CoCo ICS-1000 User manual

Internet Control Station
ICS-1000
Quick Installation Guide
Internet Control Station
ICS-1000
Quick Installation Guide
ANDROID
EN

2
3
PACKAGE CONTENTS
First, please check if the package
contains the following items:
1. Internet Control Station
2. RJ-45 cable
3. Power adapter
4. Quick installation guide
NOTE: Visit www.coco-technology.com frequently to check if updates are available
Internet Control Station
1
2
3
4

2
3
CHECKLIST COMPLETE INSTALLATION
Before you can use the Internet Control Station,
please follow these necessary steps:
1. Connect Internet Control Station to your modem/router
2. Install the ‘COCO control’ app on your smartphone or tablet
3. Create an account on www.coco-technology.com
4. Use the ‘COCO control’ app to register your smartphone/tablet with the
Internet Control Station
5. Create at least 1 room in the ‘COCO control’app and add a lamp or
device to this room
6. Assign the transmission code for that lamp/device to the relevant COCO
receiver
On the following pages all steps are clearly illustrated

4
5
1. First, connect the Internet Control Station to the modem/router using the RJ-45 cable.
2. Then, connect the power adapter to the Internet Control Station and insert the plug of the power
adapter into a wall socket. The display of the Internet Control Station will illuminate.
3. The display will show the date and time on the rst line and the letter“S”on the second line.
If this is not the case please check the following pages, otherwise continue to page 7.
1. CONNECT THE INTERNET CONTROL STATION TO YOUR MODEM/ROUTER
1 2

4
5
On the second line of the display an“X” is shown instead of an “S”
Go to option CLOUD SERVER in the MENU of your ICS-1000 (this option
will become available after pressing the topright green button multiple
times). At the option CLOUD SERVER, choose ON and wait until you see
the display with the date and time again. Additionally the letter “S”will
now appear.
The display shows the message CHECK CABLE
This message indicates that there is an issue with the RJ-45 cable. Make sure that this cable is connected
correctly. If this is indeed the case, try another cable or port on your router.
The display shows the message TIME NOT SET
This message indicates that your ICS-1000 is not connected to internet. First, try to connect your ICS-1000
on another port of your router. If the message still appears afterwards you need to look at what is stated
regarding SERVER NO REPLY on the following page.
The display shows the message RESET ROUTER
As the message already indicates, you need to reset your router by unplugging the power adapter of your
router for a couple of secondes. Make sure the ICS-1000 is not connected to your router as soon as you
repower your router. When your router is fully operational again, you can reconnect your ICS-1000 with
your router.
DISPLAY INFORMATION IS NOT CORRECT

6
7
The display shows the message SERVER NO REPLY
Unplug the power adapter of your ICS-1000 and after a few seconds repower your ICS-1000 until you see
the date, time and letter “S”. If this is not the case try to use another port of your router. If the display still
shows the message SERVER NO REPLY afterwards, your router probably doesn’t accept the ICS-1000. This
can be conrmed by going to the option SYSTEM in the MENU of your ICS-1000 by pressing MAC/IP. The
shown MAC address will most likely by 192.168.1.101. This indicates that there is an issue between your
router and your ICS-1000. To resolve this issue you can put a switch between your router and ICS-1000. This
switch will most likely resolve the issue.
Do you remain to have issues or can’t nd the solution here? Feel free to contact us at [e-mail]

6
7
Go to the Google Play Store and
search for “COCO Control”. Then
select the COCO Control app and
install it on your smartphone or
tablet.
2. INSTALL THE APP
1. Already have an account?
Enter your e-mail address and 4
digit PIN code and press the “Log
in” button. If you forgot your code
you can press “Forgotten your
password?”
2. Don’t have an account yet?
Press the “New to COCO” button.
3. CREATE AN ACCOUNT/LOG IN
2
1

8
9
4
3
5
3. Create an account
Enter your name, e-mail and
a password. The latter should
consist of 4 numbers.
4. Complete the MAC code by
adding the remaining part of
the MAC code that is displayed
at the bottom of your ICS-1000.
Then press the“Next” button.
5. After pressing the“Next”
button a PIN appears in the
display of your ICS-1000. Enter
this code and press“Done”.
3. CREATE AN ACCOUNT

8
9
After the rst log in a short
explanation of the app is shown.
By pressing the “Next” button you
can go to the next page.
By pressing the “Next” button you
can go to the next page.

10
11
In the display of your ICS-1000
you see above question. Choose YES by
pressing the green button.
Don’t see this question?
Make sure you are connected to the
WiFi network distributed by the router
to which the ICS-1000 is connected.
After pressing the green button the
display will show the text:
“Registered OK“.
To exit this explanation press“Done”.
Make sure you are near your ICS-
1000.
As soon as this message appears, look
at the display of your ICS-1000

10
11
4A. LOADING YOUR EXISTING CONFIGURATION (ANDROID)
Existing Android users
If you have previously set up
a conguration on the COCO
website (like depicted below),
you will directly see these rooms
and devices in the Android app of
your existing conguration.
New Android users
Go to chapter 5 on page 13.

12
13
Existing iPhone/iPad users
To use the conguration you have
set up on your iPhone or iPad you
rst need to make a backup of
your conguration by uploading
your database.
This can be done by pressing
Settings >> Database
management >> Backup Data to
webserver >> Upload database
to Web.
You can now use this
conguration on your Android
smartphone/tablet by going to
the settings screen and pressing
“Get settings from webserver“.
If you now go back to the
Homescreen of your Android app
you will notice that your existing
conguration is active. Go to “Settings“ and press
“Backup Data to WebServer“.
Check your e-mail address
and afterwards press
“Upload database to Web”.
4B. LOADING YOUR EXISTING CONFIGURATION (IPHONE/IPAD)

12
13
5. SET UP A NEW CONFIGURATION
1. Press the plus button to create a
new room.
2. Enter the desired name for this
room and press DONE.
3. You will now see the rst room
(in this example: Living room)
Now select this room.

14
15
4. The screen of the selected room
will be shown, with the All o
command added automatically.
5. By pressing the plus button, you can
add a device. Enter a desired name and
press OK.
6. Now select the device type
(corresponds with your COCO receiver).
Use Open Close for the ASUN-650.

14
15
7. The device will now be shown with
a CONNECT button. Press this button.
8. Activate the learn mode of the
corresponding COCO receiver
(see receiver’s manual).
1 sec.
1 sec.
9. When the LED indicator of the
receiver blinks, press OK. The receiver
will now save the signal.

16
17
10. You are now able to control
the device wirelessly with the
corresponding green buttons.
6. WIRELESS CONTROL
In the previous chapter you read
the following:
• create a room
• add device to a room
• connect a COCO receiver with
your ICS-1000
Repeat these steps to add more
rooms and/or devices.
Each type of device has its own set
of buttons, for example on/o or
open/close.
If you are using a dimmer you can
dim the light with the slider.

16
17
To control these device also on
another smartphone/tablet you
need to save your settings to our
webserver.
This can be done by going to
“Settings”and pressing “Save
settings to web server”.
On a another Android
smartphone/tablet you can simple
get these settings by pressing“Get
settings from web server”.
To use these settings on an
iPhone or iPad you need to press
“Download database from Web” in
your iOS app.
Each time you make an adjustment
remember to save these adjustments
by pressing“Save settings to
webserver”.
To use these adjustments on another
smartphone/tablet, you can press
“Get settings from webserver” in the
Android app or press “Download
database from Web”in the iPhone/
iPad app.

18
19
7. CREATE AN EVENT
1. Go to the “Events” tab and press the
“+” button to add an Event.
2. Enter a desired name for the event
and press CONTINUE.
You can set up an event that
allows you to activate up to 10
actions in one go. After setting up
this event you can activate it by
pressing a single button.
It is also possible to activate this
event automatically by setting up
a timer for this event.
Home & Away
In this chapter you learn to set
up an event. Likewise you can
add actions to the (blank) events
Home and Away, which can be
operated with the corresponding
Home and Away buttons in the
Home screen. By using these
buttons you can simple set your
home into the Home or Away
setting.

18
19
3. You can now add up to 10 actions
by checking the boxes in front of the
action. After selecting press DONE.
4. Afterwards you can add actions
or delays as desired. To add a delay
press “Add Delay”.
5. In this example a delay of 10 sec
is added. You can else add a random
delay. To add the delay press DONE.

20
21
1. To start an event, you can simply
select it in the events tab.
2. To start the event simply press
“Start Now”. You can also select “Start
at a time”.
8. START AN EVENT
6. To adjust a delay, delete an action
or change the order of actions, you
can press EDIT.
