Compaq Proliant 2000/4000/4500/4500R
Specifications
Processor
x Intel 486/50, 5/66,100,133,166; R is rack-mountable
Memory
x 2000: 16/32MB RAM up to 512MB; 4000: 64MB RAM up
to 512MB; 4500/4500R: 16MB up to 1.024GB
I/O Expansion Slots
x 8-32bit EISA bus master slots
Diskette Drive
x 1-3.5” 1.44 diskette drive
Integrated Features
x 2-Serial, parallel, pointing device port, 32-bit Fast SCSI-2
network, integrated graphics
Internal Expansion Bays
x 2000/4500R- 5, 4000/4500: 7-internal hot pluggable bays
I/O Architecture (Buses supported)
x Compaq Flex, TriFlex PC architecture
Power Supply
x 445 watt power supply, 4500/4500R: 488/540 watt
Diagnostics
x Normal Post Diags performed on Power UP of system.
x For Advanced Diags use Diskette version 9.0
x Troubleshoot according to errors found during test
Tools And Software Requirements
x Flat bladed and Torx T-8, T-10, and T-15 screwdrivers
x Needle nose pliers, * ROM removal tool
x Diagnostics and formatted blank diskettes
x Anti-static wrist strap
Jumper Settings for SCSI ID
Proliant 4500/4500R Pin3 Pin2 Pin1
Drive Bay# SCSI ID ID2 ID1 ID0
6 6 ON ON OFF
5 5 ON OFF ON
Switch Settings Proliant 2000/4000
SW2 (003116, 003862, 004486)
Switch Position Function
S1 OFF*/ON turns on video/turns off video
S2 OFF turns off processor
ON turns on processor
S3 OFF* reserved
S4 OFF* turns off diskette boot
ON turns on diskette boot
S5 OFF* turns off pwr-on password
ON turns on pwr-on password
S6 OFF*/ON turns off NV RAM/turns on
Switch Settings Proliant 4500/4500R
SW1 (004308)
Switch Position Function
S1 OFF*/ON turns on video/turns off video
S2 OFF* turns on configuration lock
ON turns off configuration lock
S3 OFF* syst. installed in tower chassis
ON syst. installed in rack chassis
S4 OFF* dsktte boot based on config
ON dsktte boot despite config
S5 OFF* turns on pwr-on password
ON turns off pwr-on password
S6 ON clears config. memory
* Default
Removal Procedures
Before beginning removal complete the following:
1. Turn off the computer and any peripheral devices.
2. Disconnect AC power cord from the outlet and system.
3. Disconnect all peripheral devices.
System Cover
Warning: High voltage is present, use caution when running
the Proliant without the system cover on.
1. Lift and remove the front bezel door
2. Loosen thumb screws and remove at front of panel
3. Slide system unit cover forward then up
4. Rack-Mounted: Turn 1/4 turn screws on front panel.
5. Slide the cover back and up.

TSS DOCUMENT #: Compaq 05/96 Doc # MT 1667 - 0025
Page 2 of 2 © International Business Machines Corp. 1996
All rights reserved
Field Replaceable Units
Memory Assembly OEM Part IBM Part
Mem. Exp. Bd. 002563-001 139947-001 20H8574
4MB 70ns mod. 118665-004 141754-001 20H6294
4MB 60ns * 139139-001 37H1197
4MB 80ns mod. 115665-002 118741-001 93F7237
8MB 60ns * 139140-001 37H1198
8MB 70ns mod. 129041-002 141755-001 90G7098
8MB 80ns mod. 129041-001 128954-001 93F7238
16MB 60ns * 139141-001 37H1199
16MB 70ns mod. 137143-003 149947-001 90G7101
16MB 80ns mod. 137143-002 139143-001 90G7880
32MB 60ns * 139142-001 37H1200
32MB 70ns mod. 139973-002 149948-001 20H8476
32MB 80ns mod. 139973-001 139949-001 20H8554
64MB 80ns mod.1188489-001 61H8955
1Proliant 4500 only, * Proliant 4500R only
Controller Boards
Description Assembly OEM Part IBM Part
SMART contrlr 002969 142130-001 20H8547
003596 181132-001 20H8736
Fast SCSI-2 002682 142040-001 90G6451
Fast wide SCSI-2/E 003529 199634-001 37H1205
NetFlex contrlr 002709 142041-001 20H8539
NetFlex contrlr TR 142035 142042-001 20H8555
NetFlex-2 ENET-TR 003382 142222-001 20H8566
NetFlx-2 Dual ENET 003101 142151-001 20H8567
NetFlex-2 TR 003647 199521-001 20H8538
NetFlex-2 Dual TR 003104 142195-001 20H8630
NetFlex-3/E contrlr 004162 169801-001 52H5606
NetFlex-3/P contrlr 004165 169811-001 74H2685
NtFlx-3 100base TX 004183 169805-001 61H8949
NtFlx3 100VG upgd 004189 169803-001 61H8947
Internal Hard Drive
Size OEM Part IBM Part
550MB Pluggable Fast SCSI-2 146799-001 20H8716
1.05GB Plggbl Fast SCSI-2 146717-001 20H8717
2.1GB Pluggable Fast SCSI-2 199428-001 20H8576
2.1GB Plggbl Fast-wide SCSI-2 1199643-001 52H5595
4.3GB Pluggable Fast SCSI-2 199584-001 52H5605
4.3GB Plggbl Fast-wide SCSI-2 1199598-001 52H5596
1Requires fast-wide SCSI-2 backplane upgrade
System Bds Assembly OEM Part IBM Part
486/50* 003164 136812-001 20H8564
486/50** 003474 148672-001 20H8563
5/66 002443-004 148677-001 20H8568
5/90 004495-001,011 163848-001 48H7139
5/100 03756 163832-001 67H9849
5/100 1,2 005154-001 184793-001 52H5600
5/133 2004715 213417-001 74H3820
I/O Bd 5/66,90,100 004486 163707-001 48H7137
I/O 486/50,5/66,100 003116/003862 148550-001 20H8571
I/O Bd. SCSI 1,2 004308-001 188414-001 52H5599
Drv bckpln SCSI 2004839-001 169185-001 62H0931
Drv. bkpln,hot SCSI 1004542-001 188490-001 61H8956
Pass Thru Bd. SCSI 1,2 004349-001 199612-001 52H5607
* Dual prcssr
** Quad prcssr,
1 4500 only,
2 4500R only
Diskette Drives OEM Part IBM Part
1.2MB 112566-001 93F7252
1.44MB 144207-001 20H8548
1.44MB (optional) 112565-001 93F7107
CD ROM Drives OEM Part IBM Part
Internal tray load 1,2,3 142223-001 20H8472
External tray load 2199430-001 20H8471
Caddy load 2,3 133881-001 93F9345
Quad speed, tray load, int. 2,3 184783-001 52H9094
14500 only, 22000/4000 only, 3 4500R only
Tape Drives OEM Part IBM Part
525MB ACA 142073-001 90G6447
1.2GB TBU 199615-001 61H8964
2/8GB DAT 142074-001 20H8559
4/16GB TurboDat 199464-001 20H8549
Internal TurboDat Autoloader 199466-001 20H8551
10/20 table top DLT 1199676-001 61H8971
15/30 table top DLT 2242469-001 74H3304
10/20 int. DLT * 199746-001
2Proliant 2000/4000 only, * 4500R only, 1Not for 4500R
Miscellaneous Assembly OEM Part IBM Part
2400bd modem 1,2,3 001732-002 121250-001 93F9380
Speedpaq 144/I 2003002 147453-001 55H1777
Speedpaq mdm 1,3 135698-001 199906-001 20H8096
hot-plg tray adap 1,3 146729-004 199656-001 61H8965
hot-plg drv tray 1,2,3 146729-003 146781-001 20H8718
hot-plg drv bckpln 2004192-001 190060-001 20H8714
clock battery 1,2,3 149344-001 20H8525
power supply 2148569-001 20H8578
power supply 1188406-001 55H5598
power supply 3188407-001 52H5604
488 watt pwr spl 1,2 163828-001 37H1191
488 watt pwr spl 3162628-001
1Proliant 4500, 2Proliant 2000/4000, 3Proliant 4500R
Cables OEM Part IBM Part
Internal SCSI HDD 2148589-001 48H6831
External SCSI signal 1,2 146776-001 22H0168
External SCSI Signal 12’ 3146776-004 20H8723
Internal SCSI-2 device 1,2 148728-001 61H8937
Internal SCSI 2-device 36” 3165706-001 20H8720
LED cables 3165680-001 20H8719
LED cables 1,2 148585-001 61H8934
Diskette drive signal 1,2 143706-001 61H8930
Diskette drive signal 3165681-001 20H8722
Dualport ENET loopback 1,2,3 142254-001 20H8725
Dual AUI breakout 1,2,3 197134-001 20H8727
DLT, 6’, std to centronics 1,2 199714-001 61H8973
DLT, 6’, wide to centronics 1,2 199780-001 61H8975
DLT, 18”, daisy chn table top 1,2 199713-001 61H8972
DLT active terminator 1,2 199715-001 61H8974
50-pin to 68-pin adapter 1,2,3 189638-001 53H1431
Int. fast wide SCSI-2 23” 1189637-003 62H0930
Ext. 100 to 50 pin cable 1,3 142159-001 20H8724
loop back cbl, NetFlex 1,3 142054-001 55H1088
14500 only, 2 2000/4000 only, 3 4500R only
System ROM OEM Part IBM Part
System ROMPaq 143198-001 20H8731
Option ROMPaq 142207-001 37H1204
Drive Backplane ROM 146705-001 20H8735
