OTTO PREBUILT SERIES. USER GUIDE 4
INTRODUCTION
Congratulations on purchasing your COMINO OTTO Professional Computer.
We are pleased to welcome you as our customer. This manual contains all
safety information and instructions required for using your COMINO OTTO
Professional Computer.
Before using your device, please familiarize yourself with all relevant in-
formation. Be sure to use the device in the manner described and for the
applications indicated. If you pass on the device, be absolutely sure to also
pass on all instructions and other relevant documents. Please contact the
manufacturer if you still have specic questions after reading these user
instructions:
COMINO HOLDING LTD.
1 Fore Street,
London, England,
EC2Y 9DT
www.comino.com
info@comino.com
Join us and share your OTTO experience:
@cominotech on Instagram
@cominotech on YouTube
@cominotech on Facebook
1.
OTTO PREBUILT SERIES. USER GUIDE 5
INTRODUCTION
Product elements
1.
Ventilation
holes
Ventilation holes
Ventilation holes
USB-A 3.2 Gen 1
USB-C 3.2 Gen 2
Detachable legs (x4)
Magnetic side panels
Power cable
socket
Reservoir
Filters
I/O ports
On/Off button
OTTO PREBUILT SERIES. USER GUIDE 6
Put the box the right way, cut the adhesive tape on the box with
an oce knife
Check if the package contains all of the components ordered
Take Otto out of the box
UNPACKING AND CHECKING
THE CONTENTS
2.
OTTO PREBUILT SERIES. USER GUIDE 7
Place OTTO on an even horizontal surface. If you want to place OTTO
in a vertical position, use the included stand. Carefully insert the cables
into the stand hole and put OTTO on the stand. Use the included stand
(applicable to Master and Super versions)
To clean OTTO surfaces, use a soft cloth/sponge with a soap aqueous
solution. After the wet cleaning, wipe your device with a dry soft cloth.
It is not allowed to use the following for cleaning: alcohol, alcohol-
containing liquids, wipes soaked in alcohol-containing liquids, solvents.
Usage of alcohol/solvent for cleaning may cause plastic parts cracking
and cloudiness.
WARNINGS
UNPACKING AND CHECKING
THE CONTENTS
2.
DO NOT place
objects on the
surface of the
device
DO NOT throw
the device
DO NOT
expose the
device to direct
sunlight during
operation
DO NOT place
the device near,
or expose it
to, liquids or
moisture
DO NOT block
ventilation
openings
DO NOT place
the device on
heat-sensitive
surfaces or
close to heaters,
air-conditioners
or combustible
materials
!
OTTO PREBUILT SERIES. USER GUIDE 8
Before starting up your device for the rst time, check:
• the connection of all internal cables
• the coolant fullness
• that there are no leaks
• that all uid ports are closed
• that the lters are latched and the ventilation openings are not blocked
• that the monitor and peripheral cables are connected
• that the power cord is plugged in
• that the switch on the power supply is in the “I” position (see p.32)
Сonnect the monitor and the peripheral devices (the mouse, the keyboard,
the Wi-Fi antenna) to the respective connectors on the back of the device.
Depending on a model of your device, OTTO MASTER or OTTO SUPER,
the type and quantity of the input and the output ports may vary, as well
as their location.
SETTING UP3.
WE SHIP YOUR OTTO WITH THE PROTECTIVE INSERTS PLACED
BETWEEN THE COMPONENTS TO PREVENT THEIR DAMAGE,
HENCE EXTRACT ALL THE INSERTS BEFORE STARTING THE
DEVICE UP TO AVOID THE DANGER OF SYSTEM OVERHEATING!
WARNING
!
BEFORE CONNECTING THE DEVICE TO THE POWER SUPPLY,
ENSURE THAT YOUR LOCAL MAINS VOLTAGE MATCHES THE
INDICATED ON THE DEVICE. IF YOU ARE UNCERTAIN ABOUT
THE POWER SOCKET VOLTAGE, CONTACT YOUR ELECTRICITY
SUPPLIER.
AC INPUT REQUIREMETS 100-240V (AC), 10A, 50-60HZ
WARNING
!
OTTO PREBUILT SERIES. USER GUIDE 9
STARTING UP THE DEVICE
To run OTTO, press the On/Off button on the device case.
A motherboard logo should appear on your monitor for a few moments.
If meanwhile you hear any strange whistling or cracking noise, please,
shut the system down immediately by pressing the POWER BUTTON
or de-energizing the whole system by unplugging the power cord from
the MAINS.
SHUTTING DOWN THE DEVICE
Press the On/Off button on the device case or switch it off via OS interface
function.
STARTING UP
THE DEVICE
4.
On/Off
button
OTTO PREBUILT SERIES. USER GUIDE 10
To control and adjust OTTO’s voltage, temperature and fan speed info use
Fan Xpert tool, which is a part of ASUS AI Suite.
AI Suite software product is developed for ASUS motherboards. This utility
allows to use the predened cooling system settings, which are managea-
ble on this PC. Use it to set Silent, Normal or Performance mode.
To adjust a nearly endless spectrum of colors, patterns and even the abili-
ty to link lighting to music, in-game action, or CPU/GPU temperatures use
ASUS Aura RGB Lighting Control for Graphic card & XG-STATION for sepa-
rate adjustment of GPU RGB.
ASUS AI Suite and ASUS Aura RGB can be downloaded from ASUS’s
ocial website: https://www.asus.com
ADJUSTING
THE SYSTEM
5.
OTTO PREBUILT SERIES. USER GUIDE 11
1. Make sure that no power is supplied to OTTO and the power cord
is not plugged into the power socket.
2. Put OTTO on its left side.
3. Remove the magnetic side panel and the air lter.
4. Remove the G1/4” plug located on the lling port with a hex wrench.
5. Carefully pour the coolant into the lling port until it reaches the level
mark. No coolant must be spilt inside the device!
6. Close the G1/4” plug with a hex wrench and place OTTO in its normal
position.
7. Switch OTTO ON to let the coolant circulate through the system.
8. Switch OTTO OFF again fast enough so the system is not overheated
(after 10-15 seconds or when the reservoir is 2/3 full).
9. Put OTTO on its left side.
10. Remove the G1/4” plug located on the lling port with a hex wrench.
11. Carefully pour the coolant into the lling port until it reaches the level
again. No coolant must be spilt inside the device!
12. Close the G1/4” plug with a hex wrench and place OTTO in its normal
position.
HOW TO FILL
THE COOLANT
6.
Diagram on next page
OTTO PREBUILT SERIES. USER GUIDE 12
13. Switch OTTO ON.
14. Lift up the fore part of OTTO at 40-45º to release air.
15. Repeat relling until the reservoir and liquid system are full to the level
mark. ATTENTION: there should be some air in the system to let warm
coolant swell out.
16. Put on the air lter and the magnetic side panel when OTTO is lled
with coolant. Now you can use OTTO.
Always use only specially prepared coolant or distilled water with the ad-
dition of an additive for liquid cooling circuits according to the instructions.
HOW TO FILL THE COOLANT6.
Air
Normal position
of OTTO
OTTO on left side,
side panel and lter
removed;
OTTO is raised 40-45º
to release air.*
* — Be careful when working with an open device,
for safety reasons we recommend closing the side panel
every iteration.
Fill the coolant into
the lling port
Coolant
OTTO PREBUILT SERIES. USER GUIDE 13
Depending on the equipment and cooling system that you want to put
in OTTO, you can change the position of the central panel, back panels
and add HDD/SDD baskets.
OTTO TRANSFORMATION
FOR DIFFERENT COOLING SYSTEMS
7.
• Standard Transformation
Is designed for building liquid-
cooled and hybrid systems.
It’s possible to install a GPU with air
cooling. This is the transformation
we use at Comino for assembling
our systems. It works best for liquid
cooling.
• +18mm Transformation
Is designed for liquid-, air-
and hybrid systems.
It’s possible to install 2х120
or 2х140мм AIO on the CPU.
• +54mm Transformation
Is designed for air or hybrid systems.
It’s possible to install 1х120mm
radiator with an AIO.
OTTO PREBUILT SERIES. USER GUIDE 14
ATTENTION
Preparation
• Unscrew 6x upper screws — 1
• Remove the top panel — 2
• Unscrew 6x bottom screws — 3
• Remove the bottom panel — 4
• Unscrew 4x screws securing the back panel — 5
• Remove the back panel — 6
OTTO TRANSFORMATION
FOR DIFFERENT COOLING SYSTEMS
7.
ALWAYS SWITCH YOUR OTTO OFF AND UNPLUG THE POWER
CORD BEFORE PERFORMING ANY WORKS
!
1 (x6)
2
3 (x6)
4
5 (x4)
6
OTTO PREBUILT SERIES. USER GUIDE 15
Unscrew 4x screws from the top and bottom sides of the chassis
Push the panels a little (6mm), having previously loosened the screws,
since there are folds on the upper and lower parts of the chassis that will
not allow removing the back frame.
OTTO TRANSFORMATION
FOR DIFFERENT COOLING SYSTEMS
7.
x4
6мм
6мм
6мм
6мм
OTTO PREBUILT SERIES. USER GUIDE 16
• Remove the back frame (sliding the top and bottom panels
of the chassis so that the frame goes between the folds) — 1
• Unscrew 2x screws securing the back panel to the partition — 2
• Remove the back panel — 3
• Unscrew 2x screws securing the partition to the front frame — 4
• Unscrew 2x screws securing the partition to the power supply
bracket — 5
OTTO TRANSFORMATION
FOR DIFFERENT COOLING SYSTEMS
7.
2 (x2)
5 (x2)
4 (x2)
1
3
OTTO PREBUILT SERIES. USER GUIDE 17
• if you need to assemble
a ’+18mm’ level, then take
a small SSD/HDD basket (+18mm)
and a back panel +18mm
• if you need to assemble
a ‘+54mm’ level, then take
a large SSD/HDD basket (+54mm)
and a back panel +54mm
Raise the partition to the chosen level (+ 18mm or + 54mm)
Depending on the selected level of installation of the partition:
OTTO TRANSFORMATION
FOR DIFFERENT COOLING SYSTEMS
7.
+54mm
+18mm
standart
OTTO PREBUILT SERIES. USER GUIDE 18
Adjust the 220V power connector on the back of the chassis
• Make sure that OTTO is switched off
• Make sure that the power cord is disconnected from the mains
• Then it is necessary to disconnect the “plug” from the power supply
inside OTTO — 1
• Unscrew 2 screws that secure the connector to the back
of the chassis — 2
• Remove the connector with the wire — 3
• Install in reverse order to the other back panel
Assemble the chassis and screw on the top, bottom and back OTTO covers.
OTTO TRANSFORMATION
FOR DIFFERENT COOLING SYSTEMS
7.
1
32
OTTO PREBUILT SERIES. USER GUIDE 19
PSU PINOUT8.
N
R
14
27
66
14
27
66
11
66
51
82
62
66
66
23
79
24
6
24PIN
SENSE
4PI
CPU / GPU
POWE
PHERIPHERIAL /
SSD / PUMP
1
24
72
41
66
64
64
64
64
64
64
64
64
64
64
64
64
71
42
+3.3V (ORANGE)
+5V (RED)
+5V SB (PURPLE)
+12V
(YELLOW)
-12V
(BLUE)
GND (BLACK)
NC (WHITE)
PS-ON
(GREEN)
PW-OK (GRAY)
1
2
3
4
5
6
7
8
9
—
—
—
—
—
—
—
—
—
If your Otto is supplied with Comino Energia SFX PSU, model: CE750A01,
please follow the PSU pinout below to use custom cabling set to connect
the internal hardware components.
4 pin SENSE socket
is for voltage mea-
surements ONLY
DO NOT use it to
power any hardware
OTTO PREBUILT SERIES. USER GUIDE 20
If you are using Otto with air-cooling
or with AIO liquid-cooling systems (+18
and +54 transformations) you can detach
the reservoir back part and use only the
front panel to free up the space inside
the chassis to t the larger GPUs.
Please refer to the assembly schematics to build your own OTTO on the
base of Builder’s Edition or DIY/Case congurations.
Assembling the radiator
Steps:
Install the fans so that the cables are on the nearest tting on the right.
Pass the fan cables under the fastening screws.
OTTO BUILDER’S EDITION / DIY /
CASE SFF. ASSEMBLY SCHEMATICS
9.1
9.
1
2
1
2
Table of contents
Other Comino Desktop manuals
