QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 1
Overview
At A Glance
AlphaServer™/AlphaStation ™
ES40 Systems include:
• Alpha 21264 68/833-MHz CPU
with 8-MB L2 Dual Data Rate
Cache
• 6-10 64-bit PCI I/O
expansion slots
• 512-MB, 1-GB, 2-GB, or 4-GB
memory options (AlphaServers)
• 512-MB memory option
(AlphaStations)
• 1.44-MB diskette drive
• 600-MB 48X IDE CD-ROM drive
• Two 9-pin serial ports
• One 25-pin parallel port
• RMC dedicated serial port, 6-pin
MMJ connector
• Dual USB ports
• Keyboard and mouse port
• Knockouts for two 68-pin
SCSI connections
• Auto-sensing power supply
• Integral remote system
management console
• Customer documentation
• Tru64™ UNIX™ or OpenVMS™
Factory Installed Software
• 90-day software warranty
• Protected by HP Services,
including three-year hardware
warranty, on-site with 5 x 9 next
business day response

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 2
Standard Features
Processor Alpha 21264 68/833-MHz CPU
Cache Memory 8-MB L2 Dual Data Rate Backup Cache (68/833-MHz CPU)
Upgradability Supports additional processors and upgrades of memory and hard drives
Memory Minimum 512 MB – AlphaServer ES40 Model 1
512 MB – AlphaStation ES40
1 GB – AlphaServer ES40 Model 2
Maximum 16 GB (16 DIMM slots) Model 1; 32 GB (32 DIMM slots) Model 2 (see Step 3)
Network Controller Choice of Ethernet controllers
Expansion PCI I/O slots 6 slots Model 1; 10 slots Model 2
Storage Diskette Drive 1.44-MB diskette drive in dedicated slot
CD-ROM 600-MB 48X IDE CD-ROM
Hard Drives Choice of 18.2-GB, 36.4-GB, 72.8-GB, or 146-GB drives
Interfaces Parallel 1 25-pin parallel port
Serial 2 9-pin serial ports
USB Dual USB ports
Keyboard 1 port
Mouse 1 port
Remote systems management 1 dedicated remote systems management port
SCSI connections Two 68-pin SCSI connections knockouts
Graphics Optional
Form Factor Tower, Pedestal, Rackmount (M-Series Cabinet)
Power Supply Auto sensing power supply, hot swappable, N+1 (see Step 4)
Manageability Compaq Insight Manager™
OS Support AlphaServer ES40 Tru64 UNIX systems include pre-installed software, Base license, Unlimited User license,
Server Extension license, Internet Express, and Secure Web Server
AlphaStation ES40 Tru64 UNIX systems include pre-installed software, 2-user Base license and Compaq Open3D
traditional license
AlphaServer ES40 OpenVMS systems include pre-installed software, Base license with System Manager license
and Enterprise Integration Server License Package for OpenVMS V3.1
AlphaStation ES40 OpenVMS systems include pre-installed software, Base license, Concurrent Use 1-user
license, NAS 150 Client license, Compaq MMS RT license and Compaq Open3D traditional license
Minimum OS support −Tru64 UNIX V4.0F, OpenVMS V7.2-2, Linux RedHat V6.2, Linux SuSE V6.3 or greater
Service and Support Protected by HP Services including a three-year on-site hardware warranty with next business day response.
Software warranty is a 90-day telephone advisory. Training, consulting, network integration, software support,
comprehensive system maintenance and guaranteed uptime services are also available for customers requiring
higher levels of service and support.

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 3
Systems/Options
Step 1 −
−−
−Select system
AlphaServer ES40 systems require the mandatory selection of the following items:
• Disk drive cage or StorageWorks™ shelf (Step 5)
• System disk drive (Step 5)
• System enclosures: Tower, Pedestal, or Rack Kit (Step 6)
• Ethernet adapter (Step 8)
• Storage adapter (Step 10)
• Software media and documentation for first system onsite
NOTES: ES40 Model 1 to Model 2 Upgrade Kit available −see Step 16.
Only 2-5-2 part numbers are factory integrated.
AlphaServer ES40 Systems
ES40 OS CPU PCI I/O Slots Memory/Cache Order Number
Model 1 Tru64 UNIX 833 MHz 6 512 MB/8 MB DA-62CAA-CA
Model 1 Tru64 UNIX 833 MHz 6 1 GB/8 MB DA-62CAA-DA
Model 1 Tru64 UNIX 833 MHz 6 2 GB/8 MB DA-62CAA-EA
Model 2 Tru64 UNIX 833 MHz 10 512 MB/8 MB DA-64CAA-CA
Model 2 Tru64 UNIX 833 MHz 10 1 GB/8 MB DA-64CAA-DA
Model 2 Tru64 UNIX 833 MHz 10 2 GB/8 MB DA-64CAA-EA
Model 2 Tru64 UNIX 833 MHz 10 4 GB/8 MB DA-64CAA-FA
Model 1 OpenVMS 833 MHz 6 512 MB/8 MB DY-62CAA-CA
Model 1 OpenVMS 833 MHz 6 1 GB/8 MB DY-62CAA-DA
Model 1 OpenVMS 833 MHz 6 2 GB/8 MB DY-62CAA-EA
Model 2 OpenVMS 833 MHz 10 512 MB/8 MB DY-64CAA-CA
Model 2 OpenVMS 833 MHz 10 1 GB/8 MB DY-64CAA-DA
Model 2 OpenVMS 833 MHz 10 2 GB/8 MB DY-64CAA-EA
Model 2 OpenVMS 833 MHz 10 4 GB/8 MB DY-64CAA-FA
AlphaStation ES40 Systems
Model 2 Tru64 UNIX 833 MHz 10 512 MB/8 MB DA-64CAA-CW
Model 2 OpenVMS 833 MHz 10 512 MB/8 MB DY-64CAA-CW

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 4
Systems/Options
Step 2 −
−−
−Additional CPU Modules −
−−
−Optional
• One CPU included, three additional CPUs are supported
SMP upgrade, includes one 67/667-MHz CPU with 8-MB cache and Tru64 UNIX
SMP license
KN610-BB
SMP upgrade, includes one 67/667-MHz CPU with 8-MB cache and OpenVMS
SMP license
KN610-BC
SMP upgrade, includes one 68/833-MHz CPU with 8-MB cache and Tru64 UNIX
SMP license
KN610-CB
SMP upgrade, includes one 68/833-MHz CPU with 8-MB cache and OpenVMS
SMP license
KN610-CC
From: To:
EV67 667-MHz CPU EV68 833-MHz CPU
Upgrade console firmware to V5.9-24 as minimum revision
Upgrade system hardware with EV68 CPUs
Ensure all system firmware matches console version V5.9-24
EV6 500-MHz CPU EV68 833-MHz CPU
Upgrade console firmware to V5.9-24 as minimum revision
Upgrade system hardware with EV68 CPUs
Re-install V5.9-24 console firmware
Ensure all system firmware matches console version V5.9-24
Step 3 −
−−
−Memory −
−−
−Optional
• Systems include one memory option
• Model 1 systems supports four memory options (total of 16 DIMMs)
• Model 2 systems support eight memory options (total of 32 DIMMs −see Note below)
• Memory performance considerations: Interleaved operations reduce the average latency and increase the memory throughput over non-
interleaved operations. With one memory option (4 DIMMs) installed, memory interleaving will not occur. With two identical memory
options (8 DIMMs) installed, memory read-write operations are two-way interleaved. With four identical memory options (16 DIMMs)
installed, memory read-write operations are four-way interleaved, maximizing memory through-put
512-MB memory option (4 x 128-MB DIMMs) MS610-CA
1-GB memory option (4 x 256-MB DIMMs) MS610-DA
2-GB memory option (4 x 512-MB DIMMs) MS610-EA
4-GB memory option (4 x 1024-MB DIMMs) MS610-FA
NOTE: ES40 configurations that require maximum N+1 power (three power supplies)
are restricted to a maximum of 24-GB of mixed memory (sixteen 1-GB DIMMs
and sixteen 512-MB DIMMs). If N+1 maximum power is not required, 32-GB of
memory is supported.

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 5
Options
Step 3 −
−−
−Memory −
−−
−Optional (continued)
NOTE:
Linux configurations with large memory require the installation of a patch.
The patch to support greater than 2 GB of memory per system is located at:
http://www.kernel.org/pub/linux/kernel/people/andrea/patches/v2.2/2.2.17 (patch
name: bigmem-2.2.18pre2-18.bz2)
The following minimum operating system versions require the patch:
− Linux RedHat V6.2
− Linux SuSE V6.3 (Kernel V2.2.17)
The following operating system minimum versions support greater than 2 GB of
memory:
− Linux RedHat V7.0 (installs Kernel V2.2.17)
− Linux SuSE V7.0 (installs Kernel V2.2.16)
When installing Linux SuSE V7.0 on a system with more than 2 GB of memory, user
will be prompted for a (ramdisk) floppy. To create a floppy:
− Mount the SuSE V7.0 installation CD-ROM #1 on the system.
− Mount a blank formatted floppy (if not formatted, execute the following
command: fdformat/dev/fd0H1440).
− Change directory, to the ″disks″directory on the install CD-ROM.
− Execute the following command to create the floppy contents:
dd if=install of=/dev/fd0.
Use this floppy when prompted by the install procedure for a floppy.
Step 4 −
−−
−Additional Power Supplies −
−−
−Required for third and fourth CPUs and/or second Disk Drive Cage
• One power supply supports two CPUs, up to 12 memory DIMMs, and one disk card cage; order second power supply if N+1 power is
required.
• Two power supplies support third and fourth CPU, 13 to 32 memory DIMMs (up to 24-GB of memory), and/or two disk card cages; order
third power supply if N+1 power is required for third and fourth CPUs, 24-GB of memory, and/or two disk card cages.
• Three power supplies support 32 GB of memory without N+1 power.
• Three power supplies support a maximum of 24 GB of memory with full N+1 power.
• Each additional power supply ordered with a tower system requires an additional country-specific power cord.
• Pedestal system and Rack kit include three internal power cords regardless of the number of power supplies ordered; Pedestal systems
support 120 V and 240 V power cords.
ES40 720W power supply H7906-A9

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 6
Options
Step 5 −
−−
−Disk Drive Cage or StorageWorks Shelf −
−−
−Mandatory
• Tower enclosure supports one system and two disk drive cages
• Pedestal enclosure supports one system and two disk drive cages, two Universal 42xx/43xx StorageWorks shelves or three BA36R
StorageWorks shelves
• M-Series cabinets support five systems each with two disk drive cages and up to six StorageWorks shelves
Step 5a −
−−
−Disk Drive Cage −
−−
−Requires selection of system disk drive
Disk Drive Cages 6-bay disk drive cage with cable for use with 1-inch Universal drives – requires
mandatory selection of UltraSCSI adapter and SCSI cable (Step 10) per disk drive cage
BA610-6D
6-bay disk drive cage with embedded Ultra2 LVD adapter; supports internal SCSI
1-inch Universal drives or tapes only
OpenVMS V7.2-2 requires OpenVMS Tima Kit located at:
- http://ftp.support.compaq.com/patches/.new/openvms.shtml
Tru64 UNIX V4.0F requires Patch Kit 2 (BL13):
- DUV40FAS0002-19991116.tar
BA610-6E
NOTE: See AlphaServer ES40 Configuration Chart for Storage Adapters in Step 10.
18.2-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive 3R-A3848-AA
36.4-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive 3R-A3838-AA
System Disk Drives
(Supported in Disk Drive Cage and
Universal StorageWorks Shelves)
36.4-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive 3R-A3849-AA
72.8-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive 3R-A3839-AA
72.8-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive 3R-A3851-AA
146-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive 3R-A3841-AA
Step 5b −
−−
−StorageWorks BA36R Shelf −Requires selection of UltraSCSI adapter and SCSI cable (Step 10) and system disk drive
• StorageWorks Shelf supports seven 3.5-inch x 1.6-inch hard disk drives; with addition of redundant power supply, only six drives are
supported
• StorageWorks shelf kits are mounted back-to-back in pedestals and cabinets
StorageWorks UltraSCSI single-bus shelf kit BA36R-RC
StorageWorks UltraSCSI split-bus shelf kit; BA36R-RD
NOTE: When ordering a split-bus shelf that will be mounted in a Pedestal Enclosure,
order one BN37A-03 cable for KZPCM-DA adapter, BN37A-03 cable for
3X-DEPVZ-AA combo adapter, or one BN38C-03 for 3X-KZPCA-AA or
KZPBA-CA adapter.
3-meter SCSI cable BN37A-03
System Disk Drive
(Supported in StorageWorks
BA36R Shelf)
36.4-GB Wide UltraSCSI 10,000 rpm disk drive DS-RZ1FC-VW

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 7
Options
Step 5 −
−−
−Disk Drive Cage or StorageWorks Shelf −
−−
−Mandatory (continued)
Step 5c −
−−
−StorageWorks Model 4314R and Model 4354R Universal Drive Shelves
• StorageWorks Model 4314R and 4354R Ultra2 SCSI (LVD) single-bus and split-
bus Universal drive shelves; refer to StorageWorks Enclosure 4300 Family
QuickSpecs when configuring shelves. When selecting a DS-SL13R-xx split-bus
shelf, order two UltraSCSI adapters. Model 43xx shelves are compatible with
Wide Ultra2 (LVD) adapters only.
• BN38C-05 cable is required per channel if the connection is not VHDCI/VHDCI.
DS-SL13R shelves include one 12-foot VHDCI/VHDCI SCSI cable.
• Note that the depth of a DS-SL13R-xx shelf does not allow front and rear
mounting.
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount
shelf, includes one power supply, U.S. (190209-0011)
DS-SL13R-AA
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount
shelf, includes one power supply, Japan (190209-291)
DS-SL13R-AJ
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount
shelf, includes two redundant power supplies, U.S. (190211-0011)
DS-SL13R-BA
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount
shelf, includes two redundant power supplies, Japan (190211-291)
DS-SL13R-BJ
To add additional power supply for single-bus Universal shelf, U.S. (212980-B21) DS-SE2UP-AA
To add additional power supply for single-bus Universal shelf, International
(119826-B31)
DS-SE2UP-AI
Model 4314T Ultra3 SCSI, single-bus tower enclosure, U.S. (190210-001) DS-SL13T-AA
StorageWorks Model 4314T Standalone
Enclosure for Universal Drives
Model 4314T Ultra3 SCSI, single-bus tower enclosure, International (190210-B31) DS-SL13T-AB
Model 4314T Ultra3 SCSI, single-bus tower enclosure, Japan (190210-291) DS-SL13T-AJ

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 8
Options
Step 6 −
−−
−System Enclosures −
−−
−Mandatory selection of Tower, Pedestal, or Rack Kit
Step 6a −
−−
−Tower Enclosure
• Tower enclosure supports one system
• Tower enclosure ordered in North America includes 120V power cord; country-specific power cord mandatory for all non-North American
systems; additional power cord mandatory for each power supply ordered with a system installed in a tower enclosure
Tower Enclosure BA61M-MT
Step 6b −
−−
−Pedestal Enclosure
• Pedestal enclosure supports one system, two Universal 43xx StorageWorks shelves or three UltraSCSI BA36R StorageWorks shelves
• Pedestal enclosures (BA61P-PA, 120V/BA61P-PB, 240V) support Universal shelves
• 120V pedestal enclosure includes two external 120V power cords; 240V pedestal enclosure requires two country-specific power cords
• Pedestal enclosure includes two factory-configured power strips that provide five available outlets; if the number of BA356-RC/RD power
supplies requires a sixth outlet, this can be accommodated only if the system chassis is limited to two H7906-A9 power supplies
120V Pedestal Enclosure, includes two external power cords BA61P-PA
240V Pedestal Enclosure, requires two country-specific power cords BA61P-PB
Step 6c −
−−
−Rack Kit for M-Series Cabinet
• Rack Kit required for each AlphaServer ES40 system installed in a new or existing M-Series Cabinet
• Rack Kit supports one system
Rack kit for AlphaServer ES40, includes dress bezel, slides, three internal power cords,
all bracketry and hardware for mounting in M-Series cabinets
BA61R-RM
NOTE: Factory integration of an ES40 system drawer in a 9000 rackmount cabinet using rack kit, 3X-BA61R-RC, is not supported. Contact
Custom Systems or Compaq Certified Integration Partner.
Step 7 −
−−
−M-Series Cabinets
M-Series cabinet enclosures support up to four systems, up to six StorageWorks shelves, and/or two BA370 enclosures; M-Series Enclosures
require selection of the following items:
• H9A10 or H9A15 cabinet, 120V or 240V
• Rack kit for each system
• H9A10 or H9A15 rear cabinet extender
• Cabinet front door based on cabinet height
• Factory integration
• Ballast kit if only one system is ordered for the H9A15 cabinet
NOTE: For configurations beyond those listed in the following charts, contact CustomSystems.

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 9
Options
Step 7 −
−−
−M-Series Cabinets (continued)
Cabinet Configuration Chart for AlphaServer ES40 (8U) with StorageWorks Shelves (4U)
Cabinet Rack Kit Cabinet
Extender Cabinet Height/Space Systems BA356 Shelves DS-SL13R 120V Shelves
2
BA356/ DS-SL13R
3
BA356 DS-SL13R
H9A10-MC/MD
1
BA61R-RM H9C10-TE 67-inches/34U 1 6 8 6 4
2 6 5 6 1
3 2 2 4 0
4
1
0 0 0 0
H9A15-MC/MD
4
BA61R-RM H9C15-TE 79-inches/41U 1 6 8 6 5
2 6 5 6 2
3 6 2 6 0
4 2 0 2 0
5
5
0 0 0 0
NOTES:
1. Contact CustomSystems for cabinet configurations with four AlphaServer ES40 systems installed in H9C10-MC/MD cabinet.
2. Japan only – 240V cabinet required when using universal shelves
3. When using a combination of BA356 and DS-SL13R shelves in the same cabinet, do not remove the top fan (only remove fan when
using DS-SL13R shelves exclusively)
4. Installation of one AlphaServer ES40 system in an H9A15 cabinet requires the mandatory selection of a ballast kit.
5. When adding the 5th system drawer, replace H7600-AA or -DB power controller with H7602-EA or -DB power controller. When replacing
H7600 controllers, replace all associated power cords; order BN35S-4E power cords for H7602-EA and H7602–DB power controllers.
• Required selection of one cabinet
M-Series Cabinets • Two H7600-xx power distribution units are standard in the M-Series cabinet
• For cabinet configurations that require a third power distribution unit (H7600-xx),
contact CustomSystems at 1-800-282-6672.
67-inch cabinet with 59.5-inch or 34U of usable vertical space, 120V dual-24A
controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P,
Americas, Asia Pacific; includes rear door and top fan tray
H9A10-MC
67-inch cabinet with 59.5-inch or 34U of usable vertical space, 240V dual-16A
controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe;
includes rear door and top fan tray
H9A10-MD
79-inch cabinet with 71.7-inch or 41U of usable vertical space, 120V dual-24A
controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P,
Americas, Asia Pacific; includes rear door and top fan tray
H9A15-MC
79-inch cabinet with 71.7-inch or 41U of usable vertical space, 240V dual-16A
controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe;
includes rear door and top fan tray
H9A15-MD

QuickSpecs Compaq AlphaServer ES40
Compaq AlphaStation ES40
DA-10392 North America — Version 57 — March 18, 2003 10
Options
Step 7 −
−−
−M-Series Cabinets (continued) • Required selection of one cabinet extender for each H9A10 or H9A15 cabinet
Rear Cabinet Extender
Rear cabinet extender, top gun blue, for H9A10-MC/MD cabinets H9C10-TE
Rear cabinet extender, top gun blue, for H9A15-MC/MD cabinets H9C15-TE
• Required selection of door based on cabinet height
Cabinet Front Door
Front door, top gun blue, for H9A10-MC/MD cabinet enclosure H9C10-TF
Front door, top gun blue, for H9A15-MC/MD cabinet enclosure H9C15-TF
• Required
Factory Integration
Factory Integration of systems and storage devices assembled and configured in
cabinet enclosure in predefined locations
YS-ASCAA-AA
• Required only if one system is ordered for the H9A15 cabinet
Ballast Kit • Ballast is added to a cabinet at particular locations for specific configurations to
meet safety regulations for installation, operation, and service; see Cabinet
Configuration Charts.
Two 35 to 40 lb steel plates H9C10-MC
• Optional
Shelves Supported in M-Series Cabinets
UltraSCSI single-ended RETMA rack, single-bus personality module, 180W power
supply
BA36R-RC
UltraSCSI single-ended RETMA rack, split-bus personality module, 180W power supply BA36R-RD
