Coleman PMD8137 User manual

PMD8137CIR020306-222
Models: PMD8137
PMD8142
18 Volt
Circular Saw
Owner’s Manual
TEAM PRODUCTS INTERNATIONAL INC. Limited Warranty
WHAT IS COVERED: Any defect in materials and workmanship.
FOR HOW LONG: 2 years from date of purchase.
WHAT WE WILL DO: If your product is defective and returned within 30 days
after the date it was purchased, we will replace it at no charge to you. If
returned after 30 days but within 2 years of the date of purchase we will
repair it or, at our option, replace it at no charge to you.
If we repair your product, we may use new or reconditioned replacement
parts. If we choose to replace your product, we may replace it with a
new or reconditioned one of the same or similar design. The repair or
replacement will be warranted under our standard 2 year warranty.
LIMITATIONS: IMPLIED WARRANTIES, INCLUDING THOSE OF FITNESS FOR A
PARTICULAR PURPOSE AND MERCHANTABILITY (AN UNWRITTEN WARRANTY
THAT THE PRODUCT IS FIT FOR ORDINARY USE), ARE LIMITED TO 2 YEARS
FROM DATE OF PURCHASE. WE WILL NOT PAY FOR LOSS OF TIME, INCONVE-
NIENCE, LOSS OF USE OF YOUR PRODUCT OR PROPERTY DAMAGE CAUSED
BY YOUR PRODUCT OR ITS FAILURE TO WORK, OR ANY OTHER INCIDENTAL
OR CONSEQUENTIAL DAMAGES INCLUDING PERSONAL INJURY.
Some states do not allow limitations on how long an implied warranty
lasts or the exclusion or limitation of incidental or consequential damages,
so the above exclusions or limitations may not apply to you.
WHAT WE ASK YOU TO DO: To get warranty service for your product,
you must provide proof of the date of purchase. Within 30 days of the
date it was purchased, return your product to your place of purchase for
immediate replacement. After 30 days, but before the end of the 2 year
warranty period, you may return the product to the following address:
Team Products International
Attn: Customer Service Returns
35 A Continental Drive
Wayne, NJ 07470
We suggest that you retain your original packing material in the event
you need to ship your product. When sending your product include your
name, address, phone number, proof of date of purchase, and a
description of the operating problem. After repairing or replacing your
product, we will ship it to your home or office within four weeks.
WHAT THIS WARRANTY DOES NOT COVER: AMONG OTHER THINGS THIS
WARRANTY DOES NOT COVER DEFECTS RESULTING FROM ACCIDENTS,
DAMAGE WHILE IN TRANSIT TO OUR SERVICE LOCATION, ALTERATIONS,
UNAUTHORIZED REPAIR, FAILURE TO FOLLOW INSTRUCTIONS, MISUSE, FIRE,
FLOOD, AND ACTS OF GOD. IF YOUR PRODUCT IS NOT COVERED BY OUR
WARRANTY, CALL OUR CUSTOMER SERVICE NUMBER AT [phone] TO
DETERMINE WHETHER WE WILL REPAIR YOUR PRODUCT AND OTHER REPAIR
INFORMATION, INCLUDING CHARGES. WE, AT OUR OPTION, MAY REPLACE
RATHER THAN REPAIR YOUR PRODUCT WITH A NEW OR RECONDITIONED
ONE OF THE SAME OR SIMILAR DESIGN. THE REPAIR OR REPLACEMENT WILL
BE WARRANTED FOR 2 YEARS.
THIS LIMITED WARRANTY IS THE ONLY ONE WE GIVE ON YOUR PRODUCT,
AND IT SETS FORTH ALL OUR RESPONSIBILITIES REGARDING YOUR PRODUCT.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION SET
FORTH ABOVE.
STATE LAW RIGHTS: This warranty gives you specific legal rights and you
may also have other rights which may vary from state to state.
©2006 The Coleman Company, Inc. All rights reserved.
COLEMAN® and are registered trademarks of The Coleman Company, Inc., used under license.
Designed in the USA and custom-manufactured in China for Team Products International Inc.
Distributed by Team Products International Inc., Mountain Lakes, NJ 07046.

Models: PMD8137
PMD8142
Owner’s Manual

Models: PMD8137
PMD8142
Owner’s Manual
15. Remove adjustment keys and wrenches. Form a habit to make sure
that the adjustment keys and wrenches are removed from the tools before
turning them ON.
16. Stay alert. To avoid injury pay attention to the work you are doing when
operating these power tools.
17. Check damaged parts. Before continuing to use any power tool, check
for damaged parts to determine that it will operate properly and perform
its intended function. Check alignment of moving parts, mounting of parts,
breakage of parts and anything else that may affect its operation. A part
that has been damaged or broken must be properly repaired or replaced by
an authorized service technician unless otherwise indicated in this manual.
Have damaged ON/OFF switches replaced by a qualified service technician.
Do not use a tool that will not turn OFF or ON.
18. Keep hands clear of moving parts.
19. Do not touch moving parts. Allow the power tool accessories (bit and
blades etc.) to cool before touching them. They can become extremely hot
during use and can burn your skin.
20. READ ALL INSTRUCTIONS BEFORE USINGTHESE POWERTOOLS.
SPECIFIC OPERATING INSTRUCTIONS WHEN USING THIS SAW.
1. Be sure to hold this tool by the insulated gripping surfaces when using it
for any operation where it is possible that the cutting tool may contact any
hidden wiring or the cord of the tool. Contact with a “live” wire will make
exposed metal parts of the tool “live” and may cause harm to the operator.
2. Use extra caution when cutting in hard to reach or high places. Be wary of
any possible wires or falling debris that may result from your use of this tool.
3. BE CERTAINTO KEEP HANDS AND FEET AWAY FROM CUTTING AREA. Keep
hands away from cutting area. Keep hands away from the blades. Do not
reach underneath work while blade is rotating. When the saw is in use, be
sure to keep hands firmly gripped on the tool. Never reach towards or below
the cutting operation. Never use your legs or feet to stabilize the cutting
operation.
CAUTION: blades continue to coast after trigger is released. Never place your
hand on the work surface in front of or behind the saw.
4.The operation of this saw may result in foreign objects being thrown into
your eye, which may result in severe damage. Before beginning any power
tool operation, always wear safety goggles or safety glasses with side shield
and a full- face shield when needed. Consider using a Wide Vision Safety
Mask for use over eyeglasses or standard safety glasses with side shields.
Always use eye protection that is marked to comply with ANSI287.1.
5.To ensure proper usage, always use a sharp blade. This will produce the best
results and minimize poor performance results.
2
Welcome
This COLEMAN® product has been carefully engineered and manufactured to
give you dependable operation. Please read this manual thoroughly before
operating your new COLEMAN® product, as it contains the information you
need to become familiar with its features and obtain the performance that will
bring you continued enjoyment for many years. Please keep this manual on file
for future reference.
GENERAL OPERATING INSTRUCTIONS WHEN USING ANY BATTERY
OPERATED TOOL.
WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS PRIOR
TO USING ANY POWER TOOLS. FAILURE TO DO SO MAY RESULT IN
ELECTRIC SHOCK, FIRE AND/OR SERIOUS PERSONAL INJURY.
1. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
2. Keep work area clean. Cluttered work areas and workbenches may cause
injury.
3. Be conscious of the work area. Do not use the power tools in damp or
moist areas. Do not expose power tools to rain. Do not use these tools in the
presence of flammable liquids or gases.
4. Keep work area well lit.
5. Keep out of reach of children.
6. Store idle tools. Remove the batteries and store tools in a dry place when
not in use.
7. Do not force tools. Forcing the tools can cause damage to the unit or
serious injury.
8. Use the right tool for the right job. Use power tools for the purpose
intended.
9. Dress properly. Do not wear loose clothing or dangling jewelry when oper-
ating any power tool as they can be caught in moving parts. Rubber gloves
and nonskid footwear are recommended when working outdoors. Keep
longer hair pulled back.
10. Always wear protective safety glasses when operating power
tools. Wear a facemask when environment is dusty.
11. Secure items being worked on. Use a vice or clamp to securely hold the
item you are working on. Do not use your hands.
12. Never overreach. Keep proper footing and balance at all times.
13. Maintain tools. Keep tool blades sharp and keep tools clean for better and
safer performance. Inspect batteries before using them with the tools. Keep
hands dry and free from grease and oil when operating these power tools.
14. Disconnect tools. Remove the batteries from the tools before changing
bits and blades.This will prevent unintentional use.
1

Models: PMD8137
PMD8142
Owner’s Manual
6. WARNING: Some dust created by power sanding, sawing, grinding, drilling
and other construction activities contains chemicals known to cause cancer,
birth defects or other reproductive harm. Some examples of these
chemicals:
a. Lead from lead-based paints,
b. Cement and other masonry products,
c. Chemically-treated lumber
Your risk from these types of exposures varies depending on how often you do
this type of work and what type of work you are doing. To reduce your risks,
• Work in a well-ventilated area.
• Work with specially designed equipment and masks.
7. Keep guards in place and in working order. Never wedge or tie lower guard
open. Check operation of lower guard before each use. Do not use if lower
guard does not close briskly and completely cover the saw blade.
CAUTION: If saw is dropped, lower guard may be bent, restricting full return.
8. Keep blades clean and sharp. Sharp blades minimize stalling, overload, kick-
back and give a cleaner cut.
9. Support large panels. Large panels must be supported to minimize the risk
of overload and kickback from blade pinching. Resting the saw on the work
piece should be done on the larger portion of the work and the smaller piece
should be cut off.
10. Guard against kickback. Kickback occurs when the saw begins to stall
rapidly and is driven back towards the operator. Kickback is a reaction to
a poorly aligned blade or a restricted blade. If kickback occurs, release the
switch immediately if blade binds or saw stalls. Keep blades sharp. Do not
force tool. Stay alert. Exercise control. Do not remove saw from work dur-
ing a cut while the blade is moving.
11. Raise lower guard. When necessary for accurate starts or when picket cut-
ting, simply raise the lower guard with the retracting lever.
12. Adjustments. Before cutting be sure depth and bevel adjustments are tight.
13. Use only correct blades. Use only blades with 10mm diameter. Do not
use blades with incorrect size holes. Never use defective or incorrect blade
washers or bolts.
14. Avoid cutting nails. Inspect for and remove all nails from lumber before
cutting.
IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CHARGER:
1. This manual includes important safety instructions for the battery charger.
Fully read all instructions and warning labels before using the battery or bat-
tery charger.
3
2.To reduce the risk of electric shock or injury, use ONLY the battery charger
supplied with this unit to charge the battery(ies).
3. Do NOT expose the battery or battery charger to rain or moisture.
4. Use of any attachment not recommended in this manual may result in the risk
of fire, electric shock or injury to a person and will void the warranty.
5.To reduce the risk of damaging the battery charger power cord, be sure to pull
the plug rather then the cord when disconnecting it from the power supply.
Always position the cord so it will not be stepped on or tripped over. This will
prevent damage to the cord.
6. An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord can result in risk of fire or electric shock. If using an
extension cord make sure that:
A)The pins on the plug of the extension cord are the same number,
size and shape as those on the plug on the charger.
B)The extension cord is properly wired and in good working condition.
C)The wire size is the same or larger than the ones specified below:
Recommended size of Extension Cord for Battery Charger
Length of Cord (Feet) 25 50 100 150
AWG Size of Cord* 18 18 16 14
*The smaller the AWG (American Wire Gauge) number of the extension cord,
the higher the capacity of the cable for conducting current to ensure proper
usage of the tool.
7. Do not operate charger with a damaged cord or plug.
8. Do not operate the charger if it has received a sharp blow, been dropped or
damaged in any other way.
9. Do not open the saw, battery or battery charger.There are no user serviceable
parts. Opening the unit will void the warranty.
10. Unplug the charger from its power source when not in use.
11. Do not touch the terminals inside the battery charger with any other metal
object such as nails or coins. This can short the charger.
12. Do not store the unit in areas where the temperature can exceed 120°F.
13. Do not throw the battery or battery charger in fire.This can cause an
explosion.
4

Models: PMD8137
PMD8142
Owner’s Manual
14. WARINING: Batteries vent hydrogen gas and may explode in the presence
of a source of ignition, such as a pilot light. To reduce the risk of serious
personal injury, never use any cordless product in the presence of an open
flame. An exploded battery can propel debris and chemicals. If exposed,
flush with water immediately for a minimum of 10 minutes and seek
medical attention.
15. During extreme conditions, the battery may leak. This does not indicate a
battery failure. However, if the liquid gets on your skin, immediately wash
with soap and water, neutralize the area with a mild acid such as lemon
juice or vinegar. If the liquid gets into your eyes, flush them with clean wa-
ter immediately for a minimum of 10 minutes and seek medical
attention.
Controls and Components:
Battery and AC Charger
1. Battery with Release Buttons On Each Side (PMD8137 comes with 2 batteries)
2. 1 Hour “Quick Charge” Charging Stand with LED Charging Indicators
Circular Saw:
3. Safety Knob (Lock-off Button)
4. On/Off Switch
5. Depth Adjustment Knob
6. Shoe Base
7. Lower Blade Guard
8. Bevel Leveling Screw
9. Shaft Lock
10. Rip Fence
1
2
5
3
4
8
9
675
10
INSTRUCTIONS FOR USE:
Charging The Battery
THE BATTERY(IES) MAY NOT BE FULLY CHARGED FROM THE
FACTORY. READ ALL INSTRUCTIONS THOROUGHLY PRIOR TO FIRST
USE.
The Saws covered by this manual use the same battery and battery charger.
Your Saw comes complete with a rechargeable battery, we recommend that you
fully charge before the first use.
Your Saw must be charged for 1 hour prior to first use. After initial charge,
allow approximately 1hour to recharge your battery.
Your battery should be recharged when the saw does not operate up to its
normal performance level. Do not continue to operate the saw in this depleted
capacity. Recharge the battery immediately.
To increase the life of your battery, do not leave the battery charging for more
than 1 hour. While this is not a safety concern, overcharging may reduce the life
of the battery(ies).
Overtime, if the saw is not used, the battery will lose capacity. For maximum
performance, recharge the battery after prolonged storage or non-use periods.
NOTE: Before inserting or removing the battery from the charging base, always
ensure that the base is not plugged into a 120V power source.
1. To begin charging, remove the battery pack from the tool by pressing on the
battery release buttons on either side of the battery pack and pulling down.
2. Plug the battery pack into the battery charger making sure the positive (+) and
negative (-) poles of the battery match the positive (+) and negative (-) poles
of the battery charger.
NOTE: The battery will only fit into the battery charger and the tool one way.
3. Plug the battery charger into any standard 120 Volt wall outlet.The RED LED
indicator on the battery charger will illuminate to indicate that the battery is
charging.
4. Full charging will take 1 hour.
NOTE: While the battery is placed in the charger, the RED LED indicator light
will remain on. After one hour and a complete charge, the GREEN LED indicator
light will illuminate to let you know it is now safe to use the battery.
If charging more than one battery, wait at least 15 minutes between each
charge.
Use only the battery charger that is supplied with this tool. Using another
charger may cause damage to the battery.
WARNING: Never charge a battery pack again immediately after it has been
fully charged. This can give rise to the battery pack being overcharged and a
reduced battery life.
6

Models: PMD8137
PMD8142
Owner’s Manual
Length of service of your battery will depend on the type of work you are doing.
The batteries in this tool have been designed to provide maximum, trouble-free
life. However, like all batteries, it will eventually wear out. Do not disassemble
battery pack and attempt to replace the batteries.
To make your batteries last as long as possible, we suggest the following:
1. Store and charge your batteries in a cool area. Temperatures above or below
normal room temperatures will shorten battery life.
2. Never store batteries in a discharged condition. Recharge them immediately
after they are discharged.
3. All batteries gradually lose their charge. The higher the temperature the
quicker they lose their charge. If you store your tool for long periods of time
without using it, recharge the batteries every month or two. Getting into this
habit will prolong battery life.
THE ASSEMBLY OFTHIS SAW:
WARNING: Always remove the battery pack from your saw when you are as-
sembling parts, making adjustments, assembling or removing blades, cleaning
or when not in use. Removing the battery pack will prevent accidental starting
that could cause serious personal injury.
To remove/attach Battery Pack:
To Remove:
1. Locate latches on side of the battery pack and depress both sides to release
battery pack from your saw.
2. Remove the battery pack from your saw.
To Attach:
1. Place the battery pack in your saw aligning the raised ribs on the battery pack
with the groove in the saw’s battery port.
2. Make sure that the latches on each side of the battery pack snap into place
and the battery pack is secured to the saw before beginning operation.
7
To install the saw blade:
1. REMOVE battery pack first.
WARNING: Failure to remove battery pack from
the saw could result in accidental starting
causing possible serious personal injury.
2.To attach blade, retract lower blade guard and
place blade over spindle and against the inner
clamp washer. Place outer clamp washer against
the blade. (Blade must go on with the printed
side out, teeth at the bottom of the blade
pointing forward.
3.Thread on blade clamping screw firmly by hand
to hold the washer in position. (Screw has left
hand threads and must be turned counter-
clockwise to tighten).
4. Lightly depress the blade lock while turning the
spindle until the blade stops rotating.
5.Tighten blade clamping screw (counter-clockwise)
firmly with the blade wrench.
6.To remove blade,TURN OFFTOOL AND REMOVE
BATTERY PACK. Engage the blade lock-off
button and unscrew the blade clamping screw by
turning it clockwise with the blade wrench.
NOTE: Never engage blade lock while saw is running, or engage in an effort to
stop the tool. Never turn switch on when blade lock is engaged. Serious
damage to your saw may result.
7. Replace the battery pack.
Blades
A dull blade will cause slow, inefficient cutting overload on the saw motor,
excessive splintering, and could increase the possibility of kickback.
CAUTION: Do not use abrasive discs or blades for cutting ferrous (steel)
materials.
8

Models: PMD8137
PMD8142
Owner’s Manual
Cutting Depth Adjustment:
1. REMOVE battery pack first.
WARNING: Failure to remove battery pack from the saw could result in
accidental starting causing possible serious personal injury.
2. Hold the saw firmly and loosen (counter clockwise) the depth adjustment
knob and move shoe to obtain the desired depth of cut.
3. Make sure the depth adjustment knob has been retightened (clockwise)
before operating the saw.
For the most efficient cutting action, set the depth adjustment so that one tooth
of the blade will project below the material to be cut. This distance is from the
tip of the tooth to the bottom of the gullet in front of it. This keeps blade friction
at a minimum, removes sawdust from the cut, results in cooler, faster sawing
and reduces the chance of kickback. To check for the correct cutting depth, lay a
piece of material you plan to cut along the side of the blade and observe how
much blade projects below the material.
NOTE: When using carbide-tipped blades, make an exception to the above and
allow only one-half of a tooth to project below the material to be cut.
Bevel Angle Adjustment:
The full range of the bevel adjustment is from 0° to 50°. The quadrant is
graduated in increments of 5°. On the front of the saw is a bevel angle
adjustment mechanism, consisting of a calibrated quadrant and a knob. To set
the saw for a bevel cut:
1. REMOVE battery pack first.
WARNING: Failure to remove battery pack from the saw could result in
accidental starting causing possible serious personal injury.
2. Loosen (counter clockwise) the quadrant knob until the base to the desired
angle mark. Re-tighten knob firmly (clockwise).
NOTE: The quadrant pointer, located between the quadrant knob and the
quadrant, can be adjusted after loosening its screw. Re-tighten firmly after
adjustment.
Base Adjustment for 90° Cuts:
If additional adjustment is needed:
1. REMOVE battery pack first.
WARNING: Failure to remove battery pack from the saw could result in
accidental starting causing possible serious personal injury.
2. Adjust the saw to 0° bevel.
3. Retract blade guard. Place the saw on the blade side.
9
4. Loosen bevel adjustment knob. Place a square edge against the blade and
base to adjust the 90° setting.
5. Loosen the hex nut with a wrench or needle nose pliers and move the
adjustment screw so that the shoe will stop at the proper angle. Lock the
screw in place by tightening the hex nut.
6. It may be necessary to adjust the quadrant angle pointer to line up on “0”
after shoe has been adjusted.
7. Confirm the accuracy of the setting by checking the squareness of an actual
cut on a scrap piece of material.
SWITCH
Release the lock-off by pressing the button as
shown. Pull the trigger switch to turn the motor
ON. Releasing the trigger turns the motor OFF. Re-
leasing the trigger also automatically actuates the
lock-off button.
NOTE: This tool has no provision to lock the switch
in the ON position and should never be locked ON
by any other means.
RIP FENCE
The scaled rip fence allows the saw to cut exactly along a work piece edge and
for accurate parallel cuts.
MAINTENANCE OF THE SAW:
CLEANING
WARNING: Always remove the battery pack from your saw when you are
assembling parts, making adjustments, assembling or removing blades,
cleaning or when not in use. Removing the battery pack will prevent accidental
starting that could cause serious personal injury.
WARNING: Do not at any time let brake fluids, gasoline, petroleum-based
products, penetrating oils, etc., come in to contact with plastic parts. They
contain chemicals that may damage, weaken or destroy the plastic.
Use only clean damp cloths or mild soap to remove dirt, carbon dust, etc.
Chemical solvents can damage the plastic.
LUBRICATION
Self-lubricating ball and roller bearings are used in the tool and re-lubrication is
not required.
10

Models: PMD8137
PMD8142
Owner’s Manual
TROUBLESHOOTING TIPS:
SAW DOES NOT WORK?
• Recharge the battery
CHARGING INDICATOR LED NOT ILLUMINATED DURING RECHARGING?
• Check that battery pack is properly connected to the battery recharger
• Check that the AC Adaptor is properly connected at both ends
SPECIFICATIONS
Voltage 18V
No load Speed 3400 rpm
Saw Blade Diameter 136mm (5 3/8”)
Charger Input 120V AC 60Hz
ChargingTime Approx. 1 Hour
BatteryType Ni-Cad
QUESTIONS?
If you have any questions about this product, please contact our Customer
Service Department at [phone], 9 am to 5 pm EST, Monday through
Friday or visit our website at: www.colemanpower.com.
