COMFILE P70 User manual

CUPC P100 Series
User Manual
[ P70 / P80/ P90 / P100 / P120 ]
[Version 1.5]
COMFILE Technology Inc.
www.comfiletech.com

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
2/40
Table of Contents
Chapter 1. hardware Specification ................................................................................................... 3
Chapter 2. Parts Diagram ................................................................................................................. 4
Chapter 3. Dimensions ..................................................................................................................... 6
3-1. CUPC-P70 Dimensions ..................................................................................................... 6
3-2. CUPC-P80 Dimensions ..................................................................................................... 7
3-3. CUPC-P90 Dimensions ..................................................................................................... 8
3-4. CUPC-P100 Dimensions ................................................................................................... 9
3-5. CUPC-P120 Dimensions ................................................................................................. 10
Chapter 4. PANEL CUTOUT .......................................................................................................... 11
4-1. Installation Requirements and Installation ...................................................................... 11
4-2. Bezel Size and Installation .............................................................................................. 12
Chapter 5. Bracket Installation ...................................................................................................... 17
5-1. CUPC-P80 Bracket Installation ...................................................................................... 17
5-2. CUPC-P90 Bracket Installation ...................................................................................... 17
5-3. CUPC-P100 Bracket Installation .................................................................................... 19
5-4. CUPC-P120 Bracket Installation .................................................................................... 20
Chapter 6. Input/Output Connector Type and Pin Assignment ...................................................... 21
6-1. VGA Output Connector .................................................................................................... 21
6-2. RS232C Input/Output Connector (COM1,COM2,COM3) .................................................. 21
6-3. COM4 Mode Setting and Connector ................................................................................ 22
6-4. RS485 Input/Output Connector (COM5) .......................................................................... 23
6-5. Ext. Power ON/OFF Switch Connector ........................................................................... 23
6-6 Power Input Connector .................................................................................................... 24
Chapter 7. System Restoration ...................................................................................................... 25
7-1. Getting Ready .................................................................................................................. 25
7-2. ROM Bios Configuration ................................................................................................... 26
7-2-1. Changing First Boot Device ............................................................................................... 26
7-4. Restoration ...................................................................................................................... 28
7-5. Backing Up ....................................................................................................................... 34
MEMO ............................................................................................................................................. 40

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
3/40
Chapter 1. hardware Specification
ITEM MODEL
CUPC-P70 CUPC-P80 CUPC-P90 CUPC-P100 CUPC-P120
CPU AMD Geode LX800 500MHz Process
Support MMX,AMD 3DNOW Instruction set
Chipset AMD LX800 & CS5536 Companion Chip
BIOS Award Bios
Display
Chipset
AMD LX800 Geode Integrated Graphics Controller
High Performance 2DAccelerator
VGACRT Output Port
LCD 7inch (800x480)
300cd/m210.2inch (800x480)
350cd/m2
10.4inch
(1024x768)
300cd/m2 15inch (1024x768)
250cd/m2
Backlight White LED
Lifetime :
>20,000hr
White LED
Lifetime : >20,000hr
1 Channel CCFL
Lifetime :
>30,000hr
2 Channel CCFL
Lifetime : >40,000hr
Ethernet 10/100 Base-T Ethernet Port
VIAVT6107 Ethernet Controller Chip
Audio VT1616AC97 Codec
Speaker Out Port. MIC In Port
USB 3 Universal Serial Bus Support
Support USB2.0 Host Controller
SDCARD 1 slot Support
Keyboard PS/2 Keyboard Port
Mouse PS/2 Mouse Port
HDD Embedded FALSH Disk(4GB), S-ATASupport
Serial 4 RS232C Serial Port.(COM4 RS232 & RS485 S/W Select Port)
One RS485 Serial Port.(Auto Direction Control Support)
Input Power DC+12V DC+14V
Power
Consumption <12W
(1.0A@DC+12V) <15W (1.2A@DC+12V) <17W (1.2A@DC+14V) <22W (1.6A@DC+14V)
Weight 0.67Kg 1.1Kg 1.8Kg 4.8Kg 4.5Kg
Operating
Temperature 00C ~ 600C 00C ~ 500C
[Table 1] CUPC Hardware Specification

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
4/40
Chapter 2. Parts Diagram
[Figure 1] CUPC Parts Diagram
Name Description
1 COM1 RS232C Port
2 COM2 RS232C Port
3 COM3 RS232C Port
4 COM4 RS232C/RS485 Port. => Switched to RS232C or RS485 by the mode
selector.1
5 COM5 RS485 port. 2
6 COM4 Mode Selection
S/W Switch for selecting COM4 mode. (Refer to Chapter 2-3)
7 USB Provides 3 USB ports (USB2.0).
1When using RS485 mode, no other RTS signal control is needed because Auto Direction Control
is supported.
2No other RTS signal control is needed because Auto Direction Control is supported.

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
5/40
8 Ethernet 10/100Base-T Ethernet Port (1EA)
9 Audio OUT Stereo sound output port
10 MIC Microphone input port.
11 Mouse PS/2 mouse input port.
12 Keyboard PS/2 keyboard input port.
13 VGA Out External monitor video output port
14 ATX Power S/W ATX mode power switch, which can turn on and off the system.3
15 Power ON/OFF Power ON/OFF switch.
16 SD Card SDCARD slot for OS recovery.
(CAUTION : Use only for OS recovery)
17 RESET S/W Reset switch.
18 Ext. Power S/W The connector which can be linked to external switch.
Same function with ATX Power S/W.
19 DC INPUT(Adaptor) Connector for adaptor power supply.
20 DC INPUT Connector for power supply.
3CUPC is released on AT power mode. If you needATX power mode, please contact us.

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
6/40
Chapter 3. Dimensions
3-1. CUPC-P70 Dimensions
[Figure 2] CUPC-P70 Dimensions
Avoid using long bolts
when assembling VESA
mounts or add-on board.
The inner maximum
length is about 9mm.
Back cover
of product

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
7/40
3-2. CUPC-P80 Dimensions
[Figure 3] CUPC-P80 Dimensions
Back cover
of product
Avoid using long bolts
when assembling
VESA mounts or add-
on board.
The inner maximum
length is about 9mm.

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
8/40
3-3. CUPC-P90 Dimensions
[Figure 4] CUPC-P90 Dimensions
Back cover
of product
Avoid using long
bolts when assembling
VESA mounts or add-
on board.
The inner maximum
length is about 9mm.

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
9/40
3-4. CUPC-P100 Dimensions
[Figure 5] CUPC-P100 Dimensions
Back cover
of product
Avoid using long
bolts when assembling
VESA mounts or add-
on board.
The inner maximum
length is about 10mm.
10

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
10/40
3-5. CUPC-P120 Dimensions
[Figure 6] CUPC-P120 Dimensions
Back cover
of product
Avoid using long
bolts when assembling
VESA mounts or add-
on board.
The inner maximum
length is about 12mm.
12

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
11/40
Chapter 4. PANEL CUTOUT
4-1. Installation Requirements and Installation
[Installation Requirements]
[Installation]
CUPC X (Width) Y (Height) T (Thickness) Unit
P70 







P80 







P90 







P100 







P120 








CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
12/40
4-2. Bezel Size and Installation
[Figure 7] CUPC-P70 Panel Cutout size

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
13/40
[Figure 8] CUPC-P80 Panel Cutout size

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
14/40
[Figure 9] CUPC-P90 Panel Cutout size

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
15/40
[Figure 10] CUPC-P100 Panel Cutout size

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
16/40
[Figure 11] CUPC-P120 Panel Cutout size

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
17/40
Chapter 5. Bracket Installation
5-1. CUPC-P80 Bracket Installation
1. Insert a bolt into each mounting bracket as shown in the diagram below.
2. Make a hole in the panel according to the CUPC's cutout diagram, and insert the CUPC into
place.
3. Hook a bracket into one of the CUPC's bracket mounting holes, and pull gently to hold it firmly
in place.
4. Tighten the bolt against the panel to secure the CUPC to the panel. (Be careful not to tighten the
bolts too tightly, or the CUPC could be damaged.)
5. Repeat steps 3 and 4 for each mounting bracket.
5-2. CUPC-P90 Bracket Installation
1. Make holes and a rectangle in your panel.
2. Insert the bezel from the front side of your panel.
(The bezel has directions of upside and downside. Refer to the "▲ Upside" mark at the rear side
of bezel)
3. At the rear side of your panel, combine each spacer with 4 bezel bolts and insert them
into CUPC. (The spacers are for protecting the touch screen)

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
18/40
4. Install washers and nuts at the 4 bezel bolts, and tighten the CUPC.
The order is flat washer, spring washer, and then nut. (Do not tighten too tightly, or it may
damage the touch pad.)
Before, Washer and Nut Assy. (Back Panel) After, Washer and Nut Assy. (Back
Panel)

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
19/40
5-3. CUPC-P100 Bracket Installation
When you purchase the product, the bracket for installing P100 to the front panel is
provided.
After mounting the CUPC to the panel, insert the bracket to the side of product and tighten
with the bolts.

CUPC P100 Series User Manual
--------------------------------------------------------------------------------------------------
---------------------------------------------------------------------
1175 Chess Dr., Suite F, Foster city, CA 94404, USA www.comfiletech.com
20/40
5-4. CUPC-P120 Bracket Installation
To fasten CUPC-P120 to an upright panel, the brackets (left 2ea, right 2ea) are supplied when
you purchase P120.
* Procedure *
1) Push and install the CUPC-P120 into your panel.
2) Press the bracket as the following directions in two steps.
3) To fix the CUPC-P120 to the panel, fasten the bolts.
