Colad Snap Lid System 93100130SLS Troubleshooting guide

Install the Snap Lid System®
adapter specific to your spray
gun model with a Wrench
#22. Keep the adapter
installed on the spray gun.
Mix paint in cup: Mixing, reducing
and mechanical agitation can be
done in the Snap Lid System®cup
prior to the Snap Lid System®lid
being snapped on.
Attach lid to cup: starting at the
side nearest the air-vent with the
lid on an angle, push down with
both thumbs and press down
around the perimeter of the lid until
the lid snaps securely onto the cup
and a seal is achieved.
Attach the spray gun
onto the lid by twisting
the threads and
tightening until secure.
Rotate gun/cup
assembly right side up
and attach air hose.
Tilt the spray gun forward
and backward to release
any air below the filter.
Now begin spraying.
The Snap Lid System®
will spray just like a
vented cup.
When finished with spraying, turn
the cup upside down and pull
the spray gun trigger to allow
flow of product back into the cup
from the gun. Remove Snap Lid
System®and clean spray gun.
1
2
3
4
5
6
7
8
OnlyColad!
Snap Lid System®
Quick Start-up Guide

FOR REFILLS
Remove the spray gun. Pull up on the tab and unlock the seal in a circular
motion to remove the lid. Refill the cup with paint and reseal the lid.
STORING UNUSED PAINT
The lid can be temporary sealed with the red Snap Lid®Sealing Caps. Also
available are the black Snap Lid®Mixing Cup Lids, that can be used for
longer storage and stack Snap Lid®cups containing unused paint.
FOUR FILTERS AVAILABLE
Suitable for all types of paint:
White - 90 micron – Clear coat
Blue – 130 micron – Waterborne base coat
Green – 190 micron – Conventional base coat
Red – 280 micron – Primer
Perfect consistency and pigment blend are crucial for a spotless
end result. Mixing paint with the Turbomix Paintsaver®speeds up
the process, reduces paint wastage and ensures a perfect result.
TURBOMIX PAINTSAVER®
MIX EXACTLY WHAT YOU NEED
Snap Lid System®maximizes airflow for a consistent spray pattern to the last drop.
This gives an optimal usage of paint with minimal waste.
SUITABLE FOR ALL
TYPES OF
MIXING CUPS
DESIGNED
TO ACHIEVE
THE PERFECT
BLEND
BREAK IT
(BEFORE MIXING)
TO SAVE PAINT
AND PIGMENTS
COLAD IS A BRAND OF EMM INTERNATIONAL
Bohemenstraat 19 8028 SB Zwolle (The Netherlands)
T [phone] E [email protected] www.colad.co
We will provide you with everything you need. All our products are meant to
help you reach your end result with durability and efficiency. So have fun on
the work floor as you create, we believe in your professionalism.
Colad, inventing more.
