commercial cool CCB51GB User manual

Beverage Cooler
User Manual
MODEL
CCB51GB, CCB81GB, CCB109GB, CCB138GB

Page 2
Thank you for purchasing our
COMMERCIAL COOL product.
This easy-to-use manual will guide
you in getting the best use of your
Beverage Cooler.
Remember to record the model and
serial numbers. They are on a label
on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions.............................................................................................................................................. 3
Refrigerant ....................................................................................................................................................................................4
Grounding Instructions .......................................................................................................................................................4-5
SET UP & USE
Parts & Features ......................................................................................................................................................................... 6
Installation Guide .......................................................................................................................................................................9
Reversing the Door Hinge ..............................................................................................................................................10-12
Operation Instructions............................................................................................................................................................13
CLEANING & CARE.........................................................................................................................................14-15
TROUBLESHOOTING & WARRANTY
Before You Call For Service.................................................................................................................................................16
Customer Service......................................................................................................................................................................16
Troubleshooting.........................................................................................................................................................................17
Limited Warranty ......................................................................................................................................................................18

Page 3
SAFETY INFORMATION
NOTE: If the Beverage Cooler has been placed in a horizontal or tilted
position for any period of time, wait 24 hours before plugging
the unit in.
1. Use this appliance only for its intended purpose as described in this use
and care guide.
2. This Beverage Cooler must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
3. Never unplug the Beverage Cooler by pulling on the power cord.
Always grasp the plug firmly and pull straight out from the outlet.
4. Do not operate any appliance with a damaged cord or plug. Return
appliance to the nearest authorized service facility for examination,
repair or adjustment.
5. Unplug the Beverage Cooler before cleaning or before making any
repairs. NOTE: If for any reason this product requires service, we
strongly recommend that a certified technician performs the service.
6. This Beverage Cooler should not be recessed or built-in in an enclosed
cabinet. It is designed for freestanding installation only.
7. Do not operate your Beverage Cooler in the presence of flammable or
explosive fumes.
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THE UNIT
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
IMPORTANT SAFETY INSTRUCTIONS

Page 4
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
DANGER
Risk of child entrapment. Before disposing of any refrigerator
or freezer, remove all doors. Leave any shelves in place so that
children may not easily climb inside.
REFRIGERANT
GAS WARNINGS
DANGER - Risk of fire or explosion. Flammable refrigerant used.
DO NOT use mechanical devices to defrost refrigerator. DO NOT
puncture refrigerant tubing.
DANGER - Risk of fire or explosion. Flammable refrigerant used. To
be repaired only by trained service personnel. DO NOT puncture
refrigerant tubing.
WARNING - Risk of fire or explosion. Flammable refrigerant used.
Consult repair manual/owner’s guide before attempting to service
this product. All safety precautions must be followed.
WARNING - Risk of fire or explosion. Dispose of properly in
accordance with federal or local regulations. Flammable refrigerant
used.
WARNING - Risk of fire or explosion due to puncture of refrigerant
tubing; Follow handling instructions carefully. Flammable refrigerant
used.
SAFETY INFORMATION
GROUNDING INSTRUCTIONS
ELECTRICAL REQUIREMENTS
In the event of malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock.
The appliance must be connected to a cord having an equipment-
grounding conductor and a grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.

Page 5
SAFETY INFORMATION
DANGER - Improper connection of the equipment grounding conductor
can result in a risk of electric shock. The grounding conductor is
insulated and features an outer green surface with or without yellow
stripes. If repair or replacement of the cord or plug is necessary, do
not connect the equipment-grounding conductor to a live terminal.
Check with a qualified electrician or service person if the grounding
instructions are not completely understood, or if in doubt as to whether
the appliance is properly grounded. Do not modify the plug if it will not
fit the outlet, have a proper outlet installed by a qualified electrician.
The appliance is for use on a nominal 120V circuit and should be
connected to a grounding outlet that looks like the one illustrated
below. The use of a temporary adaptor is not recommended.
POWER SUPPLY CORD
1. Avoid the use of an extension cord because of potential safety
hazards under certain conditions. Have a qualified electrician or
serviceman install an outlet near the appliance.
2. If it is absolutely necessary to use an extension cord, extreme care
must be exercised.
a) Use only a grounding type 3-wire extension cord that has a
3-blade grounding plug and a 3-slot receptacle that will accept the
plug on the appliance.
b) The marked electrical rating of the extension cord must equal to or
greater than the electrical rating of the appliance. The longer cord
should be arranged so that it will not drape over the counter top
or table top where it can be pulled on by children or tripped over
unintentionally.
NOTE: Neither COMMERCIAL COOL nor the dealer can accept any liability
for damage to the product or personal injury resulting from failure to
observe the electrical connection procedures.

Page 6
SET UP & USE
PARTS & FEATURES
Wire Shelf Racks
Wire Shelf Racks (2)
Mechanical Temperature
Control
Mechanical Temperature
Control
Shelf Racks (3)
Shelf Racks (3)
Electronic Temperature
Control
Electronic Temperature
Control
Wire Basket Rack
Base Rack
MODEL CCB51GB
Glass Door
Recessed Door Handle
Recessed Door Handle
Recessed Door Handle
Recessed Door Handle
Glass Door
Glass Door
Glass Door
Adjustable Leveling Legs
Adjustable
Leveling Legs
Adjustable
Leveling Legs
Adjustable
Leveling Legs
MODEL CCB81GB
MODEL CCB109GB
MODEL CCB138GB

Page 7
SET UP & USE
MODEL: CCB81GB 2.7 Cu. Ft.
(Maximum number of cans)
355ML Cola
Hight:123mm
Diameter: 66 mm
Cola
355ml
66mm
123mm
TOTAL: 81 Cans
The middle layer is
placed in the same way
as the upper layer.
3◊5+6=21 Cans
layout display (DOWN)
12+12+6=30 Cans
layout display (UP)
355ML Cola
Hight:123mm
Diameter: 66 mm
Cola
355ml
66mm
123mm
12 oz. Can
Height: 4.83”
Diameter: 2.13”
4.83”
2.13”
MODEL: CCB81GB 2.7 Cu. Ft.
MODEL: CCB51GB 1.7 Cu. Ft.
3×5+6=21 Cans
layout display (DOWN)
12+12+6=30 Cans
TOTAL: 51 Cans

Page 8
SET UP & USE
355ML Cola
Hight:123mm
Diameter: 66 mm
Cola
355ml
66mm
123mm
MODEL: CCB109GB 3.6 Cu. Ft.
(Maximum number of cans)
TOTAL: 109 Cans
3◊6+5=23 Cans
layout display (DOWN)
6◊5-4=26 Cans
layout display (UP)
12+12+6=30 Cans
Above average
Below average layout is
the same with
Above average
MODEL: CCB138GB 4.4 Cu. Ft.
(Maximum number of cans)
TOTAL: 138 Cans
355ML Cola
Hight:123mm
Diameter: 66 mm
Cola
355ml
66mm
123mm
6◊6=36 Cans
Above average
Below average layout is
the same with
Above average
6◊6-6=30 Cans
layout display (UP)
6◊2◊3=36 Cans
layout display (DOWN)
355ML Cola
Hight:123mm
Diameter: 66 mm
Cola
355ml
66mm
123mm
12 oz. Can
Height: 4.83”
Diameter: 2.13”
4.83”
2.13”

Page 9
INSTALLATION GUIDE
1. Unpack your Beverage Cooler by removing all packaging materials
like carton, base, foams, adhesive tape, etc.
2. Remove all accessories, internal packaging material that was used to
hold shelves, etc., in place during transport.
3. Clean the remains of all adhesive tape used and remove all printed
material supplied.
4. Install the Beverage Cooler in a convenient location away from
extreme heat and cold. Allow sufficient clearance between the
Beverage Cooler and side wall so the door(s) will open without
obstruction. Beverage Cooler is not designed for recessed
installation.
5. The floor on which the Beverage Cooler should be placed must be
flat, hard, solid, and even. The Beverage Cooler should not be placed
on any soft material such as carpeting, foam, plastic, etc.
6. To level your Beverage Cooler, use the two leveling legs located on
the bottom front of your Beverage Cooler. Adjust by turning the
legs counterclockwise to raise or clockwise to lower your Beverage
Cooler. The door will close easier if the leveling legs are extended.
7. The following is the recommended minimum clearance around the
Beverage Cooler for proper air circulation:
Sides: 2” (50mm)
Top: 2” (50mm)
Proper air circulation will help your Beverage Cooler work at
maximum efficiency.
NOTE: The appliance must be correctly connected to the power supply.
SET UP & USE
WARNING
It is important to keep the power cord away from the compressor at the
rear of the Beverage Cooler during operation, the compressor can reach a
high temperature and could cause serious damage to the power cord.
CAUTION
Care should be taken during handling, moving and use to avoid damaging
the refrigerant tubing or increasing the risk of a leak.

Page 10
SET UP & USE
PROTECTION FROM HEAT AND MOISTURE
• Do not install your Beverage Cooler in any location where heavy
moisture is present or if the location is not properly insulated. This
Beverage Cooler is not designed to operate in temperature settings
below 55° Fahrenheit.
• Location for the Beverage Cooler should be on a hard surface and
away from direct sunlight and heat source, e.g., radiators, baseboard
heaters, cooking appliances, etc.
REVERSING THE DOOR HINGE
(MODEL CCB51GB & CCB81GB)
1. Remove the top hinge cover.
2. Using a Phillips Head Screwdriver, loosen and remove the 2 screws
holding the top hinge in place.
3. Remove top hinge and carefully lift off the door.
4. Remove the screw hole plugs from the opposite side of the cabinet
and the door and insert the plugs in the screw hole openings of the
just removed screws.
5. Remove any loose items in the Beverage Cooler.
NOTE: Do not tilt the appliance over 45 degrees when reversing the
door as possible damage to the sealed system may occur.
6. Remove Left & Right Leveling Feet from underside of Cooler.
7. Loosen the screws holding the lower hinge bracket to the Beverage
Cooler and remove screws and bracket.
8. Remove the door pin from the lower hinge bracket by turning it
counterclockwise.
9. Remove (2) screws from the opposite side of the Cooler and insert
these screws into the previously removed screw holes. Tighten the
screws.
10. Flip the lower bracket over and then reinsert the door pin into the
threaded hole and tighten.
11. Align the door with the cabinet first. Then install the lower hinge
bracket to your desired side of the cabinet. Make sure door is resting
on door pin of the lower bracket. Then insert (2) remaining screws
into the holes. Tighten the screws.
12. Align top hinge bracket with screw holes, insert screws and partially
secure, check that door and cabinet are properly aligned and then
secure tightly.

Page 11
SET UP & USE
13. Replace the top hinge cover and leveling feet. Adjust leveling feet as
necessary.
NOTE: If the top of the door is not aligned with the cabinet, loosen the top
hinge screws, adjust door and re-tighten the screws.
REVERSING THE DOOR HINGE
(MODEL CCB109GB & CCB138GB)
1. Remove the top hinge cover.
2. Using a Phillips Head Screwdriver, loosen and remove the 2 screws
holding the top hinge in place.
3. Remove top hinge and carefully lift off the door.
4. Remove the screw hole plugs from the opposite side of the Cabinet
and the Door and insert the plugs in the screw hole openings of the
just removed screws.
5. Remove any loose items in the Beverage Cooler.
NOTE: Do not tilt the appliance over 45 degrees when reversing the
door as possible damage to the sealed system may occur.
6. Remove Leveling Leg from underside of Cooler.
7. Loosen the screws holding the lower hinge bracket to the Beverage
Cooler and remove screws and bracket.

Page 12
SET UP & USE
8. Remove cabinet screw and door plug from opposite side and insert
into the holes previously used by the door.
9. Remove the door pin from the lower hinge bracket by turning it
counterclockwise, then reinsert it into the neighboring treaded hole
and tighten.
10. Align the door with the cabinet first. Then install the lower hinge
bracket to the bottom opposite side of the cabinet. Make sure door
is resting on door pin of the lower bracket. Then insert (2) remaining
screws into the holes. Tighten the screws.
11. Align top hinge bracket with screw holes, insert screws and partially
secure, check that door and cabinet are properly aligned and then
secure tightly.
NOTE: If the top of the door is not aligned with the cabinet, loosen the top
hinge screws, adjust door and re-tighten the screws.
12. Replace the Top Hinge Cover and Leveling Leg. Make sure Leveling
Leg is installed to the opposite side of the door hinge. Adjust Leg as
necessary.

Page 13
SET UP & USE
OPERATING INSTRUCTIONS
STARTING YOUR NEW BEVERAGE COOLER
After cleaning your Beverage Cooler thoroughly. Wipe the outside with a
soft dry cloth and the interior with a clean moist cloth. Insert the power
supply cord into the socket.
NOTE: If the Beverage Cooler has been placed in a horizontal or tilted
position for any period of time, wait 24 hours before plugging the
unit in.
TEMPERATURE CONTROL
• Turn the variable temperature control knob to the appropriate
temperature for your beverages.
• The beverage cooler has a temperature range from 32°F to 61°F. Simply
turn the dial to your preferred temperature setting.
• Turning the temperature to “0” position will shut o the cooling cycle, but
does not turn o the electrical power to the unit.
• Operate the beverage center by adjusting the temperature control
buttons (up and down arrows) to various settings. The adjusting
temperature range is 32°F to 61°F (0°C to 16°C).
• Touch this pad once ( ) and the temperature will increase 1 °F (1 °C).
• Touch this pad once ( ) and the temperature will decrease 1 °F (1 °C).
• The new desired temperature will flash on the display for five seconds and
then back to the actual temperature which will gradually change until the
set point is reached.
• Touch this pad (°C/°F) and the temperature display will switch between
°C & °F.
NOTE: Wait 3-5 minutes before restarting if you unplug the Beverage
Cooler. The unit may fail to operate properly if restarted too
quickly.
CCB51GB and
CCB81GB
CCB109GB and
CCB138GB
INTERIOR LIGHT (Only CCB109GB and CCB138GB have Interior Light)
You can turn the interior light ON or OFF by pressing “LIGHT” on the light
switch located on the front of the control panel. To turn the light OFF press
the switch again.
0
1
2
3
4
5
6
7

Page 14
CLEANING AND CARE
CLEANING AND MAINTENANCE
CAUTION
To avoid personal injury or product damage always read and
follow manufacturer’s instructions and warnings before
using any cleaning products.
WARNING
Always unplug appliance before cleaning to avoid electric shock.
Ignoring this warning may result in death or injury
POWER INTERRUPTION
In case of a power interruption/outage, unplug the power cord from the wall
outlet. Replug the power cord to the wall outlet once the power has been
restored.
CLEANING METHOD
Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed with
warm water. Use sponge or soft cloth, dampened with the cleaning solution
to wipe down your Beverage Cooler.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,
concentrated detergents, solvents or metal scouring pads. Some of these
chemicals may dissolve, damage and/or discolor your Beverage Cooler.

Page 15
CLEANING AND CARE
VACATION AND MOVING CARE
• For long vacations or absences, set the temperature dial to “OFF”,
unplug the unit, empty contents from Beverage Cooler and clean the
Beverage Cooler according to “General Cleaning” section. Prop doors
open, so air can circulate inside.
• When traveling or moving the Beverage Cooler, always transport the
unit vertically. Moving the unit on its sides may damage the Beverage
Cooler and/or its compressor. Do not move or store the unit on its
side
ENERGY SAVING TIPS
• The Beverage Cooler should be located in the coolest area of the
room, away from heat-producing appliances or heating ducts, and out
of direct sunlight.
• Overloading the Beverage Cooler forces the compressor to run longer
and thus increase energy consumption.
• The shelves should not be lined with aluminum foil, wax paper, or
paper towels. This will interfere with cold air circulation, making the
Beverage Cooler less ecient.
• Organize beverages to reduce door openings and extended searches.
Remove as many items as needed at one time, and close the door as
soon as possible.

Page 16
TROUBLESHOOTING & WARRANTY
BEFORE YOU CALL FOR SERVICE
IF THE APPLIANCE FAILS TO OPERATE:
A) Check to make sure that the Beverage Cooler is plugged in securely.
If it is not, remove the plug from the outlet, wait 10 seconds and plug
it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If
these seem to be operating properly, test the outlet with another
appliance.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A
QUALIFIED TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR
THE APPLIANCE YOURSELF.
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the
W Appliance CO. Customer Satisfaction Center at
844-299-0879 or [e-mail]
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE

TROUBLESHOOTING & WARRANTY
Troubleshoot your problem by using the chart below. If the Beverage
Cooler still does not work properly, contact COMMERCIAL COOL customer
service center or the nearest authorized service center.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Beverage Cooler
does not work
• Beverage Cooler is
not switched on
• Unit is not plugged
in
• A household fuse
has blown or circuit
breaker has tripped
• Wall power socket is
defective
• Turn on the temperature
control dial. It may be in
the OFF, “0” position
• Plug in the Beverage
Cooler
• Replace the household
fuse or reset circuit
breaker
• To be corrected by a
qualified electrician
The beverage is
too cold
• Temperature is not
properly adjusted
• Set the temperature
control dial to a warmer
setting
The beverage is
too warm
• Temperature is not
properly adjusted
• Door was open for
an extended period
• A large quantity
of beverages were
placed in the
Beverage Cooler
within the last 24
hours
• The Beverage Cooler
is near a heat source
• Set the temperature
control dial to a cooler
setting
• Open the door only as
long as necessary. Check
door gasket for proper
seal
• Set the temperature
control dial to a colder
setting temporarily
• Refer to “Protection From
Heat and Moisture” section
Popping or
cracking sounds
• When compressor
comes on
• This is a normal sound of
coolant flowing through
condenser coils
Beverage Cooler
door does not
shut properly
• The Beverage Cooler
door is not properly
aligned
• Possible blockage
from bottles shelves,
bins, etc.
• Re-align the Beverage
Cooler door. Refer to the
“Door Alignment” section
• Ensure nothing is blocking
the door
Beverage Cooler
has an odor
• Interior needs
cleaning
• Please refer to “Cleaning
and Care” section

Page 18
LIMITED WARRANTY
Any repair, replacement, or warranty service,
and all questions about this product should be
directed to W Appliance Co. at 844-299-0879
from the USA or Puerto Rico.
W Appliance Co. warrants to the original purchaser
that the product will be free from defects in material,
parts and workmanship for the period designated for
this product. The warranty commences the day the
product is purchased and covers up to a period of
1 year (12 months) for labor/1 year (12 months) for
parts (manufacturing defects only).
W Appliance Co. agrees that it will, at its option,
replace the defective product with either a new
or remanufactured unit equivalent to your original
purchase during the warranty period.
Exclusions: This warranty does not apply to the
below:
1. If the appearance or exterior of
the product has been damaged or
defaced, altered or modified in design or
construction.
2. If the product original serial number
has been altered or removed or cannot
be readily determined.
3. If there is damaged due to power line
surge, user damage to the AC power
cord or connection to improper voltage
source.
4. If damage is due to general misuse,
accidents or acts of God.
5. If repair attempts are done by
unauthorized service agents, use of
parts other than genuine parts or parts
obtained from persons other than
authorized service companies.
6. On units that have been transferred
from the original owner.
7. On products that have been purchased
as refurbished, like new, second-hand, in
a “As-Is” or “Final Sale” terms.
8. To products used in a commercial or
rental setting.
9. To products used in settings other than
ordinary household use or used other
than in accordance with the provided
instructions.
10. To damages for service calls for
improper installations.
11. Transportation and shipping costs
associated with the replacement of the
unit.
12. Service calls to instruct you how to use
your product.
13. Service calls to repair or replace the
house fuse, reset the circuit breaker or
correct the wiring in the house.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CUSTOMER; W Appliance Co.. SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, or limitations
on how long the warranty lasts. In these cases the
above exclusions or limitations may not apply to you.
This warranty gives you specific legal rights and you
may also have other rights which vary from state to
state.
Obtaining Service: To obtain service, product
literature, supplies or accessories please call
844-299-0879 to create a ticket for exchange/repair.
Please make sure to provide the date of purchase,
model number and a brief description of the problem.
Our customer service representative
will contact you or send detailed return instructions.
W Appliance Co. does not warrant that the appliance will work
properly in all environmental conditions, and makes no warranty
and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or ftness for a
particular purpose other than the purpose identifed within this
user’s manual. W Appliance Co. has made every efort to ensure
that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information in
this user’s manual is subject to change without notice and does
not represent a commitment on the part of W Appliance Co.. W
Appliance Co. reserves the right to make improvements to this
user’s manual and/or to the products described in this user’s
manual at any time without notice. If you fnd information in this
manual that is incorrect, misleading, or incomplete, please contact
us at 844-299-0879.
W Appliance Co.
1356 Broadway
New York, NY 10018

Page 20
© 2021 W Appliance Company. All Rights Reserved.
1356 Broadway, New York, NY 10018
April 2021
