Coleman DB70 User manual

READ THIS MANUAL CAREFULLY!
Provincial / Municipal governments have different regulations
pertaining to owning and operating an off-road vehicle, learn the
regulations in your area.
Model: 125DX
Always wear a helmet it could save your life!
Never allow any child under the age of 16 to operate this Dirt Bike
without continual adult supervision.
READ THIS MANUAL CAREFULLY!
POWERSPORTS
[phone] Coleman Powersports
364 S Smith Rd. Tempe, AZ. 85281
Always wear a Helmet, it could save your life!
Provincial / Municipal governments have different regulations
pertaining to owning and operating an off-road vehicle, learn the
regulations in your area.
www.colemanpowered.com
OWNER’S MANUAL
Model DB70
REV# 042115

Congratulations on your purchase of a Coleman Powersports Dirt Bike.
This Owner’s/Operator’s manual will provide information regarding safe
operation, operational instructions, maintenance and care. Fully under-
standing this manual and following all of the instructions herein will provide
the knowledge needed to have safe and enjoyable Dirt Bike operation.
For questions regarding operation and maintenance of this Dirt Bike, please
call Coleman Powersports toll free 888-405-8725 or go to
colemanpowered.com
Children differ in skills, physical abilities, and judgement. Some children
may not be able to operate a Dirt Bike safely. Parents should supervise
their child’s use of the Dirt Bike at all times. Parents should permit contin-
ued use only if they determine that the child has the ability to operate the
Dirt Bike safely.
THIS DIRT BIKE IS NOT A TOY AND COULD BE HAZARDOUS TO OPERATE.
Reading the Owner’s/ Operator’s Manual
It is important this manual is read from cover to cover carefully by the Dirt
Bike owner and all operators. Parents should review the manual carefully
with their children. Never allow anyone to operate the Dirt Bike without rst
reading and understanding the Owner’s/Operator’s manual.
This Owner’s/ Operator’s manual should be a permanent part of the Dirt
Bike and should remain with the vehicle at all times. The manual should
also remain with the vehicle if sold.
To the Owner
Safety - Notice to parents
This manual is based on the latest product information available at the
time of publication. Coleman Powersports has a policy of continually im-
proving its products. Due to improvements, or other changes, there may
be some discrepancies. We reserve the right to make product changes at
any time, without notice and without incurring any obligation to make the
same or similar changes to vehicles previously built or sold.

The engine exhaust from this Dirt
Bike contains chemicals known to
the state of California to cause can-
cer, birth defects or other reproduc-
tive harm.
!WARNING

TABLE OF CONTENTS
CHAIN AND SPROCKET INSP............27
INSPECTION........................... 27
TENSION AND ADJUSTMENT..... 27
CLEANING AND LUBRICATION.. 27
TIRES.............................................. 28
TIRE PRESSURES.................. 28
TIRE SIZE.............................. 28
REPLACING........................... 28
STORAGE............................................. 29
WASHING THE DIRT BIKE..................... 30
TRANSPORTING................................... 30
TROUBLE SHOOTING............................ 31
SPECIFICATIONS.................................. 32
ELECTRIC DIAGRAM............................. 33
FRAME AND ENGINE NUMBER
LOCATION........................................... 34
EMISSION CONTROL SYSTEM
WARRANTY.......................................... 35
COLEMAN POWERSPORTS
WARRANTY............................................. 2
IMPORTANT SAFETY AND NOTATION
INFORMATION.........................................4
LABEL LOCATIONS..................................5
WARNING LABELS............................ 6
SAFETY ....................................................7
DESCRIPTION AND PART LOCATIONS.8
DESCRIPTION AND PART FUNCTIONS.9
RIGHT HAND BRAKE LEVER............ 9
RIGHT THROTTLE GRIP.................... 9
ENGINE STOP SWITCH..................... 9
ELECTRIC START BUTTON................9
FOOTBRAKE LEVER...........................10
IGNITION KEY.....................................10
CHOKE LEVER....................................10
FUEL VALVE..................................... 11
FUEL CAP......................................... 11
FUEL AND OIL...................................... 12
FUEL................................................ 12
ENGINE OIL...................................... 12
BREAK IN............................................. 13
PRE RIDE INSPECTION..........................14
RIDING DIRT BIKE................................ 15
HELMET, EYE PROTECTION AND
PROTECTIVE CLOTHING....................15
STARTING THE ENGINE.................... 16
LOAD GUIDLINES............................. 18
AFTER MARKET PARTS.................... 18
MAINTENANCE.................................... 19
MAINTENANCE CHART..................... 20
AIR FILTER....................................... 20
SPARK PLUG................................... 22
ENGINE OIL .................................... 23
CHECKING............................ 23
CHANGING........................... 23
IDLE SPEED ADJUSTMENT............... 24
THROTTLE CABLE ADJUSTMENT..... 24
BRAKES........................................... 25
FRONT BRAKE , HAND LEVER. 25
REAR BRAKE., FOOT LEVER...25
FUEL HOSE INSPECTION................. 26
VALVE CLEARANCE......................... 26
1

The Warranty
Coleman Powersports offers the following warranty to the initial purchaser
of this new Coleman Powersports product. The initial purchaser is dened
as the rst person to purchase a new Coleman Powersports product from
an Authorized Retailer of Coleman Powersports products.
The limited warranty period for this product is 90 days from the date of
purchase shown on the original sales receipt.
What is a Defect?
The Product is warranted to be free from manufacturing defects in material
and workmanship for a period of 90 days from the date of purchase shown
on the sales receipt. During this period of time Coleman Powersports will,
at its option, either repair or replace any original Coleman Powersports part
which is covered by this warranty and is proven to be defective in workman-
ship or material.
To qualify for this warranty the part:
1. Must have been purchase from Coleman Powersports or from an
authorized Coleman Powersports Retailer.
2. This warranty does not apply to any vehicle which is used in competition
or used in a manner not consistent with the normal and proper intended
use for the vehicle. This vehicle is not intended for rental or commercial
use.
Who Can Perform Repairs Under this Warranty?
Repairs under this warranty should be performed by an authorized Coleman
Powersports retailer or comparable servicing dealer.
How to get service under this warranty
To get warranty service call Coleman Powersports at 888-405-8725 for the
location of your local servicing retailer / dealer. Please do not return the
product to the retailer where the product was purchased unless instructed
to do so by Coleman Powersports The retailer of this product does not
make any warranty of its own and has no authority to implement this war-
ranty on behalf of Coleman Powersports without the approval of Coleman
Powersports A COPY OF YOUR SALES RECEIPT IS REQUIRED FOR WAR-
RANTY SERVICE.
COLEMAN POWERSPORTS LIMITED WARRANTY
This Warranty is NOT the Emissions Control Warranty
Please note this is a general Limited Warranty for this product. It IS NOT an
Emissions Control Warranty. Please see the Emissions Control Warranty in
this manual for warranties covering Emission components. The Emissions
Control Warranty can be found on page 35.
2

What this Warranty Does Not Cover
This warranty does not cover the following
1. Damage due to lack or improper maintenance as described in this
manual.
2. Damage which is caused by normal use and not caused by a defect in
materials or workmanship.
3. Use of the product which is not consistent with the intended use as
described in the operating instructions.
4. Any expendable maintenance item which need replacement or service
as part of normal maintenance, unless such items have defects in material
or workmanship which cause failure or premature wear.
5. Any product which has been altered or modied in a manner not consis-
tent with the original design of the product or in a manner not approved by
Coleman Powersports.
7. Damage or failures due to abuse, neglect, or misuse of the product.
Limitations of this Warranty
This warranty does not cover and Coleman Powersports disclaims any
responsibility for:
1. Loss of time or loss of use of the product.
2. Transportation costs to and from the authorized service center.
3. Other loss or damage to other equipment or personal items.
Length of Implied Warranties
Any implied warranties are limited to the duration set forth in this warranty.
Coleman Powersports does not make any claim as to the merchantability
or tness for a particular purpose which would extend longer than the
duration of this written warranty.
Check you State Laws as some State Laws do not allow limitations as to the
duration of an implied warranty. Some States may also not allow limitation
or exclusions based on incidental or consequential damages.
3

To emphasize special important information in the manual, please note the
following :
To emphasize important safety information, the word WARNING, with the
alert symbol, has special meaning.:
To emphasize important information, the word CAUTION has special
meaning.:
To emphasize important information, the word NOTE has special meaning.:
This is the alert symbol. The symbol means ATTENTION!, BE-
COME ALERT!,
!WARNING Indicates a potential hazard that could result
in SEVERE INJURY or DEATH to the operator,
bystander
!
CAUTION: Indicates special precautions that must be
taken to avoid damage to the Dirt Bike.
NOTE: Indicates key information to make procedures
easier or clearer to understand.
!WARNING
The rst part will identify a POTENTIAL HAZARD.
The second part will describe WHAT COULD HAPPEN if the warning or
caution is ignored.
The third part will describe HOW TO AVOID THE HAZARD.
CAUTION
or
Coleman Powersports is concerned about the environment and believes
in conserving and protecting all natural resources. For this reason ,
owners should recycle, trade in, or dispose as appropriate, batteries, oil
and tires.
Important Safety and Notation Info
This manual is based on the latest product information available at the
time of publication. Coleman Powersports has a policy of continually im-
proving its products. Due to improvements, or other changes, there may
be some discrepancies. We reserve the right to make product changes at
any time, without notice and without incurring any obligation to make the
same or similar changes to vehicles previously built or sold.
4

IMPORTANT LABELS
LOCATION
123
5

Warning Labels
WARNING
!
• Study and understand the
owner’s manual before operating
this Dirt Bike.
• Always wear a DOT certified
motorcycle helmet, protective
riding gear and eye protection.
• Never operate this Dirt Bike
while under the influence of drugs
or alcohol.
WARNING
!
No one under the age of 16
should operate this dirt bike
without adult supervision
1
2
3
Cold tire pressure:
Front: 28psi ± .5psi (200 ± 3.5kpa)
Rear: 32psi ± .5psi (225 ± 3.5kpa)
Maximum weight capacity is
165lbs. (75 kg)
WARNING
!
Check the tires before operating
to insure the proper tire pressure.
Improperly inflated tires can lead
to loss of control which could
result in injury or death.
6

Never take drugs or alcohol
before or during operating this
Dirt Bike.
Never traverse, climb or go
down a hill that is too steep.
Avoid hills with loose or
slippery terrain.
Never attempt wheelies,
jumps or any other type of
stunts on this Dirt Bike.
Always follow the pre-ride
inspection procedures and
maintenance procedures
located in this manual before
use.
Always go slow on terrain that
is not familiar, be alert, an
obstacle could come up
unexpectedly.
Always keep both hands on
the handlebars and both feet
on the footpegs, doing so will
help the operator be ready for
unexpected situations.
Never operate this Dirt Bike at
night. Night is dened as 30
minutes before sunrise and
30 minutes after sunset.
All operators under the age
of 16 should be supervised
continually by an adult. Some
children, even though they
may be the correct age to
operate a Dirt Bike, may not
have the coordination or
ability to do so safely. It is
the parents responsibility to
access the childs abilities
before allowing the child to
continue to ride.
Always wear a certied DOT or
SNELL motorcycle type hel-
met that ts properly, over the
ankle boots, eye protection,
gloves, long sleeve shirt and
long pants while operating
this Dirt Bike.
Never allow a passenger on
this Dirt Bike. This Dirt Bike is
designed for one operator and
no passengers.
Never operate this Dirt Bike
on paved surfaces and/or
public roads. Pavement may
cause the Dirt Bike to become
unstable.
Always go slowly and pay
attention to unfamiliar terrain.
Be alert to changing terrain
conditions when operating the
Dirt Bike.
SAFETY
7

1. Front Wheel
2. Front Brake Drum
3. Front Fender
4. Front Forks/
Shocks
5. Fuel tank cap
6. Fuel tank
7. Seat
8. Rear Fender
9. Rear Wheel
10. Rear sprocket
11. Drive Chain
12. Kick Stand
13. Ignition Key
14. Choke lever
15. Fuel Valve
16. Rear Wheel
17. Mufer
18. Rear Fender
19. Carburetor
20. Spark Plug
21. Foot Brake lever
22. Oil ll plug
23. Rear Mono Shock
24. Rear brake
adjustment
25. Left hand grip
26. Front brake lever
27. Right throttle hand
grip
28. ON/OFF switch
1
2
34
5
678
9
10
12 11
13
14
15
16
17
18
19
20
21
2223
24
25
27
28
26
DESCRIPTIONS AND PART LOCATIONS
8

Right hand brake lever (1). Front
brakes are applied when the right
hand brake lever is pulled toward
the hand grip.
Right Throttle Grip (2): The engine
speed is regulated by the position
of the right throttle grip. Throttle is
increased by turning the throttle grip
toward the operator. Engine speed
is decreased by turning the throttle
grip away from the operator.
Engine Stop Switch (3) : Dirt Bike
engine can start when the En-
gine stop switch is placed in the
(on) position. Engine will shut off
and the engine will not start when
the switch is placed in the (off)
position.
Note: The key switch located on
the side of the dirt bike needs to be
placed in the (on) position for the
engine to start.
1
2
Right side handlebar functions
DESCRIPTION AND PART FUNCTIONS
Left side handlebar functions
3
9

Choke Lever (1): If the engine is
cold, the choke can help start the
engine by lifting the choke lever to
the “ON” (up) position. Once engine
has warmed up , place choke lever
to the “OFF” (down) position.
2
Choke Lever
Ignition Key
Ignition Key (2)
Engine can start once the ignition
key is placed in the (on) postion.
Note: Engine stop switch located
on the handlebars also needs to be
placed in the (on) position for the
engine to start.
Foot brake lever
Foot brake lever (1): To activate the
rear brake, depress the foot brake
lever.
1
3
DESCRIPTION AND PART FUNCTIONS
10

Fuel Valve The fuel valve has 2
positions: “OFF”, “ON”
(OFF) position (1): Fuel will not
ow to the carburetor in this posi-
tion. Always turn the fuel valve to
the “OFF” position when unit is not
in use or is being transported.
(ON) position (2) This is the nor-
mal operating position. The “ON”
position allows fuel to ow from the
fuel valve to the carburetor. Turn
the fuel valve to the”ON” position
when ready to start and ride your
Dirt Bike.
OFF
ON
1
2
Fuel Tank Cap
To open the fuel tank cap (4). Turn
the cap counter clockwise. To re-
install the cap, turn the cap clock-
wise until snug. Make sure the
vent tube is attached and the cap is
seated properly .
4
Fuel Valve operation
Fuel Cap
DESCRIPTION AND PART FUNCTIONS
11

FUEL AND OIL
FUEL
Never use leaded gasoline in this
product. It could affect the engine’s
emissions and damage the engine.
Dirt bike requires clean unleaded
regular gasoline with a minimum
octane rating of 87 or higher.
Gasoline/ Ethanol blends
A blend of unleaded gasoline with
Ethanol, also known as GASOHOL,
at or below 10% (E10 ) can be used
in your Dirt Bike. Ethanol greater
than 10% can damage your engine
and will void your warranty.
Gasoline/Methanol
Blends
A blend of gasoline with Methanol
of 5% or less can be used in your
Dirt Bike. Do not use gasoline,
under any circumstances, contain-
ing more than 5% Methanol, doing
so will damage your engine and will
void the warranty.
ENGINE OIL
The recommended oil for this Dirt
Bike is SAE15W-40 motor oil, if this
oil is not available, any of the oils on
the chart below will work. Note the
temperature requirements for each
of the oils.
Quantity of oil - 1qt. (.9L).
Overlling the fuel tank can cause
the fuel to expand which can cause
overow due to the heat from the
engine or sun. Spilled fuel can
catch re.
Never ll the fuel tank above the
bottom edge of the ller neck.
!WARNING
Fuel and fuel vapor are highly
ammable and toxic. You can be
burned or poisoned while refueling.
Before refueling make sure to fol-
low the procedures listed:
1 Shut off engine, Make sure
there are no ames, sparks or
heat sources close by.
2 Refuel only outdoors in a well
ventilated area.
3 Do not smoke while refueling.
4 Wipe up any spills immediately.
5 Avoid breathing any fuel vapors.
6 Keep children and pets away.
!WARNING
Fuel Filling
12

BREAK - IN
The initial 5 hours of operation is
most important in the life of your
Dirt Bike. Proper operation during
this break in period will help assure
maximum life of your Dirt Bike
engine.
The following guidelines will explain
the proper break in procedures.
1. During the rst 5 hours of opera-
tion, do not apply more than 1/2
throttle.
2. During the next 5 hours of
operation do not apply more the
3/4 throttle
Vary the engine speed:
Make sure to vary the engine speed
during the break in period, this
allows the engine to load and un-
load which helps the parts to seat
properly. It is essential to place
some stress on the engine during
the break in process, however, too
much stress could cause damage to
the engine components. Be careful
not to load the engine too much.
Break in period
Allow oil to circulate
before riding.
Allow the Dirt Bike engine to warm
up before riding. This allows the oil
to circulate throughout the engine
which lubricates the components.
Observe your initial and
most critical mainte-
nance service
The initial service( break in main-
tenance ) is the most important
service for your Dirt Bike. During
the break-in time frame, all of the
engine components will have mated
together and seated. Maintenance
required as part of the initial service
includes correction of all adjust-
ments, tightening of all fasteners
and replacement of dirty oil. Timely
performance of this maintenance
will help make sure your Dirt Bike
will have the best service life and
performance of the engine.
13

Performing maintenance and
checks while the engine is
running could be hazardous.
You could be severely injured
by moving parts or hot sur-
faces.
Never perform maintenance
or check procedures while
the engine is running with
the exception of checking the
engine stop switch or throttle.
!WARNING
Failing to inspect and main-
tain your Dirt Bike could be
hazardous.
Not following the pre-ride
inspection procedures could
result in loosing control of the
Dirt Bike resulting in an
accident or damage to the
Dirt Bike
Always perform a Pre-ride
inspection before each ride.
PRE-RIDE INSPECTION
!WARNING
Inspecting and checking the condi-
tion of the Dirt Bike before each
ride is important. Following the pre-
ride check list will help insure the
you do not have mechanical prob-
lems which could result in injury or
becoming stranded. Make sure the
Dirt Bike is in good operating
condition before each ride.
WHAT
TO
CHECK
CHECK FOR
Steering • Smoothness
• No restriction of
movement
Brakes • Proper operation
and free-play.
Tires • Proper tire pressure
• Proper tread depth
• Rubber has no
cracks
Fuel
Tank
• Enough fuel for the
ride
• Fuel cap secure
• Hoses have no
signs of cracks or
leaks
Hand
Grip
Throttle
• Hand grip throttle
snaps back to idle
when released
• Operates freely
• Has correct free-
play
Engine
Stop
Switch
• Switch shuts off
engine when acti-
vated.
Engine
Oil
• Correct oil level
Drive
Chain
• Proper tension
• Lubricated
• No excessive wear
or damage
General
Condi-
tion
• All nuts and bolts
tight
• No rattles from en-
gine or frame while
running
14

1
2
3
4
5
6
HELMET, EYE PROTECTION,
PROTECTIVE CLOTHING
Always wear a DOT or SNELL
certied motorcycle helmet (1). A
helmet helps protect against serious
head injuries in the event of an acci-
dent. A helmet is the most impor-
tant safety gear item you can wear.
Consult with a motorcycle dealer for
the correct size and type of motor-
cycle helmet that is right for you.
Always wear eye protection when
riding a Dirt Bike such as a face
shield or goggles (2). While riding
a Dirt Bike you can be hit in the
eyes by any of the following: dust,
branches, rocks, debris from other
riders, bugs, etc. Good eye protec-
tion as well as a helmet and protec-
tive riding gear should be manda-
tory when riding an Dirt Bike.
Wear protective clothing: Long
sleeve shirt (3), Gloves (4), Long
pants (5), over the ankle boots (6).
Riding a Dirt bike exposes the rider
to many hazards, wearing protec-
tive clothing can help protect the
rider from injury.
Riding a Dirt Bike without a helmet,
eye protection, and protective cloth-
ing can be hazardous
Riding a Dirt Bike without a helmet
increases the chance of severe
head injury or death in the event of
an accident.
Riding a Dirt Bike without eye
protection such as a face shield or
goggles could result in severe injury
in the event of an accident.
Riding a Dirt Bike without protec-
tive clothing; over the ankle boots,
long pants, gloves, long sleeve shirt
could result in severe injury in the
event of an accident.
Always wear a Helmet, eye protec-
tion, long pants, long sleeve shirt,
over the ankle boots and gloves
when riding a Dirt Bike
!WARNING
RIDING THE DIRT BIKE
15

STARTING ENGINE
To start the engine
1. Before attempting to start the
engine, make sure to follow the
pre-ride
inspection checklist in this manual.
2. Place the fuel valve (1) to the
“ON” position.
3. Turn the ignition key (2) to the
“ON” position.
4. Place the ON/OFF switch (3)
located on the handlebars to the
(ON) position
5. If engine is cold, place the choke
lever (4) in the up position.
Note: If the engine is already warm
the choke will not be needed.
6. Start the engine by depress-
ing the start button located on the
handlebars(5)
7. Once engine has warmed up for a
few minutes, place the choke lever
(4) back to the down position.
Starting or running the Dirt
Bike in an enclosed area such
as a garage or shed where
there is no ventilation is
hazardous.
Inhaling exhaust fumes from
the Dirt Bike can cause
severe injury or death.
Never start or run the Dirt
Bike in an inclosed environ-
ment where there is no venti-
lation. Always start and run
outdoors.
!WARNING
RIDING THE DIRT BIKE
4
2
3
1
16

Operating this Dirt Bike at excessive
speeds could be hazardous.
Riding at excessive speeds increas-
es your chances of losing control of
theDirt Bike, which could result in
severe injury or death.
Always go at a speed that is proper
for the terrain, visibility, operating
conditions, operator skill, and
operator experience. Always know
the terrain before riding.
!WARNING
Removing hands from the handle-
bars and/or feet from the footrest
while operating the Dirt Bike could
be hazardous.
Removing both or one hand from
the handlebars and/or feet from
the footrests could result in loss of
control of the Dirt Bike resulting in
severe injury or death.
Always ride with both hands on the
handlebars and both feet on the
footrests while operating the Dirt
Bike.
!WARNING
Applying full throttle when starting
off could be hazardous.
The Dirt Bike could lurch forward
causing the front wheels to leave
the ground causing loss of control.
Always open the throttle gradually
when taking off from a stopped
position.
!WARNING
RIDING THE DIRT BIKE
17
