Compaq Presario 5600 Series User manual

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series
Product Description
Troubleshooting
Illustrated Parts
Removal & Replacement
Jumpers & Switches
Specifications
Pin Assignments
Power Cord Set Requirements
Welcome to the Presario 5600 Series Maintenance and Service Guide. This online guide is designed to serve
the needs of those whose job it is to repair Compaq products. Many of the components of the hardcopy MSG are
contained in this online guide. The Notice contains the copyright and trademark information. The Preface shows
symbol conventions, Technician Notes and Serial Number locations on the unit.
Download a ZIP file of the complete MSG to local hard drive.
For content comments or questions, contact the Editor.
Top
privacy statement and legal notices

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series Personal Computers
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts
|
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins | Power
Cord Requirements
For models 5600,5612,
5620,5630, 5635,
5640, 5660, 5686,
5696
For models 5650, 5665,
5670, 5673, 5676,
5677
Controls & Lights
Power Management
Product Description
This section describes the model numbers and features of the Compaq
Presario 5600 Series of Personal Computers.
privacy statement and legal
notices

United States December 16, 2002
Maintenance & Service Guide
Compaq Presario 5600 Series Personal Computers
MSG Index Product Description Removal & Replacement Illustrated Parts
Home Troubleshooting Jumpers & Switches Specifications
Preface Connector Pins Power Cord Requirements
Product Description - Models 5600, 5610,
5612, 5620, 5630, 5635, 5640, 5660,
5686, 5696
The following table lists Compaq Presario 5600 Series Personal Computer models and some model-specific features.
NOTE: ●All models have Pentium II Processors
●All models have 512k cache, and all have DVD2 except 5600 (32x CD)
●Modem codes:
Z = Rockwell HCF 56k DataFax PCI Modem
D = Diamond SupraExpress 56i Pro Modem
Model Processor
Speed (MHz) Memory (MB) Hard Drive (GB) Video Memory (MB) Fax/Modem
privacy statement and legal notices
56003334884Z
56103506484Z
56123506484Z
5620400128124Z
5630400128124Z

United States December 16, 2002
Maintenance & Service Guide
Compaq Presario 5600 Series Personal Computers
MSG Index Product Description Removal & Replacement Illustrated Parts
Home>Troubleshooting Jumpers & Switches Specifications
Preface Connector Pins Power Cord Requirements
Product Description - Models 5650, 5665, 5670, 5673, 5676,
5677
The following table lists Compaq Presario 5600 Series Personal Computer models and model-specific features.
NOTE: ●All processors are Pentium II
●All models have 512kbyte cache, and all have 5X Max DVD2, 56Kbps modem
●Modem codes:
BLZ = 1.5 Mb MAX Digital Modem (G.Lite, 56K V.90)
C = 6 Mb Max Digital Modem (G.Dmt, G.Lite, 56K V.90)
K = 56k PCI Modem
Z = Rockwell HCF 56k DataFax PCI Modem
Model Processor
Speed (MHz) Memory (MB) Hard Drive (GB) Video Memory (MB) Fax/Modem
privacy statement and legal notices
5650-EMEA400646,84K
5665450128124Z
5670-US450128198Blz
5670-EMEA4501288,104 U,D
5673450128198Z

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series Personal Computers
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts | Removal
& Replacement
Jumpers & Switches | Specifications | Connector Pins | Power Cord Requirements
Power Controls
Front Components
Drive Bays
Diskette,
Lights &
Instant-On
Button
Keyboards
Input/Output
Connectors
Models 5600,
5610, 5612,
5620, 5630,
5635, 5640,
5660, 5665
Models 5650,
5665, 5670,
5673, 5676,
5677
Monitors & Comm
Connectors
Models 5600,
5610, 5612,
5620, 5630,
5635, 5640,
5660, 5665
Models 5650,
5665, 5670,
5673, 5676,
5677
Digital Creativity Imaging
Center
Controls and Lights
This section covers the computer controls and lights for the Compaq
Presario 5600 Series of personal computers.
privacy statement and legal notices

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series Personal Computers
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts | Removal
& Replacement
Jumpers & Switches | Specifications | Connector Pins | Power Cord Requirements
Power Controls
Description
1Main power on/off
switch
2Voltage selector
3AC Power cord
connector
privacy statement and legal notices

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series Personal Computers
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts | Removal & Replacement
Jumpers & Switches | Specifications | Connector Pins | Power Cord Requirements
Drive Bays
Description
1CD/DVD activity light
2CD/DVD drive load/eject button
3Zip drive activity light (IDE Zip drive only)
4Zip disk eject button and activity light (ATAPI
Zip drive)
privacy statement and legal notices

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series Personal Computers
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts | Removal & Replacement
Jumpers & Switches | Specifications | Connector Pins | Power Cord Requirements
Diskette, Lights & Instant-On Button
5Diskette drive activity light
6Diskette drive eject button
7Sleep light
8Drive activity light
9Power-on light
10 Instant-on button
privacy statement and legal notices

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series Personal Computers
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts | Removal
& Replacement
Jumpers & Switches | Specifications | Connector Pins | Power Cord Requirements
Keyboards
This section covers the keyboard controls for the Compaq Presario 5600 Series of personal
computers.
Standard
Easy Internet Access
privacy statement and legal notices

United States December 16, 2002
Maintenance & Service Guide
Presario 5600 Series Personal Computers
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts | Removal & Replacement
Jumpers & Switches | Specifications | Connector Pins | Power Cord Requirements
Standard Keyboard Lights
Click here for the Easy Internet Access keyboard controls and
lights.
1 Num Lock Light
2Caps Lock Light
3Scroll Lock Light
