C-Series Handheld PC
First Edition January 1998
Part Number 266667-001
Compaq Computer Corporation

Contents v
Writer: Rebecca Wiggins Saved by: J Abercrombie Saved date: 01/08/98 1:25 PM
Pages: 4 Template: c:\microsoft office\templates\ref\ref-toc.dot
Part Number: 266667-001 File name: 03Toc.doc
CONTENTS
preface
B
EFORE
Y
OU
B
EGIN
For More Information........................................................................xi
For Updated Information..................................................................xii
Locating Information Quickly..........................................................xii
Ordering Software on Diskette........................................................xiii
Customer Registration.....................................................................xiii
In North America........................................................................xiii
Outside of North America...........................................................xiii
Symbols and Conventions...............................................................xiv
chapter 1
G
ETTING
S
TARTED
Unpacking the Box..........................................................................1-2
Setting Up for the First Time ..........................................................1-3
C-Series at a Glance........................................................................1-8
Screen and Left Side Components..............................................1-8
Front and Right Side Components..............................................1-9
Top and Rear Panel Components..............................................1-10
Bottom Panel Components .......................................................1-11
chapter 2
F
ORMING A
P
ARTNERSHIP
Step 1: Determine Computer Requirements ...................................2-2
Step 2: Install Windows CE Services..............................................2-3
Step 3: Configure the Communications Port ..................................2-3
Using Windows NT Workstation................................................2-3
Using Windows 95......................................................................2-3
Step 4: Connect the Handheld PC to the Computer........................2-4
Step 5: Install the Compaq C-Series Software................................2-5

vi Contents
a. Writer: Rebecca Wiggins Saved by: J Abercrombie Saved date: 01/08/98 1:25 PM
Part Number: 266667-001 File name: 03Toc.doc
chapter 3
U
SING THE
K
EYBOARD AND
S
TYLUS
Special Keyboard Features .............................................................3-2
Using the Application Launch Keys...........................................3-4
Using the Dual Brightness Backlight Button.............................3-5
Using the Stylus..............................................................................3-6
chapter 4
U
SING
P
OWER
Using Battery Power.......................................................................4-2
Checking Battery Power Levels.................................................4-2
Recognizing Low Battery Indicators..........................................4-2
Conserving Battery Power..........................................................4-4
Replacing Batteries.........................................................................4-5
Replacing the Main Batteries.....................................................4-6
Replacing the Backup Battery....................................................4-9
Disposal and Recycling of Used Batteries....................................4-11
Using AC Power...........................................................................4-11
Connecting to AC Power..........................................................4-12
Resetting Your C-Series Handheld PC.........................................4-13
Performing a Normal Reset......................................................4-13
Performing a Full Reset............................................................4-14
chapter 5
U
SING THE
M
ODEM
Safety Precautions for Modems......................................................5-2
Connecting the Modem...................................................................5-3
Using an External Modem..............................................................5-4
Connecting an External Modem.................................................5-4
Configuring and Using the External Modem.............................5-4
Using the Modem to Access the Internet........................................5-5
Browsing the Internet.................................................................5-5
chapter 6
U
SING
PC C
ARDS
Supported PC Cards........................................................................6-1
PC Card Software ...........................................................................6-2
Operating Guidelines......................................................................6-2
Inserting a PC Card.........................................................................6-3
Removing a PC Card ......................................................................6-4

Contents vii
a. Writer: Rebecca Wiggins Saved by: J Abercrombie Saved date: 01/08/98 1:25 PM
Part Number: 266667-001 File name: 03Toc.doc
chapter 7
U
SING THE
I
NFRARED
F
EATURE
Establishing an Infrared Connection...............................................7-2
Step 1: Configure the Software...................................................7-2
Step 2: Set Up the Infrared Devices............................................7-2
Step 3: Transfer Information.......................................................7-3
Printing with the IR Port .................................................................7-4
chapter 8
U
SING
C
OMPAQ
S
OFTWARE
Using Voice Memo .........................................................................8-2
Recording A Message.................................................................8-3
Playing a Message.......................................................................8-3
Managing Messages....................................................................8-4
Adjusting Audio Levels..............................................................8-4
Using Internet Setup Utility ............................................................8-5
Setting Up a Profile.....................................................................8-5
Getting On the Internet ...............................................................8-6
Using Internet Favorites Synchronizer............................................8-7
Synchronizing Bookmarks..........................................................8-7
Copying Bookmarks ...................................................................8-8
Using Dictionary Synchronizer.......................................................8-9
Using the Backup and Restore Utilities ........................................8-10
Using Compaq Backup and Restore .........................................8-12
Using Compaq Flash Memory Manager...................................8-14
Using Compaq Enhanced Security................................................8-16
Understanding the Password Levels.........................................8-16
Setting Passwords .....................................................................8-18
Using the Owner Control Panel Application.................................8-21
Controlling Volume.......................................................................8-21
Printing..........................................................................................8-22
Supported File Types................................................................8-22
Printing Guidelines ...................................................................8-22
Printing from the Handheld PC.................................................8-23
Setting the Alarm ..........................................................................8-23

viii Contents
a. Writer: Rebecca Wiggins Saved by: J Abercrombie Saved date: 01/08/98 1:25 PM
Part Number: 266667-001 File name: 03Toc.doc
chapter 9
C
ARING FOR
Y
OUR
C
OMPAQ
C-S
ERIES
Routine Care ...................................................................................9-2
Travel Guidelines............................................................................9-3
International Travel ........................................................................9-3
Shipping Guidelines........................................................................9-4
chapter 10
T
IPS AND
T
ROUBLESHOOTING
Tips for Maximizing Performance................................................10-1
Adjusting Memory....................................................................10-1
Increasing the Data Transfer Speed..........................................10-2
Troubleshooting............................................................................10-3
Solving Battery and Power Problems.......................................10-4
Solving Keyboard and Stylus Problems...................................10-5
Solving Audio Problems...........................................................10-5
Solving Memory Problems.......................................................10-6
Solving PC Card Problems.......................................................10-8
Solving Screen Problems..........................................................10-9
Solving Communication Problems.........................................10-10
Solving Security Problems.....................................................10-13
Servicing the C-Series ................................................................10-14
Preparing for a Technical Support Call..................................10-14
appendix A
W
ORLDWIDE
T
ELEPHONE
N
UMBERS
....................................................... A-1
appendix B
H
ARDWARE
S
PECIFICATIONS
................................................................. B-1
appendix C
A
GENCY
R
EGULATORY
N
OTICES
............................................................. C-1
I
NDEX
................................................................................................. I-1

Before You Begin xi
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/08/98 4:03 PM
Pages: 4 Words: 725 Template: c:\msoffice95\templates\ref.dot
Part Number: 266667-001 File name: 04Prefac.doc
preface
BEFORE YOU BEGIN
Congratulations on your selection of the Compaq C-Series, the
first professional handheld PC. Before using your C-Series, be
sure to read this chapter for information about:
■ documentation and online help
■ customer registration
■ symbols and conventions used in this guide
For More Information
References are provided as printed materials and as online
information that is accessible from your handheld PC. In addition
to this reference guide, the following printed references come
with your handheld PC:
■ Quick Setup card
■ Accessories Flier
■ Microsoft The Handheld PC Companion
■ Important Safety Information
■ Register Now card (North America only)
■ Warranty and service information

xii Before You Begin
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/08/98 4:03 PM
Part Number: 266667-001 File name: 04Prefac.doc
The following online and electronic references are also available.
Name: Location:
Microsoft H/PC Help Handheld PC
Microsoft Windows CE Services
Help Microsoft
Desktop Software for
Windows CE
CD (to be installed
on your computer)
Microsoft Handheld PC Home
Page www.microsoft.com/windowsce/ hpc
C-Series Home Page www.compaq.com/products/
handhelds
For Updated Information
To learn about updates that may have occurred to your C-Series
device after this document was printed, tap the Start menu on
your handheld device, then tap My Documents and select
Compaq Updates.
NOTE:
If no updated information is available, Compaq Updates
will not appear on the screen.
Locating Information Quickly
To quickly find the information you’re looking for, use this table
as a starting point.
To Find Information About: Look Here:
Using your C-Series C-Series Reference Guide
Using the Compaq software on
your C-Series
C-Series Reference Guide
Using the Windows CE operating
system and software on your
C-Series
Microsoft
The Handheld PC
Companion
Microsoft H/PC Help
Using Windows CE Services on
your computer Microsoft
Windows CE Services
Help
The latest information and offers
for your C-Series device and
accessories
C-Series Home Page
(www.compaq.com/products/
handhelds)

Before You Begin xiii
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/08/98 4:03 PM
Part Number: 266667-001 File name: 04Prefac.doc
Ordering Software on Diskette
If the computer on which you are installing Microsoft Windows
CE 2.0 does not have a CD-ROM drive, you can purchase
diskettes containing the Windows CE software necessary for
operating your handheld PC.
To order Windows CE software diskettes, contact Compaq at
1-800-841-2761 (U.S. only) or fax a request to 510-327-4070.
NOTE:
Some Windows CE applications (such as the Guided
Tour and Exchange Update) are not available on diskette. To
obtain these applications, visit the Microsoft web site at
www.microsoft.com.
Compaq C-Series software is available only on CD-ROM.
Customer Registration
In North America
To receive the latest information on your C-Series handheld PC,
as well as receive special offers on C-Series accessories and
software, be sure to register with Compaq by completing and
mailing the Register Now card included with your handheld PC.
Outside of North America
Outside of North America, use the Compaq Info Messenger
service to obtain Internet and e-mail access to the latest software
updates and service documentation for your C-Series.
Once you register with this free service at www.compaq.com/
infomessenger and build your profile(s), Info Messenger searches
the Compaq web site and collects information specific to your
handheld PC environment. Info Messenger then sends an e-mail
alerting you when new and/or updated information is available on
a Compaq customized web page.

xiv Before You Begin
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/08/98 4:03 PM
Part Number: 266667-001 File name: 04Prefac.doc
Symbols and Conventions
Some or all of the following format conventions may be used in
this guide to distinguish elements of text:
■ Names of keys are shown in bold type as they appear on the
keyboard, for example,
Ctrl, Backspace, Tab.
■ Keys that you should press at the same time are represented
by the key names and the plus (+) symbol, for example,
Ctrl+Alt+Delete.
■ Commands are presented in lowercase, bold type as shown
here:
install
or
a:\install.
■■ An arrow is used to separate icons or menu options that you
should select in succession; for example, tap
Start→Settings→Control Panel.
■ When you need to type information without pressing the
Enter
key, you are directed to “type” the information.
■ When you need to type information and press the
Enter
key,
you are directed to “enter” the information.
!
WARNING:
Text set off in this manner indicates that failure to
follow directions could result in bodily harm or loss of life.
CAUTION:
Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of
information.
IMPORTANT:
Text set off in this manner presents clarifying
information or specific instructions.
NOTE:
Text set off in this manner presents commentary,
sidelights, or interesting points of information.

Getting Started 1-1
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Pages: 12 Words: 946 Template: c:\microsoft office\templates\ref\ref.dot
Part Number: 266667-001 File name: 05Ch01.doc
chapter 1
GETTING STARTED
This chapter provides information about getting started with your
C-Series handheld PC, such as:
■ unpacking the box
■ setting up for the first time
■ learning about the handheld PC features

1-2 Getting Started
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
Unpacking the Box
Contents of the Box
Before setting up your handheld PC, be sure your shipping box
includes the following items:
1 handheld PC
2 AC Adapter
3 stylus (housed in the handheld PC)
4 auto-sync cable
5 batteries (two AA alkaline or one rechargeable NiMH,
depending on your C-Series model)
Not pictured:
■ modem cable (available with some models)
■ CD-ROM discs (2)
■ documentation
NOTE:
To order accessories that did not come with your C-Series
model, refer to the Accessories Flier included in the shipping box.

Getting Started 1-3
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
Setting Up for the First Time
To set up your handheld PC for the first time, follow the
instructions below. When it is ready to use, read “C-Series at a
Glance” later in this chapter to learn more about the special
features of your device.
1. Turn over the handheld PC.
2. Do one of the following:
■ If your C-Series comes with AA alkaline batteries, follow
the steps in the illustration below. Remove the main battery
cover and install the batteries as illustrated below. Be sure
the positive and negative end of each battery is correctly
oriented.
CAUTION:
Do not install AA alkaline batteries in C-Series
models that have color screens. Install only a Compaq-
approved rechargeable battery pack in these models.
Installing the Alkaline Batteries

1-4 Getting Started
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
■ If your C-Series comes with a rechargeable NiMH battery
pack, follow the steps in the illustration below. Be sure the
flat side of the battery is facing in toward the battery
compartment as indicated.
Installing the NiMH Battery Pack

Getting Started 1-5
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
3. Replace the main battery cover.
Replacing the Main Battery Cover
4. Pull out the backup battery tape to activate the backup battery.
Removing the Backup Tape

1-6 Getting Started
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
5. If using a rechargeable NiMH battery pack, connect the unit
to AC power and allow the battery pack to charge for three
hours. If using AA alkaline batteries, proceed to step 6.
6. Turn over the handheld PC and raise the lid.
Raising the Lid

Getting Started 1-7
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
7. Press the power button to turn on power.
Pressing the Power Button
8. Follow the instructions on the screen to complete the setup
process.
9. To learn more about your handheld PC, take the Welcome
Tour by pressing
Fn
+
Alt
.
Once setup is complete, you may want to connect your handheld
PC to a computer and load valuable Compaq software. To do so,
follow the instructions provided in Chapter 2, “Forming a
Partnership.”

1-8 Getting Started
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
C-Series at a Glance
Your handheld PC is equipped with many convenient features
that make using it quick and easy. This section familiarizes you
with the location and function of these features.
Screen and Left Side Components
Screen and Left Side Components
Item Component Function
1
Screen Displays on-screen information and
interprets stylus taps.
2
Modem
connector Connects an RJ-11 modem cable (available on some models only).
3
PC Card slot Accepts a 16-bit Type I or Type II PC
(PCMCIA) Card. For more on this
feature, see Chapter 6, “Using PC
Cards.”

Getting Started 1-9
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
Front and Right Side Components
Front and Right Side Components
Item Component Function
1
Dual brightness
backlight button Provides increased lighting for better viewing of the screen. For more
information, see “Using the Dual
Brightness Backlight Button” in Chapter 3.
2
Power button Press once to turn on the device. Press
again to turn off.
3
AC power
connector Connects to external (AC) power via the AC Adapter.
4
Serial connector Connects serial devices such as the auto-
sync cable or a printer cable.
5
Stylus slot Holds and protects the stylus when stylus
is not in use.
6
Alarm button Press once to stop the alarm when it goes
off. For instructions on using the alarm,
see “Setting the Alarm” in Chapter 8.
7
Record button Press and hold this button while speaking
into the microphone to record a voice
memo.

1-10 Getting Started
Writer: Shelly Ficalora Saved by: Rebecca Wiggins Saved date: 01/07/98 4:33 PM
Part Number: 266667-001 File name: 05Ch01.doc
Top and Rear Panel Components
Top and Rear Panel Components
Item Component Function
1
Battery charge
light (amber) ■ Turns on when the optional rechargeable NiMH battery pack is
being recharged; also turns on when
the device is connected to external
power
■ Turns off when charging is complete.
2
Alarm light
(green) ■ Blinks once when the device is turned on.
■ Blinks continuously when an alarm
you have set goes off.
■ Turns off when you press the alarm
button or stop the alarm through the
software.
3
Speaker Produces sound for the alarm, playback of
voice memos, and other audio effects. For
information on setting the speaker level,
see “Controlling Volume” in Chapter 8.
4
Microphone Speak into the microphone while pressing
the record button to record a voice memo.
Works whether device is open or closed.
5
Infrared (IR) port Allows for wireless infrared
communication.
