a traceable carrier such as United Parcel
Service (UPS) or Priority Mail to avoid loss in transit to:
Cobra Factory Service
Cobra Electronics Corporation
6500 West Cortland Street
Chicago, llinois 60707 U.S.A.
6) f the product is in warranty, upon receipt of your product it will either be
repaired or exchanged depending on the model.
Please allow approximately three to four weeks before contacting Cobra
for status. f the product is out of warranty, a letter will automatically be sent
informing you of the repair charge or replacement charge. f you have any
questions, please call 773-889-3087 for assistance.
For Products Purchased Outs de the U.S.A.
Please contact your local dealer for product service information.
Limited One-Year Warranty on Radio(s) and Charger
For Products Purchased n the U.S.A.
Cobra Electronics Corporation warrants that its Cobra GMRS radios and charger, and the
component parts thereof, will be free of defects in workmanship and materials for a period
of one year from the date of first consumer purchase. This warranty may be enforced by
the first consumer purchaser, provided that the product is utilized within the U.S.A.
Cobra will, without charge, repair or replace, at its option, defective GMRS radios,
chargers, products or component parts upon delivery to the Cobra Factory Service
department, accompanied by proof of the date of first consumer purchase, such as
a duplicated copy of a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty
service, but the return charges will be at Cobra’s expense, if the product is repaired
or replaced under warranty. This warranty gives you specific legal rights, and you
may also have other rights which may vary from state to state.
Exclus ons: Th s l m ted warranty does not apply:
1) To any product damaged by accident; 2) n the event of misuse or abuse of the product
or as a result of unauthorized alterations or repairs; 3) f the serial number has been
altered, defaced, or removed; 4) f the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and fitness for a
particular purpose are limited in duration to the length of this warranty. Cobra shall
not be liable for any incidental, consequential or other damages; including, without
limitation, damages resulting from loss of use or cost of installation.
Some states do not allow limitations on how long an implied warranty lasts and/or
do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitations may not apply to you.
For Products Purchased Outs de the U.S.A.
Please contact your local dealer for warranty information.
90-Day Warranty on Rechargeable Batteries
For Products Purchased n the U.S.A. and Canada
NOTE This device com lies with art 15 of the FCC Rules.
O eration is subject to the following two conditions: 1) This
device may not cause harmful interference, and 2) this device
must acce t any interference received, including interference
that may cause undesired o eration.
FCC Warnings: Re lacement or substitution of transistors,
regular diodes or other arts of a unique nature, with arts other
than those recommended by Cobra may cause a violation of the
technical regulations of art 95 of the FCC rules, or violation of
ty e acce tance requirements of art 2 of the rules.
Combination
Sp ak r/
Microphon
Charg Jack
Press and hold to turn the
radio on or off.
Up/Down Buttons
While in mode functions,
press and release to change
channels or privacy codes.
Press and release to adjust
the volume.
Chann l Numb rs
While in Standby mode or when selecting a
channel, shows current channel (1 through 22).
When adjusting the volume, shows current
level (1 through 8).
Privacy Cod Numb rs
While in Standby mode,
shows current privacy
code (00 through 38).
Rc iv Icon
Visible when
receiving a message.
Transmit Icon
Visible when
transmitting a message.
Batt ry Low Icon
Blinks when battery power level is low.
Your microTALK®radio has a unique
circuit designed to extend battery life.
f there are no transmissions within
10 seconds, the radio will automatically
switch to Battery Save mode. This will
not affect the radio’s ability to receive
incoming transmissions.
The Cobra®line o quality products includes:
CB Radios • microTALK®Radios • Radar/Laser Detectors • Safety Alert®Traffic Warning Systems •
Handheld GPS Receivers • Mobile GPS Navigation Systems • HighGear®Accessories •
CobraMarine®VHF Radios • CobraMarine®Chartplotters • Power nverters • Accessories
Printed in the Philippines Part No. 480-311-P Version A
Batt ry
Compartm nt
Cov r
B lt
Clip
Ant nna
Talk Button
Press and hold to communicate with
others. With the microphone about
two inches (five cm) from your mouth,
speak in a normal voice.
Release the Talk button when you are
finished talking and listen for a response.
You cannot receive incoming calls
while pressing the Talk button.
NOTE Both radios must be tuned
to the same channel and privacy
code to communicate.
Call Button
Press and release to alert others that
you are calling. This tone is used only
to establish voice communications.
Making Lif Easi r
and Saf r
Staying in touch with your family and
fri nds is conv ni nt and asy wh n using your
microTALK®radio. Som of th many
us s you will discov r includ :
Communicating with others while hiking, biking,
and working; keeping track of family and friends
at a crowded public event; checking with travel
companions in another car; talking with neighbors;
arranging meeting spots with others while
shopping at the mall.
Custom r Assistanc
n this user’s guide, you should find all the information you need to operate your microTALK®radio. f you require
further assistance after reading this guide, Cobra Electronics offers the following customer assistance services:
For Assistanc in th U.S.A.
Automated Help Desk English only.
24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Ass stance Operators English and Spanish.
8:00 a.m. to 6:00 p.m. Central Time, Monday through Friday
(except holidays) 773-889-3087 (phone).
Quest ons English and Spanish.
Faxes can be received at 773-622-2269 (fax).
Techn cal Ass stance
English only. www.cobra.com
(on-line: Frequently Asked Questions).
English and Spanish. [e-mail] (e-mail).
For Assistanc Outsid th U.S.A.
Contact Your Local Dealer
Trademark Acknowledgement
Cobra®, microTALK®, Nothing Comes Close to a Cobra®and the snake design are
registered trademarks of Cobra Electronics Corporation, U.S.A. Cobra Electronics
Corporation™ is a trademark of Cobra Electronics Corporation, U.S.A.
Maximum range may vary and is based on unobstructed
line-of-sight communication under ideal conditions.
LCD
Display
Batt ri s and Charg r
To Install or Replace Batter es:
1. Remove belt clip by releasing belt clip
latch and sliding clip up.
2. Pull up on the battery door latch to remove
the battery compartment cover.
3. nsert the supplied three (3) AAA
rechargeable batteries (also works with
non-rechargeable alkaline batteries).
Position batteries according to polarity
markings.
4. Replace battery compartment cover
and belt clip.
Ins rt Batt ri s
Pull Latch Up
R mov B lt Clip
To Charge Batter es n Rad o:
1. Check to see that the batteries have been
inserted properly. See above for battery
installation instructions.
2. nsert round connector of wall charger into the charge jack located at
the top of the radio. The wall charger has two round connectors which
enables you to charge either one or two radios at a time.
3. Plug the wall charger into electrical outlet.
t normally takes 15 hours to fully recharge batteries. t is not
recommended to recharge batteries more than 24 hours. Estimated
operation time on a full charge is 8 hours.
Use only the supplied rechargeable batteries and wall charger
for recharging your Cobra microTALK®radio. Non-rechargeable alkaline
batteries can also be used.
Radio Charg r Jack
