COMAG H30D+ Series User manual

English Germany
User’s manual
Bedienungsanleitung
ver 1.0
www.comag.de www.comag.de
DUAL LINEAR POLARIZATION
Flat Satellite Antenna

English
What is COMAG-H30D+?
Contents
...................................................................................What is COMAG-H30D+? 3
Safety Instructions
..........................................................................................Safety Instructions 4
Box Content
................................................................................................Box Content 5
Troubleshooting Check List for Initial Installation
.........................................................Troubleshooting Check List for Initial Installation 13
Loss of Signal / Rain Fade
..................................................................................Loss of Signal / Rain Fade 14
Installation Using Long Cable
.............................................................................Installation Using Long Cable 14
Install
..............................................................................................
...................................................................................
.............................................................................
....................................................
..........................................................................
..................................................................
............................................................
..................................................................................
.........................................................................................
..............................................................................
...........................................................................
...................................
How to Install?
Step 1 : Where to Install?
Step 2 : Installation Choice
Step 3 : Connecting the Antenna and the Set top box
Step 4 : Antenna Pointing Menu
Step 5 : Pointing and location the Signal
A) Table Stand Type (On a Horizontal Plain)
B) Wall Mounting Type
C) Window Type
D) Clamp on Balcony Type
A) How to prepare the cable?
B) How to connect the cable to the antenna and the set top box?
7
7
8
10
11
12
8
9
9
10
11
11

3
What is COMAG-H30D+?
COMAG-H30D+ is a Horn Array Type Satellite Antenna with Dual Linear Polarization, it can
receive signal from major Satellites and would replace a normal former Parabolic Dish.
Small, discreet and easy to use, it can be installed in a few minutes and used as a portable
antenna for all satellite receptions.
COMAG-H30D+ can be used for both free to Air and encrypted (requiring a subscription
with an operator) channel reception; it can also receive all High Denition channels with a
superior image quality.
For the use and installation, please read the following instructions and installation materials
carefully.
Product introduction
Do you have a TV’s at home more than one?
Then, take COMAG built in multi LNB output
Watching 2 channels is possible through H30D2+
Even enjoying 4 channels is possible through H30D4+
Built in Twin LNB output Built in Quad LNB output
H30D2+ H30D4+

4
English
Warning
Antennas improperly installed or installed to an inadequate structure are very susceptible to
wind damage. This damage can be very serious or even life threatening. The owner and installer
assumes full responsibility that the installation is structurally sound to support all loads (weight,
wind & ice) and properly sealed against leaks. The manufacturer will not accept liability for any
damage caused by a satellite system due to the many unknown variable applications.
Before using this product please read this manual carefully and follow exactly all installation,
mounting & orientation instructions.
All the instructions should be followed in order to avoid any technical problems.
Any electric or magnetic eld close to the COMAG-H30D+ may cause a bad reception or even cut
o the signal completely.
Do not drill the plastic cover of the antenna, which seals the antenna from moisture.
Handle the antenna with care as any impact will cause damage to the electronics.
Do not open the cover, any attempt to repair by a non-qualied person can be dangerous and void
the warranty.
Any obstacle (buildings, trees, etc....) will block the reception of the signal from the satellite to the
antenna.
Do not paint or add any substance on the antenna cover, this will block the reception of the signal
from the satellite.
The cable between the antenna and the Satellite receiver should not exceed 30m as it will decrease
the quality of the signal.
The use non- isolated jacks will result in a loss of the signal level.
Do not forget to adjust the antenna and the bracket to the cross-polarity
Tighten all the screws of the antenna once you have nished the adjustments.
This product contains one universal LNB, it is forbidden to add, change or modify the LNB.
For more precise details on the above points or for any information, please ask your retailer or
customer service.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Safety Instructions

5
No
11
Antenna
Body
2
A1
B1 1
Angle
Bracket
3B2 1
Main
Support
4B3 1
Window
Bracket A
5B4 1
Window
Bracket B
Fix
Bracket A
Fix
Bracket B
6B5 1
7B6 1
Symbol Part name Image Quantity
8B7 1
Spanner
Box Content

6
English
No
9 1
Hex Bolt
M6x18 SEMS2
10 4
Pan Head
M4X10 SEMS2
Hex Bolt
M6X50 SEMS2
11
C1
S2
S1
S3
3
Round Head
SquareNeck Bolt
M6x50
Round Head
SquareNeck Bolt
M6x30
12
S4
1
13 1
Flanged Nut
M6
14 S5 3
15 S6 2
U-Bolt
M6x85
16 N1 7
17 E1 4Rubber
Symbol Part name Image Quantity
Compass

7
How to Install?
By following the instructions step by step you can proceed easily to install COMAG-H30D+ by yourself
or with the help of a professional antenna installer.
Step 1: Where to Install?
Bad Quality Singnal Reception
Note
In order to receive a signal from the Satellite, COMAG-H30D+ is to be installed in an open loop space
(outside the house or the apartment), in the direction of the satellite towards the equator, for which,
you will need a compass to exactly orient COMAG-H30D+ toward the satellite (Note: please take
reference to the table of the Azimuth angles specied in the back pages of this manual)
Make sure that there are no obstacles in front of COMAG-H30D+
which can decrease the signal reception quality, such as buildings, or trees (you may keep in mind
that trees will grow and may block the signal).
In order to be able to x and install your antenna easily you might choose an easily accessible place
without any potential danger for installation.
Think about the way you might pass your cable in a discreet way from the COMAG-H30D+ to your Set
top Box. The antenna should not be too distant from your satellite receiver; a cable longer than 30
meters can decrease the quality of the signal.
Before installing your antenna, you check that COMAG-H30D+ box contains all the items listed
above in the ‘Box Content’. In the event of any missing parts, please contact your distributor.
To ensure an accurate compass reading, stay away from large
metal objects, specically electrical cables and then make
multiple readings
BAD!BAD!
Install

8
English
Step 2: Installation Choice
A) Table Stand Type (on a Horizontal Plain)
12
3
S2
S5
S2
N1
B1 B5
B1
A1 S1
S2 S4
N1
Depending on the choice of installation position for the COMAG-H30D+, you can then decide on the
mounting type, all parts are included.
Good Quality Singnal Reception
GOOD!GOOD!

9
C) Window Type
12
3
S2
S5
S5
N1
S2
N1
B1
B2
B6
B2
A1
S2
S3
B) Wall Mounting Type
2
4
N1
S4N1
12
3
S2
S5
S2
S1
S5
N1
B1
B4
B6
B2
A1
S2
S3
2
4
B2
B3

English
10
D) Clamp on Balcony Type
12
3
S2
S5
S5
S2
S6
S6
N1
N1
N1
B1
B6
B5 B5
B2
B2
A1
S2
S3
2
4
5
Step 3: Connecting the Antenna and the Set top box
Once you have installed the antenna in an open loop space and mounted the way you want it to be the
next step is to connect it all together.
In order to be able to watch your favorite satellite programs, you need to connect your satellite antenna
to a receiver by a cable.
The cable between the antenna and the Satellite receiver should not exceed 30m as it will decrease the
quality of the signal.
The use of a long or bad quality cable and not isolated jacks can cause a loss of the signal level, it would be
preferable to use an RG6 Coaxial cable (HF 17VATC or 19VATC cable), in order to minimize a signal loss.
