Coleman 70DX 2020 User manual

WARNING
Never Attempt to start this Dirt Bike without reading and
understanding the Owner’s/Operator’s manual. The Owner’s/
Operator’s manual provides information on safety, parts,
functions, pre-ride inspection, starting and maintenance.
!
For questions about these assembly Instructions, call Coleman
Powersports toll free 888-405-8725
ASSEMBLY/INSTRUCTIONS
Tools needed for assembly
Phillips
Screwdriver
8mm,10mm
Wrench 8mm,10mm
Ratchet 032615
Model: 70DX

Handlebar assembly Hardware
Top Clamps
Shift Lever
Removal From Crate
Number Plate
NOTE: SOME HARDWARE MY ALREADY BE AT ITS ASSEMBLY LOCATION ON THE DIRT BIKE
Removed from crate
Owner's Manual
ITEMS IN HARDWARE CARTON
Hardware
Carton
Handlebar Pad
Tool Kit
M6 x35 Bolts

Handlebar Assembly
STEP 1
STEP 6 Shift Lever Installation
NOTICE: THESE ARE ASSEMBLY INSTRUCTIONS ONLY. BEFORE STARTING THE DIRT
BIKE FOR THE FIRST TIME , REFER TO THE OWNERS MANUAL FOR PRE-RIDE INSPECTION
PROCEDURES. INCLUDING, OIL TYPE AND QUANTITY, TIRE PRESSURES, FUEL TYPE, ETC.
BEFORE STARTING THE DIRT BIKE FOR THE FIRST TIME READ OWNER’S MANUAL
THOROUGHLY. THE OWNER’S MANUAL HAS IMPORTANT INFORMATION REGARDING
SAFETY, MAINTENANCE AND PROPER PRE-RIDE INSPECTION PROCEDURES.
Torque M8 x 20bolts - 20ft.lbs
NO. NAME QTY SPEC.
1 HEX HEAD BOLT 4 M6X35
2 TOP CLAMPS 2
3 HANDLE BAR 1
4 BOTTOM CLAMPS 2
5 UPPER TRIPLE BRACKET 1
NO. NAME QTY SPEC.
1 NUT 1 M6X20
2 GEAR LEVER 1

Handlebar Pad Installation
