Codan 3112 User manual

HF RADIO COMMUNICATIONS
USER GUIDE
HF Data Modem
3112

No part of this guide may be reproduced, transcribed or
translated into any language or transmitted in any form
whatsoever without the prior written consent of Codan
Limited.
© Copyright 2007 Codan Limited.
Codan part number 15-04147-EN Issue 1, June 2007
HF Express™is a trademark of Codan Limited. NGT®,
Easitalk®and CALM®are registered trademarks of Codan
Limited. Other brand, product, and company names
mentioned in this document are trademarks or registered
trademarks of their respective holders.
Modem software © Copyright 1995–2004 SPIRIT.
The English version takes precedence over any translated
versions.

HF Data Modem 3112 User Guide i
Table of contents
Introduction
Overview of this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1Overview
The 3112 HF Data Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
The rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 Installation and setup
Unpacking the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
System requirements for a 3112 data station . . . . . . . . . . . . . . . . . . . . . . . 17
Installing the 3112 HF Data Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting the modem to the transceiver. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connecting the modem to the PC via the Ethernet ports . . . . . . . . . . . . . . 22
Connecting the modem directly to the PC using a crossover
CAT5 Ethernet cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Connecting the modem indirectly to the PC (via an Ethernet
switch) using a straight CAT5 Ethernet cable. . . . . . . . . . . . . . . . . . . . 27
Connecting the modem to the PC via an asynchronous port . . . . . . . . . . . 31
Connecting the modem to the PC via a synchronous port . . . . . . . . . . . . . 38
Testing the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Testing communication between two nodes . . . . . . . . . . . . . . . . . . . . . . . . 47
3 Operating the modem
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Using the navigation buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Operating the modem using controlling software. . . . . . . . . . . . . . . . . . . . 58
Selecting a waveform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Table of contents
ii HF Data Modem 3112 User Guide
Saving a user profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Loading a profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Resetting to factory defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Using the on-board help in the modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Appendix A—Menu structures for waveforms
MIL-STD-188-110A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
MIL-STD-188-110B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
STANAG 4539 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
STANAG 4415 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Appendix B—Connectors
Transceiver Control connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Modem Control connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Transceiver connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Sync/Async Data connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Ethernet connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Appendix C—Specifications
Appendix D—Factory-default settings
Appendix E—Compliance
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
European R&TTE Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Electromagnetic compatibility and safety notices . . . . . . . . . . . . . . . . . . . . 90
FCC compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Table of contents
HF Data Modem 3112 User Guide iii
Appendix F—Definitions
Standards and icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Acronyms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Unit multipliers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
About this issue. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Table of contents
iv HF Data Modem 3112 User Guide
This page has been left blank intentionally.

HF Data Modem 3112 User Guide v
List of figures
Figure 1: Typical system layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 2: Typical system layout using the Codan STANAG
5066 Stack with HF Express . . . . . . . . . . . . . . . . . . . . . . 6
Figure 3: Front panel of the 3112. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 4: Rear panel of the 3112 . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 5: Connecting the modem directly to the PC via the
Ethernet ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 6: Connecting the modem indirectly to the PC via an
Ethernet switch with DHCP server. . . . . . . . . . . . . . . . . 28
Figure 7: Connecting the modem to the PC via an
asynchronous port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 8: Connecting the modem to the PC via a
synchronous port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 9: Layout of the status screen . . . . . . . . . . . . . . . . . . . . . . . 51
Figure 10: Layout of a menu screen. . . . . . . . . . . . . . . . . . . . . . . . . 52
Figure 11: Screen during data transmission. . . . . . . . . . . . . . . . . . . 52
Figure 12: Screen during data reception . . . . . . . . . . . . . . . . . . . . . 53
Figure 13: Top-level menu structure for the modem . . . . . . . . . . . . 54
Figure 14: Menu structure for MIL-STD-188-110A
waveform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Figure 15: Menu structure for MIL-STD-188-110B
waveform (serial tone) . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Figure 16: Menu structure for MIL-STD-188-110B
waveform (39Tone) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Figure 17: Menu structure for STANAG 4539 waveform. . . . . . . . 71
Figure 18: Menu structure for STANAG 4415 waveform. . . . . . . . 73
Figure 19: Front view of the Transceiver Control connector. . . . . . 76
Figure 20: Front view of the Modem Control connector . . . . . . . . . 77
Figure 21: Front view of the Transceiver connector . . . . . . . . . . . . 78
Figure 22: Front view of the Sync/Async Data connector. . . . . . . . 80
Figure 23: Front view of the Ethernet connector . . . . . . . . . . . . . . . 82

List of figures
vi HF Data Modem 3112 User Guide
This page has been left blank intentionally.

HF Data Modem 3112 User Guide vii
List of tables
Table 1: Navigation buttons and their function . . . . . . . . . . . . . . 56
Table 2: Available waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Table 3: Typical data rates, SNR and channel quality . . . . . . . . . 61
Table 4: Waveform, data rate and interleaver
relationships . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Table 5: Pinouts for the Transceiver Control connector. . . . . . . . 76
Table 6: Pinouts for the Modem Control connector . . . . . . . . . . . 77
Table 7: Pinouts for the Transceiver connector . . . . . . . . . . . . . . 78
Table 8: Pinouts for the Sync/Async Data
connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Table 9: Pinouts for the Ethernet connector . . . . . . . . . . . . . . . . . 82
Table 10: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Table 11: Factory-default settings for the modem . . . . . . . . . . . . . 85
Table 12: Factory-default settings for the STANAG 4539
waveform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Table 13: Earth symbol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

List of tables
viii HF Data Modem 3112 User Guide
This page has been left blank intentionally.

HF Data Modem 3112 User Guide 1
Introduction
Thank you for purchasing a Codan 3112 HF Data Modem.
With this great product and Codan’s supreme after-sales
support, you can look forward to many years of reliable HF
data communication. Please read this guide thoroughly and
retain it for future reference. There is an index at the end of
this guide to assist you in finding information.
Overview of this guide
This guide is for technicians who install the hardware, and
system administrators who set up how the HF data
communication network interacts with other equipment. It
provides instructions on how to connect and set up a
3112 HF Data Modem with a Codan HF transceiver that is
capable of high-speed data transfer.
This guide assumes that the system administrator is familiar
with setting up HF communication networks for the Codan
NGT series Transceiver and 2110 Manpack Transceiver.
This guide contains the following sections:
Section 1 Overview—provides an overview of the
3112 HF Data Modem, how it is used within a
data communication network, how data flows
through the data system, the waveforms that it
uses, and a brief description of the front and rear
panels
Section 2 Installation and setup—describes how to
connect the Codan 3112 data system together,
how to set up the individual components of the
system, and how to test that the system is
functional
Section 3 Operating the modem—describes the modes of
operation, how to navigate through the menu
system, how to save profiles, and how to access
the on-board help

Introduction
2 HF Data Modem 3112 User Guide
Appendix A Menu structures for waveforms—details the
menu structure for each type of waveform that
may be used with the 3112
Appendix B Connectors—details the pinouts of each
connector on the 3112
Appendix C Specifications—provides the common
operational specifications for the 3112
Appendix D Factory-default settings—provides a list of the
default settings for each menu option and the
default waveform
Appendix E Compliance—provides compliance information
and safety notices for your modem
Appendix F Definitions—explains the terms and
abbreviations used in this guide

Overview
4 HF Data Modem 3112 User Guide
The 3112 HF Data Modem
The 3112 HF Data Modem provides a robust method of data
communication over an HF path.
A standard Codan HF data station (or node) comprises:
• a Codan HF transceiver that is capable of high-speed
data transfer
• an antenna system
• an appropriate 12 V DC power supply
• a 3112 HF Data Modem
• a PC with terminal software
A typical installation uses:
• an Ethernet connection between the PC and the modem
(see page 22, Connecting the modem to the PC via the
Ethernet ports), or
• three connections between COM and asynchronous/
synchronous ports on the PC and the modem (see
page 31, Connecting the modem to the PC via an
asynchronous port or page 38, Connecting the modem to
the PC via a synchronous port)
NOTE
The 3112 HF Data Modem can operate with a
standard data-capable Codan HF transceiver,
however it will operate below the optimum data
transfer rate of 9600 bps.

Overview
HF Data Modem 3112 User Guide 5
Figure 1: Typical system layout
Terminal
session
to 12 V DC
power supply
3112 HF Data Modem
NGT series Transceiver
or
2110 Manpack Transceiver
PC Node 1
to 12 V DC
power supply
3112 HF Data Modem
NGT series Transceiver
or
2110 Manpack Transceiver
PC Node 2
to 12 V DC
power supply
3112 HF Data Modem
NGT series Transceiver
or
2110 Manpack Transceiver
PC
Node 3
Terminal
session
Terminal
session
Set transceiver to a
common channel and
modem to a common
waveform
Set transceiver to a
common channel and
modem to a common
waveform
Set transceiver to a
common channel and
modem to a common
waveform

Overview
6 HF Data Modem 3112 User Guide
Figure 2: Typical system layout using the Codan
STANAG 5066 Stack with HF Express
STANAG
5066 Stack
HF Express
STANAG 5066
Stack Control
to 12 V DC
power supply
3112 HF Data Modem
NGT series Transceiver
or
2110 Manpack Transceiver
PC Node 1
to 12 V DC
power supply
3112 HF Data Modem
NGT series Transceiver
or
2110 Manpack Transceiver
PC Node 2
to 12 V DC
power supply
3112 HF Data Modem
NGT series Transceiver
or
2110 Manpack Transceiver
PC
Node 3
For example, assign
Node 1 with:
STANAG address 1.1.1.1
For example, assign
Node 2 with:
STANAG address 1.1.1.2
For example, assign
Node 3 with:
STANAG address 1.1.1.3
STANAG
5066 Stack
HF Express
STANAG 5066
Stack Control
STANAG
5066 Stack
HF Express
STANAG 5066
Stack Control

Overview
HF Data Modem 3112 User Guide 7
Signal flow
For simple operation, the Codan HF transceivers must be
manually set to the same channel, and the modems must be
manually set to the same waveform. Data is passed from the
terminal session to the modem. It is processed by the modem
then sent to the Codan HF transceiver for transfer via HF to
any transceivers tuned to that frequency. At the receiving
node, the data is passed from the transceiver to the modem,
where it is decoded, ready for presentation at the remote PC.
Figure 1 on page 5 shows a typical layout for a data
communication system.
When the modem operates under the control of the STANAG
5066 Stack, the data may be transferred via an ALE link, or
via two transceivers manually set to the same channel. The
STANAG 5066 Stack requires a STANAG address to be set
for each node. Figure 2 on page 6 shows a typical layout for
an HF data communication network that uses Codan’s
STANAG 5066 Stack and HF Express™.
If a modem self address and ALE/CALM network is defined
against the STANAG address for the remote node in the
STANAG 5066 Stack, the Codan HF transceivers establish the
ALE link according to the information provided. If no modem
self address or ALE/CALM network is defined against the
STANAG address for the remote node, the transceivers must
be manually set to the same channel before the data is
transmitted.
The data from the PC is once again prepared by the modem,
sent via HF on the set channel to the specified STANAG
address, then passed to the modem for decoding and
presentation at the remote PC.
NOTE
For ALE use, the modem is assigned a self
address. This is stored in the STANAG 5066
Stack against the corresponding STANAG
address for the node. The self address for the
modem should be different from the self address
assigned to the transceiver.

Overview
8 HF Data Modem 3112 User Guide
The 3112 HF Data Modem indicates on its screen whether it is
transmitting, receiving or idle. For information on screens that
may appear see page 51, Screens.
Power supply
The 3112 HF Data Modem is powered via its connection to
the Codan HF transceiver. When the Codan HF transceiver is
switched on, the connected modem is also switched on.
Alternatively, the 3112 HF Data Modem may be powered via
an external DC power source that provides between 10 and
15 V DC.
Interoperability
The 3112 HF Data Modem supports the following waveforms:
• MIL-STD-188-110A
• MIL-STD-188-110B (serial tone)
• MIL-STD-188-110B (39Tone, parallel)
• STANAG 4539
• STANAG 4415
Operating modes
The modem has two operating modes:
•LOC mode: the modem is under local control
•REM mode: the modem is under remote control by the
Codan STANAG 5066 Stack

Overview
HF Data Modem 3112 User Guide 9
The front panel
The front panel of the 3112 HF Data Modem comprises an
LCD and six navigation buttons. For information on
navigating through the menu structure see page 55, Using the
navigation buttons. For information on the menu structure see
page 54, Menu structure and page 67, Menu structures for
waveforms.For information on screens that are displayed on
the LCD see page 51, Screens.
Figure 3: Front panel of the 3112
3112 HF Data Modem
Made in Australia Serial No
MENU

Overview
10 HF Data Modem 3112 User Guide
The rear panel
The rear panel of the 3112 has a standard Ethernet connector
and four D-type connectors.
Figure 4: Rear panel of the 3112
The Transceiver Control connector provides a connection
between the modem and a COM port on the PC. This enables
the operator to control the transceiver via a terminal session
using CICS. For information on using these commands see
CICS in the Reference Manual provided with the Codan HF
transceiver.
The Modem Control connector provides a connection
between the modem and a COM port on the PC. This enables
the operator to control the modem using in-built Remote
Control Protocol commands. For information on using these
commands see page 66, Using the on-board help in the
modem.
NOTE For information on connector pinouts see
page 75, Connectors.
Transceiver Control Modem Control Transceiver
Sync/Async Data
Ethernet
Refer documentation before
making connections
Separate DC
input not required
when used with
Codan Transceivers
12 V
LAN activity
LED
LAN link
status LED
