Coleman 2000010327 Manual

MODEL 2000010327 2000010328
2000010330 2000010331
Fig. 1
Fig. 2
Fig. 4
Guyline
Stake
Fig. 3
Plastic Fastener
Webbing Push Button
STITCH LINE
INSTANT FLY SETUP INSTRUCTIONS
Before You Begin
• Ensure the instant tent is set up correctly by carefully reviewing and following all safety and installation instructions provided with the
instant tent.
• Take out the instant fly and stakes. (Fig. 1)
• Drape rainfly over tent. (Fig. 2)
• Attach the plastic fasteners to the leg poles below the
push button. (Fig. 3)
• Pull the webbing to adjust the firmness of rainfly on
tent. (Fig. 3)
• Attach and stake out guylines. (Fig. 4)
• Adjust sliders to make guylines tight.
Note: The tent may look different from yours. It is for
illustration purposes only.
Install The Instant Fly
1
TheColemanCompany,Inc.•3600NorthHydraulic•Wichita,Kansas67219U.S.A.
1-800-835-3278•www.coleman.com
MADE IN BANGLADESH
©2011TheColemanCompany,Inc.Allrightsreserved.
Coleman®, , and are registered trademarks of
The Coleman Company, Inc.
4010015469(ECN20020024-01)
Disassembly
To take down the tent fly, follow the previous steps and
illustrations in the reverse order:
• Take off the plastic fasteners from leg poles. (Fig. 3)
• Remove guylines and stakes. (Fig. 4)
• Remove rainfly from the tent. (Fig. 2)
To obtain additional instant tent units,
see your local retailer or visit www.coleman.com.
2
1. All stakes must be placed in the storage bag to prevent
damage to the fabric items placed in the carry case.
2. Make sure all components are clean and dry before
placing in carry case.
3. Store in a clean, dry area.
3
To Store
This tent meets the flammability requirements of CPAI-84. The
fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may
render the flame-resistant properties ineffective.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM
THIS TENT FABRIC.
Completed instant tent with fly
2000010327 2000010328 20000103312000010330
