Ductless mini-splits solve the problem
of cooling and/or heating a space
when adding ductwork is impractical
or too expensive. With the split system
design, the condenser is located
outside and an unobtrusive air handler
is mounted inside. The systems fit
virtually anywhere and are simple to
install. With SEER ratings of 13.0,
they’re also economical to operate.
Mini-splits are ideal for a wide range
of applications:
• Residential—Homes where it’s
difficult or not desirable to add
ductwork or use a window A/C,
renovations and restorations,
additions, sunrooms, bedrooms,
workshops
• Industrial/Commercial—Warehouse
offices, computer rooms, restaurants
• Specialized—Sports arena sky-
boxes, nursing homes, hospitals,
churches
Energy Efficient Zone Control
Ductless mini-splits save energy
because only the room or area being
used is conditioned—and each zone
is individually controlled to meet
specific comfort requirements.
Quiet Operation
Quality components and advanced
engineering make mini-splits
exceptionally quiet. Most of the
operating noise stays outside with
the condenser, while the air handler
itself is whisper-quiet, thanks to
advanced design technology.
section uses low voltage wiring,
eliminating the time and cost required
to add a special electric line. Because
it’s so quiet, the outdoor condenser
can be located close to the house or
building, saving space. The compact
design easily blends with the
landscaping.
The low profile design of the indoor
unit means it can fit where other A/C
systems won’t. Air handlers extend just
6-1/2” to 7” into the room, depending
on the model chosen, offering flexibility
in installation.
Wide Range of Models and Sizes
There’s a mini-split system to fit just
about any installation, from single
rooms to expansive spaces. In addition
to an impressive array of features, our
mini-splits include a wide range of
capacities. Sizes are available in both
cooling only and heat pump models.
Now with environmentally friendly
R-410A refrigerant!
Cool or heat three rooms or one large area. Includes
three indoor air handlers (12,000 BTUH each), one
outside condenser and three full feature remotes.
Cool or heat two rooms or separate areas. Includes two
indoor air handlers (9,000 or 12,000 BTUH each), one
outside condenser and two full feature remotes.
Cool or heat a room without adding ductwork or
blocking a window. Includes one indoor air handler,
one outside condenser and one full feature remote.
Improved Indoor Air Quality
Triple filtration includes an electro-
static filter to remove smoke, dust and
pollen; a deodorizing filter to freshen
the air; and an anti-fungal filter to
prevent the growth of bacteria and
mold. Also, the unit can be operated
in the dehumidification mode only to
remove excess humidity from the
indoor air, further preventing mold,
mildew and other contamination.
Controls automatically set the temp
and airflow based on current room
temperature, for comfort in even the
most humid conditions.
Comfort Features
• Random(chaos)swingairow
continually adjusts the fan speed
and air direction for a gentle,
breeze-like effect that enhances
the comfort of those in the
room
• Electronicclimatecontrolsregulate
operation to maintain a preset
level; a 24-hour timer can be
programmed to turn the unit on
and off during the day
• Autorestartresumesoperationas
soon as power is restored following
a power failure, and reverts to the
last-used settings
Simple Installation
Installation requires a hole 3” or less
in diameter to run refrigerant lines
and control wires between the indoor
and outdoor units. For multi-zone
units, a hole is needed for each
indoor air handler. Also, the indoor

One full feature
wireless remote
is included for
each indoor air
handler for true
zone control.
• CoolingMode—Unit operates
to maintain room temperature
at pre-set level
• HeatMode(HeatPumps)—
Unit extracts heat from
outside air for economical
comfort
• JetCoolMode—Fan operates
at super high speed for 30
minutes for fast cool down
• DehumidicationMode—
Unit automatically adjusts air
flow and temperature setting
according to current room
conditions for comfort even
in the most humid conditions
• AirCirculation—Fan
operates to circulate air
without cooling or heating;
the fan speed is automatically
adjusted according to
ambient temperature
• AutoSleepMode—Just a
touch of a button automati-
cally programs fan speed
and adjusts the temperature
setting for more comfortable
sleep
• AutoOperation—Climate
controls sense the tempera-
ture and turn the unit on and
off as needed to maintain the
desired temp
• 24HourTimer—Turns the
unit on and off during the
day, providing comfort while
you’re home and saving
energy when you’re away
• TemperatureDisplay—
Desired temperature can be
set in 2ointervals; check
button displays current room
temperature
• AirowDirectionControl—
Used to set the vertical
louvers for the desired airflow
• Random(Chaos)Swing—
Randomly changes fan speed
and louver direction for a
natural breeze-like effect that
prevents overcooling and is
preferred by most people; can
be selected in
most modes
CoolingOnly HeatPump
 FEATURES DMC36TB-1 DMH36TB-1
PowerSupply 208-230/60/1 208-230/60/1
 SystemCoolingCap.(BTUH) 35,200/36,000 35,200/36,000
 CoolingCap./Zone(BTUH) 11,730/12,000 11,730/12,000
SEER 13.0 13.0
Cooling Amps 16.6 16.6
 Dehumidify(Pts/Hr.)perzone 2.5 2.5
 SystemHeatingCap.(BTUH) N/A 35,200/36,000
 HeatingCap./Zone(BTUH) N/A 11,730/12,000
 HeatingAmps N/A 15
 HSPF N/A 7.8
IndoorUnit
 Airow(CFMMax.perZone) 318 318
 FanSpeeds(C/H/F) 4/3/3 4/3/3
AirDirection(4-Way)
Vertical Modulating Remote Remote
 Horizontal(left/right) Manual Manual
Random Swing Standard Standard
Indicator Lamps
 ON/OFF Standard Standard
24 Hr. Timer/Sleep Mode Standard Standard
 DefrostorHotStart N/A Standard
Temperature Setting Standard Standard
IndoorUnitDimensions
Width(inches) 35-1/4 35-1/4
 Height(inches) 11-1/8 11-1/8
 Depth(inches) 6-1/2 6-1/2
 NetWt/ShippingWt(lbs) 21/24 21/24
OutdoorUnitDimensions
Width(inches) 34-1/4 34-1/4
 Height(inches) 41-3/4 41-3/4
 Depth(inches) 12-5/8 12-5/8
 NetWt/ShippingWt(lbs) 201/217 201/217
ElectricalDa
 MainPwr.Connection OutdoorUnit OutdoorUnit
Min. Circuit Ampacity 26.2 26.2
Max. Fuse /HACR Cir. Brkr. 40 40
 RecommendedIndoor/ 18-4(300V) 18-4(300V)
Outdoor Connecting
 CableType(SJOW)
Line Se
Refrigerant R-410A
Liquid(Flare) 1/4 1/4
 Suction(Flare) 3/8 3/8
 Max.Length 50ft. 50ft.
 Max.Elevation(Outdoor) 25ft. 25ft.
**Always follow local and national codes
Design,specicationsandperformancedatasubjecttochangewithoutnotice.
   Tri-Zone
CoolingOnlyHeatPump
 FEATURES DMC24DB-1 DMH18DB-1 DMH24DB-1
PowerSupply 208-230/60/1 208-230/60/1 208-230/60/1
 SystemCoolingCap.(BTUH) 23,600/24,000 18,000 23,600/24,000
 CoolingCap./Zone(BTUH) 11,800/12,000 9,000 11,800/12,000
SEER 13.0 13.0 13.0
 CoolingAmps 10.1 9.2 10.1
 Dehumidify(Pts/Hr.)perzone 2.5 2.2 2.5
 SystemHeatingCap.(BTUH) N/A 18,000 23,600/24,000
 HeatingCap./Zone(BTUH) N/A 9,000 11,800/12,000
 HeatingAmps N/A 8.8 9.8
 HSPF N/A 7.7 7.8
IndoorUnit
 AirFlow(CFMMax.perZone) 318 250 318
 FanSpeeds(C/H/F) 4/3/3 3/3/3 4/3/3
AirDirection(4-Way)
Vertical Modulating Remote Remote Remote
 Horizontal(left/right) Manual Manual Manual
Random Swing Standard Standard Standard
Indicator Lamps
 ON/OFF Standard Standard Standard
24 Hr. Timer/Sleep Mode Standard Standard Standard
 DefrostorHotStart N/A Standard Standard
Temperature Setting Standard Standard Standard
IndoorUnitDimensions
Width(inches) 35-1/4 33-1/16 35-1/4
 Height(inches) 11-1/8 10-5/8 11-1/8
 Depth(inches) 6-1/2 6-1/32 6-1/2
 NetWt/ShippingWt(lbs) 21/24 15.4/18 21/24
OutdoorUnitDimensions
Width(inches) 34-1/4 34-5/16 34-1/4
 Height(inches) 31-1/2 25-13/16 31-1/2
 Depth(inches) 12-5/8 12-5/8 12-5/8
 NetWt/ShippingWt(lbs) 152/159 132/138 152/159
ElectricalDataOutdoorUnit**
 MainPwr.Connection OutdoorUnit OutdoorUnit OutdoorUnit
 Min.CircuitAmpacity 17.9 15.0 17.9
 Max.Fuse/HACRCir.Breaker 25 20 25
 RecommendedIndoor/ 18-4(300V) 18-4(300V) 18-4(300V)
Outdoor Connecting
 CableType(SJOW)
LineSetsO.D.(in.)/Refrigerant
Refrigerant R-410A
Liquid(Flare) 1/4 1/4 1/4
 Suction(Flare) 3/8 3/8 3/8
 Max.Length 50ft. 50ft. 50ft.
 Max.Elevation(Outdoor) 25ft. 25ft. 25ft.
DualZone Mini-Splits

JP 2.5M 05/08 HC-DMCH-B
CoolingOnlyModels   HeatPumpModels
 FEATURES DMC09SB-0 DMC12SB-0 DMC18SB-1 DMC24SB-1 DMH09SB-0 DMH12SB-0 DMH18SB-1 DMH24SB-1
PowerSupply 115/60/1 115/60/1 208-230/60/1 208-230/60/1 115/60/1 115/60/1 208-230/60/1 208-230/60/1
 CoolingCap.(BTUH) 9,000 11,500 17,800/18,000 22,100/22,500 9,800 11,500 19,000/19,500 22,100/22,500
SEER 13.0 13.0 13.0 13.0 13.0 13.0 13.0 13.0
 CoolingAmps 7.0 10.5 9.5/8.6 12.5/11.5 9.5 10.5 12.5/11.5 12.5/11.5
 Dehumidify(Pts/Hr.) 2.6 3.0 5.3 6.6 3.0 3.0 6.6 6.6
 HeatingCap.(BTUH) N/A N/A N/A N/A 9800 11,500 19,000/19,500 22,100/22,500
 HeatingAmps N/A N/A N/A N/A 9.5 10.5 14.0/12.7 14.0/12.7
 HSPF N/A N/A N/A N/A 7.8 7.8 7.8 7.8
IndoorUnit
 AirFlow(CFM) 250 330 460 530 330 330 530 530
 FanSpeeds(C/H/F) 3/-/3 3/-/3 3/-/3 3/-/3 3/3/3 3/3/3 3/3/3 3/3/3
AirDirection(4-Way)
Vertical Modulating Remote Remote Remote Remote Remote Remote Remote Remote
 Horizontal(left/right) Manual Manual Manual Manual Manual Manual Manual Manual
Random Swing Standard Standard Standard Standard Standard Standard Standard Standard
Indicator Lamps
 ON/OFF Standard Standard Standard Standard Standard Standard Standard Standard
24 Hr. Timer/Sleep Mode Standard Standard Standard Standard Standard Standard Standard Standard
 DefrostorHotStart N/A N/A N/A N/A Standard Standard Standard Standard
Temperature Setting Standard Standard Standard Standard Standard Standard Standard Standard
IndoorUnitDimensions
Width(inches) 33-1/16 35-1/4 42-15/16 42-15/16 35-1/4 35-1/4 42-15/16 42-15/16
 Height(inches) 10-5/8 11-1/8 11-13/16 11-13/16 11-1/8 11-1/8 11-13/16 11-13/16
 Depth(inches) 6-1/32 6-1/2 7-1/32 7-1/32 6-1/2 6-1/2 7-1/32 7-1/32
 NetWt/ShippingWt(lbs) 15.4/18.0 20.5/23.1 28.6/35.3 28.6/35.3 20.5/23.1 20.5/23.1 28.6/35.3 28.6/35.3
OutdoorUnitDimensions
Width(inches) 30-5/16 30-5/16 34-5/16 34-5/16 30-5/16 30-5/16 34-5/16 34-5/16
 Height(inches) 21-5/16 21-5/16 25-13/16 31-1/2 21-5/16 21-5/16 31-1/2 31-1/2
 Depth(inches) 9-19/32 9-19/32 12-5/8 12-5/8 9-5/8 9-5/8 12-5/8 12-5/8
 NetWt/ShippingWt(lbs) 66.1/73.4 72.8/75.7 149.9/156.5 166.6/181.6 72.8/75.7 72.8/75.7 169.6/181.6 169.6/181.6
ElectricalDataOutdoorUnit**
 MainPwr.Connection OutdoorUnit OutdoorUnit OutdoorUnit OutdoorUnit OutdoorUnit OutdoorUnit OutdoorUnit OutdoorUnit
 Min.CircuitAmpacity 8.6 14.3 14.3 17.7 14.3 14.3 17.7 17.7
 Max.Fuse/HACRCir.Brkr 15 20 20 30 20 20 30 30
 RecommendedIndoor/ 18-4(300V) 18-4(300V) 18-4(300V) 18-4(300V) 18-4(300V) 18-4(300V) 18-4(300V) 18-4(300V)
Outdoor Connecting
 CableType(SJOW)
LineSetsO.D.(in.)/Refrigerant
Refrigerant R- 410A R-410A
Liquid(Flare) 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4
 Suction(Flare) 3/8 1/2 1/2 5/8 1/2 1/2 5/8 5/8
 Max.Length 50ft. 50ft. 50ft. 50ft. 50ft. 50ft. 50ft. 50ft.
 Max.Elevation(Outdoor) 25ft. 25ft. 25ft. 25ft. 25ft. 25ft. 25ft. 25ft.
Single Zone DuctlessMini-SplitSystems  13SEER
**Always follow local and national codes
THE QUALITY LEADER IN CONDITIONING AIR
1900 Wellworth Ave., Jackson, Michigan 49203 • Ph. 517-787-2100 • www.heatcontroller.com
Design,specicationsandperformancedatasubjecttochangewithoutnotice.
