Columbia CEG-C Technical Document

INSTINST INSTINST
INSTALLAALLA
ALLAALLA
ALLATION MANUTION MANU
TION MANUTION MANU
TION MANUALAL
ALAL
AL AND OPERAAND OPERA
AND OPERAAND OPERA
AND OPERATING INSTRTING INSTR
TING INSTRTING INSTR
TING INSTRUCTIONSUCTIONS
UCTIONSUCTIONS
UCTIONS
CEG-CCEG-C
CEG-CCEG-C
CEG-C
GAS FIRED BOILERS
FOR STEAM HEATING
Columbia Boiler Company
Main Offices and Factory: Pottstown, PA

TT
TT
TABLE OF CONTENTSABLE OF CONTENTS
ABLE OF CONTENTSABLE OF CONTENTS
ABLE OF CONTENTS
Safety Symbols & Warnings ................................................................................. Page 1
Installation Procedure ........................................................................................... Page 2
Ventilation and Combustion Air ...................................................................... Pages 3-4
Connecting Supply and Return Piping ............................................................... Page 5-6
Vent Installation .................................................................................................... Page 7
Vent System Modification ..................................................................................... Page 8
Vent Damper Installation and Instructions ........................................................... Page 9
Connecting Gas Service ..................................................................................... Page 10
Electrical Wiring .................................................................................................. Page 10
Thermostat Installation ....................................................................................... Page 11
Lighting Instructions ................................................................................... Pages 11-13
Normal Sequence of Operation .......................................................................... Page 14
Connecting Supply And Return Piping Water-Chilled Medium ........................... Page 15
General Instructions .................................................................................... Pages 16-20
Replacement Parts Lists ............................................................................. Pages 20-25
Ratings, Data and Dimensions .......................................................................... Page 26
KEEP THIS MANUAL NEAR BOILER
RETAIN FOR FUTURE REFERENCE
SERIES CEG-C
CAST IRON
GAS FIRED BOILERS
INSTALLATION MANUAL AND
OPERATING INSTRUCTIONS
Published April 1997
Printed in USA
Made in USA
A.G.A. Certified
for Natural gas
or Propane
Tested for 100 lbs.
ASME Working
Pressure

PAGE 1
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANT!ANT!
ANT!ANT!
ANT! READ ALL INSTRUCTIONS BEFORE INSTALLING.
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING:
1. Keep boiler area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
2. DO NOT obstruct air openings to the boiler room.
3. Modification, substitution or elimination of factory equipped, supplied or specified
components may result in property damage, personal injury or the loss of life.
4. To the owner: Installation and service of this boiler must be performed by a qualified
installer.
5. To the installer: Leave all instructions with the boiler for future reference.
DANGERDANGER
DANGERDANGER
DANGER
DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL
result in death or serious injury.
WW
WW
WARNINGARNING
ARNINGARNING
ARNING
WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD
result in death or serious injury
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
CAUTION - Indicates a potential hazardous situation which, if not avoided, MAY result
in minor or moderate injury. It may also be used to alert against unsafe practices.
WARNING:WARNING:
WARNING:WARNING:
WARNING: ALL INSTALLATIONS OF BOILERS AND VENTINGALL INSTALLATIONS OF BOILERS AND VENTING
ALL INSTALLATIONS OF BOILERS AND VENTINGALL INSTALLATIONS OF BOILERS AND VENTING
ALL INSTALLATIONS OF BOILERS AND VENTING
SHOULD BE DONE ONLY BY A QUALIFIED EXPERT AND INSHOULD BE DONE ONLY BY A QUALIFIED EXPERT AND IN
SHOULD BE DONE ONLY BY A QUALIFIED EXPERT AND INSHOULD BE DONE ONLY BY A QUALIFIED EXPERT AND IN
SHOULD BE DONE ONLY BY A QUALIFIED EXPERT AND IN
ACCORDANCE WITH THE APPROPRIATE COLUMBIA BOILERSACCORDANCE WITH THE APPROPRIATE COLUMBIA BOILERS
ACCORDANCE WITH THE APPROPRIATE COLUMBIA BOILERSACCORDANCE WITH THE APPROPRIATE COLUMBIA BOILERS
ACCORDANCE WITH THE APPROPRIATE COLUMBIA BOILERS
MANUAL. INSTALLING OR VENTING A BOILER OR ANY OTHER GASMANUAL. INSTALLING OR VENTING A BOILER OR ANY OTHER GAS
MANUAL. INSTALLING OR VENTING A BOILER OR ANY OTHER GASMANUAL. INSTALLING OR VENTING A BOILER OR ANY OTHER GAS
MANUAL. INSTALLING OR VENTING A BOILER OR ANY OTHER GAS
APPLIANCE WITH IMPROPER METHODS OR MATERIALS MAY RESULTAPPLIANCE WITH IMPROPER METHODS OR MATERIALS MAY RESULT
APPLIANCE WITH IMPROPER METHODS OR MATERIALS MAY RESULTAPPLIANCE WITH IMPROPER METHODS OR MATERIALS MAY RESULT
APPLIANCE WITH IMPROPER METHODS OR MATERIALS MAY RESULT
IN SERIOUS INJURY OR DEATH DUE TO FIRE OR TO ASPHYXIATIONIN SERIOUS INJURY OR DEATH DUE TO FIRE OR TO ASPHYXIATION
IN SERIOUS INJURY OR DEATH DUE TO FIRE OR TO ASPHYXIATIONIN SERIOUS INJURY OR DEATH DUE TO FIRE OR TO ASPHYXIATION
IN SERIOUS INJURY OR DEATH DUE TO FIRE OR TO ASPHYXIATION
FROM POISONOUS GASES SUCH AS CARBON MONOXIDE WHICH ISFROM POISONOUS GASES SUCH AS CARBON MONOXIDE WHICH IS
FROM POISONOUS GASES SUCH AS CARBON MONOXIDE WHICH ISFROM POISONOUS GASES SUCH AS CARBON MONOXIDE WHICH IS
FROM POISONOUS GASES SUCH AS CARBON MONOXIDE WHICH IS
ODORLESS AND INVISIBLE.ODORLESS AND INVISIBLE.
ODORLESS AND INVISIBLE.ODORLESS AND INVISIBLE.
ODORLESS AND INVISIBLE.
Safety SymbolsSafety Symbols
Safety SymbolsSafety Symbols
Safety Symbols
The following defined symbols are used throughout this manual to notify the
reader of potential hazards of varying risk levels.

INSTINST
INSTINST
INSTALLAALLA
ALLAALLA
ALLATION PRTION PR
TION PRTION PR
TION PROCEDUREOCEDURE
OCEDUREOCEDURE
OCEDURE
WARNING: Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
1. The installation must conform to the requirements of the authority having jurisdiction
or, in absence of such requirements, to the latest revision of the National Fuel Gas Code,
ANSI Z223.1. (Available from the American Gas Association, Pleasant Valley Road,
Cleveland, Ohio 44134.) Reference should also be made to local gas utility regulations and
other codes in effect in the area that the installation is to be made.
2. Where required by the authority having jurisdiction, the installation must conform to
American Society of Mechanical Engineers Safety Code for Controls and Safety Devices
For Automatically Fired Boilers, No.CSD-1.
3. This boiler is classified as a Category 1 appliance and the vent installation shall be
in accordance with Part 7 & 11 of the latest revision of the National Fuel Gas Code noted
above or applicable provisions of the local building codes. See Vent Installation on page 7.
4. This boiler meets safe lighting and other preference criteria with the gas manifold and
control assembly provided on the boiler per the latest revision of ANSI Z21.13b.
5. This boiler shall be installed such that the gas ignition system components are
protected from water (dripping, spraying, rain, etc.) during appliance operation and service,
(circulator replacement, condensate trap, control replacement, etc.).
6. LOCATE BOILER on level, solid base as near chimney as possible and centrally
located with respect to the heat distribution system as practical.
7. ALLOW 24 inches at the front and right side for servicing and cleaning.
8. When installing in a utility room, the door should be wide enough to allow the largest
boiler part to enter, or to permit replacement of another appliance such as a water heater.
9. FOR INSTALLATION ON NONCOMBUSTIBLE FLOORS ONLY. *The boiler must
not be installed on carpeting. Minimum clearances to combustible construction are:
TOP.................................................................... 24 IN.
FRONT .......................................................... ALCOVE
FLUE COLLECTOR ............................................. 6 IN.
REAR ................................................................... 8 IN.
SIDES .................................................................. 6 IN.
NOTE: GREATER CLEARANCES FOR ACCESS SHOULD SUPERSEDE FIRE
PROTECTION CLEARANCE.
PAGE 2

PAGE 3
FIGURE 1
VENTILAVENTILA
VENTILAVENTILA
VENTILATION & COMBTION & COMB
TION & COMBTION & COMB
TION & COMBUSTIONUSTION
USTIONUSTION
USTION AIRAIR
AIRAIR
AIR
WARNING:WARNING:
WARNING:WARNING:
WARNING: AIR OPENINGS TO COMBUSTION AREA MUST NOT BE
OBSTRUCTED. BY FOLLOWING THE INSTRUCTIONS BELOW, ADEQUATE
COMBUSTION AIR CAN BE MAINTAINED
*Unconfined area: A space whose volume is not less than 50 cubic feet per 1000
BTU per hour of all appliances installed in that space (cubic feet of space = height x
width x length).
** Confined area: A space whose volume is less than 50 cubic feet per 1000 BTU per
hour of all appliances installed in that space (cubic feet of space = height x width x
length).
1. Ventilation of the boiler room must be adequate to provide sufficient air to properly
support combustion per the latest revision of the National Fuel Gas Code, ANSI Z223.1
section 5.3.
2. When a boiler is located in an unconfined space in a building or conventional construction
frame, masonry or metal building, infiltration normally is adequate to provide air for
combustion and ventilation. However, if the equipment is located in a building of unusually tight
construction (See the national Fuel Gas Code, Ansi Z223.1 section 1.7), the boiler area
should be considered as a confined space. In this case air for combustion and ventilation shall
be provided according to part 5 below. If there is any doubt, install air supply provisions in
accordance with the latest revision of the National Fuel Gas Code.
3.Whenaboiler is installed in an unconfined
space, in a building of unusually tight
construction, air for combustion and ventilation
must be obtained from outdoors or from
spaces freely communicating with the
outdoors. A permanent opening or openings
having a total free area of not less than 1
square inch per 5,000 BTU per hour of total
input rating of all appliances shall be provided.
Ducts may be used to convey makeup air
from the outdoors and shall have the same
cross-sectional area of the openings to which
they are connected.
4. When air for combustion and ventilation
is from inside buildings, the confined space
shall be provided with two permanent
openings, one starting 12 inches from the top
and one 12 inches from the bottom of the
enclosed space. Each opening shall have a
minimum free area of 1 square inch per one thousand (1000) BTU per hour of the total input
rating of all appliances in the enclosed space, but must not be less than one hundred (100)
square inches. These openings must freely communicate directly with other spaces of
sufficient volume so that the combined volume of all spaces meets the criteria for an
unconfined space.

FIGURE 4
PAGE 4
FIGURE 3FIGURE 2
5. When the boiler is installed in a confined space and all air is provided from the outdoors
the confined space shall be provided with one or two permanent openings according to
methods A or B. When ducts are used, they shall be of the same cross sectional area as the
free area of the area of the openings to which they connect. The minimum dimension of
rectangular air ducts shall be not less than 3 x 3 inches or 9 square inches.
A. When installing two openings, one must commence within 12 inches from the top and
the other within 12 inches from the bottom of
the enclosure. The openings shall
communicate directly, or by ducts, with the
outdoors or spaces (crawl or attic) that freely
communicate with the outdoors. One of the
following methods must be used to provide
adequate air for ventilation and combustion.
1. When directly communicating
with the outdoors, each opening shall have a
minimum free area of 1 square inch per 4,000
BTU per hour of total input rating of all
equipment in the enclosure. See figure 2
below.
2. When communicating with the
outdoors by means of vertical ducts, each
opening shall have a minimum free area 1
square inch per 4,000 BTU per hour of total input rating of all appliances in the enclosed
space. See figure 3 above.
3. If horizontal ducts are used, each opening and duct shall have a minimum free
area 1 square inch per 2,000 BTU per hour of total input rating of all appliances in the enclosed
space. See figure 4 at right.
B. One permanent opening, commencing within 12 inches of the top of the enclosure,
shall be permitted where the equipment has clearances of at least 1 inch from the sides, 1
inch from the back, and 6 inches from the front of the boiler. The opening shall directly
communicate with the outdoors or shall communicate through a vertical or horizontal duct to
the outdoors or spaces (crawl or attic) that freely communicate with the outdoors. The
openings must have a minimum free area of 1 square inch per 3000 Btu per hour of the total

CONNECTING SUPPLCONNECTING SUPPL
CONNECTING SUPPLCONNECTING SUPPL
CONNECTING SUPPLYY
YY
Y AND RETURN PIPINGAND RETURN PIPING
AND RETURN PIPINGAND RETURN PIPING
AND RETURN PIPING
1. Suggested piping for steam heating system can be seen in figure 5 below. Actual
piping may vary based on system design and local conditions.
2. Suggested piping for a modular steam boiler using pumped returns may be seen in
figures 6a and 6b on page 6. Actual piping may vary based on system design and local
conditions.
3. Refer to pages 17 & 18 for procedures on cleaning and skimming off impurities.
4. "Near Boiler Piping" is crucial for proper performance of a replacement steam boiler
and should always be considered as part of the boiler installation. Always be sure to include
cleanout and skimming tees in the near boiler piping. These "Tees" are necessary for proper
cleaning and servicing of the boiler.
5. For further piping information refer to the I=B=R installation piping guide.
PAGE 5
FIGURE 5
SUGGESTED PIPING FOR A SINGLE STEAM
BOILER HEATING SYSTEM
input rating of all equipment located in the enclosure. The free area must be no less than the
sum of the areas of all vent connectors in the confined space.
6. In calculating free area using louvers, grilles or screens for the above, consideration
shall be given to their blocking effect. Screens used shall not be smaller than 1/4 inch mesh.
If the free area through a design of louver or grill is known, it should be used in calculating
the size opening required to provide the free area specified. If the design and free area is
not known, it may be assumed that wood louvers will have 20-25% free area and metal
louvers and grilles will have 60-75% free area. Louvers and grilles should be fixed in the open
position or interlocked with the boiler so they are opened automatically during the boiler
operation.

PAGE 6
FIGURE 6b
SUGGESTED PIPING FOR A MODULAR STEAM BOILERS
PUMPED RETURNS
GRAVITY RETURNS
FIGURE 6a

VENT INSTVENT INST
VENT INSTVENT INST
VENT INSTALLAALLA
ALLAALLA
ALLATIONTION
TIONTION
TION
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING: This boiler shall not be connected to any portion of a mechanical
draft system operating under positive pressure.
1. The vent pipe must slope upward from the boiler not less than 1/4 inch for every 1 foot
to the vent terminal.
2. Horizontal portions of the venting system shall be supported rigidly every 5 feet and
at elbows. No portion of the vent pipe should have dips or sags.
3. This boiler series is classified as a Category 1 appliance and the vent installation shall
be in accordance with Part 7 & 11 of the latest revision of the National Fuel Gas Code or
applicable provisions of the local building codes.
4. Inspect chimney to make certain it is constructed according to National Board of Fire
Underwriters.
5. Attach draft hood to flue collector at rear of boiler, (See figure 7, below), with sheet
metal screw(s) through hole(s) provided. The vent or vent collector shall be Type B or metal
pipe having resistance to heat and corrosion not less than that of galvanized sheet steel or
aluminum not less than 0.016 inch thick (No. 28 GA).
6. Connect flue pipe same as draft hood to chimney. Bolt or screw joints together to avoid
sag. Flue pipe should not extend beyond inside wall of chimney. Do not install manual
damper in flue pipe or reduce size of flue outlet except as provided by the latest revision of
ANSI Z223.1. Protect combustible ceiling and walls near flue pipe with fireproof insulation.
Where two or more appliances vent into a common flue, the area of the common flue must
be at least equal to the area of the largest flue plus 50 percent of the areas of each additional
flue.
PAGE 7
WARNING:WARNING:
WARNING:WARNING:
WARNING: ALLALL
ALLALL
ALL
INSTALLATIONS OF BOILERSINSTALLATIONS OF BOILERS
INSTALLATIONS OF BOILERSINSTALLATIONS OF BOILERS
INSTALLATIONS OF BOILERS
AND VENTING SHOULD BEAND VENTING SHOULD BE
AND VENTING SHOULD BEAND VENTING SHOULD BE
AND VENTING SHOULD BE
DONE ONLY BY A QUALIFIEDDONE ONLY BY A QUALIFIED
DONE ONLY BY A QUALIFIEDDONE ONLY BY A QUALIFIED
DONE ONLY BY A QUALIFIED
EXPERT AND IN ACCORDANCEEXPERT AND IN ACCORDANCE
EXPERT AND IN ACCORDANCEEXPERT AND IN ACCORDANCE
EXPERT AND IN ACCORDANCE
WITH THE APPROPRIATEWITH THE APPROPRIATE
WITH THE APPROPRIATEWITH THE APPROPRIATE
WITH THE APPROPRIATE
COLUMBIA BOILERS MANUAL.COLUMBIA BOILERS MANUAL.
COLUMBIA BOILERS MANUAL.COLUMBIA BOILERS MANUAL.
COLUMBIA BOILERS MANUAL.
INSTALLING OR VENTING AINSTALLING OR VENTING A
INSTALLING OR VENTING AINSTALLING OR VENTING A
INSTALLING OR VENTING A
BOILER OR ANY OTHER GASBOILER OR ANY OTHER GAS
BOILER OR ANY OTHER GASBOILER OR ANY OTHER GAS
BOILER OR ANY OTHER GAS
APPLIANCE WITH IMPROPERAPPLIANCE WITH IMPROPER
APPLIANCE WITH IMPROPERAPPLIANCE WITH IMPROPER
APPLIANCE WITH IMPROPER
METHODS OR MATERIALS MAYMETHODS OR MATERIALS MAY
METHODS OR MATERIALS MAYMETHODS OR MATERIALS MAY
METHODS OR MATERIALS MAY
RESULT IN SERIOUS INJURYRESULT IN SERIOUS INJURY
RESULT IN SERIOUS INJURYRESULT IN SERIOUS INJURY
RESULT IN SERIOUS INJURY
OR DEATH DUE TO FIRE OR TOOR DEATH DUE TO FIRE OR TO
OR DEATH DUE TO FIRE OR TOOR DEATH DUE TO FIRE OR TO
OR DEATH DUE TO FIRE OR TO
ASPHYXIATION FROMASPHYXIATION FROM
ASPHYXIATION FROMASPHYXIATION FROM
ASPHYXIATION FROM
POISONOUS GASES SUCH ASPOISONOUS GASES SUCH AS
POISONOUS GASES SUCH ASPOISONOUS GASES SUCH AS
POISONOUS GASES SUCH AS
CARBON MONOXIDE WHICH ISCARBON MONOXIDE WHICH IS
CARBON MONOXIDE WHICH ISCARBON MONOXIDE WHICH IS
CARBON MONOXIDE WHICH IS
ODORLESS AND INVISIBLE.ODORLESS AND INVISIBLE.
ODORLESS AND INVISIBLE.ODORLESS AND INVISIBLE.
ODORLESS AND INVISIBLE. FIGURE 7

VENT SYVENT SY
VENT SYVENT SY
VENT SYSTEM MODIFICASTEM MODIFICA
STEM MODIFICASTEM MODIFICA
STEM MODIFICATIONTION
TIONTION
TION
When an existing boiler is removed from a common venting system, the common venting
system is likely to be too large for the proper venting of the appliances remained connected
to it. If this situation occurs, the following test procedure must be followed:
At the time of removal of an existing boiler, the following steps shall be followed with
each appliance remaining connected to the common venting system placed in operation,
while the other appliances remaining connected to the common venting system are not in
operation.
A. Seal any unused openings in the common venting system.
B. Visually inspect the venting system for proper size and horizontal pitch and determine
there is no blockage or restriction, leakage, corrosion and other deficiencies which could
cause an unsafe condition.
C. Insofar as is practical, close all building doors and windows and all doors between
the space in which the appliances remaining connected to the common venting system are
located and other spaces in the building. Turn on clothes dryers and any appliance not
connected to the common venting system. Turn on any exhaust fans, such as range hoods
and bathroom exhausts, so they will operate at maximum speed. Do not operate a summer
exhaust fan. Close fireplace damper.
D. Place in operation the appliance being inspected. Follow the lighting instructions.
Adjust thermostat so appliance will operate continuously.
E. Test for spillage at the draft hood relief opening after 5 minutes of main burner
operation. Use the flame of a match or candle, or smoke from a cigarette, cigar or pipe.
F. After it has been determined that each appliance remaining connected to the common
venting system properly vents when tested as outlined above, return doors, windows,
exhaust fans, fireplace dampers and any other gas burning appliance to their previous
conditions of use.
G. Any improper operation of the common venting system should be corrected so the
installation conforms with the latest revision of the National Fuel Gas Code, ANSI Z223.1.
When resizing any portion of the common venting system, the common venting system
should be resized to approach the minimum size as determined using the appropriate tables
in appendix G in the latest revision of the National Gas Fuel Code, ANSI Z223.1.
PAGE 8

PAGE 9
VENT DVENT D
VENT DVENT D
VENT DAMPER INSTAMPER INST
AMPER INSTAMPER INST
AMPER INSTALLAALLA
ALLAALLA
ALLATIONTION
TIONTION
TION
AND INSTRUCTIONSAND INSTRUCTIONS
AND INSTRUCTIONSAND INSTRUCTIONS
AND INSTRUCTIONS
INSTALLATIONINSTALLATION
INSTALLATIONINSTALLATION
INSTALLATION
NOTE: REFER TO FIGURE 8 BELOW FOR STEPS 1-7
1. Place Vent Damper on or as close to vent outlet of boiler as possible.
2. Remove Locknut from connector at the free end of the Damper wire harness.
3. Feed Damper connector and Damper wire harness through bracket hole on Damper Motor
frame.
4. Replace and tighten locknut onto Damper wire harness connector.
5. Plug Damper connector into socket on Damper Motor frame.
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONS
1. Ensure that only the boiler is serviced by the Vent Damper. See figure 9 above.
2. Clearance of not less than 6 inches between Vent Damper and combustible
construction must be maintained. Additional clearance should be allowed for service
of the Vent Damper.
3. Vent Damper must be in open position when appliance main burners are operating.
4. The Vent Damper position indicator must be in a visible location following installation.
5. The thermostats heat anticipator must be adjusted to match the total current draw of
all controls associated with the boiler during a heating cycle.
6. The Vent Damper wire harness may be removed and installed in flexible metal conduit
if local codes or jurisdiction requires. If this is necessary, the flexible metal conduit
must be mounted to a J-box and all appropriate connections must be made to this J-
box.
FIGURE 8 FIGURE 9

PAGE 10
CONNECTING GAS SERCONNECTING GAS SER
CONNECTING GAS SERCONNECTING GAS SER
CONNECTING GAS SERVICEVICE
VICEVICE
VICE
Connect gas service meter to control assembly in accordance with the latest revision of
ANSI Z223.1 and local codes or utility. A ground joint union should be installed for easy
removal of gas control for servicing. A drip or trap must be installed at the bottom of a vertical
section of piping at the inlet to the gas valve. A pipe compound resistant to the action of
liquefied petroleum gases must be used on all threaded pipe connections. Check with the
local utility for location of manual shutoff valve if required. See figure 10 below.
1. The gas line should be of adequate size to prevent undue pressure drop and never
smaller than the pipe size of the main gas control valve.
2. The boiler and its gas connection must be leak tested before placing the boiler in
operation. To check for leaks in gas piping, use a soap and water solution or other approved
method.
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING: DO NOT USE
AN OPEN FLAME.
3. The boiler and its individual shutoff
valve must be disconnected from the gas
supply piping system during any pressure
testing of that system at test pressures in
excess of 1/2 psi (3.5 kPa). The boiler must
be isolated from the gas supply piping system
by closing its individual manual shutoff valve
during any pressure testing of the gas supply
piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
ELECTRICAL WIRINGELECTRICAL WIRING
ELECTRICAL WIRINGELECTRICAL WIRING
ELECTRICAL WIRING
SEE ADDENDUM "A" FOR WIRING DIAGRAMS AND COMPONENT CODING
Electrical wiring must conform with the latest revision of the National Electrical Code, ANSI/
NFPA No. 70 and/or local authority having jurisdiction.
WARNING:WARNING:
WARNING:WARNING:
WARNING: 1. The boiler, when installed, MUST BE electrically grounded
in accordance with these requirements.
2. Install a fused disconnect switch between boiler and meter at a convenient location.
FIGURE 10

LIGHTING PROCEDURE FOR BOILER WITH
INTERMITTENT PILOT SYSTEM.
FOR YOUR SAFETY READ BEFORE OPERATING.
A. This appliance is equipped with an ignition system which automatically lights the pilot.
Do not try to light the pilot by hand.
B. Before operating smell all around the appliance area for gas. Be sure to smell next
to the floor because some gas is heavier than air and will settle on the floor.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION: WHAT TO DO IF YOU SMELL GAS:WHAT TO DO IF YOU SMELL GAS:
WHAT TO DO IF YOU SMELL GAS:WHAT TO DO IF YOU SMELL GAS:
WHAT TO DO IF YOU SMELL GAS:
* Do not try to light any appliance.
* Do not touch any electrical switch.
* Do not use any phone in your building.
* Immediately call your gas supplier from a neighbor's phone.
* Follow your gas supplier's instructions.
* If you cannot reach your gas supplier, call the fire department.
PAGE 11
THERMOSTTHERMOST
THERMOSTTHERMOST
THERMOSTAA
AA
AT INSTT INST
T INSTT INST
T INSTALLAALLA
ALLAALLA
ALLATIONTION
TIONTION
TION
1. Thermostat should be installed on an inside wall at least two feet from an uninsulated
or outside wall, approximately four feet above the floor.
2. NEVER install a thermostat on an outside wall.
3. Do not install a thermostat where it will be affected by:
A. Drafts
B. Hot or cold pipes
C. Sun light
D. Lighting fixtures
E. Television
F. Fireplace or chimneys
4. Check thermostat operation by raising and lowering thermostat as required to start
and stop the burners.
5. Instructions for the final adjustment of the thermostat are packaged with the
thermostat ( adjusting heating anticipator, calibration, etc.).
LIGHTING INSTRUCTIONSLIGHTING INSTRUCTIONS
LIGHTING INSTRUCTIONSLIGHTING INSTRUCTIONS
LIGHTING INSTRUCTIONS
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EX-
ACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
Before any procedures are attempted on this appliance, it is necessary to
determine if the ignition system is intermittent or continuous pilot system. If you are
uncertain, contact the manufacturer before proceeding.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION: Before operating, make certain steam boiler is full of water
to water line and system is vented of air. See the operating lighting instructions.

C. Use only your hand to push in or turn gas control knob. NEVER USE TOOLS. If the
knob will not push in or turn by hand, don’t try to repair it, call a qualified service technician.
Force or attempted repair may result in a fire or explosion.
D. Do not use this appliance if any part has been under water. Immediately call a
qualified service technician to inspect the appliance and to replace any part of the control
system and gas control which has been under water.
OPERAOPERA
OPERAOPERA
OPERATING INSTRTING INSTR
TING INSTRTING INSTR
TING INSTRUCTIONS FORUCTIONS FOR
UCTIONS FORUCTIONS FOR
UCTIONS FOR
INTERMITTENT PILOT SYSTEMSINTERMITTENT PILOT SYSTEMS
INTERMITTENT PILOT SYSTEMSINTERMITTENT PILOT SYSTEMS
INTERMITTENT PILOT SYSTEMS
1. STOP!STOP!
STOP!STOP!
STOP! Read the safety information in the user’s information manual.
2. Set thermostat to lowest setting.
3. Turn off all electric power to the appliance.
4. This appliance is equipped with an ignition device which automatically lights the pilot.
DO NOT try to light the pilot by hand. See figure 11, below.
5. Remove access panel (if present)
6. Push in gas control knob slightly and
turn clockwise to "OFF."
7. Wait five (5) minutes to clear out any
gas. If you then smell gas, STOPSTOP
STOPSTOP
STOP, Follow “B”
in the safety information “What To Do IF You
Smell Gas”. If you don’t smell gas, go to the
next step.
8. Turn gas control knob
counterclockwise to “ON.”
9. Replace control access panel (IF
PRESENT).
10. Turn on all electric power to the
appliance.
11. Set thermostat to desired setting.
12. If the appliance will not operate,
follow the instructions “To Turn Off Gas To
Appliance” and call a qualified service
technician or your gas supplier.
LIGHTING PROCEDURE FOR BOILER WITHLIGHTING PROCEDURE FOR BOILER WITH
LIGHTING PROCEDURE FOR BOILER WITHLIGHTING PROCEDURE FOR BOILER WITH
LIGHTING PROCEDURE FOR BOILER WITH
CONTINUOUS PILCONTINUOUS PIL
CONTINUOUS PILCONTINUOUS PIL
CONTINUOUS PILOO
OO
OTT
TT
T
..
..
.
FOR YOUR SAFETY READ BEFORE LIGHTINGFOR YOUR SAFETY READ BEFORE LIGHTING
FOR YOUR SAFETY READ BEFORE LIGHTINGFOR YOUR SAFETY READ BEFORE LIGHTING
FOR YOUR SAFETY READ BEFORE LIGHTING
A. Read warning at the beginning of this instruction.
B. This appliance has a pilot which must be lighted by hand. When lighting the pilot,
follow these instructions exactly.
C. Before lighting, smell all around the appliance area for gas. Be sure to smell next to
the floor because some gas is heavier than air and will settle on the floor. Follow “B” in the
lighting instructions for safety information for what to do if you smell gas on page 10.
D. Use only your hand to push in or turn the gas control knob or reset button. Never use
tools. If the knob or reset button will not push in or the knob will not turn by hand, don’t try
to repair it. Call a qualified service technician. Force or attempted repair may result in fire
or explosion. See figure 12, on page 13.
PAGE 12
INTERMITTENT PILOT GAS VALVE
FIGURE 11

PAGE 13
E. Do not use this appliance if any part has
been under water. Immediately call a qualified
service technician to inspect the appliance
and to replace any part of the control system
and any gas control which has been under
water.
LIGHTING INSTRUCTIONS FOR
CONTINUOUS PILOT SYSTEM
1. Stop! Read the safety information at
the beginning of this manual.
2. Set thermostat to lowest setting.
3. Turn off all electric power to the
appliance.
4. Remove manifold cover and burner
door, (figures 13 & 15 on pages 14 & 16).
5. Turn gas control knob clockwise to “off” (See Note #1).
NOTE #1: Some gas control knobs cannot be turned from “pilot” to “off” unless knob is
pushed in slightly. Do not force.
6. Wait (5) minutes to clear out any gas. If you smell gas, stop!stop!
stop!stop!
stop! Follow safety information
“What to do if you smell gas,” located on page 10 of this manual. If you don’t smell gas, go
to the next step.
7. Find pilot. Follow metal tube from gas control. Depending on the model of the boiler,
pilot is mounted on the base or on one of the burner tubes.
8. Turn gas control knob counterclockwise to “pilot”.
9. Push in gas control knob, or reset button if so equipped, all the way in and hold.
Immediately Light the pilot with a match. Continue to hold the gas control knob or reset button
for about one (1) minute after the pilot is lit. Release knob or button and it will pop back up.
Pilot should remain lit. If it goes out, repeat steps 5 through 10.
* If knob or button does not pop up when released, stop and immediately call your
service technician or gas supplier.
* If the pilot will not stay lit after several tries, turn the gas control knob clockwise
to “off” (see note #1 above) and call a service technician or gas supplier.
10. Replace burner door and manifold cover, (figures 13 & 15 on pages 14 & 16).
11. Turn gas control knob counterclockwise to "on".
TO TURN OFF GAS TO APPLIANCE
1. Set the thermostat to the lowest setting.
2. Turn off all electric power to the appliance if service is to be performed.
3. Remove access panel (if present)
4. Turn gas control knob clockwise to “off”. (See note #1) in the lighting
instructions. Do not force.Do not force.
Do not force.Do not force.
Do not force.
CONTINUOUS PILOT GAS VALVE
FIGURE 12

PAGE 14
NORMAL SEQNORMAL SEQ
NORMAL SEQNORMAL SEQ
NORMAL SEQUENCE OF OPERAUENCE OF OPERA
UENCE OF OPERAUENCE OF OPERA
UENCE OF OPERATIONTION
TIONTION
TION
On a call for heat:
1.) The thermostat will actuate completing the circuit between T and T.
2.) The damper will then open thus closing the end switch completing the circuit, and
ignition will begin.
3.) In the event that the boiler steam pressure exceeds the pressure control setting,
the pressure control will interrupt the circuit to the boiler ignition system. The power will
remain off until the steam pressure drops below the pressure control setting.
4.) In the event a low water condition occurs, an automatic low water cut-off device
will interrupt the circuit to the ignition system until the low water condition is satisfied,
(i.e., manually restore the water or utilize an electric water feeding device which will
automatically restore boiler water to its normal operating level).
5.) In the event the flow of combustion products through the boiler venting system
becomes blocked, a blocked vent safety switch will shut the main burner gas off (See figure
13 below).
6.) In the event the flow of combustion products through the flueways becomes blocked
a flame rollout switch will shut the main burner gas off (See figure 13 below).
FIGURE 13

PAGE 15
CONNECTING SUPPLCONNECTING SUPPL
CONNECTING SUPPLCONNECTING SUPPL
CONNECTING SUPPLYY
YY
Y ANDAND
ANDAND
AND
RETURN PIPINGRETURN PIPING
RETURN PIPINGRETURN PIPING
RETURN PIPING,,
,,
, WW
WW
WAA
AA
ATER CHILLED MEDIUMTER CHILLED MEDIUM
TER CHILLED MEDIUMTER CHILLED MEDIUM
TER CHILLED MEDIUM
1. When the boiler is used in connection with refrigerated system, connect supply and
return piping as suggested in figure 14 below.
A. The chilled medium MUST BE IN PARALLEL with the boiler.
B. Use appropriate valves to prevent the chilled medium from entering the heating
boiler.
a. During heating cycle open valves A and B. Close valves C and D.
b. During cooling cycle open valves C and D. Close valves A and B.
C. Maintain a minimum clearance of one inch between combustible materials and
hot water pipes.
* Reduced pressure backflow preventer must be present under provisions required by
the Environmental Protection Agency, (EPA).
2. When the boiler is connected to heating coils located in air handling units where they
may be exposed to refrigerated air circulation, the boiler piping system MUST be supplied
with flow control valves or other automatic means to prevent gravity circulation of the boiler
water during the cooling cycle.
3. A hot water boiler installed above radiation level must be provided with a low water
cutoff device either as a part of the boiler or at the time of boiler installation.
4. Suggested piping for steam heating system can be seen in figure 5 on page 5. Actual
piping may vary based on system design and local conditions.
FIGURE 14

PAGE 16
GENERAL INSTRUCTIONSGENERAL INSTRUCTIONS
GENERAL INSTRUCTIONSGENERAL INSTRUCTIONS
GENERAL INSTRUCTIONS
Before seasonal start up it is advisable to have a competent service agency check the
boiler for soot and scale in the flues, clean the burners, and check the gas input rate to
maintain high operating efficiency.
On steam boilers make certain the boiler is filled to the water line as indicated in figure
15. The gauge cocks should be normally open. To remove dirt from the gauge glass the
petcock may be opened to flush out the glass.
WARNING:WARNING:
WARNING:WARNING:
WARNING: DISCHARGE WILL BE BOILING HOT WATER.
The radiator valves on a one-pipe steam system must be either wide open or tightly shut.
Do not attempt to regulate room temperature by partially closing the radiator valve.
Air vents on steam radiators and the supply main release air from the system. If radiators
do not heat satisfactorily, make sure the air vents are clean and operational.
The lever of the safety valve, shown in figure 15 below, on the boiler should be operated
periodically to make sure that it is functioning properly.
WARNING:WARNING:
WARNING:WARNING:
WARNING: DISCHARGE WILL BE BOILING HOT WATER AND STEAM.
The safety valve should open before the steam pressure exceeds the 15 lb. reading on the
gauge, (figure 15 to right). If this pressure is
exceeded and the safety valve does not
open, it must be replaced. If the safety valve
leaks steam when the boiler is operating at
normal pressures, it should be immediately
replaced. Corrosion can build up rapidly at
the valve seat and prevent its functioning as
a safety device.
During the heating season the drain cock,
on the bottom rear of the boiler, should be
opened once a month to flush out the boiler
so the device will be free to function properly.
Use a pail to catch the discharge.
WARNING:WARNING:
WARNING:WARNING:
WARNING: DISCHARGE
WILL BE BOILING HOT WATER.
If the water in a steam boiler appears to be dirty or oily, or the water level in the gauge
glass fluctuates considerably, the boiler should be cleaned and skimmed (See page 18 for
instructions). A competent service person will use approved cleaning compounds and
properly clean and flush out the boiler. He/she should also clean or replace air vents and traps,
clean flue passages and check for proper operation of all controls and safety devices.
The venting system should be inspected at the start of each heating season. Check the
vent pipe from the boiler to the chimney for signs of deterioration by rust or sagging joints.
Repair if necessary. Remove the vent pipe at the base of the chimney or flue and, using
a mirror, check for obstruction.
The boiler flue gas passageways may be inspected by a light and mirror. Remove the
burner access door, (figure 15 above). Place a trouble lamp in the flue collector through the
draft-hood relief opening. With the mirror positioned above the burners, the flue gas
passageways can be checked for soot or scale.
FIGURE 15

TT
TT
TO CLEANO CLEAN
O CLEANO CLEAN
O CLEAN THE BOILER FLTHE BOILER FL
THE BOILER FLTHE BOILER FL
THE BOILER FLUEWUEW
UEWUEW
UEWAA
AA
AYY
YY
YS:S:
S:S:
S:
1. Remove the burners from the combustion chamber by raising the burners upward
from the manifold orifices and pulling toward the front of the boiler. To remove the burner
with the pilot burner attached, first disconnect the pilot line tubing and thermocouple or pilot
generator leads at the main electric gas valve. Do not remove the pilot line tubing at the pilot
as the pilot burner orifice may drop out and become damaged or lost.
2. Disconnect the vent pipe from the draft hood.
3. Remove the draft hood. The draft hood is attached to the flue collector at the top by
sheet metal screw(s).
4. Remove the top jacket panel. It is attached to the jacket by sheet metal screws.
5. Remove the flue collector from the boiler casting by loosening the nuts on the “J” bolts
at either side of the flue collector.
6. Place a sheet of heavy paper or similar material over the bottom of the combustion
chamber and brush down the flue passageways. The soot and scale will collect on the paper
and is easily removed with the paper.
7. With the paper still in place in the combustion chamber, clean the top of the boiler
castings of the boiler putty or silicone used to seal between the castings and the flue
collector. Make certain chips are not lodged in the flueways.
When the cleaning process is completed, restore the boiler components to their original
position. Use boiler putty or GE IS-808 silicone to seal around the flue collector and castings.
Make certain the burner ends are inserted in the slots at the back of the combustion chamber
and well down in position over the burner orifices. Follow the lighting instructions on the
boiler to put the burners back in operation.
CHECK SAFETY CONTROL CIRCUITCHECK SAFETY CONTROL CIRCUIT
CHECK SAFETY CONTROL CIRCUITCHECK SAFETY CONTROL CIRCUIT
CHECK SAFETY CONTROL CIRCUIT, after burner adjustments are made, for
satisfactory operation.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION: Label all wires prior to disconnection when servicing
controls. Wiring errors can cause improper and dangerous operation.
Verify proper operation after service.
1. Pilot: with main burner operating turn the pilot gas adjusting screw clockwise
until pilot gas is turned off. See figures 11 and 12 on pages 12 & 13. Within 90 seconds the
main gas control should close, shutting off the gas to the main burner. After, check pilot
operation. Relight following lighting instructions on pages 10-12.
2. Pressure control - on steam boilers - remove cover and note pressure setting. With
the boiler operating, decrease the setting. When setting is lower than boiler pressure, the
control will open, closing the automatic main gas valve. After checking pressure control,
reset control to original setting.
3. Mechanical Low water cut-off: Operation may checked by opening the blow-off valve
located in the lower portion of the body. This will drain water quickly from the cut-off body
and break circuit to automatic main gas valve. Owner should blow off this control at least
once each month of the heating season.
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING: WATER WILL BE BOILING HOT.
PAGE 17

4. Electronic Low Water Cut-off: Operation may be checked by opening the drain valve
in the back side of the boiler. This will drain the water from the boiler and break the electronic
circuit to the automatic gas valve.
IMPURITIES IN BOILER WATER of a steam boiler may cause foaming and an unsteady
water line, or prevent steam generation. They may result in objectionable odors escaping
from the vents on water boilers. This condition is caused by oil, grease, and sediment from
pipe fittings collecting within the boiler and can be remedied only by giving the boiler a
thorough cleaning.
BOILERS CAN BE CLEANED by skimming or blowing down.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION: The boiler should not be left unattended during the cleaning
process.
SKIMMING OFF IMPURITIESSKIMMING OFF IMPURITIES
SKIMMING OFF IMPURITIESSKIMMING OFF IMPURITIES
SKIMMING OFF IMPURITIES
Some of the impurities in the boiler water will float on the water and must be skimmed off.
With the boiler empty and cool, slowly begin to add water. After water has entered boiler
- never before - turn “on” main gas burners and adjust flame at main manual shut-off valve
so that the water being added is kept just below boiling point. Avoid boiling and turbulence.
Gradually raise hot water level to skimming tee, see figure 5 on page 5, installed at the
supply outlet piping of the boiler being careful not to raise it above the opening of the tee.
Skim until there are no impurities. Repeat the process if necessary.
Water may be checked to make sure it is free from oil by drawing off a sample at the
skimming tee. If the sample is reasonably free from oil, it will not froth when boiled on stove.
This test does not indicate the amount of sediment which may lay in the bottom of the boiler.
It is therefore necessary that the boiler be further cleaned by “blowing down”.
BLOWING DOWN BOILERBLOWING DOWN BOILER
BLOWING DOWN BOILERBLOWING DOWN BOILER
BLOWING DOWN BOILER
Before blowing down the boiler, fill it to the water line. Light burners and allow five pounds
of steam pressure to build up. Run a temporary connection from one of the drain valves to
a nearby sewer. Connect to a drain valve on the opposite end of the boiler from feed water
inlet, if possible. Shut off the gas burners, open drain valve and blow down the entire
contents of boiler.
Allow boiler to thoroughly cool and slowly refill to water line. Repeat step 2 as many times
as required until blow off water is clear. Owner should blow down boiler at least once each
month of the heating season.
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING: WATER WILL BE BOILING HOT.
USING CLEANING COMPOUNDUSING CLEANING COMPOUND
USING CLEANING COMPOUNDUSING CLEANING COMPOUND
USING CLEANING COMPOUND
If an exceptional amount of dirt or sludge seems to be present in the boiler, a boiler
cleaning compound made by a reputable manufacturer may be used according to the
instructions of the manufacturer of the compound. When any type of cleaning compound
is used, care must be taken to thoroughly flush all traces of the compound out of the boiler.
Following blow down allow the boiler to cool. Add fresh water slowly. Be certain to blow
enough times as required to remove compounds from system.
PAGE 18
