SATEL Proof-TR4/-TR9
User Guide, Version 1.2
1
SATEL Proof-TR4/-TR9
Radio Modem
User Guide

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
2
TABLE OF CONTENTS
TABLE OF CONTENTS .......................................................................................................... 2
IMPORTANT NOTICE ............................................................................................................ 4
RESTRICTIONS ON USE – SATEL PROOF-TR4 .......................................................................... 5
RESTRICTIONS ON USE – SATEL PROOF-TR9 .......................................................................... 6
PRODUCT CONFORMITY ...................................................................................................... 7
WARRANTY AND SAFETY INSTRUCTIONS ................................................................................ 8
GROUNDING ....................................................................................................................... 9
1 DESCRIPTION OF THE PRODUCT ................................................................................... 10
2 SATEL PROOF-TR4/-TR9 TECHNICAL SPECIFICATIONS ..................................................... 11
3 CONFIGURATION ........................................................................................................ 15
3.1 Configuration ....................................................................................................... 15
3.1.1 Configuration Manager ............................................................................................................... 15
3.1.2 Changing parameters using the SL COMMANDS ........................................................................ 16
3.1.2.1 SL Commands ........................................................................................................................... 16
3.1.2.2 SL Command Mode ................................................................................................................... 17
4 MODEM SETTINGS ....................................................................................................... 18
4.1 Default settings of SATEL Proof-TR4 ....................................................................... 18
4.2 Default settings of SATEL Proof-TR9 ....................................................................... 19
5 ANTENNA CONNECTOR ................................................................................................ 21
6 DEUTSCH CONNECTOR ................................................................................................ 22
6.1 Power supply ....................................................................................................... 22
7 SERIAL PORT .............................................................................................................. 23
7.1 Pause length ........................................................................................................ 23
7.2 Data buffering ...................................................................................................... 24

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
3
8 RF INTERFACE ............................................................................................................ 25
8.1 Transmitter ......................................................................................................... 25
8.2 Receiver .............................................................................................................. 26
8.3 Encryption ........................................................................................................... 27
8.4 Radio state .......................................................................................................... 28
8.5 Priority RX/TX ...................................................................................................... 28
8.6 Forward Error Correction (FEC) .............................................................................. 28
8.7 Error checking ...................................................................................................... 29
8.8 TX delay .............................................................................................................. 29
8.9 Add RSSi to data ................................................................................................... 29
8.10 Separate RX/TX-frequencies .................................................................................. 29
8.11 Call Sign .............................................................................................................. 30
8.12 Channel list .......................................................................................................... 30
8.13 Repeater –mode ................................................................................................... 31
8.14 Pacific Crest and TRIMTALK compatibility ............................................................... 31
8.14.1 Settings in compatibility modes ................................................................................................. 33
8.14.2 Repeater function ........................................................................................................................ 35
8.14.3 Support for Local / Remote addresses ....................................................................................... 35
8.14.4 Transmission delays .................................................................................................................... 35
9 MECHANICAL DIMENSIONS ........................................................................................... 38
10 INSTALLATION ............................................................................................................ 39
11 ACCESSORIES ............................................................................................................. 40
12 PROPOSALS FOR MORE RELIABLE RADIO LINK ............................................................... 41
13 APPENDIX A ................................................................................................................ 42
13.1 Transmission delays ............................................................................................. 42
14 VERSION HISTORY ...................................................................................................... 45

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
4
IMPORTANT NOTICE
All rights to this manual are owned solely by SATEL Oy (referred to in this user guide as SATEL).
All rights reserved. The copying of this manual (without the written permission from the owner)
by printing, copying, recording or by any other means, or the full or partial translation of the
manual to any other language, including all programming languages, using any electrical,
mechanical, magnetic, optical, manual or other methods or devices is forbidden.
SATEL reserves the right to change the technical specifications or functions of its products, or to
discontinue the manufacture of any of its products or to discontinue the support of any of its
products, without any written announcement and urges its customers to ensure, that the
information at their disposal is valid.
SATEL software and programs are delivered ”as is”. The manufacturer does not grant any kind
of warranty including guarantees on suitability and applicability to a certain application. Under
no circumstances is the manufacturer or the developer of a program responsible for any
possible damages caused by the use of a program. The names of the programs as well as all
copyrights relating to the programs are the sole property of SATEL. Any transfer, licensing to a
third party, leasing, renting, transportation, copying, editing, translating, modifying into
another programming language or reverse engineering for any intent is forbidden without the
written consent of SATEL.
SATEL PRODUCTS HAVE NOT BEEN DESIGNED, INTENDED NOR INSPECTED TO BE USED IN ANY
LIFE SUPPORT RELATED DEVICE OR SYSTEM RELATED FUNCTION NOR AS A PART OF ANY OTHER
CRITICAL SYSTEM AND ARE GRANTED NO FUNCTIONAL WARRANTY IF THEY ARE USED IN ANY OF
THE APPLICATIONS MENTIONED.
Salo, FINLAND 2020
Copyright: 2020 SATEL Oy
No part of this document may be reproduced, transmitted or stored in a retrieval system in any
form or by any means without the prior written permission of SATEL Oy. This document is
provided in confidence and must not be distributed to third parties without the express
permission of SATEL Oy.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
5
RESTRICTIONS ON USE – SATEL Proof-TR4
SATEL Proof-TR4 radio transceiver module has been designed to operate on 403-473 MHz, the
exact use of which differs from one region and/or country to another. The user of a radio
transceiver module must take care that the said device is not operated without the permission
of the local authorities on frequencies other than those specifically reserved and intended for
use without a specific permit.
SATEL Proof-TR4 is allowed to be used in the following countries, either on license free
channels or on channels where the operation requires a license. More detailed information is
available at the local frequency management authority.
Countries: AE, AT, AU, BE, BG, BR, CA, CH, CY, CZ, DE, DK, EE, ES, FI, FR, GB, GR, HU, HR, IE, IS, IT,
JP, KR, LT, LU, LV, MT, NL, NO, PL, PT, RU, RO, SE, SI, SK, TR, US
WARNING! Users of SATEL Proof-TR4 radio transceiver modules in North America should be
aware, that due to the allocation of the frequency band 406.0 – 406.1 MHz for government use
only, the use of radio transceiver module on this frequency band without a proper permit is
strictly forbidden.
WARNING - RF Exposure
To comply with CE, FCC and IC RF exposure compliance requirements,
maximum antenna gain is 14 dBi and separation distance of at least 1 meter
must be maintained between the antenna of this device and all persons. This
device must not be co-located or operating in conjunction with any other
antenna or transmitter.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
6
RESTRICTIONS ON USE – SATEL Proof-TR9
SATEL Proof-TR9 radio transceiver module has been designed to operate on 902-928 MHz, the
exact use of which differs from one region and/or country to another. The user of a radio
transceiver module must take care that the said device is not operated without the permission
of the local authorities on frequencies other than those specifically reserved and intended for
use without a specific permit.
SATEL Proof-TR9 is allowed to be used in the following countries. More detailed information is
available at the local frequency management authority.
Countries: AU, CA and US.
This radio transmitter 2422A-SATELTA31 has been approved by Industry Canada to operate with
the antenna types listed below with the maximum permissible gain indicated. Antenna types
not included in this list, having a gain greater than the maximum gain indicated for that type,
are strictly prohibited for use with this device.
Antenna type Manufacturer Antenna model Maximum gain (dBi)
Omnidirectional Oy CompleTech Ltd CA915H 5
Directional (yagi) Oy CompleTech Ltd CA930Y 6
NOTE!
According to the requirements of the FCC, the integrator should make sure that the SATEL
Proof-TR9 is compliant to part 15C while integrated in the host device. Output power and
spurious emissions should be verified.
WARNING - RF Exposure
To satisfy FCC and ISED RF exposure requirements for mobile transmitting devices, a
separation distance of 25 cm or more should be maintained between antenna of this device
and persons during device operation. To ensure compliance, operations at closer than this
distance is not recommended. The antenna used for this transmitter must not be co-located
in conjunction with any other antenna or transmitter. FCC regulations allow up to 36 dBm
equivalent isotropically radiated power (EIRP). Therefore, the sum of the transmitted power
(in dBm), the cabling loss and the antenna gain cannot exceed 36 dBm.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
7
PRODUCT CONFORMITY
Hereby, SATEL Oy declares that radio modems are in compliance with the essential
requirements (radio performance, electromagnetic compatibility and electrical safety) and
other relevant provisions of Directive 2014/53/EU. Therefore the equipment is labelled with CE-
marking.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
8
WARRANTY AND SAFETY INSTRUCTIONS
Read these safety instructions carefully before using the product:
-Warranty will be void, if the product is used in any way that is in contradiction with the
instructions given in this manual, or if the radio modem housing has been opened or tampered
with.
-The radio modem is only to be operated at frequencies allocated by local authorities, and
without exceeding the given maximum allowed output power ratings. SATEL and its distributors
are not responsible, if any products manufactured by it are used in unlawful ways.
-The devices mentioned in this manual are to be used only according to the instructions
described in this manual. Faultless and safe operation of the devices can be guaranteed only if
the transport, storage, operation and handling of the devices is appropriate. This also applies to
the maintenance of the products.
-To prevent damage both the radio modem and any terminal devices must always be switched
OFF before connecting or disconnecting the serial connection cable. It should be ascertained
that different devices used have the same ground potential. Before connecting any power
cables the output voltage of the power supply should be checked.
- Any radio link can susceptible to external interference and signal degradation by its nature.
Because of that, the effects of possible interference mechanism and the sufficient back-up
schemes must be taken into account in the system design of the critical applications.
NOTE!
When selecting a suitable location for the radio modem it must be ensured that no water can
get into the radio modem under any conditions. Direct sunlight is also to be avoided. It is not
recommendable to install the radio modem on a strongly vibrating surface. Suitable
dampening and/or isolation materials should be used in cases where the installation surface
will be subjected to vibration.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
9
GROUNDING
SATEL Proof-TR4 / -TR9 is equipped with a grounding terminal, as shown below. It is
recommended to connect a ground wire from the grounding terminal to the earth ground and
that all other interconnected devices share the same electrical ground potential.
Besides the mains voltage safety, proper grounding is essential also for the error free operation
of radio links and the protection against over-voltages and lightning. Although SATEL Proof-TR4
/ -TR9 incorporates a robust internal surge protection, the surge spikes and power transients
caused by lightning, ESD or other electrical systems must be discharged to earth ground.
 General installation guidelines for grounding:
 Perform grounding of the system in accordance with local and national regulations.
 Check the grounding related information of other products in the system.
 Use short low impedance cables. Although DC resistance of a ground cable may be a
fraction of an ohm, its impedance may be thousands of ohms on the radio frequency.
Wide copper straps are the best.
 The ground connection should be connected directly to the power supply, not the
ground connection of the load, in order to isolate the radio from voltage drops across the
ground return for the load.
 Equipment of the radio system should be grounded in a star ground configuration. The
center of the star should be usually connected directly to a good external earth ground
scheme.
 The mast installations require special measures in the construction of ground electrodes
and equipotential bonding – consult professional installation providers.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
10
1 DESCRIPTION OF THE PRODUCT
SATEL Proof-TR4/-TR9 is a UHF radio transceiver modem. It provides a transparent data link
with other SATELLINE- family modems (SATELLINE-EASy, -TR1, -TR3, -TR4, -R3, -R4, -TR9, -R9, -
TR49, -EASy Pro, -4Pro, SATEL Compact-Proof and EASy-Proof). SATEL Proof-TR4/-TR9 can be
interconnected to a data terminal or similar devices by RS-232.
SATEL Proof-TR4/-TR9 contains a 6 pin Deutsch DT connector for RS-232 and power supply, and
TNC female connector for antenna.
SATEL Proof-TR4/-TR9 is intended to be used inside or outside environment and fulfills IP69K
ratings (high pressure hot water). See more detailed description on chapter “Technical
Specifications”. SATEL Proof-TR4/-TR9 meets the IP classification rating according to correctly
assembled and connected mating connector in the device Deutsch connector. See details from
the connector manufacturer’s datasheet.
Available models and product codes:
 YM6583 SATEL Proof-TR4 with AES128 encryption support
 YM6584 SATEL Proof-TR4 without AES128 encryption support
 YM6587 SATEL Proof-TR9

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
11
2 SATEL Proof-TR4/-TR9 TECHNICAL SPECIFICATIONS
SATEL Proof-TR4 complies with the following international standards:
EN 300 113
EN 300 489 (EMC)
IEC 60950 (safety)
FCC CFR47 part90
RECEIVER TRANSMITTER Note!
Frequency Range 403 ... 473 MHz
Tuning range 70 MHz
Minimum RF Frequency
Step 6.25 kHz (10kHz @20kHz channel spacing)
Channel Bandwidth 12.5 kHz / 25 kHz Programmable
Channel Spacing 12.5, 20 (uses 12.5kHz channel width), 25 kHz Programmable
Frequency Stability <1 kHz
Maximum Receiver Input
Power without Damage +14 dBm
Maximum Receiver Input
Power without
Transmission Errors
-10 dBm FEC ON
Sensitivity -112 dBm @ 25 kHz
-116 dBm @12.5 kHz FEC ON
Blocking > 86 dB @ 25 kHz
> 88 dB @ 12.5 kHz FEC ON
Intermodulation
Attenuation
> 61 dB @ 25 kHz
> 61 @ 12.5 kHz FEC ON
CO-Channel Rejection > -11 dB @ 25 kHz
> -10 dB @ 12.5 kHz FEC ON
Adjacent Channel
Selectivity
> 56 dB @ 25 kHz
> 51 dB @ 12.5 kHz FEC ON
Spurious Rejection > 67 dB FEC ON
Typical Power
Consumption
RX 12 V: 1.32 W
TX 12 V: 5.8 W @ 1 W RF
Transmitter Power
(programmable) 0.1, 0.2, 0.5, 1 W TX-mode, 50Ω load
Communication Mode Half-Duplex
Adjacent Channel Power acc. to EN 300 113 TX-mode
Transient Adjacent
Channel Power acc. to EN 300 113 TX-mode
Carrier power stability < ±1.5 dB

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
12
DATA MODEM Note
Electrical Interface RS-232
Data speed of Serial
Interface 1200 – 115200 bps
Data speed of Radio
Interface
4FSK FEC OFF: 19200 bps (25 kHz) 9600 bps (12.5 kHz)
4FSK FEC ON: 14400 bps (25 kHz) 7200 bps (12.5 kHz)
8FSK FEC OFF: 28800 bps (25 kHz) 14400 bps (12.5
kHz)
8FSK FEC ON: 19200 bps (25 kHz) 9600 bps (12.5 kHz)
16FSK FEC ON: 28800 bps (25 kHz) 14400 bps (12.5
kHz)
Data Formats Asynchronous data
Air Interface Encryption AES128 Programmable
Modulation 4FSK, 8FSK, 16FSK, GMSK
Values are subject to change without a notice.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
13
SATEL Proof-TR9 complies with the following international standards:
FCC Parts 15.209 and 15.247 of Title 47
IC RSS-247, ICC RSS-Gen
AS/NZS 4268:2012, AS/NZS 4771:2000
RECEIVER TRANSMITTER
Frequency Range 902-928 MHz
Spreading Method
Frequency Hopping
Occupied
Bandwidth
230
kHz
Frequency Stability <1 kHz
Maximum Receiver Input
Power without Transmission
Errors
-3 dBm
Sensitivity
typ.
-
109 dBm for BER 10
-4
Transmitter Power 0.01, 0.02, 0.5, 0.1, 0.2, 0.5, 1 W
Carrier power stability
< ±1.5 dB
Electrical Interface
RS
-
232
Data Speed of Radio Interface
115200 bps
Modulation Method
2
-
GFSK
Hopping Bands
7, user selectable
Hopping Patterns
15 per band, 105 total, user selectable
Hopping Channels
50
-
112, user selectable
Frequency Zones
16
Zones, 7 Channels per Zone
Data speed of Serial interface
9600
–
115200 bps

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
14
GENERAL FOR BOTH TR4 and TR9 Note
Operating Voltage +6 … +30 Vdc +/- 10% Vdc External DC supply
Temperature
Ranges
-30 °C ... +65 °C Operational
-40 °C … +75 C Absolute min / max
-25 °C ... +55 °C Complies with standards
-40 °C … +85 C Storage
Antenna Connector 50 , TNC female
Interface Connector Deutsch DT04-6P-CL09
Housing Shielded / bare PCB inside a metal housing
Size L x W x H 176 x 95 x 43 mm
See Mechanical
dimensions chapter
Mechanical
Properties
IEC60068-2-32, ISO9022-36-08, ISO9022-31-06,
ISO9022-33-06
Weight <500 g
IP rating IP69K
High pressure. SATEL
Proof-TR4/-TR9 meets the
IP classification rating
according to correctly
assembled and connected
mating connector in the
device Deutsch
connector. See details
from the connector
manufacturer’s datasheet
OTHER MEASURES Note
ESD-failure
threshold 8 kV contact, 15 kV air discharge
Immunity test 10 V/m
Values are subject to change without a notice.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
15
3 CONFIGURATION
The configuration of settings can be changed easily - the next chapters describe the details:
SATEL Configuration Manager PC software
This clear to use software suits in most cases. Additional to other tools, it includes the channel
list editor for creating the channel lists.
SL commands
A terminal device can command or configure the radio modem by using special commands. SL
commands are applied especially in cases where radio modems are to be integrated seamlessly
inside a system behind the integrator’s own user interface.
3.1 Configuration
The configuration of SATEL Proof–TR4/-TR9 radio modem can be modified by connecting the
modem to the PC and using SATEL Configuration Manager. Programming is done using RS-232
port. The RS-232 serial port settings must match between SATEL Proof–TR4/-TR9 and terminal
port.
Minimum requirements: SATEL Configuration Manager PC-program COM port with baud rate
min. 9600 bps (alternatively with industrial level USB-RS adapter), recommended Win10 64-bit
OS. The software is available from the dealers or at www.satel.com.
3.1.1 Configuration Manager
SATEL Configuration manager program makes it possible to edit the modem settings and
update the firmware.
QuickStart
Preliminary settings
1. Save the SATEL Configuration Manager files in the same
directory.
2. Connect the modem to the PC using a proper interface
cable.
3. Connect power to the modem. Before connecting,
check that you have correct supply voltage.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
16
4. Open the SATEL Configuration Manager program. Check from the “Program Preferences”
tab, that you have selected correct COM-port number and that the serial port settings
match to the modem. Default settings are 115200 bps, 8 bit, none parity, 1 stop bit.
5. To establish connection between the modem and the PC, click the blue Connect tab. To
get the radio modem info, click blue Read Settings tab.
6. Check the settings and modify if needed.
7. Store settings to a modem using “Write settings” –button.
8. More information about Configuration Manager can be found from user guide.
3.1.2 Changing parameters using the SL COMMANDS
The controlling terminal device can change the configuration settings of the module. This is
accomplished with the help of SL commands. SL commands can be used to change e.g. the
frequency or addresses. It is also possible to ask the radio transceiver module to show current
settings which are in use.
3.1.2.1 SL Commands
An SL command is a continuous string of characters, which is used to control the device and its
settings for example from the terminal screen (similar to AT commands).
Serial interface settings are the same as in data transfer, however, if SERV pin is set to LOW,
baud rate is fixed 38400, 8, N, 1. SL command is properly recognised also in the case when the
command string is terminated by <CR> (<CR> = Carriage Return, ASCII character no. 13, Carriage
Return, 0x0d in hex) or <CR><LF> (<LF>= Line Feed, ASCII char. no. 10, Line Feed, 0x0a in hex). No
extra characters are allowed at the end of an SL command.
SL command is separated from other data by pauses which are equal or greater than time
defined by Pause Length-parameter (default = 3 characters) in the settings. If multiple SL
commands are sent to the module, the next command can be given after receiving the response
("OK" or "ERROR") of the proceeding command. In addition, it is recommended to implement a
timeout to the terminal software for recovering the case when no response is received from the
radio module.
The module will acknowledge all commands by returning an "OK" (command carried out or
accepted) or the requested value, or an "ERROR" (command not carried out or interpreted as
erroneous) message.
SL commands are described in separate documentation. In order to get information of the latest
and/or special SL commands or additional information on the time delays related to the use of
SL commands, please contact SATEL.

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
17
3.1.2.2 SL Command Mode
When the SL commands are enabled there are possibilities that the user data may start with the
characters “SL” which is handled as the SL command. This has caused the firmware to go to the
continuous SL command search mode and any data has not been sent or even an “ERROR”
acknowledgment has been received. To avoid this kind behaviour the user can disable the SL
commands.
The SL commands can be disabled or enabled by using SL commands or toggling the “SL
Command mode” parameter via the SATEL Configuration Manager, version v1.3.15 or newer.
By default the SL Command mode is set to ON. If the SL Command mode is set to OFF then the SL
commands can be enabled or disabled by using the below described procedure. Regardless of
original SL command –setting state, changing the setting state with this procedure will effect to
the reception process of the radio module. SL command –setting state can be changed only via
SATEL Configuration Manager in maintenance access level.
Radio can be set to Command mode separately with “+++” command, regardless of the set SL
command mode (ON/OFF). Enabling the Command mode temporarily enables the SL command
mode and disables the radio interface functions (Tx/Rx).
To enable the Command mode:
 Send three “+” characters via serial port so that there is at least three bytes delay
(according to Pause Length -setting) between each character. The response is “OK”,
when successfully set.
<+><at least three bytes pause*><+><at least three bytes pause*><+>
To disable the Command mode:
 Send three “-” characters via serial port so that there is at least three bytes delay
(according to Pause Length -setting) between each character. The response is “OK”,
when successfully set.
<-><at least three bytes pause*><-><at least three bytes pause*><->
*Pause Length -setting
Note!
The “+ + +” and “- - -” procedures are not recommended to be used when radio is transmitting or
receiving data (i.e. the application data occupies the TD or RD lines of the radio).

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
18
4 MODEM SETTINGS
4.1 Default settings of SATEL Proof-TR4
The radio modem is delivered with the following default settings (unless otherwise specifically
ordered):
DEFAULT VALUES OF THE ADJUSTABLE SETTINGS ( the user can change these settings later on )
Setting
Default value
Range
Radio
frequency
Operating TX frequency
438.000 MHz
Range: 403
-
473 MHz
Operating RX frequency
438.000 MHz
Range: 403
-
473 MHz
Reference Frequency
438.000 MHz
Range: 403
-
473 MHz
Channel Bandwidth
12.5 kHz / 25 kHz
Channel Spacing
25 kHz
12.5, 20
(uses 12.5kHz channel width), 25 kHz
Min. RF Frequency Step
6.25 kHz (10kHz @20kHz channel spacing)
Radio settings
TX Power
1000 mW
Range: 100, 200,
500 or 1000 mW
Signal threshold
-
115 dBm
-
80 …
-
118 dBm
TX
-
Start Delay
0 ms
0
-
65535 ms
Radio
Compatibility
(Available set depends on
the factory configuration)
SATELLINE-3AS
SATEL
LINE
-
3AS
PacCrest-4FSK
PacCrest-GMSK
PacCrest-FST
TrimTalk450s(P)
TrimTalk450s(T)
SATELLINE-2ASxE*
SOUTH
SATEL-8FSK-1 (FEC OFF)
SATEL-8FSK-2 (FEC ON)
SATEL-16FSK-1 (FEC ON)
Addressing
RX Address
OFF
ON/OFF
TX Address
OFF
ON/OFF
Serial port
Data speed
115200 bps
1200
–
115200 bps
Data bits
8
8
Parity bits
None
None, Even, Odd.
Stop bits
1
1
Note*) Ask availability from SATEL

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
19
Handshaking
Handshaking lines apply to the DATA
-
port.
Pause length
3 bytes
3….255
Additional setup
Error correction, FEC
OFF
ON/OFF
Error check
OFF
O
FF, CRC8Partial, CRC8Full, CRC16Full
Repeater Mode
OFF
ON/OFF
SL
-
commands
ON
ON/OFF
TX Delay
0
0 …. 65535 ms
Over
-
the
-
Air
-
Encryption
OFF
ON/OFF
Use Channel List
OFF
ON/OFF
Power Save Mode
OFF
ON/OFF
Add RSSI to Data
OFF
ON/OFF
Radio State
TX
TX/RX
Priority
TX
TX/RX
4.2 Default settings of SATEL Proof-TR9
The radio modem is delivered with the following default settings (unless otherwise specifically
ordered):
DEFAULT VALUES OF THE ADJUSTABLE SETTINGS (the user can change these settings later on)
Operation Mode
Default value
Note
Point
-
to
-
Multipoint Slave
3
Set Baud Rate
Baud Rate
115200
Data Parity
0
Modbus RTU
0
RS232/485
0
Setup Port
3
TurnOffDelay/OnDelay
0/0
FlowControl
0
Radio Parameters
FreqKey
5
Hop Table Version
0
Hop Table Size
112
Hop Freq
Offset
0
Frequency Zone
All 1s (Enabled)
Max Packet Size 8
Min Packet Size
9
Xmit Rate
1
RF Date Rate
3
RF Xmit Power
1000

SATEL Proof-TR4/-TR9
User Guide, Version 1.2
20
Slave Security
0
RTS to CTS
0
Retry Timeout
255
Low Power Mode
0
High Noise
0
MCU Speed
0
Remote LED
0
Multipoint Parameters
Number of Repeaters
1
Master Packet Repeat
3
Max Slave Retry
9
Retry Odds
9
DTR Connect
0
Repeater Frequency
0
Network ID
255
Multimaster Sync
0
Slave/Repeater
0
Subnet ID
“Disabled”
