Coemar LEDKO EXT M User manual

EXT M

2
Please note in the space provided above the relative service information of the model and the
retailer from whom you purchased your LEDko EXT MLEDko EXT M: this information will assist us in providing
spare parts, repairs or in answering any technical enquiries with the utmost speed and accuracy.
WARNING:WARNING: the security of the fixture is granted only if these instructions are strictly followed;
therefore it is absolutely necessary to keep this manual.
Serial Number:
....................................................................................................................................................
Purchase date:
....................................................................................................................................................
Dealer:
....................................................................................................................................................
Address:
....................................................................................................................................................
Suburb:
....................................................................................................................................................
Country:
....................................................................................................................................................
Phone / Fax:
....................................................................................................................................................
User Manual version 1.0User Manual version 1.0
Edition 10 October 2022
EXT M

3
Index
1. Packaging and transportation ..........................................................................................Pag. 5
1.1 Packaging ........................................................................................................................Pag. 5
1.2 Transportation ...............................................................................................................Pag. 5
2. General information .......................................................................................................... Pag. 5
2.1 Safety informations ..................................................................................................... Pag. 5
2.2 Warranty conditions ................................................................................................... Pag. 6
2.3 EC norms ...................................................................................................................... Pag. 6
3. Product specifications ......................................................................................................Pag. 7
3.1 Technical characteristics .............................................................................................Pag. 7
3.2 Dimensions ................................................................................................................... Pag. 7
3.3 Unit’s main components .............................................................................................Pag. 8
4. Installation ..........................................................................................................................Pag. 9
4.1 Mechanical installation ............................................................................................... Pag. 9
4.2 Safety chain .................................................................................................................Pag. 9
4.3 Adjusting unit’s tilt .....................................................................................................Pag. 10
5. Powering up ........................................................................................................................Pag. 11
5.1 Operating voltage and frequency ............................................................................. Pag. 11
5.2 Connection to mains power .......................................................................................Pag. 11
6. Turning on the projector .................................................................................................Pag. 12

4
7. Accessories and spare parts ........................................................................................... Pag. 12
8. Maintenance .................................................................................................................... Pag. 13
8.1 Firmware update ......................................................................................................... Pag. 13
8.2 Periodic cleaning ........................................................................................................ Pag. 13
8.3 Periodic controls ........................................................................................................ Pag. 13
8.4 Fuses ............................................................................................................................Pag. 13
9. F.A.Q. and answers ........................................................................................................... Pag. 14

5
Congratulations on having purchased a CoemarCoemar product. You have assured yourself of a fixture
of the highest quality, both in componentry and in the technology used. We renew our invitation
to you to complete the service information on the previous page, to expedite any request for
service information or spares (in case of problems encountered either during, or subsequent
to, installation). This information will assist in providing prompt and accurate advice from your
CoemarCoemar service centre. Following the instructions and procedures outlined in this manual will
ensure the maximum eciency of this product for years to come.
1.1. Packaging and transportationPackaging and transportation
1.11.1 PackagingPackaging
Open the packaging and make sure that no part of the equipment has suered any damage
during the transportation. In case of damage to the fixture, contact your currier and your
supplier immediately by telephone, fax or email, and inform them you will formally notify them
in writing through registered letter.
Packing listPacking list
Ensure the packaging contains:
1 LEDko1 LEDko EXT MEXT M
1 Instruction manual1 Instruction manual
22. General information. General information
2.12.1 Safety informationsSafety informations
Fire prevention:Fire prevention:
1. Never locate the fixture on any flammable surface.
2. Minimum distance from flammable materials: 0,5 m.
3. Minimum distance from the closet illuminable surface: 0,5 m.
4. Replace any blown or damaged fuse only with those of identical values.
Refer to the schematic diagram if there is any doubt.
5. Connect the projector to mains power protected by a thermal magnetic
circuit breaker.
Prevention from electric shock:Prevention from electric shock:
1. Presence of high voltage inside of the fixture. Insulate the projector from
mains supply before opening or performing any function which involves
touching the inside of the fixture, including lamp replacement.
2. For the connection to the mains, adhere strictly to the guidelines outlined in
this manual.
1.21.2 TransportationTransportation
The LEDkoLEDko EXT MEXT M should be transported in either its original packaging or in an appropriate
flight case.

6
Safety:Safety:
1. The projector must always be installed with bolts, clamps, or other fixing
devices which are suitably rated to support the weight of the projector.
2. Always use a secondary safety fixing device with chain or steel wire of a
suitable rating to sustain the weight of the unit in case of failure of the
principal fixing point.
3. The external surfaces of the unit, at various points, may reach 60°C. Never
handle the unit until at least 10 minutes have elapsed since the LED was
turned o.
4. Never install the fixture in an enclosed area lacking sucient air flow; the
room temperature must not exceed 35°C.
5. The projector contains electronic and electrical components which must
under no circumstances be in contact with water, oil or any other liquid.
Failure to do so will compromise the proper functioning of the projector.
2.22.2 Warranty conditionsWarranty conditions
1. The fixture is under warranty for 36 months from the purchase date against factory
defections.
2. Damage ought to unskillfulness, inappropriate use, or lack of suggested maintenance are
excluded from the warranty.
3. Warranty expires when the projector is opened by unauthorized personnel.
4. Warranty doesn’t include the replacement of the fixture.
5. Serial number and model ofthe fixture are necessaryto retrieve informations and assistance
from the dealer.
2.32.3 EC NormsEC Norms
1. The fixture satisfies the essential requirements of the directive 2004/108/EC, 2006/95/
EC, 2011/65/EC, 2002/96/EC & 2003/108/EC.
2. The fixture is in accordance with the standard EN 50419 (RoHS) and satisfies the
requirements of the directive 2002/96/EC (WEEE).
3. The level of technology of LEDko EXT M requires the use of specialised per-
sonnel for all service applications; refer all work to your authorised Coemar
service centre.
4. A good earth connection is essential for the proper functioning of the pro-
jector. Never connect the fixture if there is no earth connection.
5. Mains cables must not come into contact with other cables.
6. Do not operate the projector with wet hands or in an area where water is
present.
7. The fixture must never be located in an exposed position, or in areas of ex-
treme humidity.

7
Power supplyPower supply 85264 V, auto-sensing, 47/63 Hz
Maximum currentMaximum current 0.28 A @ 230 V, 0.56 A @ 115 V
Power factorPower factor Cosϕ= 0.9
Power consumptionPower consumption 58 W
Color temperatureColor temperature Fixed white temperature at 3.200 K or 5.600 K
WeightWeight Body: 2.8 Kg (6.17 lbs)
Power Supply Box: 0.96 Kg (2.12 lbs)
Working TemperatureWorking Temperature From -25°C to +40°C (-13°F to 104°F)
Storage TemperatureStorage Temperature From -30°C to +80°C (-22°F to 176°F)
IP ratingIP rating IP65
3.3. Product specificationsProduct specifications
3.13.1 Technical characteristicsTechnical characteristics
3.23.2 DimensionsDimensions
351 mm
13.82 in
Ø 100 mm
3.94 in
60 mm
2.36 in
63 mm
2.48 in
500 mm
19.69 in
137 mm
5.39 in
500 mm
19.69 in
151 mm
5.94 in
132 mm
5.19 in
175 mm
6.89 in
Ø 10.5 mm
0.41 in
Ø 45 mm
1.77 in

8
3.33.3 Unit’s main componentsUnit’s main components
Components descriptionComponents description
AA Lens
BB Cooling unit
CCPower Box
DD Yoke with mounting holes
BB
CC
AA
>
DD

9
44. Installation. Installation
4.14.1 Mechanical installationMechanical installation
LEDkoLEDko EXT MEXT M may be hung from an appropriate structure in any position or on tripode. If
hanging the fixture from a lighting truss or similar, we recommend the use of an appropriate
clamp “AA”, as shown in the following diagram.
Warning!!Warning!!
Always ensure that your support structure
and fixing (bolts, clamps, etc…) are rated to
support the weight of the fixture.
4.24.2 Safety chainSafety chain
When hanging LEDkoLEDko EXT MEXT M it is recommended to use a safety chain, as required by current
legislation. The safety chain must pass through the handles of the unit and then attached to
the structure.
If using steel cables and chains not Coemar’s production, make sure they are suitable to support
the weight of the unit according to normative UL/ETL (required: the weight of 6 complete
devices for at least one hour).
A

10
4.34.3 Adjusting unit’s tiltAdjusting unit’s tilt
In order to adjust the tilt of the unit simply loose the side screw “BB” on the yoke, adjust the tilt
and lock the yoke by tightening the screw again.
B

11
55. Powering up. Powering up
5.25.2 Connection to mains powerConnection to mains power
Mains cable characteristicsMains cable characteristics
The mains cable provided is thermally resistant, complying to the most recent International
standards.
Note: in case of cable replacement, similar cable with comparable thermal resistant qualities
must be used exclusively (cable 3 X 1,5 ø external 10 mm, rated 300/500V, tested to 2 KV,
operating temperature -40°C + 180°C, Coemar cod. CV5311).
Connection to mains powerConnection to mains power
LEDko EXT MLEDko EXT M is equipped with one power connectors.
The max absorption of LEDkoLEDko EXT MEXT M is reported in the following table:
- 230 VaC 0.28 A constant during normal exercise.
- 115 VaC 0.56 A constant during normal exercise.
5.15.1 Operating voltage and frequencyOperating voltage and frequency
The unit may operates at voltages ranges from 85 to 264 VaC at a frequency of 47 or 63 Hz.
It is not needed to eect any setup procedures: LEDko EXT M will automatically adjust its op-
eration to suit any frequency or voltage within this range.
brown
blue
yellow / green
fase
neutral
mass
Warning!!Warning!!
• The use of a thermal/magnetic circuit breaker is recommended. Strict adherence to
regulatory norms is strongly recommended.
•• LEDkoLEDko EXT MEXT M should not be powered through a dimmer as this may damage the internal
switching power supply.
• Prior to connecting the device to mains power, ensure that the mains characteristics are
within the recommended range for the use of LEDkoLEDko EXT MEXT M.
• All cabling and connections should be carried out by a suitably qualified personnel.

12
6.16.1 Control signal connection by XLR5 plugsControl signal connection by XLR5 plugs
The digital control signal is transmitted to the projector via a two pole cable screened as per
International standards for the transmission of DMX 512 data. The connection must be serial,
using connectors XLR5 male and female located on the back of LEDkoLEDko EXT MEXT M Series labelled
DMX512 IN e OUT (see diagram).
Connectors equipped on LEDkoLEDko EXT MEXT M are IP rated, which ensures protection against water
and dust. In order to keep this rating they must be connected exclusively to other IP rated
connectors.
6.6. Control signal connectionsControl signal connections
Controller
Standard
DMX 512
OUT
3
2
1
Pin 1 = Ground (GND)
Pin 2 = Data -
Pin 3 = Data +
Pin 4 = Not connected
Pin 5 = Not connected
DMX in DMX out
DMX in DMX out
Warning!
Make sure that screening and conductors are not in contact one another or with the metal
housing of the connector.
Pin#1 and housing never must be connected to the power supply unit.

13
7.7. Turning the projector onTurning the projector on
After having followed the preceding steps described, proceed with the power supply and turn on
the projector connecting it to the mains power.
8.18.1 Quick guide to menuQuick guide to menu
The LEDkoLEDko EXT MEXT M required RDM (Remote Device Management) to set up fixtures. Using
an RDM compliant DMX controller, you can communicate with all the fixtures on a data link
without needing to connect to each fixture individually. RDM lets you set the DMX addresses
of all the fixtures on the link, carry out fixture configuration and retrieve fixture data including
details of any error that has been logged. If two or more identical fixtures are set up with
the same DMX address and in the same DMX mode, they will receive the same instructions
and behave identically. Setting up identical fixtures with the same address is a good tool for
troubleshooting unexpected behavior and an easy way to achieve synchronized action. Setting
DMX addresses via RDM involves running a scan to identify the fixtures that are present on the
data link and then allocating addresses either automatically or manually.
To use RDM:
1. Obtain an RDM-compatible controller such as the RDM UPGRADE INTERFACE B
(cod. AC10011A001 ) application running on a Windows PC.
2. Use a USB cable to connect the PC to a USB/DMX interface box
3. Connect the interface box to the data link.
4. Power the fixture on and carry out an RDM discovery / scan in your RDM-compatible
controller.
5. You can then configure or retrieve data from the fixtures on the data link.
8.8. Setup via RDMSetup via RDM
8.28.2 RDM ChartRDM Chart
PARAMETER DESCRIPTION
DMX ADDRESS Set DMX Address: (1512)
CURVE Set Dimming Curve: Linear, Logarithmic, Exponential, Halogen
FREQUENCY Set Pwm Frequency: 600Hz-1500Hz-2000Hz-5000Hz-20.000Hz
LOCK PIN Set Lock Pin
LOCK STATE Set Screen Lock
FACTORY DEFAULT Factory Reset
PERSONALITY Set Personality: 5Ch, 2Ch, 4Ch, Sunrise Mode
SENSOR Visualize Sensor
LED HOURS Visualize Led Life Hours
DEVICE HOURS Visualize Device Life Hours

14
8.38.3 RDM Error ChartRDM Error Chart
ERROR DESCRIPTION SOLUTION
MEMORY Memory Reading Error Perform A “Factory Reset”
HW MEMORY Memory Hardware Error Contact Coemar
DMX ADDR DMX Addressing Error The Personality Dimension
Exceeds 512 Channels
NTC ERROR Temperature Sensor
Disconnected
Check Wiring NTC Led
SHORT NTC Short-Circuited Temperature
Sensor
Check Wiring NTC Led
OVER TEMP Electronic Board
Overtemperature
Ambient temperature too
high, place the projector in an
environment with temperature
below 40 °C

15
8. DMX chart Fixed White Version
8.1 DMX Chart 5 and 1 channels
channel function type of
control eect decimal percentage
5 1
1 1 master dimmer proportional adjust luminous output
intensity from 0 to 100% 0 - 255 0% - 100%
2 - spare channel step no eect 0 - 255 0% - 100%
3 - dimmer fine proportional fine dimmer control 16 bit 0 - 255 0% - 100%
4 - strobe
step no eect 0 - 9 0% - 4%
proportional variable speed strobing eect,
from slow to fast 10 - 57 4% - 22%
step stop strobe 58 - 59 23% - 23%
proportional
sequenced pulse eect,
slow closing, fast opening
(variable speed pulsing, from slow to fast)
60 - 108 24% - 42%
step stop strobe 109 - 110 43% - 43%
proportional
sequenced pulse eect,
fast closing, slow opening
(variable speed pulsing, from slow to fast)
111 - 159 44% - 62%
step stop strobe 160 - 161 63% - 63%
proportional random strobe eect with variable speed
from slow to fast 162 - 207 64% - 81%
step stop strobe 208 - 209 82% - 82%
proportional random strobe eect with variable speed
from slow to fast 210 - 255 82% - 100%
5 - special
functions
step
park 0 - 9 0% - 4%
600 Hz 10 - 22 4% - 9%
no eect 23 - 84 9% - 33%
fan at SILENT mode 85 - 96 33% - 38%
fan at STUDIO mode 97 - 108 38% - 42%
fan at AUTO mode 109 - 120 43% - 47%
proportional fan speed control 121 - 133 47% - 52%
step
enables the automatic display blackout 134 - 185 53% - 73%
disables the automatic display blackout 186 - 199 73% - 78%
LED control frequency tuning 1.500 Hz 200 - 205 78% - 80%
LED control frequency tuning 2.000 Hz 206 - 211 81% - 83%
LED control frequency tuning 5.000 Hz 212 - 217 83% - 85%
no eect 218 - 240 85% 94%
LED control frequency tuning 20.000 Hz 241 - 255 95% - 100%

16
8. DMX chart VariWhite Version
8.1 DMX Chart 5 channels
channel function type of
control eect decimal percentage
1 master dimmer proportional adjust luminous output intensity
from 0 to 100% 0 - 255 0% - 100%
2 dimmer fine proportional fine dimmer control 16 bit 0 - 255 0% - 100%
3 white tone
step 2.800 K 0 - 6 0% - 2%
proportional proportional value from 2.800 K to 3.200 K 7 - 33 3% - 13%
step 3.200 K 34 - 60 13% - 24%
proportional proportional value from 3.200 K to 4.000 K 61 - 87 24% - 34%
step 4.000 K 88 - 114 35% - 45%
proportional proportional value from 4.000 K to 5.000 K 115 - 141 45% - 55%
step 5.000 K 142 - 168 56% - 66%
proportional proportional value from 5.000 K to 5.600 K 169 - 195 66% - 76%
step 5.600 K 196 - 222 77% - 87%
proportional proportional value from 5.600 K to 6.000 K 223 - 249 87% - 98%
step 6.000 K 250 - 255 98% - 100%
4 strobe
step no eect 0 - 9 0% - 4%
proportional variable speed strobing eect,
from slow to fast 10 - 57 4% - 22%
step stop strobe 58 - 59 23% - 23%
proportional
sequenced pulse eect,
slow closing, fast opening
(variable speed pulsing, from slow to fast)
60 - 108 24% - 42%
step stop strobe 109 - 110 43% - 43%
proportional
sequenced pulse eect,
fast closing, slow opening
(variable speed pulsing, from slow to fast)
111 - 159 44% - 62%
step stop strobe 160 - 161 63% - 63%
proportional random strobe eect with variable speed
from slow to fast 162 - 207 64% - 81%
step stop strobe 208 - 209 82% - 82%
proportional random strobe eect with variable speed
from slow to fast 210 - 255 82% - 100%
5special
functions
step
park 0 - 9 0% - 4%
600 Hz 10 - 22 4% - 9%
no eect 23 - 84 9% - 33%
fan at SILENT mode 85 - 96 33% - 38%
fan at STUDIO mode 97 - 108 38% - 42%
fan at AUTO mode 109 - 120 43% - 47%
proportional fan speed control 121 - 133 47% - 52%
step
enables the automatic display blackout 134 - 185 53% - 73%
disables the automatic display blackout 186 - 199 73% - 78%
LED control frequency tuning 1.500 Hz 200 - 205 78% - 80%
LED control frequency tuning 2.000 Hz 206 - 211 81% - 83%
LED control frequency tuning 5.000 Hz 212 - 217 83% - 85%
no eect 218 - 240 85% 94%
LED control frequency tuning 20.000 Hz 241 - 255 95% - 100%

17
channel function type of
control eect decimal percentage
1 master dimmer proportional adjust luminous output intensity
from 0 to 100% 0 - 255 0% - 100%
2white tone proportional proportional value from 2.800 K to 6.000 K 0 - 255 0% - 100%
8.1 DMX Chart 2 channels
77. Accessories and Spare parts. Accessories and Spare parts
All the components of LEDkoLEDko EXT MEXT M are available as spare parts from your CoemarCoemar dealer or
Service. Accurate description of the fixture, model number and type will assist us in providing
for your requirements in an ecient and eective manner.

18
88. Maintenance. Maintenance
11.111.1 Firmware updateFirmware update
The firmware of LEDkoLEDko EXT MEXT M can be updates through the RDM protocol (ANSI E1.20). Contact
Coemar assistance to receive the software and the device updater.
11.211.2 Periodic cleaningPeriodic cleaning
!Regular cleaning is essential for fixture life and performance.!Regular cleaning is essential for fixture life and performance.
Buildup of dust and dirt degrades the fixture’s light output and cooling ability.Buildup of dust and dirt degrades the fixture’s light output and cooling ability.
!To clean the housing and front cover Isolate the fixture from AC power and allow the fixture to!To clean the housing and front cover Isolate the fixture from AC power and allow the fixture to
cool for 20 minutes.cool for 20 minutes.
!Before closing the cover after each cleaning, remember to heat the LEDs for at least 20 minutes,!Before closing the cover after each cleaning, remember to heat the LEDs for at least 20 minutes,
so as to eliminate all traces of humidity.so as to eliminate all traces of humidity.
LensesLenses
Even a thin layer of dust can reduce the luminous output and alter the consistency of the beam.
Regularly clean all filters and lenses using a soft cotton cloth, dampened with a special lens
cleaning solution.
Cleaning of the unitCleaning of the unit
Use a soft brush or a common vacuum cleaner or a source of compressed air for removing dust.
For the cleaning of the housing use a soft cloth and a non-aggressive cleaner, Lukewarm Water
or Mild Soap.
FORBIDDEN: (Abrasive Cleaners, Highly Alkaline Cleaners, Aromatic Solvents, Halogenated
Solvents, Brushes, Steel Wood).
Check that the internal fans (if provided in the product) and heat exchanger must be perfectly
clean.
Don’t use pressure washer or water jet, do not leave cleaners on plastic parts for a long period
and do not apply cleaners in direct sunlight or at elevated temperatures.

19
99. F.A.Q. and answers. F.A.Q. and answers
The following list shows common issues that may be simply solved. If issues persist, the unit
must be repaired by a qualified personnel or just contact your CoemarCoemar service.
QuestionQuestion Possible solutionPossible solution
LEDkoLEDko EXT MEXT M does not
emit light
Projector not powered on:Projector not powered on:
• Make sure the power cable is plugged in or test the input
voltage;

20
User notes
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
....................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
......................................................................................
.....................................................................................
